OPERATOR'S MANUAL
AGC 150
Generators, Mains and BTB
4189341312A

1. Introduction
1.1 Symbols for hazard statements......................................................................................................................................................................................... 3
1.2 About the operator's manual...............................................................................................................................................................................................3
1.3 Warnings and safety.................................................................................................................................................................................................................4
1.4 Legal information.......................................................................................................................................................................................................................4
2. Getting started
2.1 About controller operation................................................................................................................................................................................................... 5
2.1.1 Display settings...................................................................................................................................................................................................................5
3. About the AGC 150 Generator
3.1 Display, buttons and LEDs................................................................................................................................................................................................... 6
3.2 Mimic function............................................................................................................................................................................................................................. 7
3.3 Running modes...........................................................................................................................................................................................................................8
3.4 Exhaust after-treatment (Tier 4/Stage V).......................................................................................................................................................................8
4. About the AGC 150 Mains
4.1 Display, buttons and LEDs................................................................................................................................................................................................. 11
4.2 Mimic function...........................................................................................................................................................................................................................12
4.3 Running modes........................................................................................................................................................................................................................ 12
5. About the AGC 150 BTB
5.1 Display, buttons and LEDs.................................................................................................................................................................................................13
5.2 Mimic function...........................................................................................................................................................................................................................14
5.3 Running modes........................................................................................................................................................................................................................ 14
6. Menus
6.1 Menu structure..........................................................................................................................................................................................................................15
6.2 Settings menu........................................................................................................................................................................................................................... 15
6.2.1 Menu numbers..................................................................................................................................................................................................................16
6.2.2 The jump to parameter function................................................................................................................................................................................ 16
6.3 View menu................................................................................................................................................................................................................................... 16
6.3.1 Display views.....................................................................................................................................................................................................................17
6.3.2 Display text.........................................................................................................................................................................................................................19
6.4 Status texts.................................................................................................................................................................................................................................20
6.5 Service view............................................................................................................................................................................................................................... 23
7. Alarm handling and log list
7.1 Alarm handling......................................................................................................................................................................................................................... 24
7.2 Logs menu.................................................................................................................................................................................................................................. 25
OPERATOR'S MANUAL 4189341312A EN Page 2 of 25

1. Introduction
1.1 Symbols for hazard statements
DANGER!
This shows dangerous situations.
If the guidelines are not followed, these situations will result in death, serious personal injury, and equipment damage or
destruction.
WARNING
This shows potentially dangerous situations.
If the guidelines are not followed, these situations could result in death, serious personal injury, and equipment damage
or destruction.
CAUTION
This shows low level risk situation.
If the guidelines are not followed, these situations could result in minor or moderate injury.
NOTICE
This shows an important notice
Make sure to read this information.
1.2 About the operator's manual
This document gives the necessary information to operate the controller.
CAUTION
Installation errors
Read this document before working with the AGC 150 controller. Failure to do this may result in human injury or damage
to the equipment.
Intended users of the operator's manual
The operator's manual is for the operator that uses the controller regularly.
The manual describes the LEDs, buttons and screens on the controller, alarm handling, and the logs menu.
OPERATOR'S MANUAL 4189341312A EN Page 3 of 25

1.3 Warnings and safety
Factory settings
The controller is delivered pre-programmed from the factory with a set of default settings. These settings are based on typical values
and may not be correct for your system. You must therefore check all parameters before using the controller.
Data security
To minimise the risk of data security breaches:
• As far as possible, avoid exposing controllers and controller networks to public networks and the Internet.
• Use additional security layers like a VPN for remote access, and install firewall mechanisms.
• Restrict access to authorised persons.
1.4 Legal information
Third party equipment
DEIF takes no responsibility for the installation or operation of any third party equipment, including the genset. Contact the genset
company if you have any doubt about how to install or operate the genset.
Warranty
NOTICE
Warranty
The controller is not to be opened by unauthorised personnel. If opened anyway, the warranty will be lost.
Disclaimer
DEIF A/S reserves the right to change any of the contents of this document without prior notice.
The English version of this document always contains the most recent and up-to-date information about the product. DEIF does not
take responsibility for the accuracy of translations, and translations might not be updated at the same time as the English document.
If there is a discrepancy, the English version prevails.
Copyright
© Copyright DEIF A/S. All rights reserved.
Software version
This document is based on the AGC 150 software version 1.10.0.
OPERATOR'S MANUAL 4189341312A EN Page 4 of 25

2. Getting started
2.1 About controller operation
The AGC 150 Generator controller contains all the functions needed to protect and control a genset, and the genset breaker. If you
do not use power management, the controller can also protect and control the mains breaker.
The AGC 150 Mains controller protects and controls a mains breaker, and a tie breaker.
The AGC 150 BTB controller protects and controls a bus tie breaker. The power management system manages the busbar sections.
Power management system
AGC 150 controllers can work together in a power management system (PMS). This includes synchronisation, island operation, and
running parallel to mains. The PMS can automatically start and stop gensets, and open and close breakers. You can also use AGC
150 in power management systems with other DEIF controllers.
Buttons and LEDs
Use the buttons to operate the system. You can change running modes, stop alarms, see the shortcut menu, and navigate the
controller. You can only use the start and stop buttons and the buttons to open and close the breakers in SEMI-AUTO mode and
manual mode. Use the mimic function to select how the control buttons and LEDs are shown on the controller's display.
Display screen
Use the display screen to:
• See the operating status
• See the alarms and logs list
• Monitor the exhaust after-treatment (Tier 4/Stage V)
• Configure the controller settings and parameters
2.1.1 Display settings
To adjust for ambient lighting, configure the display settings.
Settings > Basic settings > Controller settings > Display > Display control
Parameter Text Range Default
9151 Backlight dimmer 0 to 15 * 12
9152 Green LEDs dimmer 1 to 15 * 15
9153 Red LEDs dimmer 1 to 15 * 15
9154 Contrast level -20 to +20 0
9155 Sleep mode timer 1 to 1800 s 60 s
9156 Enable (Sleep mode timer) OFF
ON ON
9157 Alarm Jump OFF
ON ON
9158 Engineering units Bar/Celcius
PSI/Fahrenheit Bar/Celcius
* Note: Low numbers are minimum brightness and high numbers are maximum brightness.
OPERATOR'S MANUAL 4189341312A EN Page 5 of 25

3. About the AGC 150 Generator
3.1 Display, buttons and LEDs
4
3
3
5
6
7
8
9
15 14 11 1112 12
1
17
16
2 3 3
18
1013
No. Name Function
1 Power Green: The controller power is ON.
OFF: The controller power is OFF.
2 Display screen
Resolution: 240 x 128 px.
Viewing area: 88.50 x 51.40 mm.
Six lines, each with 25 characters.
3 Navigation Move the selector up, down, left and right on the screen.
4 OK Go to the Menu system.
Confirm the selection on the screen.
5 Back Go to the previous page.
6 AUTO mode
For generator controllers, the controller automatically starts and stops (and connects and disconnects)
gensets. No operator actions are needed. The controllers use the power management configuration to
automatically select the power management action.
7 Silence horn Stops an alarm horn (if configured) and enters the Alarm menu.
8 Shortcut menu Access the Jump menu, Mode selection, Test, Lamp test.
9 SEMI-AUTO
mode
The operator or an external signal can start, stop, connect or disconnect the genset. The generator
controller cannot automatically start, stop, connect or disconnect the genset.
The controller automatically synchronises before closing a breaker, and automatically deloads before
opening a breaker.
10 Mains symbol Green: Mains voltage and frequency are OK. The controller can synchronise and close the breaker.
Red: Mains failure.
11 Close breaker Push to close the breaker.
12 Open breaker Push to open the breaker.
13 Breaker symbols Green: Breaker is closed.
OPERATOR'S MANUAL 4189341312A EN Page 6 of 25

No. Name Function
Green flashing: Synchronising or deloading.
Red: Breaker failure.
14 Generator
Green: Generator voltage and frequency are OK. The controller can synchronise and close the
breaker.
Green flashing: The generator voltage and frequency are OK, but the V&Hz OK timer is still running.
The controller cannot close the breaker.
Red: The generator voltage is too low to measure.
15 Engine
Green: There is running feedback.
Green flashing: The engine is getting ready.
Red: The engine is not running, or there is no running feedback.
16 Stop Stops the genset if SEMI-AUTO or Manual is selected.
17 Start Starts the genset if SEMI-AUTO or Manual is selected.
18 Load symbol
OFF: Power management application.
Green: The supply voltage and frequency are OK.
Red: Supply voltage/frequency failure.
3.2 Mimic function
Settings > Basic settings > Controller settings > Display > LED mimic
Parameter no. Item Range
6082 LED mimic
Standard with genset
Standard
Guided with genset
Guided
Standard
The control buttons and LEDs are shown.
If you stop the genset, the motor/generator symbols are not shown.
Standard with genset
The control buttons and LEDs are shown.
If you the stop the genset, the motor/generator symbols are shown in
red.
Guided
Active control buttons and LEDs are shown inactive are not shown.
Example: The controller is in SEMI-AUTO mode, and the genset is not
operating. Only the start button is shown, as this is the only possible
action.
Guided with genset
Active control buttons, LEDs and the motor/generator symbols are
shown, inactive are not shown.
Example: The controller is in SEMI-AUTO mode. The genset is not
operating. The only possible action is to start the genset, and so only
the start button and the red motor/generator symbols are shown.
OPERATOR'S MANUAL 4189341312A EN Page 7 of 25

All Mimic settings
The breaker symbol is shown in red:
• Breaker position failure
• Breaker close failure
The breaker symbol flashes green:
• The controller is synchronising
• The controller is de-loading
3.3 Running modes
The AGC 150 Generator controller has four running modes, and a test mode. To configure the running mode push the Shortcut
button and select Running Modes. Configure the test mode in Settings > Power set points > Test. To run the test push
the Shortcut button and select Start Test.
Mode Description
AUTO
The controller automatically starts and stops (and connects and disconnects) the genset. The operator cannot start
a sequence manually. The controllers use the power management configuration to automatically select the power
management action.
SEMI-AUTO
The controller cannot automatically start, stop, connect and disconnect the genset. The operator or an external
signal can start these sequences. The controller automatically synchronises before closing a breaker, and
automatically de-loads before opening a breaker.
MANUAL The operator can use the digital increase/decrease inputs (if they are configured) and the Start and Stop buttons.
When the genset starts in manual mode, it starts without subsequent regulation.
BLOCK The controller cannot start a sequence. Select the block mode when you do maintenance work on the genset.
Test The test sequence starts when you select the test mode.
NOTE The genset shuts down if you select the block mode while the genset is operating.
3.4 Exhaust after-treatment (Tier 4/Stage V)
AGC 150 supports Tier 4 (Final)/Stage V requirements. It provides monitoring and control of the exhaust after-treatment system, as
required by the standard.
OPERATOR'S MANUAL 4189341312A EN Page 8 of 25

AGC 150 Tier 4/Stage V screen
DEF level: 32.0% 1/20
ISLAND SEMI
No. Referent Symbol Description
1. Engine emission system failure Shows an emission failure or malfunction.
2. Diesel Particle Filter (DPF) Shows that a regeneration is needed.
3. Application mode - -
4. Diesel Particle Filter (DPF) Inhibit Shows that regeneration is inhibited.
5. High temperature - Regeneration Shows a high temperature and regeneration is in process.
6. Engine interface status Shows an engine warning.
7. Operation mode - -
8. Engine emission system failure level Shows the severity of an emission failure or malfunction.
9. Diesel Particle Filter (DPF) level Shows the severity of a needed regeneration.
10. Page number - Shows the number of the View menu screen.
11. Engine interface status Shows a malfunction.
OPERATOR'S MANUAL 4189341312A EN Page 9 of 25

No. Referent Symbol Description
12. Engine interface status Shows an engine shutdown.
13. LIMIT lamp Only for MTU engines.
14. Diesel Exhaust Fluid (DEF) Shows the fluid tank level is low.
15. Diesel Exhaust Fluid (DEF) % level - Shows the level (%) of the Diesel Exhaust Fluid.
NOTE Grey symbols show that communication is available for the referent. An engine type might not support all of the referents.
OPERATOR'S MANUAL 4189341312A EN Page 10 of 25

4. About the AGC 150 Mains
4.1 Display, buttons and LEDs
4
3
3
5
6
7
8
9
11 12
1
2 3 3
13
No. Name Function
1 Power Green: The controller power is ON.
OFF: The controller power is OFF.
2 Display screen
Resolution: 240 x 128 px.
Viewing area: 88.50 x 51.40 mm.
Six lines, each with 25 characters.
3 Navigation Move the selector up, down, left and right on the screen.
4 OK Go to the Menu system.
Confirm the selection on the screen.
5 Back Go to the previous page.
6 AUTO mode
For BTB controllers, the controller automatically joins and splits the busbar. No operator actions are
needed. The controllers use the power management configuration to automatically select the power
management action.
7 Silence horn Stops an alarm horn (if configured) and enters the Alarm menu.
8 Shortcut menu Access the Jump menu, Lamp test.
9 SEMI-AUTO
mode
The operator or an external signal can join or split the busbar. The BTB controller cannot automatically
join or split the busbar.
The controller automatically synchronises before closing a breaker, and automatically deloads before
opening a breaker.
11 Close breaker Push to close the breaker.
12 Open breaker Push to open the breaker.
13 Breaker symbols
Green: Breaker is closed.
Green flashing: Synchronising or deloading.
Red: Breaker failure.
OPERATOR'S MANUAL 4189341312A EN Page 11 of 25

4.2 Mimic function
Settings > Basic settings > Controller settings > Display > LED mimic
Parameter no. Item Range
6082 LED mimic Standard
Guided
Standard
The LEDs are shown.
Guided
Active LEDs are shown and inactive are not shown.
Example: The controller is in SEMI-AUTO mode, and the breakers are
closed. Only the Open breaker symbols are shown, as this is the only
possible action.
All Mimic settings
The breaker symbol is shown in red:
• Breaker position failure
• Breaker close failure
The breaker symbol flashes green:
• The controller is synchronising
• The controller is de-loading
4.3 Running modes
The AGC 150 Mains controller has three running modes, and a test mode. Push the Shortcut button and select Running Modes
to configure the mode. Configure the test mode in Settings > Power set points > Test. To run the test push the Shortcut
button and select Start Test.
Mode Description
AUTO The controller automatically connects and disconnects the mains. The operator cannot start a sequence manually.
The controllers use the power management configuration to automatically select the power management action.
SEMI-AUTO
The controller cannot automatically connect and disconnect the mains. The operator or an external signal can start
these sequences. The controller automatically synchronises before closing a breaker, and automatically de-loads
before opening a breaker.
Test The test sequence starts when you select the test mode.
BLOCK The controller cannot start sequences. Select the block mode when you do maintenance work.
OPERATOR'S MANUAL 4189341312A EN Page 12 of 25

5. About the AGC 150 BTB
5.1 Display, buttons and LEDs
4
3
3
5
6
7
8
9
11 12
1
2 3 3
13
No. Name Function
1 Power Green: The controller power is ON.
OFF: The controller power is OFF.
2 Display screen
Resolution: 240 x 128 px.
Viewing area: 88.50 x 51.40 mm.
Six lines, each with 25 characters.
3 Navigation Move the selector up, down, left and right on the screen.
4 OK Go to the Menu system.
Confirm the selection on the screen.
5 Back Go to the previous page.
6 AUTO mode
For BTB controllers, the controller automatically joins and splits the busbar. No operator actions are
needed. The controllers use the power management configuration to automatically select the power
management action.
7 Silence horn Stops an alarm horn (if configured) and enters the Alarm menu.
8 Shortcut menu Access the Jump menu, Lamp test.
9 SEMI-AUTO
mode
The operator or an external signal can join or split the busbar. The BTB controller cannot automatically
join or split the busbar.
The controller automatically synchronises before closing a breaker, and automatically deloads before
opening a breaker.
11 Close breaker Push to close the breaker.
12 Open breaker Push to open the breaker.
13 Breaker symbols
Green: Breaker is closed.
Green flashing: Synchronising or deloading.
Red: Breaker failure.
OPERATOR'S MANUAL 4189341312A EN Page 13 of 25

5.2 Mimic function
Settings > Basic settings > Controller settings > Display > LED mimic
Parameter no. Item Range
6082 LED mimic Standard
Guided
Standard
The LEDs are shown.
Guided
Active LEDs are shown and inactive are not shown.
Example: The controller is in SEMI-AUTO mode, and the breaker is
closed. Only the Open breaker symbol is shown, as this is the only
possible action.
All Mimic settings
The breaker symbol is shown in red:
• Breaker position failure
• Breaker close failure
The breaker symbol flashes green:
• The controller is synchronising
• The controller is de-loading
5.3 Running modes
The AGC 150 BTB controller has three running modes. To configure the running mode push the Shortcut button and select
Running Modes.
Mode Description
AUTO The controller automatically joins and splits the busbar. The operator cannot start a sequence manually. The
controllers use the power management configuration to automatically select the power management action.
SEMI-AUTO
The controller cannot automatically join and split the busbar. The operator or an external signal can start these
sequences. The controller automatically synchronises before closing a breaker, and automatically de-loads before
opening a breaker.
BLOCK The controller cannot start sequences. Select the block mode when you do maintenance work.
OPERATOR'S MANUAL 4189341312A EN Page 14 of 25

6. Menus
6.1 Menu structure
The AGC 150 has two menu systems, which can be used without password entry:
•The View menu system: Shows the operating status and values. The system has 20 configurable windows, that can be entered
with the arrow buttons.
•The Settings menu system: The operator can see the controller's parameters. A password is necessary to change the
parameter settings.
6.2 Settings menu
You can configure the controller in the settings menu and you can also find information, which is not available in the view menu.
From the view menu, push the button to find the settings menu. Use the and buttons to find the different settings
parameter and select with the button.
Settings menu example
This is an example of how to change the nominal voltage settings.
!
Push
Push
Push
Push
Push
Push
OPERATOR'S MANUAL 4189341312A EN Page 15 of 25

6.2.1 Menu numbers
Each parameter has a menu number. You can find the number in the upper right corner on the display screen.
You can also find the menu number with the utility software:
1. Select Parameters from the vertical toolbar on the left.
2. Set the view mode to list. The view mode can be found in the left corner of the screen.
3. The menu numbers are in the Channel column.
6.2.2 The jump to parameter function
If you know the menu number for a parameter, you can use the jump to parameter function to go directly to the parameter.
On the controller
1. From the view menu, push the Shortcut button to see the jump to parameter function:
2. Use the and buttons to go to Jump to parameter and push the button.
3. Use the and buttons to change the numbers, and push the button to save. Use the and buttons to move to
the next number.
6.3 View menu
The view menu is shown when the controller is turned on, and you can see the operating status and values. The event and alarms
list is also shown if an alarm is active.
OPERATOR'S MANUAL 4189341312A EN Page 16 of 25

1
2
3
1. Operating status
2. Values and information
3. Page number, power management priority, power management ID and engine DEF level.
The view menu has 20 different display views. Use the and buttons to select a view.
AGC 150 Generator example
Push
AGC 150 Mains example
Push
AGC 150 BTB example
Push
6.3.1 Display views
The controllers have 20 different display views, and some are pre-configured. You can configure the views with the utility software.
OPERATOR'S MANUAL 4189341312A EN Page 17 of 25

AGC 150 Generator
Line View 1 View 2 View 3 View 4 View 5
1 U-Supply 0.0V BB L1 0.0Hz 0V - BB L1 0.0Hz 0V G U-L1L2 0V
2 G 0.00PF 0kW G L1 0.0Hz 0V Synchroniser G 0.00PF 0kW G U-L2L3 0V
3 G 0kVA 0kvar G 0.00PF 0kW - G 0kVA 0kvar G U-L3L1 0V
4 Energy Total 0kWh G 0kVA 0kvar - G 0 0 0A G U-Max 0V
5 Run absolute 0hrs G 0 0 0A - G L1 0.0Hz 0V G U-Min 0V
Line View 6 View 7 View 8 View 9 View 10
1 G I-L1 0A G f-L1 0.00Hz G P 0kW P available 0kW G U-L1N 0V
2 G I-L2 0A G f-L2 0.00Hz G Q 0kvar P consumed 0kW G U-L2N 0V
3 G I-L3 0A G f-L3 0.00Hz G S 0kVA P 0kW 0% G U-L3N 0V
4 GB Operations 0 - G PF 0.00 - -
5 MB Operations 0 - Date and Time - -
Line View 11 View 12 View 13 View 14 View 15
1 BB U-L1L2 0V G Angle L1L2 0deg L-L and P total P GTot and P % BB-Gen Angle
2 BB U-L2L3 0V G Angle L2L3 0deg Current and Q total Q GTot and Q % G Angle L1L2
3 BB U-L3L1 0V G Angle L3L1 0deg Pf and kW % BB freq and G freq BB Angle L1L2
4 BB U-Max 0V AVR reg. type GOV and AVR output BB L-N and G L-N BB Angle L2L3
5 BB U-Min 0V GOV reg. type Ramp down/up
setpoint kW % and kvar % -
Line View 16 View 17 View 18 View 19 View 20
1 EIC T. Coolant Aftertreatment text Multi input 20 0 P available 0% P 0kW 0%
2 EIC T. TurboOil EIC Tier 4 Icons Multi input 21 0 P consumed 0% Q 0kvar 0%
3 EIC T. Exh. R - Multi input 22 0 G 0.00PF 0%P S 0kVA 0%
4 EIC T. Oil - Multi input 23 0 BB f-L1 0.00Hz -
5 EIC T. Fuel - MPU 0rpm BB Angle L1L2 0deg -
AGC 150 Mains
Line View 1 View 2 View 3 View 4 View 5
1 U-Supply 0.0V BB L1 0.0Hz 0V - M 0 0 0V M P 0kW
2 M 0.00PF 0kW M 0.0Hz 0V Synchroniser M L1 0.0Hz 0V M Q 0kvar
3 M 0kVA 0kvar M 0.00PF 0kW - - M S 0kVA
4 Energy Total 0kWh M 0kVA 0kvar - BB 0 0 0V M 0 0 0V
5 M 0.00PF okW M 0 0 0A - BB L1 0.0Hz 0V M 0 0 0A
Line View 6 View 7 View 8 View 9 View 10
1 M I-L1 0A M f-L1 0.00Hz M U-L1N 0V P available 0kW M U-L1N 0V
2 M I-L2 0A M f-L2 0.00Hz M U-L2N 0V P consumed 0kW M U-L2N 0V
OPERATOR'S MANUAL 4189341312A EN Page 18 of 25

Line View 6 View 7 View 8 View 9 View 10
3 M I-L3 0A M f-L3 0.00Hz M U-L3N 0V P 0kW 0% M U-L3N 0V
4 M 0.00PF 0kW M 0.00PF 0kW M f-L1 0.00Hz Q 0kvar 0% M f-L1 0.00Hz
5 M 0 0 0V M 0 0 0V M 0 0 0A S 0kVA 0% M 0 0 0A
Line View 11 View 12 View 13 View 14 View 15
1 BB U-L1L2 0V M U-L1N 0V Multi Input 20 0 - BB-M Angle 0deg
2 BB U-L2L3 0V M U-L2N 0V Multi Input 21 0 Date and Time M Angle L1L2 0deg
3 BB U-L3L1 0V M U-L3N 0V Multi Input 22 0 - M Angle L2L3 0deg
4 BB f-L1 0.00Hz M 0.00PF 0kW Multi Input 23 0 MB operations BB Angle L1L2 0deg
5 M 0 0 0A Energy Total 0kWh - TB Operations BB Angle L2L3 0deg
AGC 150 BTB
Line View 1 View 2 View 3 View 4 View 5
1 U-Supply 0.0V BB L1 0.0Hz 0V - BA 0 0 0V BA P 0kW
2 BA L1 0.0Hz 0V BA L1 0.0Hz 0V Synchroniser BA f-L1 0.00Hz BA Q 0kvar
3 BA 0kVA 0kvar BA 0kVA 0kvar - - BA S 0kVA
4 BA 0.00PF 0kW BA 0.00PF 0kW - BB 0 0 0V BA 0 0 0V
5 BA 0 0 0A BA 0 0 0A - BB f-L1 0.00Hz BA 0 0 0A
Line View 6 View 7 View 8 View 9 View 10
1 BA I-L1 0A BA f-L1 0.00Hz BA U-L1L2 0V BB U-L1L2 0V Multi Input 20 0
2 BA I-L2 0A BA f-L2 0.00Hz BA U-L2L3 0V BB U-L1L2 0V Multi Input 21 0
3 BA I-L3 0A BA f-L3 0.00Hz BA U-L3L1 0V BB U-L3L1 0V Multi Input 22 0
4 BA 0.00PF 0kW BA 0.00PF 0kW BA f-L1 0.00Hz BB f-L1 0.00Hz Multi Input 23 0
5 BA 0 0 0V BA 0 0 0A BA 0 0 0A BA 0 0 0A -
Line View 11 View 12 View 13 View 14 View 15
1 - Angle BB-BA 0deg - - -
2 Date and Time BA Angle L1L2 0deg - - -
3 - BA Angle L2L3 0deg - - -
4 BTB Operations 0 BB Angle L1L2 0deg - - -
5 - BB Angle L2L3 0deg - - -
6.3.2 Display text
Configure the display views
You can configure the display views with the utility software.
1. Select the Configuration of the user views button in the toolbar.
2. In the pop-up window, select the display view you want to change.
OPERATOR'S MANUAL 4189341312A EN Page 19 of 25

3. Select the display line you want to change.
4. In the pop-up window, select the text you want and click OK.
Display text
You can select five of the display texts for each display view.
6.4 Status texts
Status text Condition
ACCESS LOCK The configurable input is activated, and the operator tries to activate one of the blocked keys.
ADAPT IN PROGRESS Power management: The controller is receiving the application it has connected to.
AMF ACTIVE The controller is in auto mode during a mains failure.
AMF AUTO The mains controller is in auto mode and ready to respond.
AMF MAN The controller is in manual mode and waiting for operator input.
AMF SEMI The controller is in semi-automatic mode and waiting for operator input.
AUTO OPERATION BTB power management: BTB controller is in AUTO mode, but is not ready for breaker operation
(because of an active BTB trip alarm).
Aux. test ##.#V ####s The battery test is activated.
BLACKOUT ENABLE Generator power management: CAN failure in a power management application.
BLOCK Block mode is activated.
BLOCKED FOR CLOSING BTB power management: Last open BTB in a ring bus.
BROADCAST ABORTED Power management: Broadcast terminated.
OPERATOR'S MANUAL 4189341312A EN Page 20 of 25
