Cake Aik User manual

Åik
Manual

Welcome
to CAKE!
We are extremely flattered that you have chosen to ride a CAKE electric
bike. It’s our obligation to do the best we can to serve you with the
product, information, service and spare parts for an eortless experience.
Our ambition is to develop uncompromising high-performance motorbikes.
CAKE´s mission is to inspire people, contributing to speeding up the journey
towards a zero-emission society, combining excitement with responsibility.
To optimize the performance and benefits for a lightweight electric bike.
Established with an electric drivetrain, establishing a new category, we
needed to start from scratch. Every little detail, hard, and software has
been engineered, designed, and chiseled for perfection while considering
the perspectives of sustainability.

Explore with Respect.


Stefan Ytterborn, Founder & CEO

4
Contents
Symbols used in this document 4
1. Safety 6
1.1 Owner’s manual 6
1.2 Risk symbols 6
1.3 Misuse 6
1.4 Safety labels and marks on the product 6
1.6 Safety advice 7
1.6.1 Tampering warning 7
1.6.2 Safe operation 8
1.6.3 Accident/damaged vehicle 8
1.6.4 Service and work on the vehicle 8
1.6.5 Disposal 9
1.7 Customer service 9
2. Warranty 9
3. Getting started 10
3.1 Unboxing the vehicle 10
3.2 Preparing for use 10
3.3 Powering on 11
3.3.1 Attaching the battery and removing the battery 12
3.4 Downloading the Ride CAKE App 13
4. Riding 13
4.1 Before every ride 14
4.2 Riding 14
4.3 Cadence 14
4.4 Light 14
4.5 Powering o/locking 14
5. Description 15
5.1 General description 15
5.2 Battery 15
5.3 Display 16

5
Contents
6. Operating 16
6.1 Handling battery and charger 16
6.2 Storing and charging to optimize the battery life span 17
6.3 Removing the battery 18
6.4 Storing the vehicle 18
7. Service schedule 18
8.0 Troubleshooting 19
9. Spare parts and accessories 21
10. Technical data 21
10.1 Åik EU/ Åik US 21
10.2 Charger 23
11. Contact and Support 23

6
Symbols used
Indicates mandatory safety information.
Indicates required maintenance according to the service schedule.
Indicates environmental measures.
Indicates a reference to the CAKE app.
Indicates additional tips.
i

7
1. Safety
1.1 Owner’s manual
Before riding the vehicle for the first time, read through this entire manual
and make sure you fully understand it. Contact ridecake.com if you have any
questions.
The manual contains useful and important information on how to operate,
service, and customize the vehicle, and protect yourself from injury.
This manual is being updated continuously. Make sure you have the latest
version; visit ridecake.com/manuals.
1.2 Risk symbols
Safety instructions are emphasized in the text. Read them carefully to avoid
hazardous situations and to operate the vehicle safely.
Danger A hazard that will immediately lead to death or serious permanent injury.
Warning A hazard that may lead to death or serious permanent injury.
Caution A hazard that may lead to minor injuries.
Notice A hazard that may lead to machine, material, or environmental damage.

8
1.3 Misuse
Only use the vehicle and its accessories, battery, and charger as intended.
Ensure to use the stated fluids and tools when servicing.
Misuse may lead to danger for people, property, or the environment.
1.4 Safety labels and marks on the product
Information labels and warning labels are attached to the product. Do not
remove any labels, as you or others may then not recognize danger.
A
G
D
E
F
B and C
Fig. 1. Placement of safety labels and marks on the vehicle

9
A Electric battery
B Hot parts
C No high-pressure cleaning
D Type label EU/ US
E Vehicle Identification Number (VIN) YWXXXXXXXXXXX
F Class 2 label (only valid for US)
G Tire pressure 3 bar / 45 psi
1.6 Safety advice
Tampering warning
Tampering with the vehicle is prohibited, or safe operation cannot be
guaranteed, and the warranty coverage will become void.
Examples of prohibited tampering:
• Modifying any part of the vehicle.
• Opening the battery.
• Opening the charger.
• Misusing the vehicle.

10
1.6.2 Safe operation
Each of the below safety instructions is repeated where relevant.
WARNING! Risk of personal injury.
Do not use the vehicle if you are not fit to ride due to alcohol, drugs,
or medicine. Do not use the vehicle if you are physically or mentally
impaired.
There is no foot brake. Remember that you control both the rear and
front brakes from the handlebar. When charging, always first connect
the charger to the battery. Thereafter, connect the charger to the mains
supply. Safe charging cannot be guaranteed if another charger or
battery than intended is used. Only use the intended charger. Only use
the intended battery. Regularly examine the charger for any damages,
especially the cord, plug, and enclosure. Do not use a damaged charger.
Contact CAKE Service & support. During charging, place the battery in a
well-ventilated area.
WARNING! Risk of burns. Stay clear of vehicle parts that are hot
after usage.
CAUTION! Do not leave the battery unattended during charging.
Fire hazard. During charging, do not place the charger on top of the
battery. The electrical components of the vehicle may be damaged
if cleaned improperly. This may in turn cause personal injury and/or
damage to the vehicle or other property. Do not flush the vehicle with
water. Do not use a pressure washer or a water hose to clean the
vehicle/battery.
• Follow the local trac laws and regulations.
• Adhere to the vehicle warning labels.
• Always wear a helmet

11
1.6.3 Accident/damaged vehicle
WARNING! Fire hazard.
Do not use a damaged battery, as it is highly flammable. A damaged
battery may self-ignite.
If the vehicle should catch fire, inform the fire brigade that it is an
electrical vehicle with a lithium battery.
After an accident or fall, check the vehicle for any damages. Do not ride the
vehicle if it requires service. If in doubt, do not ride the vehicle but contact
CAKE Service & support, see ridecake.com/en/service-support/.
1.6.4 Service and work on the vehicle
DANGER! Risk of electric shock.
Do not open the battery. Do not open the charger.
Work on high voltage components must only be performed by an
authorized CAKE workshop.
Remove the battery before starting any work on the vehicle.
NOTICE When the battery is not connected to the vehicle or the charger, the
battery must be stored indoors. Otherwise, humidity may enter through the
inlet and permanently damage the battery.
Service the vehicle according to the service schedule. Do not drop the battery,
or it may be permanently damaged.
NOTICE For safety reasons, only use spare parts and accessories
recommended by CAKE. CAKE accepts no liability for any damage or loss
caused by other spare parts or accessories. CAKE accepts no liability for any
damage or loss caused by incorrectly used accessories. When required by this
manual, have spare parts and accessories installed by an authorized CAKE
workshop. Visit ridecake.com/en/products/spare-parts/ for spare parts and
accessories.

12
1.6.5 Disposal
Dispose of used parts and material in a safe way, respecting the environment
and local laws and regulations, e.g., oil, other auxiliary fluids, and
components.
It is prohibited to dispose of electrical devices, such as the charger and the
battery in the household waste. Dispose of electrical devices in local recycling
centers.
Aluminum, steel and plastic parts are marked with their material type, such as
“6061” for aluminum EN-AW-6061 or “316” for stainless steel EN 1.4401 /AISI
316 and “PP” for plastic Polypropylene. Dispose of it accordingly.
The European Union has put legislation in place to ensure the collection and
recycling of both batteries and vehicles. The collection, recycling, treatment
and disposal of batteries and accumulators are ruled at European level by
Directive 2006/66/EC, also known as the Battery Directive and the WEEE
Directive (Directive 2012/19/EU), a directive aims to improve the collection and
recycling of waste electrical and electronic equipment. Make sure to follow
these regulations. For more information, please read the following document:
http://bike-eu.com.s3-eu-central-1.amazonaws.com/app/uploads/2015/09/
rules-regulation-on-electric-cycles-in-the-european-union-may-2017.pdf
Please, contact CAKE if you need support in this matter.
1.7 Customer service
Visit ridecake.com/en/service-support/ for information on authorized dealers
and workshops.
2. Warranty
Only authorized CAKE workshops may perform the manual’s service tasks that
are indicated by a tool symbol, or the warranty will be void. The warranty
does not cover damage or secondary damage caused by vehicle tampering.
The warranty does not cover unintended use.

13
3. Getting started
3.1 Unboxing the vehicle
The delivery from CAKE includes:
• 1x Preassembled CAKE Åik, pedals and handlebar need to be assembled,
see unboxing guide Link here
• 1x Charger
• Reflectors
•2pcs orange reflector for wheel
•1 pcs white reflector for front
• 1 pcs red reflector for rear
• 1x Toolset
• 2x Key to the battery lock
• 2x Grey key card for activating the vehicle
• 1x White master key card: required to reprogram a new gray key card if
one is lost.
NOTICE Do not keep the white master key with the vehicle. Keep it safe.
Once unpacked, recycle packaging in accordance with local laws and
regulations.
3.2 Preparing for use
WARNING! When charging, always first connect the charger to the
battery. Thereafter, connect the charger to the mains supply.
• Mount the handlebar and adjust the handlebar angle to optimize rider
comfort, see unboxing guide Link here
• Mount the pedals, see unboxing guide Link here
• Pump the brake levers three times and make sure that they function properly
• Charge the battery to 100 %, i.e, until the battery is fully charged, see
indicators on battery (Due to shipping regulations, the battery state of
charge is low during transport.)
• Add reflectors, see unboxing guide Link here
• Remove the protective film from the display.
• Read the safety instructions.
• Adjust the seatpost, see unboxing guide Link here
• Activate alarm, see 3.4

14
Fig. 2. Åik
A Seat post G Motor
B Battery connector H Right brake lever (rear wheel
brake)
C Battery docking I On/o button/thumb throttle
D Battery J Display
E Battery lock K Bell
Central stand L Left brake lever (front wheel
brake)
A
I
J
K
B
C
D
E
G
H
L
F

3.3 Powering on
1. Attach the battery, see fig. 3.
2. Connect the battery, see fig. 4.
3. Push and hold the start button for 2 seconds. The key card symbol is
shown pulsating on the display, see fig. 5.
4. Place the key card on the key card symbol The vehicle is activated and
unlocked. see fig 5
5. Check that that the rear hub automatic interface blinks with a green
light.
6. To change ride mode, briefly push the start button and toggle between
Reach, Eciency, Power and Walk assist see fig 5
7. Pushing and holding the same button for 3 seconds when at a standstill,
powers o the vehicle.
8. Get ready for your first ride!

16
3.3.1 Attaching the battery and removing the battery
Attaching the battery
1. Place the battery onto the battery dock
2. Push the battery onto the dock hook, so the dock hook locks into the
battery slot
3. Push down the top of dock to lock the battery in place
Removing the battery
1. Use key to unlock battery. The top of the dock will pop-up.
2. Pull up the top of the dock, while pushing the battery away from the
battery dock.
3. Pull battery up to remove battery.
1
2
3
dock hook
Fig. 3. Attaching and removing the battery

17
Fig. 4. Battery cable entry on the battery
Fig. 5. Handlebar
On / O button
Key Card symbol

18
3.4 Getting started with the Ride CAKE App
Download the app to access features, and to make vehicle customizations
1. In App Store or Google Play, search Ridecake and download the CAKE app.
2. Create an account and then connect your bike using the Connectivity ID
that you received in an email at the vehicle delivery.
3. Power on the vehicle, see Powering on.
4. Once logged in, standing by the vehicle, enable Bluetooth on your mobile
device.
5. When asked to pair with Cake, answer Yes. => The vehicle is connected to
your mobile device. You can start using the below app features.
• Battery level check
• Track rides
• Troubleshooting
• Bike movement, vehicle location/GPS
• Activate alarm
• Trigger alarm and play sound
• Change cadence
• Remote disable
• Metric change on display
6. Remember to activate your alarm in the app to keep your bike protected
from theft. See Activate alarm under 3.5
3.5 Overview of functions
Battery level check
Your main battery state of charge is available for your convenience in the app.
If your bike is equipped with multiple batteries then the main icon will show
the total average state of charge level of all connected batteries. It’s possible
to press the battery icon on the home screen to see each individual battery
state of charge.
By pressing the bike on the main page you can also access an overview that
shows the location of each battery and their respective charge level.

19
Track rides
When your bike is unlocked you can choose to track your ride using the record
button on the main page. This will save your ride data in your app.
Troubleshooting
If you experience a problem with your bike or detect an error code in your
display you can use the diagnostic section in your app, found in the bottom of
the home screen, to see detailed information of the reported error.
Bike movement, vehicle location/GPS
Your bike is equipped with satellite location tracking. The location is repor-
ted via cellular connection and forwarded to your app. The tracking unit has
a backup battery installed that will ensure location is collected and reported
even if you remove the main battery.
Keep in mind that this backup battery is limited and to ensure continued
operation of the tracking functionality please connect the main battery once a
week and keep it connected for at least an hour (for example during a ride).
NOTE: Satellite tracking requires a clear view of the sky and that the bike
cannot report an accurate location if it’s parked in an underground garage for
example. The app will always tell you when your location shown in the app
was collected.
Activate alarm
Your bike is equipped with a movement activated alarm. The bike is delivered
with the alarm functionality turned o and you can activate it in the app under
“Bike Settings”. Access bike settings by pressing the bike on the home screen.
Trigger alarm and play sound
You can use the “Trigger Alarm” functionality in the map view to manually trig-
ger the alarm on the bike - if you e.g. suspect your bike has been stolen.
Using the “Play sound” feature available in the map view you can use the
alarm buzzer to trigger a sound that e.g. lets you identify the bike in a crow-
ded parking area.

20
Change cadence
To adjust the cadence of the bike, press the “Cadence” section on the home
screen.
Remote disable
Your bike is equipped with a feature to disable it remotely. It will use the cellu-
lar connection to disable the possibility to unlock the bike even using the keys.
Use this function if you e.g. suspect your bike has been stolen together with
the keys.
To access this function enter Bike settings and press “Remote disable”, use the
same method to enable it again.
NOTE: The function uses cellular connectivity to access the bike. This featu-
re will work even with the main battery removed as it relies on the tracking
module’s backup battery. Keep in mind that this backup battery is limited and
to ensure continued operation of the tracking functionality please connect
the main battery once a week and keep it connected for at least an hour (for
example during a ride).
Metric change on display
It is possible to change between Metric and Imperial measuring units in the
display. Use the app to change this setting under “Bike settings” available by
pressing the bike on the main page.
4. Riding
WARNING! Risk of personal injury.
• There is no foot brake, remember that you control both the front and rear
brakes from the handlebar. Left brake lever will engage the front wheel
and the right brake lever will engage the rear wheel.
• Risk of burns, stay clear of vehicle parts that are hot after usage.
• When activating walk assist be careful since you might accidentally push
the throttle down.
• Do not use the battery handle to lift the bike, it is only designed to be used
when carrying the battery.
