PTP820:Bringingupyourfirstlink!
13February2015

What’sneededtobringupamicrowavelink?
2
1. Toaccessthelink:
a) IPaddresses:10.120.109.100,10.120.109.101
b) Loginsandpasswords:adminandadmin
2. RF
a) Tx andRxfrequencies:19400MHz,17840MHz
b) Channelbandwidth:30MHz
c) Modulationmode(s):Adaptive,fromQPSK(4QAM)to2048QAM
d) Transmitpowers:2dBm
e) LinkID(identifier):1
3. Ethernet
a) In‐bandorOut‐Of‐Bandmanagement?
b) Ethernetportstobeused
c) VLAN

Bringingupyourfirstlink!
3
ThefollowingstepsconfigureaPTP820linkasasimpletransparentLayer2
bridge:
1. Login
2. ConfiguretheIPaddress
3. Applylicensekey(s)
4. Select/configureMRMCscripts(channelbandwidth,ACM,andmodulation
mode)
5. ConfigureTx/RxFrequency,TxPower,andLinkID
6. ConfigureATPCandReferenceRxLevel
7. ConfiguretheEthernetservice
–OOBManagement
–In‐bandManagement

Here’showyourlaptopshouldbeconnectedtoaradio
•HereisapictureofalaptopconnectedtoaPTP820radiovia
anEthernetcable.

EnterIPaddressintowebbrowser(defaultis192.168.1.1)

MainView—thisisthefirstscreenyouseeafterloggingin

ApplyLicensekey(s):Platform,License,LicenseConfiguration
Pasteyourlicensekey(s)here

ConfiguretheIPaddress: Platform,Management,IP,Local
ConfiguretheIPaddress

ConfigureACM:Radio,MRMC,SymmetricalScripts,FCC
Hitthe“Configurescript”button

ConfigureACM:Radio,MRMC,SymmetricalScripts,FCC
Configurethechannelbandwidth
EnableordisableACM
Setmaximumandminimum
modulationmodes

ConfigureACM:Radio,MRMC,SymmetricalScripts,FCC
Herearethemodulationmodes
thatareavailable

ConfigureTx/RxfrequenciesandLinkID:Radio,RadioParameters
SetTxandRxFrequencies
Bothendsofthelinkmust
havethesameLinkID

ConfigureATPC:Radio,ATPC

ConfigureEthernetService
•Ethernet,Services
•Addin‐bandmanagement—connectport3totheMNGservice
–SelectMNGService
–HitServicePointsbutton
–Hitthe“Add”button(addservicepointtoMNGservice)
–Interfacelocation:Ethernet:Slot1,port3
–Apply
•MoveEthernetcabletoport3andverifythatradiocanbemanagedfromport3
•AddEthernetservicetoconnectport3toradioport
•Ethernet,Services
•Hit“Add”button
•SelectServiceType“P2P”
•SelectP2PServiceandhit“ServicePoints”button
•Hit“Add”button
•Under“Pre definedoptions”Select“Option#8(PIPE,dot1q)”
•Under“Interfacelocation”Select“Ethernet:Slot1,port3”
•Hit“Add”button
•Under“Interfacelocation”Select“Radio:Slot2,port1”

ConfigureEthernetServices:Ethernet,Services

Left‐clickon“MNG”Serviceandleft‐clickon“ServicePoints”

AddServicePointforin‐bandmanagement:left‐click“Add”

Under“Interfacelocation”,select“Ethernet:Slot1,port3”

Nowyou’vegotin‐bandmanagement!(left‐clickon“Backto
Servicestable”)

AddP2PServiceforEthernetport3:left‐click“Add”
