CAHABA Juniper CAVJUN48CG User manual

FOR WARRANTY ISSUES OR QUESTIONS, CONTACT CAHABA AT [phone].
©2021 CAHABA. ALL RIGHTS RESERVED.
1
BEFORE YOU BEGIN INSTALLATION
• Carefully Read the instructions
before starting installation.
• This product should be installed
by an experienced professional.
If you are missing any part,
please stop and contact us
immediately at [phone].
JUNIPER 48 IN. VANITY
CAVJUN48CG (Charcoal Gray)
FEATURES
MODEL CAVJUN48CG
SIZE 21” L x 48” W x 34-1/2” H
BASIN 15” L x 20-1/4” W x 7-1/5”D
VANITY
TOP 3/4” thickness
FAUCET 8 in. Spread
OVERFLOW Included
DRAIN Rear
WEIGHT 224.9 lbs.
HARDWARE 1 set Brushed Gold
1 set Brushed Nickel
MATERIAL Wood; engineered stone
INSTALL Freestanding
• Charcoal Gray cabinet with two
sets of hardware in brushed gold &
brushed nickel
• Made from wood; engineered stone
top & ceramic basin
• Pre-drilled holes for 8 in. faucet;
Faucet not included
• Cabinet features 2 soft-closing
doors, 1 flip-down drawer, 1 deep
and 3 regular soft-closing drawers, 1
standard shelf, 1 power bar with slide
out shelf, 1 hair dryer holder, drawer
dividers; matching 3 in. backsplash
• Coordinating sidesplash
(CASSJUN21) sold separately.
48”
21”
34-1/2”
3”
20-1/4”
48”
15”
8”
21”

FOR WARRANTY ISSUES OR QUESTIONS, CONTACT CAHABA AT [phone].
©2021 CAHABA. ALL RIGHTS RESERVED.
2
JUNIPER 48 IN. VANITY
Parts
PART NO. DESCRIPTION QUANTITY
A Countertop 1
B Backsplash 1
C Basin 1
D Drawer dividers set 2
E Top drawer 2
F Adjustable shelf 1
G Door (left) 1
H Tilt-down drawer 1
I Drawer 1
J Double depth drawer 1
K Pull-out tray 1
PART NO. DESCRIPTION QUANTITY
L Door (right) 1
M Power bar 1
N Knob 8 x 8
O Hinge 6
P Drawer glides 1
Q Drawer glides 4
R Butterfly hinge 1
S Curling iron holder 1
T Hair dryer holder 1
U Shelf holder 4
BA
E
G
F
C
N
H
I
J
K
O
P
R
S
T
Q
M
U
L
D

FOR WARRANTY ISSUES OR QUESTIONS, CONTACT CAHABA AT [phone].
©2021 CAHABA. ALL RIGHTS RESERVED.
3
JUNIPER 48 IN. VANITY
Installation Instructions
PREPARE THE VANITY
Vanity arrives pre-assembled, complete with pre-drilled
vanity top ready for the installation of your favorite faucet
(faucet not included).
1. Hardware may be pre-attached to the inside drawers
and/or doors. Carefully remove and reinstall the
hardware as shown.
2. Position the vanity in your desired location.
3. Clean the surface of the vanity and backsplash.
4. Apply a thin line of silicone along the unnished edge
of the backsplash. Set the backsplash in place.
5. Carefully set the backsplash in place. Immediately
remove any excess silicone.
NOTE: Allow the silicone to dry for a full 24 hours.NOTE: Allow the silicone to dry for a full 24 hours.
6. Place the curling iron and hair dryer holders as
shown.
APPLY SILICONE
ALONG THE BOTTOM,
UNFINISHED EDGE OF
THE BACKSPLASH

FOR WARRANTY ISSUES OR QUESTIONS, CONTACT CAHABA AT [phone].
©2021 CAHABA. ALL RIGHTS RESERVED.
4
JUNIPER 48 IN. VANITY
Installation Instructions
REMOVING & INSTALLING SLIDE-OUT SHELF
The slide out shelf is pre-installed in the vanity. Should
you need to remove it for any reason, refer to the
following instructions.
1. Extend the slide-out self to its full length.
2. Locate the toggle at the very back of the slide, in the
channel and press it down. This will release the main
slide mechanism.
3. Hold the toggle down and carefully pull out the shelf
until it is free from the vanity.
NOTE: To reinstall the slide-out shelf, align the slideNOTE: To reinstall the slide-out shelf, align the slide
mechanism with the track and gently push the shelfmechanism with the track and gently push the shelf
into place within the cabinet.into place within the cabinet.
ADJUSTING SHELF
The adjustable shelf is pre-installed in the vanity. Should
you need to adjust it for any reason, refer to the following
instructions.
4. Unscrew the shelf from the brackets and lift out of
the vanity.
5. Pull the bracket out and move to desired location.
Make sure all brackets are on the same level.
6. Replace the shelf.
NOTE: Once the shelf is replaced, secure the shelf inNOTE: Once the shelf is replaced, secure the shelf in
place using screws removed in step one.place using screws removed in step one.
PRESS TOGGLE DOWN TO
RELEASE SLIDE MECHANISM.
SLIDE THE SHELF OUT WHILE
HOLDING DOWN THE TOGGLE.
TO RE-INSTALL, LINE THE SLIDE MECHANISM
WITH THE TRACK AND PUSH INTO PLACE.
SAVE THE
SCREWS TO
SECURE THE
SHELF AFTER
REINSTALLING
MAKE SURE BRACKETS
ON SAME LEVEL
REPLACE THE
SHELF AND
SECURE THE
SHELF IN PLACE

FOR WARRANTY ISSUES OR QUESTIONS, CONTACT CAHABA AT [phone].
©2021 CAHABA. ALL RIGHTS RESERVED.
5
Stone countertops (Granite, Marble, etc.) are surprisingly resilient to stains and scratches. However, as a preventative
measure, any spills on the stone surfaces should be wiped up within a reasonable amount of time. Don’t let liquid sit on
the stone overnight. Stones are most prone to staining by oil and acid, so be sure to blot these spills up as soon as they
happen. Follow up by cleaning the stone with a mild non-abrasive soap and water. In bathrooms specically, stone tends
to attract soap scum, just like man-made tile. Rinse vanity top with clean, hot water frequently.
The use of sealers is also a powerful preventative measure. Your stone was sealed at the factory, but reapplication is
necessary over time. How often is determined by the quality of the sealer used, and the frequency of use. We recommend
using a penetrating non-toxic sealer for bath areas, but a food-safe sealer is is typically not necessary.
If stains and scratches do occur, there are many things you can do as a consumer to remove them. Remove oil based
stains with acetone, mineral spirits, or ammonia. Organic stains like coffee, tea, or juice can be removed with hydrogen
peroxide, mixed with a few drops of ammonia.
Water spots or rings are the most common problem with bath vanities, and are caused by minerals left behind when
water evaporates. These can be removed by bufng the spots gently with 00 gauge steel wool. Likewise, small nicks and
scratches can often be removed the same way. Larger scratches, chips, and resilient stains may require professional
help. Please contact your local stonemason for details.
DO’S & DON’TS
• DO use preventative cleaning measures to keep your stone pristine.
• DO use sealers, applied according to the product specic directions.
• DO blot spills quickly, and wash with mild soap and warm water.
• DON’T use harsh bathroom cleaners or grout cleaners on any natural stone.
• DON’T worry if you get a signicant stain or scratch that your stone investment is ruined. Virtually anything can be
xed with professional help.
JUNIPER 48 IN. VANITY
Care & Maintenance

FOR WARRANTY ISSUES OR QUESTIONS, CONTACT CAHABA AT [phone].
©2021 CAHABA. ALL RIGHTS RESERVED.
6
This warranty applies to CAHABA vanities installed for commercial and residential use.
CAHABA warrants that, when installed in accordance with the Recognized Plumbing Industry Practice, the vanities are
free of manufacturing defects for a period of one (1) year from the date of purchase.
We guarantee your satisfaction with each vanity. Should any vanity not meet your satisfaction due to a visual defect,
simply return it to your retailer with the original packaging, PRIOR TO INSTALLATION, for a replacement.
This warranty applies only to the original purchaser and installation site and is not transferable.
INFORMATION ABOUT YOUR WARRANTY COVERAGE
This warranty does not cover damages or failure attributable to:
• Vanities installed with obvious visual defects.
• Defects or damages to vanities caused by installation that does not comply strictly with the instructions set forth in
CAHABA’s installation manual.
• Defects or damage to vanities caused by severe accidents (e.g., re, impacts).
• Damage caused by flooding or standing water from leaking pipes, faucets, household appliances, etc; up to and
including flooding and any damage caused by acts of God.
FOR WARRANTY SERVICE
To make a claim, contact CAHABA no later than 30 days following the date of discovery or detection of defect.
Proof of purchase, such as the bill of sale is mandatory when requesting warranty service.
CAHABA reserves the right to designate a representative to inspect the vanity for analysis.
No unauthorized person, installer, dealer, agent or employee of CAHABA or any representative is entitled to assume any
liability on behalf of CAHABA relating to the sale of this product or has the authority to increase or alter the obligations
or limitations of this warranty.
THE SOLE REMEDY PROVIDED BY THIS WARRANTY IS THE REPAIR OR REPLACEMENT OF DEFECTIVE PRODUCTS.
THIS WARRANTY DOES NOT COVER THE COST OF REMOVAL OR INSTALLATION OF NEW PRODUCTS. THE WARRANTY
WILL BE VOID IF THIS ITEM IS INSTALLED WITH OBVIOUS VISUAL DEFECTS.
JUNIPER 48 IN. VANITY
Limited 1-Year Warranty
