CALEFFI 161010 User manual

*11211952* 11211952
Thank you for buying this product.
Please read this manual carefully to get the best performance from this unit. Please keep this manual safe.
Manual
en
Heating controller
Manual for the
specialised craftsman
Installation
Operation
Troubleshooting
Digital controller with system representation 161010
Please read this manual carefully to get the best performance from this unit. Please keep this manual safe.

2
en
© 20170606_11211952_Calef_Nuovo_161.monen
Safety advice
Please pay attention to the following safety advice in order to avoid danger and
damage to people and property.
Instructions
Attention must be paid to the valid local standards, regulations and directives!
Information about the product
Proper usage
The heating controller is designed for controlling single-circuit heating circuits and/
or single-circuit cooling systems in compliance with the technical data specied in
this manual.
Improper use excludes all liability claims.
CE-Declaration of conformity
The product complies with the relevant directives and is therefore
labelled with the CE mark. The Declaration of Conformity is available
upon request, please contact the manufacturer.
Note:
Strong electromagnetic elds can impair the function of the controller.
ÎMake sure the controller as well as the system are not exposed to
strong electromagnetic elds.
Subject to technical change. Errors excepted.
Target group
These instructions are exclusively addressed to authorised skilled personnel.
Only qualied electricians should carry out electrical works.
Initial installation must be effected by the system owner or qualied personnel
named by the system owner.
Description of symbols
WARNING! Warnings are indicated with a warning triangle!
ÎThey contain information on how to avoid the danger
described.
Signal words describe the danger that may occur, when it is not avoided.
• WARNING means that injury, possibly life-threatening injury, can occur.
• ATTENTION means that damage to the appliance can occur.
Note:
Notes are indicated with an information symbol.
ÎArrows indicate instruction steps that should be carried out.
Disposal
• Dispose of the packaging in an environmentally sound manner.
• Dispose of old appliances in an environmentally sound manner. Upon request we
will take back your old appliances bought from us and guarantee an environmen-
tally sound disposal of the devices.

3
en
Heating controllers
The heating controller is designed for controlling single-circuit heating circuits
and / or single-circuit cooling systems.
Contents
1 Overview .............................................................................................. 4
2 Installation ........................................................................................... 5
2.1 Mounting.........................................................................................................................5
2.2 Electrical connection....................................................................................................5
3 Operation and function ...................................................................... 6
3.1 Buttons and adjustment dial.......................................................................................6
3.2 Adjustment values and user code.............................................................................6
3.3 Control LED ..................................................................................................................7
4 Systems ................................................................................................ 7
5 Indications, functions and options.................................................... 10
5.1 Home screen .............................................................................................................. 10
5.2 Display values ..................................................................................... 11
5.3 Warning messages ............................................................................. 11
5.4 Conguration.............................................................................................................. 12
5.5 Balance values .................................................................................... 16
5.6 Manual mode............................................................................................................... 16
6 Application example ......................................................................... 18

4
en
1 Overview
110
166 130
47
Technical data
Inputs: 3 inputs for Pt1000 temperature sensors, 1 Grundfos Direct Sensor™
(analogue), 1 input for a room thermostat, 1 input for a dew point switch, 1 poten-
tial-free switch
Outputs: 3 semiconductor relays, 1 potential-free extra-low voltage relay, 1 PWM
output
PWM frequency: 512 Hz
PWM voltage: 10.8 V
Switching capacity: 1 (1) A 240 V~ (semiconductor relay),
1 (1) A 30 V DC (potential-free relay)
Total switching capacity: 4 A 240 V~
Power supply: 100 … 240 V~ (50 … 60 Hz)
Supply connection: type Y attachment
Power consumption < 1 W
Mode of operation: type 1.B.C.Y action
Rated impulse voltage: 2.5 kV
Data interface: VBus®
VBus®current supply: 60 mA
Housing: plastic, PC-ABS and PMMA
Mounting: wall mounting, also suitable for mounting into patch panels
Indication / Display: full graphic display, control lamp (Lightwheel®) and back-
ground illumination
Operation: 2 push buttons at the front and 1 adjustment dial (Lightwheel®)
Protection type: IP 20 / EN 60529
Protection class: I
Ambient temperature: 0 … 40 °C
Degree of pollution: 2
Dimensions: 110 x 166 x 47 mm
Upper fastening
Lower fastening

5
InstallationIndications, functions and options Operation and function en
2 Installation
2.1 Mounting
WARNING! Electric shock!
Upon opening the housing, live parts are exposed!
ÎAlways disconnect the device from power supply
before opening the housing!
Note:
Strong electromagnetic elds can impair the function of the controller.
ÎMake sure the controller as well as the system are not exposed to
strong electromagnetic elds.
The unit must only be located in dry interior rooms.
The controller must additionally be supplied from a double pole switch with contact
gap of at least 3 mm.
Please pay attention to separate routing of sensor cables and mains cables.
In order to mount the device to the wall, carry out the following steps:
ÎUnscrew the crosshead screw from the cover and remove it along with the
cover from the housing.
ÎMark the upper fastening point on the wall. Drill and fasten the enclosed wall
plug and screw leaving the head protruding.
ÎHang the housing from the upper fastening point and mark the lower fastening
point (centres 130 mm).
ÎInsert lower wall plug.
ÎFasten the housing to the wall with the lower fastening screw and tighten.
ÎCarry out the electrical wiring in accordance with the terminal allocation (see
chapter 2.2).
ÎPut the cover on the housing.
ÎAttach with the fastening screw.
2.2 Electrical connection
WARNING! Electric shock!
Upon opening the housing, live parts are exposed!
ÎAlways disconnect the device from power supply
before opening the housing!
ATTENTION! ESD damage!
Electrostatic discharge can lead to damage to electronic com-
ponents!
ÎTake care to discharge properly before touching the
inside of the device! To do so, touch a grounded sur-
face such as a radiator or tap!
Note:
Connecting the device to the power supply must always be the last step
of the installation!
The controller is supplied with power via a mains cable. The power supply of the
device must be 100 … 240 V~ (50 … 60 Hz).
The controller is equipped with 4 relays in total, to which loads such as pumps,
valves, etc. can be connected:
• Relays 1 … 3 are semiconductor relays:
Conductor R1 … R3
Neutral conductor N
Protective conductor ⏚
• Relay 4 is a potential-free extra-low voltage relay
Depending on the product version, mains cables and sensor cables are already con-
nected to the device. If that is not the case, please proceed as follows:
Connect the temperature sensors (S1 to S3) to the following terminals with
either polarity:
S1 = Sensor 1 (outdoor temperature sensor)
S2 = Sensor 2 (heating circuit ow)
S3 = Sensor 3 (e. g. return sensor)
Connect the remote control (if used in the system selected) to the S3 / RTA12
input with either polarity.
Connect the room thermostat to the TA input with either polarity.
Connect the dew point switch (if used in the system selected) to the S5/ TS10
input with either polarity.

6
Installation Indications, functions and optionsOperation and function
en
Connect the RPS Grundfos Direct Sensor™ (pressure sensor) to the input S6.
S7 can be used as an input for a potential-free switch for the cooling mode.
Pins 2 and 3 come with a pluggable cable link already connected. If the contact is
closed (cable link connected), the heating mode will be active when demanded. If
the contact is open (cable link not connected) and the cooling option is activated,
the cooling mode will be active when demanded.
In order to connect a switch, cut the cable link and connect the switch to both
wires.
The terminal marked PWM A is the control output for a high-ef ciency pump.
If the Central Outdoor Sensor is to be used, connect it to the terminals marked
VBus with either polarity.
VBus
VBus
TA
S3 RTA12
S5 TS10
GND
Sensors
S2 S1
100 ... 240V
T4A
50-60 Hz
N
R3 R2 R1
L
R1-R3|1 (1) A 240 V~R4|1 (1) A 30V
IP 20
R4
PWM A
R4
Manufactured
by RESOL - TYPE SLT
Heiskampstr. 10
D-45527 Hattingen
S6
S7
161010
AX
AX
The mains connection is at the terminals:
Neutral conductor N
Conductor L
Protective conductor ⏚
ÎUse a cable with a cross section of at least 0.75 mm² of the H05VV-F type for
connecting the device to the mains.
Note:
The connection depends on the system layout selected (see page 7).
The auxiliary terminals can be used instead of R4 as the mixer switch for the heat
generator, if a voltage higher than 30 V is applied.
Antifreeze: Standard function – if the temperature at S2 falls below 7 °C , the con-
troller activates the pump for 30 min, in order to reach 20 °C.
Outdoor sensor: If the outdoor temperature sensor is defective, 0 °C is used as
the reference value.
3 Operation and function
3.1 Buttons and adjustment dial
The controller is operated via 2 buttons and 1 adjustment dial (Lightwheel®) below
the display:
Left button (⟲) - escape button for changing into the previous menu
Right button (✓) - con rming / selecting
Lightwheel® - scrolling upwards / scrolling downwards, increasing adjustment
values / reducing adjustment values
3.2 Adjustment values and user code
Adjustment values will only be available if the correct user code has been entered.
In order to access the user code enquiry from the home screen, press the right
button (✓) for approx. 3 s.
User code: 0322
If the user code has been entered, the adjustment values menu will be displayed.
In order to get back to the home screen, press the left button (⟲).
If no button is pressed for 5 min, the controller will display the home screen.
Note:
The user code has to be entered again each time you wish to access the
adjustment values menu.

7
InstallationIndications, functions and options Operation and function en
3.3 Control LED
The controller is equipped with a multicolour LED in the centre of the Lightwheel®,
indicating the following states:
Colour Permanently shown Flashing
Green Everything OK Manual mode: at least one relay in manual
mode (Off, Max or Min)
Yellow PMin has fallen below the threshold, TMax
exceeded by up to 5 K überschritten
Red Sensor fault, safety shutdown active, TMax
exceeded by > 5 K
4 Systems
System 1 (fl ow temperature controlled heating with optional effi ciency
control of the heat exchange – fl ow controlled cooling)
Flow
Return
R2 = open
R3 = closed R1 S3 (optional)
S2
The controller monitors the room thermostat (TA).
If the room thermostat demands heat, the pump (R1) starts and R4 is energised for
the heating demand.The temperature at S2 is monitored.The mixer is controlled so
that the adjusted temperature Tset is reached and maintained at S2.
If the TFcalculated option (return temperature monitoring S3, factory setting =
active) is activated, the controller runs a heat demand-based calculation of the set
 ow temperature needed for keeping the system at the optimum temperature. For
this purpose, the return temperature (S3) is monitored. The calculated set  ow
temperature is displayed as TFset..
The controller is equipped with a non-adjustable safety shutdown function. If the
temperature at S2 reaches or exceeds 90 °C, the mixer closes. The warning symbol
⚠appears on the screen and the Lightwheel®  ashes yellow. If the temperature
at S2 reaches or exceeds 95 °C,R1 and R4 switch off. The Lightwheel®  ashes red.
If the TMax option is activated, the value for the safety shutown function can be
reduced. If the temperature at S2 exceeds TMax by less than 5 K, the warning sym-
bol ⚠appears on the screen and the Lightwheel®  ashes yellow. If the temperature
at S2 exceeds TMax by more than 5 K, R1 and R4 switch off. The Lightwheel®
 ashes red.
If the Cooling option is activated, the mixer is controlled so that the adjusted
cooling temperature TCool is reached and maintained at S2.The S7 contact can be
used for connecting a switch for remotely controlling the heating / cooling mode.
Contact open = cooling mode
Contact closed = heating mode
If the Condensation option is activated, the controller monitors a dew point
switch. If the dew point switch triggers an alarm, cooling stops and the warning
symbol is indicated. If the humidity falls again below the adjusted value, the cooling
mode continues.
Terminal allocation
S1 = outdoor temperature sensor
S2 = heating circuit  ow
S3/RTA12 = return sensor (optional)
TA = room thermostat
S5/TS10 = dew point switch (optional)
S6 = RPS Grundfos Direct Sensor™ pressure sensor (optional)
S7 = contact for remotely controlling the heating / cooling mode (optional)
R1 = pump
R2 = mixer open
R3 = mixer closed

8
Installation Indications, functions and optionsOperation and function
en
R4 = demand contact of the heat generator (potential-free extra-low voltage
relay). If the voltage at the contact used is higher than 30 V, use the
auxiliary terminals at the 230 V side for the mixer.
PWM 1 = R1 speed signal, prole selectable
Adjustment and balance values menu system 1
Factory
setting
Range Description
System 1 1, 2 System selection
Tset 40 °C 15 °C … 90 °C Set ow temperature
TFcalculated Ye s Yes, No Heat demand-based set ow temperature
calculation option
TMin No Yes, No Minimum temperature heating circuit option
TMin 25 °C 15 °C … 40 °C Minimum temperature heating circuit
TMax Ye s Yes, No Maximum temperature heating circuit option
TMax 50 °C 30 °C … 90 °C Maximum temperature heating circuit
tLimit 5 min 1 … 30 min Time for which the calculated set ow tem-
perature is to be used
Cooling No Yes, No Cooling option
TCool 16 °C 5 °C … 25 °C Cooling temperature
Condensat. Ye s Yes, No Dew point switch (DPS) option
Chiller on No Yes, No Cooling demand on option
Pressure No Yes, No Low pressure monitoring option
PMin 0.6 bar 0.2 … 10.0 bar Switch-on threshold low pressure monitoring
tMixer 75 s 30 … 240 s Mixer runtime
Corr.tMixer 90 s 5 … 300 s Surplus mixer runtime when the mixer is
closing
tPLAY 4 s 1…15 s Mixer control time for change of ow
direction
Block. prot. Ye s Yes, No Blocking protection option
PWM Heating Heating, Solar PWM prole PWM A
Slab drying - - Slab drying submenu
TStart 20 °C 10 °C … 30 °C Slab drying start temperature
TMax 45 °C 20 °C … 60 °C Slab drying holding temperature
Rise 5 K 1 … 10 K Slab drying rise value
Rise time 24 h 1 … 24 h Slab drying rise time
tBacking 7 d 1 … 20 d Slab drying holding time
Factory
setting
Range Description
Start - Start, Cancelled Activation / Deactivation slab drying
Language Italiano Deutsch, English,
Francais, Italiano
Language selection
Reset No Yes, No back to factory settings
Operation - 0 … 9999 Operating days of the controller (balance val-
ue, cannot be set back to zero)
Pump - 0 … 9999 Balance values, can be set back to zero (see
page 16)
Mixer open - 0 … 9999
Mixer closed - 0 … 9999
Backup heating - 0 … 9999
Max. S1 - max. 999.9 °C
Max. S2 - max. 999.9 °C
Max. S3 - max. 999.9 °C
Min. press. - 0.0 … 10.0 bar
Max. press. - 0.0 … 10.0 bar
Version - - Display of software version
All relays Auto Auto, Off Operating modes of all relays
Man. 1 Auto On, Auto, Off Manual mode relay 1
Man. 2,3 Auto Mixer closed, Auto,
Mixer open, Off
Manual mode relay 2,3
Man. 4 Auto On, Auto, Off Manual mode relay 4
back

9
InstallationIndications, functions and options Operation and function en
System 2 (weather-compensated heating – ow temperature controlled cooling)
R2 = open
R3 = closed
Flow
Return
R1
S2
S1
The controller monitors the room thermostat (TA).
If the room thermostat demands heat, the pump (R1) starts and R4 is energised for
the heating demand.The temperature at S2 is monitored.
The controller calculates the set ow temperature by means of the outdoor tem-
perature (S1) and the selected heating curve. The mixer is controlled so that the
calculated set ow temperature is reached and maintained at S2.
The controller is equipped with a non-adjustable safety shutdown function. If the
temperature at S2 reaches or exceeds 90 °C, the mixer closes. The warning symbol
⚠appears on the screen and the Lightwheel® ashes yellow. If the temperature
at S2 reaches or exceeds 95 °C,R1 and R4 switch off. The Lightwheel® ashes red.
If theTMax option is activated, the value for the safety shutown function can be
reduced. If the temperature at S2 exceeds TMax by less than 5K, the warning symbol
⚠appears on the screen and the Lightwheel® ashes yellow. If the temperature at S2
exceeds TMax by more than 5 K, R1 and R4 switch off. The Lightwheel® ashes red.
If the Cooling option is activated, the mixer is controlled so that the adjusted
cooling temperature TCool is reached and maintained at S2.The S7 contact can be
used for connecting a switch for remotely controlling the heating / cooling mode.
Contact open = cooling mode
Contact closed = heating mode
If the Condensation option is activated, the controller monitors a dew point
switch. If the dew point switch triggers an alarm, cooling stops and the warning
symbol is indicated.
Terminal allocation
S1 = outdoor temperature sensor
S2 = heating circuit ow
S3/RTA12 = return sensor or remote control (optional)
TA = room thermostat
S5/TS10 = dew point switch (optional)
S6 = RPS Grundfos Direct Sensor™ pressure sensor (optional)
S7 = contact for remotely controlling the heating / cooling mode (optional)
R1 = pump
R2 = mixer open
R3 = mixer closed
R4 = demand contact of the heat generator (potential-free extra-low volt-
age relay). If the voltage at the contact used is higher than 30 V, use the
auxiliary terminals at the 230 V side for the mixer.
PWM 1 = R1 speed signal, prole selectable
Adjustment and balance values menu system 2
Factory
setting
Range Description
System 1 1, 2 System selection
Curve 0.8 0.3 … 3.0 Heating curve
TMin Ye s Yes, No Minimum temperature heating circuit option
TMin 25 °C 15 °C … 40 °C Minimum temperature heating circuit
TMax Ye s Yes, No Maximum temperature heating circuit option
TMax 50 °C 30 °C … 90 °C Maximum temperature heating circuit
Remote control No Yes, No Remote control option
Cooling No Yes, No Cooling option
TCool 16 °C 5 °C … 25 °C Cooling temperature
Condensat. Ye s Yes, No Dew point switch (DPS) option
Chiller on No Yes, No Cooling demand on option
Pressure No Yes, No Low pressure monitoring option
PMin 0.6 bar 0.2 … 10.0 bar Switch-on threshold low pressure monitoring
tMixer 75 s 30 … 240 s Mixer runtime

10
Installation Indications, functions and optionsOperation and function
en
5 Indications, functions and options
Note:
The display and adjustment channels as well as the adjustment ranges de-
pend on the system selected, the functions and options as well as on the
system components connected to the controller.
5.1 Home screen
The home screen is a graphic representation of the current system state.
The following indications are possible:
Standby mode
The room thermostat does not demand heating / cooling.
Heating mode in system 1 with return temperature monitoring
The room thermostat demands heat, TFcalculated = Yes.
Heating mode in system 1 without return temperature monitoring
The room thermostat demands heat, TFcalculated = No.
Factory
setting
Range Description
Corr.tMixer 90 s 5 … 300 s Surplus mixer runtime when the mixer is
closing
tPLAY 4 s 1 … 15 s Mixer control time for change of  ow
direction
Block. prot. Ye s Yes, No Blocking protection option
PWM Heating Heating, Solar PWM pro le PWM A
Slab drying - - Slab drying submenu
TStart 20 °C 10 °C … 30 °C Slab drying start temperature
TMax 45 °C 20 °C … 60 °C Slab drying holding temperature
Rise 5 K 1 … 10 K Slab drying rise value
Rise time 24 h 1 … 24 h Slab drying rise time
tBacking 7 d 1 … 20 d Slab drying holding time
Start - Start, Cancelled Activation / Deactivation slab drying
Language Italiano Deutsch, English,
Francais, Italiano
Language selection
Reset No Yes, No back to factory settings
Operation 0 0 … 9999 Operating days of the controller (balance
value, cannot be set back to zero)
Pump - 0 … 9999 Balance values, can be set back to zero (see
page 16)
Mixer open - 0 … 9999
Mixer closed - 0 … 9999
Backup heating - 0 … 9999
Max. S1 - max. 999.9 °C
Max. S2 - max. 999.9 °C
Max. S3 - max. 999.9 °C
Min. press. - 0.0 … 10.0 bar
Max. press. - 0.0 … 10.0 bar
Version - - Display of software version
All relays Auto Auto, Off Operating modes of all relays
Man. 1 Auto On, Auto, Off Manual mode relay 1
Man. 2,3 Auto Mixer closed,
Auto, Mixer
open, Off
Manual mode relay 2,3
Man. 4 Auto On, Auto, Off Manual mode relay 4
back

11
InstallationIndications, functions and options Operation and function en
Cooling mode in system 1
The room thermostat demands cold.
Heating mode in system 2
The room thermostat demands heat, the outdoor temperature is indicated.
Cooling mode in system 2
The room thermostat demands cold, the outdoor temperature is indicated.
5.2 Display values
In order to access the display values from the home screen, brie y press the right
button (✓).
5.3 Warning messages
TMax is exceeded.
Pressure has fallen below PMin.
Sensor fault warning message
Sensor cable broken or short-circuit.
Dew point switch warning message
The dew point switch has detected condensation, the cooling mode is interrupted.

12
Installation Indications, functions and optionsOperation and function
en
100
90
80
70
60
50
40
30
20
-20 -15 -10 -5 0510 15
20
1,0
0,9
1,2
1,5
1,8
2,1
0,8
0,6
0,3
TMin
Minimum temperature heating circuit option
5.4 Confi guration
In order to access the adjustment values from the home screen, press the right
button (✓) for approx. 3 s and enter the user code (see page 6).
Tset
Set  ow temperature
TFcalculated
Heat demand-based set  ow temperature calculation option
TFset
Display value: calculated set  ow temperature
Curve
Heating curve

13
InstallationIndications, functions and options Operation and function en
TMin
Minimum temperature heating circuit
TMax
Maximum temperature heating circuit option
TMax
Maximum temperature heating circuit
tLimit
Time for which the calculated set  ow temperature is to be used
Remote control
Remote control option
Cooling
Cooling option
TCool
Cooling temperature
Condensat.
Dew point switch (DPS) option

14
Installation Indications, functions and optionsOperation and function
en
Corr.tMixer
Surplus mixer runtime when the mixer is closing
tPLAY
Mixer control time for change of  ow direction
Block. prot.
Blocking protection option
PWM
PWM pro le selection
Chiller on
Cooling demand on, if the dew point switch detects condensation (only if Conden-
sation = Yes)
Pressure
Low pressure monitoring option
PMin
Switch-on threshold low pressure monitoring
tMixer
Mixer runtime

15
InstallationIndications, functions and options Operation and function en
Slab drying
Slab drying submenu
TStart
Start temperature
TMax
Holding temperature
Rise
Rise value
Rise time
Rise duration
tBacking
TMax holding time
Start
Activation / Deactivation of the slab drying
Language
Selection of the menu language

16
Installation Indications, functions and optionsOperation and function
en
Reset
Reset to factory settings
5.5 Balance values
Operation
Operating hours counter
Pump, Mixer open, Mixer closed, Backup heat.
Operating hours counter of the relays
Max. S1 (2, 3)
Maximum temperature at the corresponding sensor
Min. press., Max. press.
Minimum and maximum pressure
The balance values can be set back to zero. In order to reset a value, proceed as
follows:
ÎSelect the desired value and press the right button (✓).
Does the security enquiry Delete? appear?
ÎTurn the Lightwheel®clockwise.
Ye s instead of No will be displayed.
ÎCon rm your selection with the right button (✓).
The value will be set back to zero.
In order to interrupt this process, press the left button (⟲).
5.6 Manual mode
All relays
Operating modes of all relays

17
InstallationIndications, functions and options Operation and function en
Man. 1 (4)
Manual mode of the relays 1 and 4
For control and service work, the operating mode of the relays can be manually
adjusted.
• On Relay on
• Auto Relay in automatic operation
• Off Relay off
Man. 2,3
Manual mode of the mixer
For control and service work, the operating mode of the mixer can be manually
adjusted.
• Mixer open Relay 2 on, Relay 3 off
• Auto Relays 2 and 3 in automatic operation
• Mixer closed Relay 2 off, Relay 3 on
• Off Relays 2 and 3 off
Note:
Always adjust the operating mode back to Auto when the control and
service work is completed. Normal operation is not possible in manual
mode.

18
en
VBus
VBus
TA
S3 RTA12
S5 TS10
GND
Sensors
S2 S1
100 ... 240V
T4A
50-60 Hz
N
R3 R2 R1
L
R1-R3|1 (1) A 240 V~R4|1 (1) A 30V
IP 20
R4
PWM A
R4
Manufactured
by RESOL - TYPE SLT
Heiskampstr. 10
D-45527 Hattingen
S6
S7
161010
AX
AX
6 Application example
6
1 2 8
9
10
11 12 13
4
5
1Outdoor temperature sensor
2Heating circuit ow
3Return sensor (optional)
4Room thermostat
5Dew point switch (optional)
6Boiler demand when voltage < 30 V
7Central Outdoor Sensor
8RPS Grundfos Direct Sensor™ pressure sensor (optional)
9Contact for remotely controlling the heating / cooling
mode (optional)
10 Boiler demand when voltage > 30 V
11 Mixer closed
12 Mixer open
13 Pump
37

19
en
°C Ω
Pt1000
°C Ω
Pt1000
-10 961 55 1213
-5 980 60 1232
0 1000 65 1252
5 1019 70 1271
10 1039 75 1290
15 1058 80 1309
20 1078 85 1328
25 1097 90 1347
30 1117 95 1366
35 1136 100 1385
40 1155 105 1404
45 1175 110 1423
50 1194 115 1442
Short circuit or line break.
Disconnected temperature sensors can be checked with an ohmmeter. Please check
if the resistance values correspond with the table.

Distributed by: Distributed by
Calef S.p.A.
S.R. 229, no 25,
IT-28010 Fontaneto
d’Agogna (NO)
© All contents of this document are protected by copyright.
