Caffitaly System S01HS User manual

Model S01HS / P01HS
Manuale di istruzioni
Instruction book
Mode d'emploi
Bedienungsanleitung
Italiano English Français Deutsch

26
Table of contents
Introduction
Intended use .......................................................................................... 27
Warning symbols................................................................................... 27
Safety warnings..................................................................................... 28
Instructions for use and disposal ....................................................... 29
Your Cataly System contact ............................................................. 29
Description of machine components ............................................... 30
Installation
First use or after a long period of disuse .......................................... 31
Turning on the appliance..................................................................... 32
General operating indications............................................................ 33
Dispensing the product
Dispensing coee.................................................................................. 35
Dispensing lter coee ........................................................................ 36
Dispensing other beverages ............................................................... 38
Dispensing hot water ........................................................................... 39
Preparing cappuccino / Dispensing steam....................................... 40
Cleaning and Maintenance
Daily maintenance ................................................................................ 42
Descaling ................................................................................................ 43
Changing the gasket ............................................................................ 47
Miscellaneous
Troubleshooting.................................................................................... 48
Technical data ........................................................................................ 49
2
3
4
4
5
6
7
8
9
0
2
3

27
Introduction
ear Customer,
Thank you for having chosen our product and for your con dence in our company.
You can savour your favourite hot beverages at any time of the day with our appliance by choosing one
of the capsules that Ca taly o ers you. For example: An espresso, a cocoa- avoured beverage or a tea
will be ready in just a few seconds.
Intended use
his appliance is intended to be used in domestic and similar applications such as, for example:
- sta cooking areas in shops, o ces and other work environments;
- holiday farms;
- by guests staying at hotels, motels and other residential facilities;
- facilities like bed and breakfasts.
Use only Ca ta System capsules. Use of the appliance in any manner other than as directed herein
could cause harm to persons and void the guarantee.
he manufacturer will not be responsible for injury or damage resulting from improper use of the
appliance.
Warning symbols
CAUTION
his is the safety warning symbol. It is used to call your attention to possible risks of
personal injury. Abide by the safety messages provided in order to avoid possible injury
or death.
NOTE
his is the symbol used to highlight some actions that will optimise use of the
appliance.
Not dishwasher safe Maintenance tips
his symbol is used to highlight a GREEN light indication.
his symbol is used to highlight an ORANGE light indication.
his symbol is used to highlight a BLUE light indication.
his symbol is used to highlight a RED light indication.

28
Introduction
Safety warnings
Carefully read the following instructions! In this way you will avoid the risk of personal injury and
damage to the appliance.
After removing the packaging, check that the appliance is not damaged. If damage is found, or
upon the  rst sign of a defect (unusual noise or odours), do not use the appliance and contact
the Authorised Service Centre.
he packaging elements (plastic bags, etc.) must not be left within reach of children as they are
potential sources of danger.
Only use the appliance if the power cord is intact. If the cord is damaged, it should be replaced:
contact an Authorised Service Centre. Lethal danger of electric shocks.
Only use and store the appliance indoors. Make sure the electrical elements, plug and cord are
dry. Never submerge the appliance in water. Protect the appliance from sprays and drips. Water
and electricity together constitute a risk of electrocution.
Only connect the appliance to power outlets complying with the requirements of the law. Make
sure that the power supply voltage matches the rating shown on the data plate on the bottom
of the appliance.
o avoid the risk of  re, set the appliance on a  at, heat-resistant surface. Do not leave the
power cord hanging from the edge of the support surface.
Do not allow the appliance to be used by children or persons with impaired mental, physical
or sensory faculties or insu cient experience and/or skills, unless they are under the careful
supervision and guidance of a person responsible for their safety. Children must be kept under
supervision to prevent them from playing with the appliance.
Do not leave the power cord near hot surfaces, sharp edges or other sharp objects.
Never place your hands inside the capsule compartment. Danger of injury
Always close the lever. Never open the lever while the appliance is operating.
Never remove parts of the appliance. Do not insert objects into the openings. his could cause
electric shocks! Any operation that is not described in this instruction manual should only be
performed by an Authorised Service Centre!
Do not pull on the power cord to disconnect it. Remove the plug to avoid damage to the outlet.

29
Instructions for use and disposal
Introduction
he appliance has been manufactured using high quality materials that can be reused
or recycled. Dispose of the appliance in a suitable waste collection centre.
o rule out any abuse and dangers involved, ensure that the machine cannot be
plugged into the mains before delivering it to the scrapping service.
o achieve this, unplug the appliance from the outlet and cut the power cord as close
as possible to the machine.
Directions for correct disposal of the product according to European Directive
2002/96/EC and Italian Legislative Decree no. 151 dated 25 July 2005. At the end of
its useful life, the product should not be disposed of with unsorted household waste.
It should be taken to a suitable selective waste collection centre set up by the local
authorities or returned to a retailer who provides this service. Separate collection of
an electric household appliance avoids a possible negative impact on the environ-
ment and health arising from improper disposal and enables the materials it is made
of to be recovered so as to achieve signi cant savings of energy and resources. he
crossed-out wheelie bin symbol applied on the product highlights the need to dispose
of electric appliances separately. Improper disposal of the product by the user shall be
subject to speci c administrative sanctions as provided for under current regulations.
he packaging is made from recyclable materials. Contact the competent authorities
for information regarding local legislation.
Descale the appliance regularly, following the instructions provided. If you do not, the appli-
ance may be damaged and may become harmful to your health.
Clean the appliance carefully and regularly. If it is not cleaned, the build-up that forms may be
hazardous to your health. Unplug the appliance and allow it to cool before cleaning.
If you do not expect to use the appliance for a long period of time (leaving on vacation, etc.),
unplug it.
Your Cataly System contact info@cataly.com

30
Power cord
Power on/o switch
"team"
button
"Filter co ee"
button
"Multifunction"
alarm
"Filter co ee"
indicator light
Drip tray
Co ee position
Central
position (0)
Hot water /
steam position
Adjustable co ee dis-
penser
Lever for opening
capsule compartment
Co ee / hot water /
steam control lever
Hot water / steam
dispensing tube
Used capsule
drawer
Capsule
compartment
Water tank
Water tank cover
Description of machine components
Introduction

31
First use or after a long period of disuse
Fill the tank with fresh, still water. Plug in the appliance and turn it on.
he multifunction indicator light blinks
in GREEN. After approximately 1 minute, it
becomes lit steadily and the appliance is ready
to use.
o  ll the circuit, draw o approximately one
glass of water from the co ee dispensing spout
(without using a capsule), setting the control
lever to the co ee position.
At the end of this step, set the lever back to its
central position (0).
Flush the circuit by drawing o another glass
from the hot water dispensing pipe, setting the
control lever to the hot water position.
5
6
1
43
2
1

32
Turning on the appliance
2Turning on the appliance
Empty the water from the used capsule drawer.
At the end of this step, set the lever back to its
central position (0).
Fill the tank with fresh, still water. urning on
the appliance
he multifunction indicator light blinks
in GREEN. After approximately 1 minute, it
becomes lit steadily and the appliance is ready
to use.
12
8
7
2

33
General operating indications
When the water runs out during operation
Heating
When the multifunction indicator light is lit in
RED, the water tank is empty.
Set the control lever back to the centre (0).
he multifunction indicator light blinks in
GREEN.
Set the control lever to the co ee position; the
appliance will resume brewing.
Fill the tank with fresh water.
21
3 4
3

34
If the lever is raised while a product is being
dispensed.
General operating indications
CAUTION!
Raising the lever incorrectly while dispensing a product may cause brief
splashes of hot water.
Danger of scalding!
If the lever is raised
he appliance will immediately stop dispensing.
Close the lever.
he appliance is ready for a new dispensing
cycle.
3
12
3

35
Dispensing coee
Raise the lever to open the capsule compart-
ment. Insert the capsule, pressing it gently into place.
Close the lever  rmly. Place a cup or mug under the co ee dispensing
spout.
urn the control lever to the co ee position. When the desired quantity has been
dispensed, set the control lever back to its
central position (0).
1
2
34
65
Caution! Before you
start brewing, make sure
the capsule container is not
full.
4

36
Dispensing lter coee
Dispensing lter coee
Raise the lever to open the capsule compart-
ment. Insert the capsule, pressing it gently into place.
78
2
1
Caution! Before you
start brewing, make
sure the capsule container is
not full.
5
Raise the lever to eject the used capsule into
the drawer.
Close the lever.
5

37
Dispensing lter coee
Close the lever  rmly.
Place a mug under the co ee dispensing spout.
urn the control lever to the co ee position.
Raise the lever to eject the used capsule into
the drawer.
Press the  lter co ee button; the  lter co ee
indicator light is lit steadily in BLUE.
When the desired quantity has been
dispensed, set the control lever back to its
central position (0).
Close the lever.
8
34
6
5
7
5

38
Dispensing other beverages
Capsules for preparing beverages such as tea, chamomile tea, lter coee, etc. are
available.
When using them, proceed as directed in
Chapter 5,
"Dispensing lter coee".
o prepare beverages using barley capsules, cocoa drinks, etc., proceed as directed in
Chapter 4,
"Dispensing coee".
NOTE:
races of the product just dispensed may remain in the circuit of the machine.
When switching from one product to another, in order to fully enjoy the  avour of
the beverage we suggest rinsing the machine by pressing the co ee button as if
to dispense a co ee without inserting a capsule.
6

39
CAUTION! During preparation there may be some brief splashes of hot water
and the steam dispensing tube reaches very high temperatures. Danger of
scalding! Handle the tube only by means of the special rubber grip. After
each use, clean the tube with a damp cloth.
Dispensing hot water
Place a metal container under the hot water
dispensing pipe.
urn the control lever all the way to the right.
Start dispensing hot water.
o stop dispensing, turn the lever to the left,
returning it to a central position.
Remove the container of hot water.
3 4
1 2
7

40
Preparing cappuccino / Dispensing steam
CAUTION! During preparation there may be some brief splashes of hot water
and the steam dispensing tube reaches very high temperatures. Danger of
scalding! Handle the tube only by means of the special rubber grip. After
each use, clean the tube with a damp cloth.
Press the steam button; the multifunction
indicator light blinks in ORANGE. After approxi-
mately 1 minute, the appliance will be ready to
dispense steam. he multifunction indicator
light is lit steadily in ORANGE.
Half- ll a metal container with milk. Submerge
the steam tube in the container.
urn the control lever to the steam position to
start dispensing steam.
Dispense the co ee as desired (see Ch. 4).
34
1 2
8

41
Preparing cappuccino / Dispensing steam
5
7
6
Move the container in a slight circular motion
to ensure the milk is uniformly heated.
Pour the heated and frothed milk into a co ee
cup.
When preparation is complete, return the lever
to central position.
Press the steam button; the multifunction
indicator light blinks rapidly in GREEN. he
machine is in its cooling phase. When the
multifunction indicator light is lit steadily in
GREEN, the machine is ready to use.
NOTE:
o speed up machine cooling, we recommend dispensing hot water into a metal
container for a few seconds.
his cleans out the steam dispensing tube.
8
8

42
Daily maintenance
Remove the water tank. Empty and rinse out
the tank. he water tank is NO dishwasher
safe.
Remove the outside of the steam dispensing
tube and wash it in hot water to remove any
milk residue.
Clean the inside with a damp cloth.
Use a soft cloth and a neutral
detergent to clean the surfaces of the
appliance.
he plastic parts of the appliance are
not dishwasher safe.
ake out the used capsule drawer; empty and
rinse it.
Remove the drip tray and the grid. Empty the
drip tray. Wash the parts with fresh water.
3 4
1 2
9

43
urn o the machine. Empty and rinse out the used capsule drawer
and drip tray.
Descale the appliance regularly in accordance with the water hardness level.
CAREFULLY read the directions for use on the descaling agent packaging. Avoid con-
tact with eyes, skin and machine surfaces. Switch the appliance o during descaling,
and do not lift the lever.
A person must be present during the operation.
Do not use vinegar: it could damage your appliance!
It is advisable to use the Cata System descaling agent. It has been studied to comply
with the technical characteristics of the appliance, in full observance of consumer safety.
The descaling agent must be disposed of in compliance with manufacturer instructions
and/or with current regulations in force in the country where the appliance is used.
Remove and empty the water tank. Mix the descaling agent with water as in-
structed on the package and pour the solution
into the tank.
Water hardness French degrees German degrees Descale after ... cups
low 0 - 18°F 0 - 10°dH 1200
medium 18 - 36°F 10 - 20°dH 600
high 36 - 54°F 20 - 30°dH 300
Descaling
12
4
3
10

44
Descaling
Place a container (at least 250 ml) under the
co ee dispensing spout.
urn the control lever to the co ee position.
Make sure the lever is lowered.
Press the Steam button and switch on the ma-
chine; the multifunction indicator light blinks
in GREEN and ORANGE alternately.
he appliance dispenses the descaling solution
at intervals (5 doses with a 4 minute pause
between each one, for a total duration of
about 20 minutes). During this step, when
the buttons must not be pressed, the mul-
tifunction indicator light blinks alternately
(GREEN and ORANGE).
If the container  lls up, empty it.
5
7 8
6
10
9
10
