BLK BOX 21-0122-0B User manual

OWNERS MANUAL & QUICK START GUIDE
FREE STANDING COMPACT EXTENSION RIG GOLIATH
NOTE : PLEASE READ ALL THE INSTRUCTIONS
CAREFULLY BEFORE ASSEMBLING THIS PRODUCT.
BLK BOX
21-0122-0B
#MADEINBELFAST
100kg
PRODUCT SPECIFICATION
PRODUCT WEIGHT
MAX USER WEIGHT
MAX USER
MAX TRAINING WEIGHT
DIMENSIONS
SAFE WORKING ZONE
-125kg
300kg
2940mm x 2408mm x 820mm
-
-
-
-3690mm x 3272mm x 2020mm
4
-

5
6
7
8
9
WARNING
SPIRIT LEVEL
10MM MASONRY
DRILL BIT
TOOLS REQUIRED
17MM SPANNER X2
13MM SPANNER
HAMMER
HAMMER DRILL VACUUM STEP LADDER
PARTS & ATTACHMENTS
1
4
3
SERIOUS OR FATAL INJURIES MAY OCCUR FROM INCORRECTLY ASSEMBLED EQUIPMENT. ALWAYS ENSURE
BOLTS ARE TIGHTENED CORRECTLY AND ALL PARTS ARE LEVEL AND PLUMB. TO FURTHER REDUCE RISK OF
INJURIES OR DEATH PLEASE USE OUR SUGGESTED TOOLS AND PERSONAL PROTECTIVE EQUIPMENT (PPE).
WE SUGGEST THAT A MINIMUM OF THREE PEOPLE ARE INVOLVED IN THE ASSEMBLY OF THIS PRODUCT.
EACH PERSON SHOULD BE EQUIPPED WITH SAFETY GLASSES, STEEL TOE CAP BOOTS AND EAR PLUGS.
PLEASE BE AWARE OF THIS SYMBOL AS AN INDICATION TO CHECK THAT A PART IS LEVEL
OR PLUMB.
THIS SYMBOL IS AN INDICATION OF THE RECOMMENDED TORQUE EACH
BOLT SHOULD BE TIGHTENED TO. THIS VALUE WILL BE DEPENDENT ON
THE BOLT TYPE. PLEASE HAND TIGHTEN ALL BOLTS UNTIL YOU SEE THIS SYMBOL.
#MADEINBELFAST
No. Name SKU QTY
12.4 UPRIGHT
DNA60 WITH
FEET
21-0036-0A 4
21.8 SINGLE BAR
CM DNA60
21-0028-0A 2
31.2 SINGLE BAR
CM DNA60
21-0015-0A 2
40.7 BOX & BAR
CM DNA60
21-0011-0A 2
5J-HOOK
PAIR
16-0001 1
6M10X80 SLEEVE
ANCHOR
10-0031 12
7M10X90 BOLT 10-0008 24
8M10 NYLOCK NUT 10-0024 24
9M10 FLAT
WASHER
10-0016 60
2
xx
Nm

x
2
4
ASSEMBLY
1
BOLT 2QTY 1.2 BAR (21-0015-0A)AND 2QTY 0.4 BOX & BAR (21-0009-0A) BETWEEN 4QTY
UPRIGHTS (21-0036-0A) WITH BOLT ASSEMBLY AS SHOWN. ENSURE UPRIGHTS LOGOS
ARE FACING OUTWARD AND BOLTS ARE FACING INWARD.
10.0008
10.0019 x2
10.0024
#MADEINBELFAST

#MADEINBELFAST
x
1
2
1740MM
2
10.0008
10.0019 x2
10.0024
POSITION FS RIG 1740MM AWAY FROM EXISTING RIG. BOLT 2QTY 1.8 SINGLE BAR (21-0028-0A) ON
TO 2.4 UPRIGTHS (21-0036-0A) REUSING BOLT ASSEMBLY AS SHOWN. ENSURE BOLTS ARE FACING
INWARD.

x
2
4
3
TIGHTEN ALL BOLT ASSEMBLIES WITHIN THE CIRCLE AS SHOWN TO SPECIFIED TORQUE. ENSURE
UPRIGHTS ARE PLUMB AND DRILL AND SECURE ALL HOLES ON UPRIGHTS A SHOWN IN GUIDE.
#MADEINBELFAST
10.0031
10.0019
30
Nm
DRILL HOLE VACUUM HAMMER IN
BOLT
TIGHTEN
90MM
SLEEVE ANCHOR BOLT FITTING
-DRILL 10MM HOLE THROUGH FLOOR COVERING,
90MM DEEP USING PLATE AS A GUIDE.
-VACUUM OUT THE DUST.
-HAMMER SLEEVE ANCHOR DOWN INTO THE HOLE.
-TIGHTEN SLEEVE ANCHOR TO SPECIFIED TORQUE
USING 13MM SPANNER.
30
Nm
x48

#MADEINBELFAST
1:1 SCALE FASTENERS
FOR TERMS AND CONDITIONS VISIT OUR WEBSITE AT
www.blkboxfitness.com/pages/terms-conditions
GET IN TOUCH
TEL: [phone]
EMAIL: [e-mail]
DISCOVER MORE AT:
www.blkboxfitness.com
M10x80 SLEEVE ANCHOR
10-0031
NYLOCK NUT
10-0024
M10 FLAT WASHER
10-0019
M10x90 BOLT
10-0008
