CAHABA BRAXTON CA101005 User manual

FOR WARRANTY ISSUES OR QUESTIONS, CONTACT CAHABA AT [phone].
©2018 CAHABA. ALL RIGHTS RESERVED. 1
p. 1
BRAXTON 32
DIMENSIONS / DIMENSIONES
Measures: inch [millimeter]
Mesures: pouce [millimètre]
Medidas: pulgadas [milímetros]
18”
[457]
23”
[584]
33-5/8”
[854]
32”
[813]
1-3/8
”
[ø35]
32”[813]
18”[457]
1-3/4”[ø45]
33-5/8”[854]
10-5/8”[270]
11-5/8” [296]16” [404]
http://cahabadesigns.com
866-837-2550
Installation Manual
• Carefully read the instructions
before starting the installation.
• This bathtub should be installed by
an experienced plumber.
• Drain pipe and drain trap are not
supplied. Connect to an existing
drain pipe.
If you are missing any part, please stop
and contact us immediately at:
866-837-2550
Manual de instalación
• Lea las instrucciones antes de
comenzar la instalación.
• Esta bañera debe ser instalado por
un experimentado plomero.
• Tubo de desagüe y sifón no se
suministran. Conectarse a una
tubería de drenaje.
Si le faltan cualquier parte, por favor
parar y contacto inmediatamente en:
866-837-2550
Manuel d’installation
• Lire attentivement ces instructions
avant de débuter l’installation.
• Ce bain devrait être installé par un
plombier professionnel.
• Drain et trappe non fournis.
Connecter à un drain existant.
En cas de pièces manquantes,
vous êtes priés d’arrêter et de nous
contacter au:
866-837-2550
BRAXTON 32” X 18” VANITY
CA101005 (Walnut)

FOR WARRANTY ISSUES OR QUESTIONS, CONTACT CAHABA AT [phone].
©2018 CAHABA. ALL RIGHTS RESERVED. 2
BRAXTON 32” X 18” VANITY
Caution
p. 2
EVEN WHEN INSTALLED ON LEGS, PLEASE MAKE SURE TO SECURE THE VANITY TO THE WALL WITH SCREWS
AS INSTRUCTED IN THE INSTALLATION MANUAL
--------------------------------------------------------------------------------------------------------------------------------
MÊME LORSQU’IL EST INSTALLÉ SUR PIED, S’ASSURER DE FIXER LE MEUBLE-LAVABO AU MUR AVEC DES
VIS, COMME IL EST INDIQUÉ DANS LE MANUEL D’INSTALLATION
--------------------------------------------------------------------------------------------------------------------------------
INCLUSO AL INSTALAR EL GABINETE CON LAS PATAS, ASEGÚRESE DE COLOCAR EL GABINETE A LA PARED
CON TORNILLOS COMO SE INDICA EN EL MANUAL DE INSTALACIÓN
NOTE TO MEMBERS
NOTE POUR LES MEMBRES
NOTAS PARA LOS MIEMBROS

FOR WARRANTY ISSUES OR QUESTIONS, CONTACT CAHABA AT [phone].
©2018 CAHABA. ALL RIGHTS RESERVED. 3
BRAXTON 32” X 18” VANITY
Caution
p. 3
DURING THE UNPACKING AND THE HANDLING OF THIS VANITY:
NOTE THAT THE BASIN IS NOT PRE-GLUED TO THE FRAME
--------------------------------------------------------------------------------------------------------------------------------
LORS DU DÉBALLAGE DU MEUBLE-LAVABO :
VEUILLEZ NOTER QUE LE LAVABO N’EST PAS PRÉCOLLÉ AU MEUBLE
--------------------------------------------------------------------------------------------------------------------------------
AL DESEMBALAR EL GABINETE:
TENGA EN CUENTA QUE EL LAVABO NO ESTÁ PEGADO AL GABINETE
NOTE TO MEMBERS
NOTE POUR LES MEMBRES
NOTAS PARA LOS MIEMBROS

FOR WARRANTY ISSUES OR QUESTIONS, CONTACT CAHABA AT [phone].
©2018 CAHABA. ALL RIGHTS RESERVED. 4
BRAXTON 32” X 18” VANITY
Caution
p. 4
DURING THE UNPACKING AND THE HANDLING OF THIS VANITY:
NOTE THAT THE SUPPORT BAR IS ATTACHED TO THE BACK OF THE VANITY
--------------------------------------------------------------------------------------------------------------------------------
LORS DU DÉBALLAGE DU MEUBLE-LAVABO :
VEUILLEZ NOTER QUE LA BARRE DE SUPPORT EST ATTACHÉE À L’ARRIÈRE DU MEUBLE
--------------------------------------------------------------------------------------------------------------------------------
AL DESEMBALAR EL GABINETE:
TENGA EN CUENTA QUE LABARRA DE SOPORTE ESTÁ UNIDO A LA PARTE POSTERIOR DEL ARMARIO
NOTE TO MEMBERS
NOTE POUR LES MEMBRES
NOTAS PARA LOS MIEMBROS

FOR WARRANTY ISSUES OR QUESTIONS, CONTACT CAHABA AT [phone].
©2018 CAHABA. ALL RIGHTS RESERVED. 5
BRAXTON 32” X 18” VANITY
Parts
p. 5
PARTS / PIÈCES / PIEZAS
A
B
D
E
C
Item Article Ítem Qty
ABasin Lavabo Lavabo 1
BLeg Pied Pata 2
CTop drawer Tiroir supérieur Cajón superior 1
DBottom drawer Tiroir inférieur Cajón inferior 1
EHanging bar Barre de support Barra de soporte 1
FGlide Coulisse Diapositiva 2
HARDWARE / QUINCAILLERIE / HARDWARE
F
BB
4x
DD
4x4x
CCAA
ST5x70
10x
EE
ST4x20
6x
TOOLS REQUIRED / OUTILS REQUIS / HERRAMIENTAS NECESARIAS
NOT INCLUDED / NON FOURNIS / NO INCLUIDO
Level
Niveau
Nivel
Measuring Tape
Ruban à mesurer
Cinta medidora
Hammer
Marteau
Martillo
Screwdriver
Tournevis
Destornillador
Silicone
Silicone
Silicona
Drill
Perceuse
Brocas
FF
ST4x16
16x

FOR WARRANTY ISSUES OR QUESTIONS, CONTACT CAHABA AT [phone].
©2018 CAHABA. ALL RIGHTS RESERVED. 6
BRAXTON 32” X 18” VANITY
Installation
p. 6
UNPACKING / DÉBALLAGE / DESEMBALAJE
1-1 1-2
1-3 1-4
1-5

FOR WARRANTY ISSUES OR QUESTIONS, CONTACT CAHABA AT [phone].
©2018 CAHABA. ALL RIGHTS RESERVED. 7
BRAXTON 32” X 18” VANITY
Installation
p. 7
INSTALLATION WITHOUT LEGS / INSTALLATION SANS LES PIEDS /
INSTALACIÓN SIN PATAS
AA
2-1 2-2
2-3
2-4A B

FOR WARRANTY ISSUES OR QUESTIONS, CONTACT CAHABA AT [phone].
©2018 CAHABA. ALL RIGHTS RESERVED. 8
BRAXTON 32” X 18” VANITY
Installation
p. 8
2-5
2-7
2-6
BB
CC
DD
AA
24h
2-8

FOR WARRANTY ISSUES OR QUESTIONS, CONTACT CAHABA AT [phone].
©2018 CAHABA. ALL RIGHTS RESERVED. 9
BRAXTON 32” X 18” VANITY
Installation
p. 9
INSTALLATION WITH LEGS / INSTALLATION AVEC PIEDS /
INSTALACIÓN CON PATAS
FF
BB
3-1
3-2
3-3
EE

FOR WARRANTY ISSUES OR QUESTIONS, CONTACT CAHABA AT [phone].
©2018 CAHABA. ALL RIGHTS RESERVED. 10
BRAXTON 32” X 18” VANITY
Installation
p. 10
CC
DD
AA
3-4
3-5
24h
3-6
