CalAmp Fusion User manual

FUSION™
HIGH-PERFORMANCE MULTI-BAND LTE ROUTER
User Manual
Fusion™High-Performance Multi-Band LTE Router
PN 001-0000-602 Rev. B
Revised November 2013

REVISION HISTORY
REV
DATE
REVISION DETAILS
0
April 2012
Initial release. Part number 001-0000-602.
1
June 2012
Updated based on user feedback.
2
March 2013
Updated to reflect new configuration settings and functionality and added model part
numbers, carriers, MIL-STD 810, and IEC 61000-4-2 (2009).
A
July 2013
Updated for Firmware version 1.1.7 with DeviceOutlook™.
B
November 2013
Updated for Firmware version 1.2.0: added SMS support for shoulder tap; added
enhancements for configuring and editing IPsec tunnels; provider modes are now auto-
selected in Carrier Settings for WWAN connections.

Fusion Multi-Network LTE Router PN 001-0000-602 Rev. B | Page i
Copyright Notice
© 2012-2013 CalAmp. All rights reserved.
CalAmp reserves the right to modify the equipment, its specification or this manual without prior notice, in the interest
of improving performance, reliability, or servicing. At the time of publication all data is correct for the operation of the
equipment at the voltage and/or temperature referred to. Performance data indicates typical values related to the
particular product. Product updates may result in differences between the information provided in this manual and the
product shipped. For access to the most current product documentation and application notes, visit www.calamp.com.
No part of this documentation or information supplied may be divulged to any third party without the express written
consent of CalAmp. Products offered may contain software which is proprietary to CalAmp. The offer or supply of these
products and services does not include or infer any transfer of ownership.
Modem Use
The Fusion routers are designed and intended for use in fixed and mobile applications. “Fixed” assumes the device is
physically secured at one location and not easily moved to another location. Please keep the cellular antenna at a safe
distance from your head and body while the modem is in use.
Important
Maintain a distance of at least 20 cm (8 inches) between the transmitter antenna and any person while in use. This
modem is designed for use in applications that observe the 20 cm separation distance.
Interference Issues
Avoid possible radio frequency (RF) interference by following these guidelines:
The use of cellular telephones or devices in aircraft is illegal. Use in aircraft may endanger operation and disrupt the
cellular network. Failure to observe this restriction may result in suspension or denial of cellular services to the
offender, legal action, or both.
Do not operate in the vicinity of gasoline or diesel fuel pumps unless use has been approved or authorized.
Do not operate in locations where medical equipment that the device could interfere with may be in use.
Do not operate in fuel depots, chemical plants, or blasting areas unless use has been approved and authorized.
Use care if operating in the vicinity of protected personal medical devices, i.e., hearing aids and pacemakers.
Operation in the presence of other electronic equipment may cause interference if equipment is incorrectly
protected. Follow recommendations for installation from equipment manufacturers.
Mobile Application Safety
Do not change parameters or perform other maintenance of the Fusion while driving.
Road safety is crucial. Observe National Regulations for cellular telephones and devices in vehicles.
Avoid potential interference with vehicle electronics by correctly installing the Fusion. Leveraging the FCC Modular
approval of the Cellular and WiFi module requires professional installation to avoid antenna correlation.
UL Listed models only
When operating at elevated temperature extremes, the surface may exceed +70 Celsius. For user safety, the
Fusion should be installed in a restricted access location.
WARNING —EXPLOSION HAZARD, do not connect while circuit is live unless area is known to be non-
hazardous.
For more information see APPENDIX C —UL Installation Instructions and Non-Incendive Field Wiring.

Fusion Multi-Network LTE Router PN 001-0000-602 Rev. B | Page ii
TABLE OF CONTENTS
1Product Overview ........................................................................................................................... 1
1.1 Module Identification ............................................................................................................................................1
1.2 Features and Benefits of the Fusion Multi-Network LTE Router ...........................................................................2
1.3 General Specifications............................................................................................................................................2
1.4 Mechanical Specifications......................................................................................................................................4
1.5 Order Information..................................................................................................................................................5
1.5.1 Accessories ...................................................................................................................................................5
1.6 External Connectors...............................................................................................................................................6
1.7 LEDs........................................................................................................................................................................8
1.7.1 Normal Power-Up Sequence ........................................................................................................................9
1.8 Antenna..................................................................................................................................................................9
2Getting Started.............................................................................................................................. 10
2.1 Package Contents.................................................................................................................................................10
2.2 Power Supply Connection ....................................................................................................................................10
2.3 Device Connections..............................................................................................................................................10
2.4 LAN Configuration................................................................................................................................................11
2.5 Log In....................................................................................................................................................................12
2.6 LTE Connection ....................................................................................................................................................13
3Fusion Web Interface.................................................................................................................... 15
3.1 Unit Status............................................................................................................................................................15
3.2 General Settings...................................................................................................................................................17
3.2.1 Unit ID.........................................................................................................................................................17
3.2.2 Unit Password.............................................................................................................................................18
3.2.3 Dynamic DNS ..............................................................................................................................................18
3.3 ETH0, ETH1, ETH2 (Ethernet 0, 1, and 2) .............................................................................................................20
3.3.1 Status ..........................................................................................................................................................20
3.3.2 IP Settings ...................................................................................................................................................22
3.3.3 Connection Manager ..................................................................................................................................24
3.3.4 Statistics......................................................................................................................................................26
3.4 GeminiG3 (ETH2)..................................................................................................................................................27
3.5 WiFi (Access Point)...............................................................................................................................................28
3.5.1 Status ..........................................................................................................................................................28
3.5.2 Wireless Settings.........................................................................................................................................29
3.5.3 IP Settings ...................................................................................................................................................31
3.5.4 Statistics......................................................................................................................................................32

Fusion Multi-Network LTE Router PN 001-0000-602 Rev. B | Page iii
3.6 WiFi (Client)..........................................................................................................................................................33
3.6.1 Status ..........................................................................................................................................................33
3.6.2 Wireless Settings.........................................................................................................................................35
3.6.3 IP Settings ...................................................................................................................................................37
3.6.4 Site Survey ..................................................................................................................................................38
3.6.5 Connection Manager ..................................................................................................................................38
3.6.6 Statistics......................................................................................................................................................40
3.7 WWAN0 / WWAN1 ..............................................................................................................................................41
3.7.1 Status ..........................................................................................................................................................41
3.7.2 Carrier Settings ...........................................................................................................................................44
3.7.3 IP Settings ...................................................................................................................................................45
3.7.4 Connection Manager ..................................................................................................................................47
3.7.5 Statistics......................................................................................................................................................48
3.8 Serial ....................................................................................................................................................................49
3.8.1 Status ..........................................................................................................................................................49
3.8.2 Serial Settings .............................................................................................................................................50
3.8.3 IP Settings ...................................................................................................................................................52
3.8.4 Statistics......................................................................................................................................................53
3.9 Router Settings.....................................................................................................................................................53
3.9.1 Interface Priority.........................................................................................................................................53
3.9.2 Application Routing ....................................................................................................................................54
3.9.3 Port Forwarding ..........................................................................................................................................55
3.9.4 MAC Filtering ..............................................................................................................................................57
3.9.5 IP Filtering ...................................................................................................................................................58
3.9.6 Static Routing..............................................................................................................................................61
3.9.7 Routing Table..............................................................................................................................................62
3.10 Security ................................................................................................................................................................63
3.10.1 IPsec............................................................................................................................................................63
3.10.2 HTTPS..........................................................................................................................................................66
3.10.3 RADIUS........................................................................................................................................................67
3.10.4 Security Policy.............................................................................................................................................68
3.11 Monitor & Control................................................................................................................................................69
3.11.1 Status ..........................................................................................................................................................69
3.11.2 SMS .............................................................................................................................................................70
3.11.3 SNMP ..........................................................................................................................................................71
3.11.4 NMEA..........................................................................................................................................................73
3.11.5 Power Management ...................................................................................................................................73
3.11.6 Monitoring ..................................................................................................................................................74
3.11.7 I/O Control ..................................................................................................................................................76
3.12 GPS .......................................................................................................................................................................77
3.12.1 Status ..........................................................................................................................................................77
3.12.2 AAVL Settings..............................................................................................................................................79

Fusion Multi-Network LTE Router PN 001-0000-602 Rev. B | Page iv
3.13 Maintenance ........................................................................................................................................................82
3.13.1 Status ..........................................................................................................................................................82
3.13.2 Firmware.....................................................................................................................................................83
3.13.3 WWAN Firmware ........................................................................................................................................84
3.13.4 Hardware ....................................................................................................................................................85
3.13.5 Unit Configuration ......................................................................................................................................86
3.13.6 DeviceOutlook™..........................................................................................................................................87
3.13.7 System Log ..................................................................................................................................................89
3.13.8 USB Log .......................................................................................................................................................90
APPENDIX A —Abbreviations and Definitions ................................................................................... 91
APPENDIX B —Mechanical Specifications.......................................................................................... 93
APPENDIX C —UL Installation Instructions and Non-Incendive Field Wiring .................................... 98
APPENDIX D —Firmware Upgrades ................................................................................................. 100
Procedure for upgrading Fusion router firmware.........................................................................................................102
Procedure for upgrading cell module firmware in the Fusion router...........................................................................103
APPENDIX E —WiFi Concurrent Configuration as Access Point and Client ..................................... 107
WiFi Concurrent Mode..................................................................................................................................................107
WiFi Nonconcurrent Mode –Client Mode....................................................................................................................108
WiFi Nonconcurrent Mode –Access Point Mode.........................................................................................................109
APPENDIX F —Using IPsec to Create IP Persistence ......................................................................... 110
1. The Problem With Multiple WANs ............................................................................................................................110
2. IPsec Tunnel...............................................................................................................................................................111
3. Advantages of Using IPsec.........................................................................................................................................114
APPENDIX G —Service And Support And Warranty Statement....................................................... 115
Warranty Statement .....................................................................................................................................................116

Fusion Multi-Network LTE Router PN 001-0000-602 Rev. B | Page 1
1PRODUCT OVERVIEW
Fusion offers a single, flexible platform to address a variety of wireless communications needs with over-the-air
configuration and system monitoring for optimal connectivity. This ready-to-deploy broadband router enables wireless
data connectivity over public and private LTE cellular networks at 4G speeds.
For the ultimate in versatility, the Fusion provides high-speed 4G LTE public safety band 14 broadband connectivity for
private infrastructure as well as 700 MHz Band 13 or 17 and 1700/2100 MHz AWS Band 4 (with 3G EV-DO/HSPA
fallback modes) based on 3GPP Standard E-UTRA Release 8 technologies. Three Ethernet ports support LAN
configurations that provide for the unique requirements of third-party VPN middleware providers.
An optional 802.11 b/g/n WiFi interface access point and client operations supports connectivity to IP applications in a
variety of different connection scenarios. Dual USB 2.0 host interfaces are provided to support Serial IP communication
(using the supported USB to RS-232 Converter cable accessory) and writing event log files to a USB flash drive.
Anticipated future uses include connection of other optional USB peripherals such as ZigBee or Bluetooth adapters.
The Fusion includes an easy to use web-based management and configuration interface, and comprehensive remote
management facilities are available. Cellular/WiFi/Ethernet rule-based and application port-based switching enables IP
control such as segregating traffic specific to designated bearer networks and choosing the WAN fallback order. The
Fusion aggregates WANs, including CalAmp’s narrowband technology, making it a powerful and unique enabler of
interoperable network technologies.
The Fusion includes an IP router that facilitates traffic routing between all of the concurrently operating networks. The
integrated router simplifies installation cabling requirements by requiring only a single cable connection with onboard
computing equipment, and offloading routing processor burdens and setup complexities. The Fusion fully integrates
with CalAmp Gemini narrowband equipment to extend their functionality to include LTE connectivity and access
additional Fusion peripherals.
1.1 MODULE IDENTIFICATION
The module identification label can be found on the bottom of your Fusion device. This label contains the product part
number, the serial number, FCC and IC IDs as well as carrier specific information that will be required when activating
your data account. The following is a sample portrayal of the identification label; identifiers and their placement will
vary depending on model and installed options, and actual bar-coded numbers on each unit will differ.
Figure 1 Fusion identification label example

Fusion Multi-Network LTE Router PN 001-0000-602 Rev. B | Page 2
1.2 FEATURES AND BENEFITS OF THE FUSION MULTI-NETWORK LTE ROUTER
Band 13, 17 or 4 LTE for public infrastructure
Support for Band 12 or 14 LTE or where permitted (Band 14 pending FCC certification) for private or commercial
infrastructure
Supports dual cell modules for mixing public and private bands or multiple carriers
Superior RF performance with MIMO capabilities
Secure IPsec VPN connectivity, HTTPS, and RADIUS
Autonomous WAAS enabled GPS with local and host reporting
Supports Dynamic or Static WAN IP
Inbound and Outbound Ethernet Routing
DHCP Server and Inbound port mapping/translation (Port Forwarding)
Firewall configuration for increased network security
Diversity antenna port/auxiliary port for increased receive sensitivity for dual cell module
Local or remote configuration using HTML web server
Inbound IP termination with Static IP
Persistent Domain Names with Dynamic DNS
Ethernet and WiFi ports support LAN and WAN operation
Dual SIM card slot, support multiple carrier contracts
USB and digital/analog I/O for external devices
Housed in a rugged metal chassis, Fusion meets MIL-STD-810F certification (for dry heat and cold storage and
operation, cold start, humidity, random vibration, and mechanical shock) and IEC 61000-4-2 (2009) for electrostatic
discharges
CalAmp DeviceOutlook remote management service, built on the solid, proven performance of the COLT (CalAmp
On-Line Telemetry) platform and CalAmp Enterprise Services (CES)
1.3 GENERAL SPECIFICATIONS
Product specifications are subject to change without notice.
General
Input Voltage
10 to 30 VDC
Power Consumption
Single Cellular Module and GPS
Rx: 5.5W (no WiFi); 7.7W with WiFi
Tx: 9.1W (no WiFi); 13.0W with WiFi
Dual Cellular Modules and GPS
Rx: 5.8W (no WiFi); 10W with WiFi
Tx: 14W (no WiFi); 16.9W with WiFi
LTE Diversity Support
DL MIMO, UL SISO
Security
3GPP Rel 8 security sublayer, IPsec IKEv1 and IKEv2 VPN tunnel termination, HTTPS,
and RADIUS
Carrier Approvals
Verizon Wireless, VTEL, PTCRB certified for AT&T
Certifications
FCC Part 15 Subpart B Class A, IC ICES-003
MIL-STD 810F (dry heat and cold storage and operation, cold start, humidity, random
vibration, and mechanical shock), IEC 61000-4-2 (2009) electrostatic discharges
Connectors/Interface
Antenna connectors and LED indicators vary with device model (installed options)
Device Management
SNMP, embedded HTTP server for setup and help, DeviceOutlook

Fusion Multi-Network LTE Router PN 001-0000-602 Rev. B | Page 3
LED Indicators
POWER, STATUS, ETH0, ETH1, ETH2, GPS, WWAN0, WWAN1 (with dual radio option),
WiFi (when equipped with WiFi option)
Power
4-pin locking, ignition sense and alarm inputs
Console/Setup
3-wire serial connection in USB Mini-B form factor
Ethernet
(3) 10/100 Mbps RJ-45, auto MDIX, Auto-negotiation
USB
(2) Type A female
I/O
2 digital I/O, 2 analog inputs,
2 outputs (relay driven contact closures)
Antenna
(3) SMA-RP (802.11 b/g/n WiFi, optional)
(2) SMA (cellular) WWAN0 (single or dual radio)
(2) SMA (cellular) WWAN1 (dual radio option only)
(1) SMA (GPS)
Mechanical/Environmental
Dimensions
1.9 in. (4,8 cm) height × 6.0 in (15,3 cm) width × 5.5 in. (14 cm) depth
Weight
2.5 lb. (1,13 kg)
Temperature Range
-22° to +158° F (-30° to +70° C)
Humidity
5% to 95% non-condensing
LTE Technology/Bands
Supported bands vary with device model.
Band 14
700 MHz “D” Block DL MIMO, UL SISO
Band 13
700 MHz DL MIMO, UL SISO
Band 17
700 MHz DL MIMO, UL SISO
Band 4
1700/2100 MHz AWS DL MIMO, UL SISO
CDMA Technology/Bands
Supported bands vary with device model.
EVDO Rev A (IS-856-A)
800 MHz Cellular/1900 MHz PCS
Downlink 3.1 Mbps; Uplink 1.8 Mbps
1xEVDO Rev 0 (IS-856)
800 MHz Cellular/1900 MHz PCS
Downlink 2.4 Mbps; Uplink 153.6 kbps
1xRTT (IS-2000)
800 MHz Cellular/1900 MHz PCS
Downlink 153.6 kbps; Uplink 153.6 kbps
GSM Technology/Bands
Supported bands vary with device model.
UMTS/HSPA
850/900, 1800/1900, 2100 MHz
Downlink 7.2 Mbps, Uplink 2.0 Mbps
EDGE/GPRS
Quad-band 850/900, 1800/1900 MHz
Downlink 236 kbps, Uplink 236 kbps
WiFi Technology/Bands
IEEE 802.11 b/g/n
32 bit mPCI type lllA high power/performance WiFi
Security
WPA-PSK (TKIP encryption), WPA2-PSK (CCMP encryption), 64-bit/128 bit WEP
encryption, WPA Enterprise and WPA2-Enterprise
Data Rates
802.11b: up to 11Mbps
802.11g: up to 54Mbps
802.11n: up to 144Mbps

Fusion Multi-Network LTE Router PN 001-0000-602 Rev. B | Page 4
1.4 MECHANICAL SPECIFICATIONS
The following table and figure show overall dimensions of the chassis of the Fusion Multi-Network LTE Router.
Dimensioned drawings of the chassis with mounting options (bracket, mounting plate, or DIN rail mount) are provided
in APPENDIX B. The drawings and associated data may be used for layout reference, but it is advised that a physical
comparison be made to the unit and bracket before laying out and drilling any holes.
Table 1 Fusion chassis overall dimensions
Dimension
Inches
Centimeters
Height
1.90
4,83
Width
6.00
15,2
Depth
(Overall)
5.50
14,0
Depth
(Chassis only)
5.28
13,4
Figure 2 Fusion router Mechanical Drawing
Figure 3 Side tapped mounting hole location detail —typical
both sides.
#8-32 UNC –2B thread × 0.30 in. (0,76 cm) depth
2 holes for mounting both sides (4 holes total).
Figure 4 Tapped mounting hole location detail —top only.
#6-32 UNC –2B thread × 0.12 in. (0,30 cm) depth
4 holes for mounting (top surface only).
