Cablematic KD054 User manual

Total Dual Bike
Trainer for Hands and Legs
4. Press the ball lock and insert the upper
main stem into the lower part until the ball
lock stuck into the hole.
5. Use 2pcs 5×58mm smaller screws with
2 washers at each 2 sides to assemble the
hand operated pedal on the main stem from
the direction of picture A. Tighten the
screws until the pedal stable.
a:ball lock
a:smaller
Total Dual Bike Trainer for Hands and Legs
5
4

Welcome to use the Dual Bike,
which is mainly for hands and legs
exercise that improves blood cir
circulation for the elder.
Total
Warn: To reduce the risk of getting hurt, please read the following content
carefully to avoid personal injury or property damage.
Cautions:
When using this product, user should sit on a chair to do exercise.
Stop using this product when feeling adverse reaction.
The elder or juveniles should be accompanied by their guardians
when using this product.
This product should be used on flat ground.
1. Use 4pcs 8×28mm screws with washers
to connect the frame and horizontal
connection rods from the direction of
picture A. Then tighten the screws until
the frame and horizontal connection
stable (Picture 1)
2. Use 2pcs 8×28mm screws with washers
to fixer the pedal on the frame from the
direction of picture A.
3.Use 2pcs 8×50mm longer screws with
a curved washer at one side and a flat one
at another side to assemble the main stem
and frame. Tighten the screws until the
main stem stable.
Installation Instructions:
Total Dual Bike Trainer for Hands and Legs
A
A
A:longer
Total Dual Bike Trainer for Hands and Legs
1
2
3
