Cadillac CUE Infotainment System (GMNA-Localizing-Europe-9367711) -
2016 - CRC - 6/15/15
Contents Introduction . . . . . . . . . . . . . . . . . . 2
Radio ....................... 10
Audio Players . . . . . . . . . . . . . . 16
Rear Seat Infotainment . . . . 24
Navigation . . . . . . . . . . . . . . . . . . 54
Voice Recognition . . . . . . . . . . 75
Phone . . . . . . . . . . . . . . . . . . . . . . 82
Settings .................... 90
Trademarks and Licence
Agreements . . . . . . . . . . . . . . . 93
Index ................... 103

Cadillac CUE Infotainment System (GMNA-Localizing-Europe-9367711) -
2016 - CRC - 6/15/15
2 Introduction
Introduction
The names, logos, emblems,
slogans, and vehicle body designs
appearing in this manual including,
but not limited to, GM, the GM logo,
CADILLAC, the CADILLAC Emblem,
and CADILLAC CUE are registered
trademarks of General Motors LLC.,
its subsidiaries, affiliates,
or licensors.
This manual describes features that
may or may not be on the vehicle
because of optional equipment that
was not purchased on the vehicle,
model variants, country
specifications, features/applications
that may not be available in your
region, or changes subsequent to
the printing of this manual.
Keep this manual with the owner
manual in the vehicle, so it will be
there if it is needed. If the vehicle is
sold, leave this manual in the
vehicle.
Overview
Read the following pages to
become familiar with the
infotainment system features.
{Warning
Taking your eyes off the road for
too long or too often while using
any infotainment feature can
cause a crash. You or others
could be injured or killed. Do not
give extended attention to
infotainment tasks while driving.
Limit your glances at the vehicle
displays and focus your attention
on driving. Use voice commands
whenever possible.
The infotainment system has built-in
features intended to help avoid
distraction by disabling some
functions when driving. These
functions may grey out when they
are unavailable. Many infotainment
features are also available through
the instrument cluster and steering
wheel controls.
Before driving:
.Become familiar with the
operation, faceplate buttons, and
screen buttons.
.Set up the audio by presetting
favourite stations, setting the
tone, and adjusting the
speakers.
.Set up phone numbers in
advance so they can be called
easily by pressing a single
button or by using a single voice
command if equipped with
Bluetooth phone capability.
See "Defensive Driving" in the
owner manual.
To play the infotainment system with
the ignition off, see “Retained
Accessory Power (RAP)”in the
owner manual.

Cadillac CUE Infotainment System (GMNA-Localizing-Europe-9367711) -
2016 - CRC - 6/15/15
Introduction 3
Customer Assistance
Assistance may be available to help
with Bluetooth pairing, other mobile
device interfaces, and operation
support of the CUE infotainment
system. See your dealer.
Infotainment System
The infotainment system is
controlled by using the touchscreen,
the buttons below the touchscreen,
steering wheel controls, and voice
recognition.
1. O(Power and Mute)
2. VOLUME
3. {(Home Page)
Power (On/Off/Mute)
.When off, press O(1) to turn the
system on. Press and hold to
turn off.
.When on, press Oto mute the
system. Press Oagain to
unmute the system.
Retained Accessory Power (RAP)
The vehicle has RAP. When in RAP
the audio system can be played
even after the ignition is turned off.
See “Retained Accessory Power
(RAP)”in the owner manual.
Volume
The black area above the chrome
bar (2) is used to increase or
decrease the volume. There are
three ways to adjust the volume:
.Slide a finger.
.Press.
.Press and hold.
Rear Seat Armrest Control
Panel
If equipped, there is a control panel
in the centre of the rear seat back.
See “Armrest Storage”in the owner
manual.
1. O(Power): Press to turn the
power on or off for the sourced
audio or media playback and
sunshade control button (if
equipped).
2. SVOL T(Volume): Press the
left or right arrow to adjust the
volume of current playback.
3. Q(Sunshade Switch): Press
and release the switch to
control the rear window

Cadillac CUE Infotainment System (GMNA-Localizing-Europe-9367711) -
2016 - CRC - 6/15/15
4 Introduction
sunshade. See “Rear Window
Sunshade”in the owner
manual.
4. PRESET: Press to go to a
saved favourite.
5. SSEEK T: Press the left or
right arrow to go to the
previous or next station on the
radio or track on a media
source.
6. SRCE (Source): Press to
change the source of playback.
Home Page
The Home Page is where
application icons are accessed.
Some features are disabled when
the vehicle is moving.
The Home Page can be set up to
have up to five pages with eight
icons per page.
Touch the left uor right vor slide
a finger left/right across the screen
to access the pages of icons.
v(Next) : Touch to go to the next
Home Page.
u(Previous) : Touch to go to the
previous Home Page.
k(Interaction Selector) : Touch to
display the favourites list.
Touch and hold a location within the
favourites area to begin the process
of saving a favourite application.
Touch the application icon to store
as a favourite, and the name of the
application will be shown in
favourites.
Managing Home Page Icons
1. Touch and hold any of the
Home Page icons to edit
that icon.
2. Drag the icon to a new location
on the Home Page or to save it
to the applications tray.
3. Press {to exit edit mode.
Steering Wheel Controls
The infotainment steering wheel
controls can be used to control the
infotainment features displayed in
the instrument cluster.
When in Valet Mode (if equipped),
access to the infotainment functions
is disabled. See Settings 090.

Cadillac CUE Infotainment System (GMNA-Localizing-Europe-9367711) -
2016 - CRC - 6/15/15
Introduction 5
g(Press to Talk) : Press to answer
an incoming call or to start a voice
recognition. See Bluetooth
(Overview) 082 or Bluetooth
(Infotainment Controls) 083 or
Bluetooth (Voice Recognition) 086.
c(End Call) : Press to decline an
incoming call, or end a current call.
Press to mute or unmute the
infotainment system when not on
a call.
Sor T(Previous or Next) : Press
the five-way control to the left or
right to go to the previous or next
area in the display or to the previous
or next menu.
yor z(Previous or Next) :
Press the five-way control up or
down to go up or down in a list
or page.
SEL : Press to select a highlighted
menu item.
Cor B(Next or Previous
Favourite) : Press to go to the next
or previous favourite when listening
to the radio. Press to go to the next
or previous track when listening to a
media source.
x+ or x−(Volume) : Press to
increase or decrease the volume.
Using the System
Audio
Touch the AUDIO icon to display the
active audio source page. Available
sources are AM, FM, CD (if
equipped), My Media, USB, SD,
Bluetooth, and AUX Input.
Phone
Touch the PHONE icon to display
the Phonemain page. See Bluetooth
(Overview) 082 or Bluetooth
(Infotainment Controls) 083 or
Bluetooth (Voice Recognition) 086.
NAV (Navigation, If equipped)
Touch the NAV icon to display the
navigation map. See Using the
Navigation System 054.
Settings
Touch the SETTINGS icon to
display the Settings menu. See
Settings 090.
Energy (If Equipped)
Touch the ENERGY leaf icon to
display energy flow on the hybrid
vehicle. See the owner manual.
Climate
Touch the CLIMATE icon to display
the Climate main page. See “Dual
Automatic Climate Control System”
in the owner manual.

Cadillac CUE Infotainment System (GMNA-Localizing-Europe-9367711) -
2016 - CRC - 6/15/15
6 Introduction
Rear Climate (If Equipped)
Touch the R. CLIMATE icon to
display the Rear Climate main page.
See “Rear Climate Control System”
in the owner manual.
Video (If Equipped)
Touch the VIDEO icon to display the
video Rear Seat Entertainment main
page. See Rear Seat Entertainment
(RSE) System 024 or Rear Seat
Entertainment (RSE) System
(Platinum) 041.
Applications Tray
The applications tray is at the top
centre of the screen. The
applications tray can have three to
five applications.
To add an application from the
Home Page to the applications tray:
1. Touch and hold any icon on the
Home Page to enter edit mode.
2. Drag the icon to the
applications tray.
To remove an item from the
applications tray, drag the icon
from the applications tray back
to the Home Page.
Adding or removing applications
from the applications tray will not
remove them from the Home Page.
Touchscreen Buttons
Touchscreen buttons show on the
screen when available. When a
function is unavailable, the button
may grey out. When a function is
selected, the button may highlight.
Proximity Sensing
The infotainment system uses
proximity sensing. When enabled,
certain screen buttons and features
will become visible when a hand
approaches the screen. When the
hand is removed, these features
fade. Proximity sensing can be
disabled in the Settings applications
in the Display menu options.
Haptic Feedback
Haptic feedback is a pulse that
occurs when a button is touched on
the screen or when buttons below
the screen are touched.

Cadillac CUE Infotainment System (GMNA-Localizing-Europe-9367711) -
2016 - CRC - 6/15/15
Introduction 7
Infotainment Gestures
Use the following finger gestures to
control the infotainment system.
Touch/Tap
Touch/Tap is used to select a button
or option, activate an application,
or change the location inside a map.
Touch and Hold
Touch and hold can be used to start
another gesture, move, or delete an
application.
Drag
Drag is used to move applications
on the Home Page, or to pan the
map. To drag the item, it must be
held and moved along the screen to
the new location. This can be done
up, down, right, or left.

Cadillac CUE Infotainment System (GMNA-Localizing-Europe-9367711) -
2016 - CRC - 6/15/15
8 Introduction
Nudge
Nudge is used to move items a
short distance on a list or a map. To
nudge, hold and move the selected
item up or down to a new location.
Fling or Swipe
Fling or swipe is used to scroll
through a list, pan the map,
or change page views. Do this by
placing a finger on the screen then
moving it rapidly up and down or
right and left.
Spread
Spread is used to zoom in on a
map, certain images, or a web
page. Place finger and thumb
together on the screen, then move
them apart.

Cadillac CUE Infotainment System (GMNA-Localizing-Europe-9367711) -
2016 - CRC - 6/15/15
Introduction 9
Pinch
Pinch is used to zoom out on a
map, certain images, or a web
page. Place finger and thumb apart
on the screen, then move them
together.
Cleaning High Gloss Surfaces
and Vehicle Information and
Radio Displays
For vehicles with high gloss
surfaces or vehicle displays, use a
microfiber cloth to wipe surfaces.
Before wiping the surface with the
microfiber cloth, use a soft bristle
brush to remove dirt that could
scratch the surface. Then use the
microfiber cloth by gently rubbing to
clean. Never use window cleaners
or solvents. Periodically hand wash
the microfiber cloth separately,
using mild soap. Do not use bleach
or fabric softener. Rinse thoroughly
and air dry before next use.
Software Updates
Contact your retailer for software
updates.

Cadillac CUE Infotainment System (GMNA-Localizing-Europe-9367711) -
2016 - CRC - 6/15/15
10 Radio
Radio
AM-FM Radio
Playing the Radio
While on the audio main page the
available sources are: AM, FM,
DAB, CD (if equipped), My Media,
USB, SD, Bluetooth, and AUX Input.
.Touch the RADIO screen button
to scroll through AM, FM,
or DAB.
.Touch the MEDIA screen button
to scroll through CD (if
equipped), My Media, USB, SD,
Bluetooth, and Aux Input.
Infotainment System Settings
Touch the RADIO screen button to
access broadcast sources.
Touch the MENU screen button to
display the following menus:
Tone Settings:
.Bass, Midrange, Treble: Touch +
or −to adjust the volume of the
seat speakers.
.Surround: If equipped, touch +
or −to adjust.
.Balance: Touch Sor Tfor more
sound from the left or right
speakers. The middle position
balances the sound between the
left and right speakers.
.Fade: Touch yor zfor more
sound from the front or rear
speakers. The middle position
balances the sound between the
front and rear speakers.
DSP Modes (If Equipped) :
.Bose
®
Studio Surround
®
and
Bose Centerpoint
®
surround
sound systems have four DSP
modes including:
‐Normal: Adjusts the audio to
provide the best sound for all
seating positions.
‐Driver: Adjusts the audio to
provide the best sound for the
driver.
‐Rear: Adjusts the audio to
provide the best sound for the
rear seat occupants.
‐Centerpoint: Turns on the
Bose Centerpoint surround
technology. This setting
creates a surround sound
listening experience from
nearly any audio source;
existing stereo, CD collection,
satellite radio, and MP3
players. For more information
on Bose Centerpoint surround
technology, visit
www.bose.com/centerpoint.
Auto Volume (If Equipped) : This
feature adjusts the volume based on
vehicle speed. The options are Off,
Low, Medium - Low, Medium,
Medium - High, or High.
Bose
®
AudioPilot
®
noise
compensation technology (If
Equipped) : This feature adjusts
the volume based on the noise in
the vehicle and speed. When turned
on, AudioPilot technology detects
ambient noise and vehicle speed to
continuously adjust many aspects of
the audio signal so that music will
sound the same at a set volume
level.
The options are ON and OFF.

Cadillac CUE Infotainment System (GMNA-Localizing-Europe-9367711) -
2016 - CRC - 6/15/15
Radio 11
This feature is most effective at
lower radio volume settings where
background noise can affect how
well the music is being played
through the vehicle audio system. At
higher volume settings, where the
music is much louder than the
background noise, there may be
little or no adjustments by
AudioPilot. For more information on
Bose AudioPilot noise
compensation technology, see
www.bose.com/audiopilot.
EQ (Equaliser) : If equipped with a
Bose
®
Sound System, the EQ
settings are selected through the
tone menu. Touch the left or right
arrows to cycle through the EQ
options. The available choices are
Custom and Talk.
Update Station List : For AM, FM,
and DAB only, touch to update the
station list. Touch [Back to go back
to the previous menu.
Tag Song (If Equipped) : Touch to
bookmark a song on an Apple
®
device for later purchase using
iTunes
®
.
Timeshifting (If Equipped) :
Timeshift is the recording of a radio
station for up to 25 minutes. See
“Timeshifting”later in this section.
Finding a Station
Seeking a Station
Touch tor uto search for the
previous or next strongest station.
Direct Tune (If Equipped)
Touch the TUNE screen button to
switch to Direct Tune for manually
searching for a station.
If not equipped with Direct Tune,
touch the SEEK screen button to
switch to TUNE. Touch again to
change back. Touch tor uto
manually search for a station.
Storing Radio Station Presets
Favourites are stored in the area at
the bottom of the screen.
Up to 60 preset stations can be
stored under the following:
AM, FM, DAB Stations : Touch and
hold a favourite button to save the
current station as a favourite. Touch
a favourite button to recall a
favourite station.
Mixed-Audio Favourites
Favourites that can be stored
include radio stations, applications,
contacts, tone settings, artists,
songs, albums, podcasts, etc
To scroll through the favourites:
.Drag up along the top of the
favourites. To close the
favourites, drag them down.
.Slide a finger to the right or left
to scroll through each page of
favourites. A Vindicates which
page is being viewed.

Cadillac CUE Infotainment System (GMNA-Localizing-Europe-9367711) -
2016 - CRC - 6/15/15
12 Radio
Tone Settings : While viewing the
tone settings and lifting up the
favourite buttons, press and hold to
store a tone setting. Touch a screen
button in the favourite area to recall
a favourite tone setting.
The number of favourites displayed
is automatically adjusted by default,
but can be manually adjusted in the
Settings menu under Radio and
then Manage Favourites.
Radio Data System (RDS)
The audio system has an RDS.
RDS features are available for use
only on FM and DAB stations that
broadcast RDS information. With
RDS, the radio can:
.Seek to stations broadcasting
the selected type of
programming
.Receive announcements
concerning local and national
emergencies
.Display messages from radio
stations
This system relies on receiving
specific information from these
stations and only works when the
information is available. In rare
cases, a radio station may
broadcast incorrect information that
causes the radio features to work
improperly. If this happens, contact
the radio station.
The RDS is always on. When
information is broadcast from the
current FM station, the station name
or call letters display on the audio
screen. RDS may provide a
program type (PTY) for current
programming and the name of the
program being broadcast.
When RDS signal information has
been detected, the metadata fields
will be updated on the screen
display to show the RDS data. The
radio text will be updated any time
new information is received.
The RDS fields on the screen will
show in the order of:
.Frequency and /or RDS-PSN.
.RDS text line one is the
information provided by the
broadcast.
.RDS text line two and three is
RDS text. Line three is used only
if necessary, to wrap over from
the text on line two.
If the RDS text information
overflows from line two and three,
the previous information given on
line two and three will clear. The
overflow of information will finish
starting from the previously used
line two and then if necessary, line
three.
If an RDS text update occurs during
the paging, the display fields are
cleared and the new information is
displayed, beginning on line two.
Once the entire broadcast text is
finished paging, the amount of text
that can fit in lines two and three will
be displayed and an ellipsis will
indicate further text exists.

Cadillac CUE Infotainment System (GMNA-Localizing-Europe-9367711) -
2016 - CRC - 6/15/15
Radio 13
RDS Traffic Volume Setting
Traffic alert volume can be adjusted
by turning the volume up or down
while the alert is playing. The
system will store this setting for
future traffic alerts.
If the current source is playing at a
higher volume than the traffic alert
volume setting, the traffic alert will
play back at the current source
volume setting. If the current source
is playing at a lower volume than
the traffic alert volume setting, the
traffic alert will play at the volume
set for traffic.
Once an alert is complete, the
system volume returns to its
previously set level prior to the
traffic alert.
If the traffic alert volume is set to
zero during an alert, the next traffic
alert will play at the minimum
connection volume level.
If stations or sources are switched
during a traffic alert, the current
traffic alert will be cancelled.
If the RDS On/Off option is set to
Off, and the Traffic Program (TP) is
set to On, a traffic alert will
automatically override the Off
setting and place the RDS mode
to On.
The default station list is sorted by
RDS stations first, in order of signal
strength, and followed by non-RDS
stations grouped at the end of
the list.
Stations that support traffic
programming are marked TP and
show on the right side of the
line item.
Timeshifting (If Equipped)
The audio system can record live
radio for up to 25 minutes. When
tuned to a station, the system
automatically begins recording the
audio along with the associated
metadata. Timeshift must be turned
on in the menu before recording can
take place.
Touch jto pause playback of the
audio and to initiate timeshift mode.
Touch rto resume playback of the
live audio.
When timeshifting begins, a time is
indicated on the right of the play/
pause indicator. This time initially
indicates the time of day at which
playback is paused. This time
continues to show as long as the
system is in a paused mode and the
buffer continues to fill.
Buffer Reset
The buffer will reset anytime the
broadcast band or stations/channels
are changed. Changing to a media
source while in pause mode will not
reset the buffer.

Cadillac CUE Infotainment System (GMNA-Localizing-Europe-9367711) -
2016 - CRC - 6/15/15
14 Radio
Rewinding or Fast Forwarding a
Timeshifted Broadcast
.Touch and hold the tindicator
to reverse playback at a rate of
15 times the rate of normal
playback.
.Touch and hold the uindicator
to advance playback at a rate of
15 times the rate of normal
playback. The timeshift buffer
can be advanced up to the end
of the timeshift buffer and return
to live mode.
Returning to Live Broadcast
If listening to timeshifted radio,
touch the LIVE button to return to
live radio.
Timeshifting and Station/Channel
Lists
If browsing a station/channel list is
started while listening to the
timeshift content, the list content is
shown in live time, not
buffered time.
Skipping Back in a Broadcast
For programs with metadata,
touching the previous button less
than five seconds into a program
will make the system skip to the
beginning of the previous program.
If more than five seconds into the
current song/program, the system
starts at the beginning of the current
program. If no metadata is available,
the system skips back 30 seconds.
Reaching the End of the Buffer
If the audio is paused and the
25 minute buffer is reached, the
buffer continues recording the latest
content and will erase the oldest
content. When playback is started,
the content played will be the last
25 minutes in the buffer.
Radio Reception
Unplug electronic devices from the
accessory power outlets if there is
interference or static in the radio.
FM
FM signals only extend about 16 to
65 km (10 to 40 mi). Although the
radio has a built-in electronic circuit
that automatically works to reduce
interference, some static can occur,
especially around tall buildings or
hills, causing the sound to fade in
and out.
AM
The range for most AM stations is
greater than for FM, especially at
night. The longer range can cause
station frequencies to interfere with
each other. Static can also occur
when things like storms and power
lines interfere with radio reception.
When this happens, try reducing the
treble on the radio.
Mobile Phone Usage
Mobile phone usage, such as
making or receiving phone calls,
charging, or just having the phone
on may cause static interference in
the radio. Unplug the phone or turn
it off if this happens.

Cadillac CUE Infotainment System (GMNA-Localizing-Europe-9367711) -
2016 - CRC - 6/15/15
Radio 15
Backglass Aerial
The AM-FM aerial is integrated with
the rear window demister in the rear
window. Do not scratch the inside
surface or damage the lines in the
glass. If the inside surface is
damaged, it could interfere with
radio reception. For proper radio
reception, the aerial connector
needs to be properly attached to the
post on the glass.
If attaching a mobile phone aerial to
the glass, attach it between the grid
lines.
Caution
Using a razor blade or sharp
object to clear the inside rear
window can damage the rear
window aerial and/or the rear
window defogger. Repairs would
not be covered by the vehicle
warranty. Do not clear the inside
rear window with sharp objects.
Caution
Do not apply aftermarket glass
tinting with metallic film. The
metallic film in some tinting
materials will interfere with or
distort the incoming radio
reception. Any damage caused to
the backglass aerial due to
metallic tinting materials will not
be covered by the vehicle
warranty.
Multi-Band Aerial
The roof aerial is for the GPS
(Global Positioning System). Keep
clear of obstructions for clear
reception. If the vehicle has a
sunroof, and it is open, reception
can also be affected.

Cadillac CUE Infotainment System (GMNA-Localizing-Europe-9367711) -
2016 - CRC - 6/15/15
16 Audio Players
Audio Players
CD Player
If equipped, the player can be used
for CD and MP3 audio.
The system is capable of playing:
.Most audio CDs
.CD-R
.CD-RW
.MP3 or unprotected WMA
formats
When playing any compatible
recordable disc, the sound quality
can be reduced due to disc quality,
the method of recording, the quality
of the music that has been
recorded, or the way the disc has
been handled.
There can be increased skipping,
difficulty in finding tracks, and/or
difficulty in loading and ejecting.
If these problems occur, check the
disc for damage or try a known
good disc.
To avoid damage to the CD player:
.Do not use scratched or
damaged discs.
.Do not apply labels to discs. The
labels could get caught in the
player.
.Insert only one disc at a time.
.Keep the loading slot free of
foreign materials, liquids, and
debris.
.Use a marking pen to label the
top of the disc.
Loading and Ejecting Discs
To load a disc:
1. Turn the vehicle on.
2. Insert a disc into the slot, label
side up. The player pulls it in
the rest of the way. If the disc
is damaged or improperly
loaded, there is an error and
the disc ejects.
Press Xto eject a disc from the
CD player. If the disc is not removed
within a short period of time, it is
automatically pulled back into the
player.
Playing an Audio MP3 or CD
Touch the MEDIA screen button
until CD Audio icon Now Playing
view is selected.
On the CD main page, a track
number displays at the beginning of
each track. Song, Artist, and Album
information displays when available.
Use the following controls to play
the disc:
t(Previous/Fast Reverse) :
.Touch to seek to the beginning
of the current or previous track.
If the track has been playing for
less than five seconds, it seeks
to the previous track. If longer
than five seconds, the current
track starts from the beginning.

Cadillac CUE Infotainment System (GMNA-Localizing-Europe-9367711) -
2016 - CRC - 6/15/15
Audio Players 17
.Touch and hold to fast reverse
through a track. Release the
button to return to playing
speed. Elapsed time displays.
u(Next/Fast Forward) :
.Touch to seek to the next track.
.Touch and hold to fast forward
through a track. Release the
button to return to playing
speed. Elapsed time displays.
When a Blu-ray
®
or DVD disc,
if equipped, is loaded and the CD
button is touched, a message
displays. Go to video application to
play DVD/BD.
Error Messages
If Disc Error displays and/or the disc
comes out, it could be for one of the
following reasons:
.The disc has an invalid or
unknown format.
.The road is very rough. Try the
disc again when the road is
smoother.
.The disc is dirty, scratched, wet
or upside down.
.The air is very humid. Try the
disc again later.
.There was a problem while
burning the disc.
.The label is caught in the CD
player.
If Disc Player Error displays, it could
be for one of the following reasons:
.The player temperature is
too high.
.There are load or eject errors.
If the CD is not playing correctly, for
any other reason, try a known
good CD.
If any error continues, contact your
dealer.
CD Menu
Touch the MENU button while that
source is active to access the menu.
Touch any of the following buttons
on the CD Menu:
Shuffle : Touch to play the tracks
randomly. Touch again to stop
shuffle.
Auto Volume (If Equipped) : This
feature adjusts the volume based on
the speed of the vehicle. See
AM-FM Radio 010.
Tone Settings : Touch + or −to
adjust Bass, Midrange, Treble,
or Surround. See AM-FM Radio
010.
MP3 Guidelines
.Sampling rate: 16 kHz, 22.05
kHz, 24 kHz, 32 kHz, 44.1 kHz,
and 48 kHz.
.Bit rates supported: 8, 16, 24,
32, 40, 48, 56, 64, 80, 96, 112,
128, 144, 160, 192, 224, 256,
and 320 kbps.
.Recorded on a CD-R or CD-RW.
MP3 Folder Information
Touch anywhere between the top
applications tray or the bottom menu
to display the browse screen.
Root Directory : To access, touch
the screen anywhere in the centre
area of the screen. The root
directory is treated as a folder.

Cadillac CUE Infotainment System (GMNA-Localizing-Europe-9367711) -
2016 - CRC - 6/15/15
18 Audio Players
All files contained directly under the
root directory are accessed prior to
any root directory folders.
No Folder : When the CD only
contains compressed audio files
without any folders or playlists, all
files are under the root folder.
File System and Naming : The
song titles, artists, albums, and
genres are taken from the file's ID3
tag and are only displayed if present
in the tag. If a song title is not
present in the ID3 tag, the radio
displays the file name as the
track name.
USB Port
Audio from videos stored on USB
devices may be listened to while the
vehicle is in a forward gear. Videos
can be watched while the vehicle is
in P (Park). Use play/pause or next/
previous to control the video or
touch in the browse to display a list
of the current video filters.
This vehicle may have three USB
ports. There may be one USB port
in the centre console, one USB port
in the storage behind the climate
control system, and if equipped with
Rear Seat Entertainment (RSE),
one USB port in the rear media
console storage area.
Playing from a USB
A USB mass storage device can be
connected to the USB port.
Audio extensions supported by the
USB are:
.MP3
.WMA
.AAC
.OGG
.AIFF
.3GPP
Gracenote
®
When plugging in a USB device,
Gracenote service builds voice tags
for music. Voice tags allow artists,
albums with hard to pronounce
names, and nicknames to be used
to play music through voice
recognition.
While indexing, infotainment
features are available.
My Media Library
The infotainment system allows
access to content from all of the
connected devices. Touch the
MEDIA screen button to scroll
through the options until My Media
is selected. Touch anywhere in the
centre area of the screen to browse
the content.
USB MP3 Player and USB Drives
The USB MP3 players and USB
drives connected must comply with
the USB Mass Storage Class
specification (USB MSC).
To play a USB device:
1. Connect the USB.
2. Touch MEDIA until the
connected device is shown.
Use the following when playing an
active USB source:
r(Play) : Touch to play the current
media source.
j(Pause) : Touch to pause play of
the current media source.

Cadillac CUE Infotainment System (GMNA-Localizing-Europe-9367711) -
2016 - CRC - 6/15/15
Audio Players 19
t(Previous/Reverse) :
.Touch to seek to the beginning
of the current or previous track.
If the track has been playing for
less than five seconds, the
previous track plays. If playing
longer than five seconds, the
current track restarts.
.Touch and hold to reverse
quickly through playback.
Release to return to playing
speed. Elapsed time displays.
u(Next/Fast Forward) :
.Touch to seek to the next track.
.Touch and hold to advance
quickly through playback.
Release to return to playing
speed. Elapsed time displays.
USB Menu
Touch Menu to display the USB
menu. The following may be
available:
Shuffle : Touch to play the tracks
randomly. Touch again to stop
shuffle.
Bose
®
AudioPilot
®
(If Equipped) :
Touch to turn Bose AudioPilot on or
off. The AudioPilot technology is an
On/Off selection on the list entry
from the Main menu. See AM-FM
Radio 010.
Tone Settings : Touch + or −to
adjust Bass, Midrange, Treble,
or Surround. See AM-FM Radio
010.
USB Browse Menu
Touch the browse screen button to
view the browse menu and the
following options are displayed
along the bottom of the screen:
Playlists:
Supported Playlist extensions are:
m3u, pls, wpl, asx, b4s, and xspf.
1. Touch to view the playlists
stored on the USB.
2. Select a playlist to view the list
of all songs in that playlist.
3. Select a song from the list to
begin playback.
Artists:
1. Touch to view the list of artists
stored on the USB.
2. Select an artist name to view a
list of all albums by the artist.
3. To select a song, touch All
Songs or touch an album and
then select a song from the list.
Albums:
1. Touch to view the albums on
the USB.
2. Select the album to view a list
of all songs on the album.
3. Select a song from the list to
begin playback.
Songs:
1. Touch to display a list of all
songs on the USB.
2. To begin playback, select a
song from the list.
Genres:
1. Touch to view the genres on
the USB.
2. Select a genre to view a list of
artists.
