CalorDerm Knee Compression & Heat Massager User manual

CalorDerm Knee Compression
& Heat Massager - Cordless
User Manual

Introduction
Thank you for using the intelligent knee massager.
This product allows you to perform knee air
pressure massage, hot compress and vibration
anytime and anywhere according to your own needs,
and relieve knee pressure and fatigue.
Thank you sincerely for
choosing this product
Please read this manual carefully before use
Please keep it safe for future inquiry

Product introduction
1. Device x1
2. TYPE-C charging line x 1
3. Manual ×1
Parameter
Input voltage: 5V 1A
Operating voltage: 3.7V
Battery capacity: 2500mAH
Operation time: 15 minutes
Packing list

Product introduction
Introduction to operation panel
Visual LED large screen display, physical buttons,
clear functions and simple operation
3D wrap-around three-stage full wrap, which fits knee
joint and leg
Three massage models, contact air pressure massage,
segmented massage, balanced stress
High frequency micro vibration
15-minute regular massage
Mode indicator
Motion Indicator
Heating indicator
Intensity
indicator
Vibration
indicator
Mode Button
Intensity Button ON/OFF Heating Button
Vibration
button
Vibration
Heating
Mode
Intensity
Three heating levels：Low-45 degrees；Middle-50
degrees；High-55 drgrees

Product introduction
How To Use
Operation Panel
Thigh area
Calf area
Knee area
1. Wear the product on the knees and legs, fix and tie
the product tightly with hook and loop tape, and fit
the knees and legs.
2. Press the switch key for a long time to start the
machine. After starting the machine, the default mode
is one, the first gear of strength and the first gear
of heating.
3. Press the mode key briefly to switch modes.
4. Press the strength key briefly to adjust the massage
strength.
5. Press the heating key briefly to adjust the heating
temperature (low-medium-high-turn off the heating
cycle in turn).
6. Press the vibration key briefly to turn on and off
the vibration.

Points to note
Charging
1. Before the first use, please fully charge the product
and charge it for about 3.5 hours.
2. It is not recommended to completely drain the battery.
3. Please charge in time when you are prompted for
low power.
4.When charging, connect the plug wire of the Type-c
interface to the charging port of the product.
5.The USB interface at the other end is plugged into
the USB charging head and connected to the power supply.
Battery
Because the electromagnetic field generated by the
motor of the massager is relatively small, it will
generally not affect the electronic equipment and
human body!
The device(including lithium battery) and accessories
of this product have reached the service life, so
please do not throw them away at will, otherwise,
e-waste will pollute the environment. Please make
corresponding treatment according to the relevant
regulations of the local environmental protection
department on this kind of e-waste.

Notification
It is forbidden to stuff sundries into the gap
of massage instrument.
Do not pour liquid on the product, so as to avoid
accidents caused by short circuit.
Do not unplug the charging cable with wet hands.
Do not use accessories and accessories that are
not recommended.
Do not use this product outdoors or in high
temperature and humidity.
Do not take part in any strenuous exercise after
wearing the product.
It is forbidden to lie or sit on the product.
It is forbidden to bring huge impact and load to
the product.
Do not use it while sleeping.
Caution

Safety precautions for use
Useful tips
Before use, you must know the following, otherwise it
may cause damage or danger!
There are leg nerve disorders or skin sensory disorders.
People who inject metal, silicone or plastic into their
knees due to fracture or surgery.
Implantable medical electronic instruments that are easily
affected by electromagnetic faults such as pacemakers.
Those with malignant tumors.
People with heart disease.
A person who is unstable in early pregnancy or soon after
giving birth.
Diabetes causes perceptual disorders.
Osteoporosis, severe fracture, sprain, muscle pain and
acute pain should be guided by doctors.
This product is not a medical device and is not
recommended for medical use.
This product contains a lithium battery, so please do
not disassemble, modify, immerse in water or throw it
into the fire, otherwise you can cause product damage.
Safety precautions for use
In case of the following conditions, please shut
down the machine immediately and contact the
designated service center of the machine.
If severe pain occurs during massage, please stop
massage immediately and seek medical advice.
If you notice any mechanical failure or abnormal
condition in use, please stop using it immediately.

Product maintenance
Maintenance, storage and transportation
of instruments
Cleaning
Wipe with a soft cloth, do not wet the host, and do not
wipe the host with a wet towel to avoid water seepage.
Do not wipe with thinner, gasoline or other flexible
liquid when entering the host.
After stopping use, press the switch button for a long
time to turn off the machine, and use the plastic bag
for storage only after the instrument has normal heat
dissipation.
Storage, custody:
Keep the instrument out of reach of children, away from
humidity, high temperature, direct sunlight and water
splash.
Do not disassemble, repair or replace it without
authorization; Parts, which may cause accidents and
failures.
If the equipment is not used for a long time, the product
should be charged once a month to prevent the battery life
from being shortened.
Transportation:
The product is designed with simple shockproof facilities,
so please avoid large amplitude shaking during
transportation.
No throwing, falling, rain, snow and exposure.

Trouble shooting method
Usage failure Reasons Solution
The product
does not work
properly
The product has
just been completed
for 15 minutes
Please press the power
switch again to restart
Product is
not heated
When used outside
the recommended
ambient temperature
range, the heating
effect is not
obvious
It is recommended to use
at the ambient
temperature of 15-35
degrees Celsius
Abnormal sound
of products
This sound is caused
by the mechanical
structure of the
product
This sound is normal,
which does not mean
that the product
function is faulty
Stop during
operation
The battery is
exhausted
Connect the charging
cable to charge
After 15 minutes,
the massage will
stop automatically
restart
Transportation environment Working environment
Temperature: -20℃~+50℃
Relative humidity: ≤90%
Atmospheric pressure:
70kPa~106kPa
Temperature: +5℃~+40℃
Relative humidity: ≤80%
Atmospheric pressure:
86kPa~106kPa
