Cambium Networks PTP 820S User manual

INSTALLATION GUIDE
PTP 820S and PTP
820S Assured
System Release 10.0

Accuracy
While reasonable efforts have been made to assure the accuracy of this document, Cambium Networks
assumes no liability resulting from any inaccuracies or omissions in this document, or from use of the
information obtained herein. Cambium reserves the right to make changes to any products described
herein to improve reliability, function, or design, and reserves the right to revise this document and to
make changes from time to time in content hereof with no obligation to notify any person of revisions
or changes. Cambium does not assume any liability arising out of the application or use of any
product, software, or circuit described herein; neither does it convey license under its patent rights or
the rights of others. It is possible that this publication may contain references to, or information about
Cambium products (machines and programs), programming, or services that are not announced in
your country. Such references or information must not be construed to mean that Cambium intends to
announce such Cambium products, programming, or services in your country.
Copyrights
This document, Cambium products, and 3rd Party software products described in this document may
include or describe copyrighted Cambium and other 3rd Party supplied computer programs stored in
semiconductor memories or other media. Laws in the United States and other countries preserve for
Cambium, its licensors, and other 3rd Party supplied software certain exclusive rights for copyrighted
material, including the exclusive right to copy, reproduce in any form, distribute and make derivative
works of the copyrighted material. Accordingly, any copyrighted material of Cambium, its licensors, or
the 3rd Party software supplied material contained in the Cambium products described in this
document may not be copied, reproduced, reverse engineered, distributed, merged or modified in any
manner without the express written permission of Cambium. Furthermore, the purchase of Cambium
products shall not be deemed to grant either directly or by implication, estoppel, or otherwise, any
license under the copyrights, patents or patent applications of Cambium or other 3rd Party supplied
software, except for the normal non-exclusive, royalty free license to use that arises by operation of
law in the sale of a product.
Restrictions
Software and documentation are copyrighted materials. Making unauthorized copies is prohibited by
law. No part of the software or documentation may be reproduced, transmitted, transcribed, stored in a
retrieval system, or translated into any language or computer language, in any form or by any means,
without prior written permission of Cambium.
License Agreements
The software described in this document is the property of Cambium and its licensors. It is furnished
by express license agreement only and may be used only in accordance with the terms of such an
agreement.
High Risk Materials
Cambium and its supplier(s) specifically disclaim any express or implied warranty of fitness for any
high risk activities or uses of its products including, but not limited to, the operation of nuclear
facilities, aircraft navigation or aircraft communication systems, air traffic control, life support, or
weapons systems (“High Risk Use”). Any High Risk is unauthorized, is made at your own risk and you
shall be responsible for any and all losses, damage or claims arising out of any High Risk Use.
© 2018 Cambium Networks Limited. All Rights Reserved.

phn-3972 004v000
Page i
Contents
List of Figures ................................................................................................................................ iv
List of Tables................................................................................................................................... v
About This User Guide .......................................................................................................................... 1
Contacting Cambium Networks .................................................................................................... 1
Purpose ........................................................................................................................................... 2
Cross references............................................................................................................................. 2
Feedback ......................................................................................................................................... 2
Problems and warranty ........................................................................................................................ 3
Reporting problems ....................................................................................................................... 3
Repair and service.......................................................................................................................... 3
Hardware warranty ........................................................................................................................ 3
Security advice ...................................................................................................................................... 4
Warnings, cautions, and notes ............................................................................................................ 5
Warnings......................................................................................................................................... 5
Cautions .......................................................................................................................................... 5
Notes ............................................................................................................................................... 5
Caring for the environment.................................................................................................................. 6
In EU countries ............................................................................................................................... 6
In non-EU countries ....................................................................................................................... 6
Chapter 1: Product description.......................................................................................................1-1
Important Notes .................................................................................................................................1-2
Safety Precautions & Declared Material ..........................................................................................1-3
General Equipment Precautions ................................................................................................1-3
Précautions générales relatives à l'équipement ......................................................................1-4
Allgemeine Vorsichtsmaßnahmen für die Anlage ...................................................................1-4
Chapter 2: Pre-Installation Instructions..........................................................................................2-1
Packing ................................................................................................................................................2-2
Transportation and Storage ..............................................................................................................2-2
Unpacking ...........................................................................................................................................2-2
Inspection............................................................................................................................................2-2
Chapter 3: Product Hardware Description .....................................................................................3-1
PTP 820S Hardware Overview ..........................................................................................................3-2
PTP 820S Interfaces.....................................................................................................................3-3
PoE Injector.........................................................................................................................................3-4
PoE Injector Interfaces ................................................................................................................3-5
System Components .........................................................................................................................3-6
Adaptors and Installation Kits...........................................................................................................3-7

Contents
phn-3972 004v000
Page ii
Antenna Connection ........................................................................................................................3-10
Power Specifications .......................................................................................................................3-11
Electrical Requirements ............................................................................................................3-11
Important Notes ........................................................................................................................3-11
Environmental Specifications .........................................................................................................3-12
Chapter 4: Cable Installation and Grounding ................................................................................4-1
Minimum and Maximum Cable Diameter .......................................................................................4-2
Cable Grounding ................................................................................................................................4-3
To Connect the Grounding kit ....................................................................................................4-3
Grounding the PTP 820S Unit ....................................................................................................4-5
Power Source ..............................................................................................................................4-7
Surge Protection ................................................................................................................................4-8
Securing the Cables ...........................................................................................................................4-9
Available Cable Options ..................................................................................................................4-10
Fiber Optic Cables .....................................................................................................................4-10
DC Cable and Connector...........................................................................................................4-10
Ethernet Cable and Specifications...........................................................................................4-10
Outdoor Ethernet Cable Specifications ...................................................................................4-11
Outdoor DC Cable Specifications ............................................................................................4-12
Special Instructions for use of Glands ...........................................................................................4-14
General Installation Procedure ................................................................................................4-15
Connecting an Optical Fiber Cable and SFP ..................................................................................4-20
Connecting a DC Power Cable ........................................................................................................4-24
Connecting the Ethernet Cable .......................................................................................................4-27
Preparing the Ethernet Cable and Plug-in Field .....................................................................4-27
Preparing the Ethernet Cable Already Assembled.................................................................4-30
Connection of Ethernet Cable to PTP 820S.............................................................................4-31
Management Connection for 1+1 HSB Configurations ................................................................4-33
Preparing a Protection Signaling Cable ..................................................................................4-33
Connecting the Protection Splitters and Protection Signaling Cable...................................4-34
Chapter 5: PoE Injector Installation and Connection .....................................................................5-1
PoE Injector Cable Connection..........................................................................................................5-2
PoE Injector Grounding .....................................................................................................................5-3
PoE Injector Wall Mount Installation................................................................................................5-4
List of Items .................................................................................................................................5-4
Required Tools ............................................................................................................................5-4
Procedure.....................................................................................................................................5-4
PoE Injector 19” Rack Installation.....................................................................................................5-6
List of Items .................................................................................................................................5-6
Required Tools ............................................................................................................................5-6
Procedure.....................................................................................................................................5-6
PoE Injector ETSI Rack Installation ...................................................................................................5-8
List of Items .................................................................................................................................5-8

Contents
phn-3972 004v000
Page iii
Required Tools ............................................................................................................................5-8
Procedure.....................................................................................................................................5-8
Chapter 6: Generic Installation Procedures and Notes .................................................................6-1
Torque Requirements ........................................................................................................................6-2
Pole Mount Installation......................................................................................................................6-3
PTP 820S DC Pole Mount Procedure .........................................................................................6-3
Chapter 7: PTP 820S Detailed Configurations Description............................................................7-1
1+0 Direct Mount Installation............................................................................................................7-2
List of Items .................................................................................................................................7-2
Required Tools ............................................................................................................................7-2
Procedure.....................................................................................................................................7-2
2+0 Dual Polarization Direct Mount..................................................................................................7-5
List of Items .................................................................................................................................7-5
Required Tools ............................................................................................................................7-5
Procedure.....................................................................................................................................7-5
2+0 Dual Polarization Remote Mount...............................................................................................7-8
List of Items .................................................................................................................................7-8
Required Tools ............................................................................................................................7-8
Common Installation Procedures ..............................................................................................7-9
1+1HSB/2+0 Single Polarization Direct Mount ..............................................................................7-14
List of Items ...............................................................................................................................7-14
Required Tools ..........................................................................................................................7-14
Procedure...................................................................................................................................7-14
1+1HSB/2+0 Single Polarization Remote Mount ...........................................................................7-17
List of Items ...............................................................................................................................7-17
Required Tools ..........................................................................................................................7-17
Procedure...................................................................................................................................7-18
Mediation Device Losses.................................................................................................................7-21
Chapter 8: Acceptance and Commissioning Procedures ............................................................ 8-22
Site Acceptance Procedure .............................................................................................................8-23
Site Acceptance Checklist Notes ....................................................................................................8-27
Radio Link Commissioning Procedure ...........................................................................................8-29
Scope..........................................................................................................................................8-29
Commissioning Test .................................................................................................................8-29
PTP 820 Commissioning Log ..........................................................................................................8-31

Contents
phn-3972 004v000
Page iv
List of Figures
Figure 1 PTP 820S Rear View (Left) and Front View (Right) ................................................................3-2
Figure 2 Cable Gland Construction........................................................................................................3-2
Figure 3 PTP 820S Interfaces..................................................................................................................3-3
Figure 4 PoE Injector ...............................................................................................................................3-4
Figure 5 PoE Injector Ports .....................................................................................................................3-5
Figure 6 System components ................................................................................................................3-6
Figure 7 Grounding cable .......................................................................................................................4-3
Figure 8 Cable design ...........................................................................................................................4-11
Figure 9 Glands .....................................................................................................................................4-14
Figure 10 Removing glands .................................................................................................................4-15
Figure 11 Protection Signaling Cable Pinouts ....................................................................................4-33
Figure 12 PoE Injector cable connection ...............................................................................................5-2
Figure 13 PoE Injector Wall Mount Installation ....................................................................................5-4
Figure 14 Mount PTP 820S DC Pole Mount to Pole .............................................................................6-3
Figure 15 Horizontal / Vertical Pole........................................................................................................7-3
Figure 16 Twist orientation.....................................................................................................................7-3
Figure 17 2+0 Dual Polarization Direct Mount ......................................................................................7-5
Figure 18 2+0 Dual Polarization Remote Mount ...................................................................................7-8
Figure 19 1+1HSB/2+0 Single Polarization Direct Mount ..................................................................7-14
Figure 20 1+1HSB/2+0 Single Polarization Remote Mount ...............................................................7-17

Contents
phn-3972 004v000
Page v
List of Tables
Table 1 PoE Injector part number ..........................................................................................................3-4
Table 2 Adaptors and installation kits for 6 to 18 GHz.........................................................................3-7
Table 3 Adaptors and installation kits for 23 to 38 GHz.......................................................................3-7
Table 4 Remote Mount –6 to 15 GHz ....................................................................................................3-8
Table 5 Remote Mount –18 to 38 GHz ..................................................................................................3-8
Table 6 Antenna Circ. Adapters for OMT for 6 to 18 GHz....................................................................3-9
Table 7 Antenna Circ. Adapters for OMT for 12 to 38 GHz..................................................................3-9
Table 8 PoE Injector ................................................................................................................................3-9
Table 9 Antenna list ..............................................................................................................................3-10
Table 10 Cable Grounding Kit. ...............................................................................................................4-3
Table 11 Fiber Optic cables part numbers ..........................................................................................4-10
Table 12 DC cable and connector ........................................................................................................4-10
Table 13 DC cable and connector ........................................................................................................4-10
Table 14 Ethernet cable Color Code ....................................................................................................4-11
Table 15 Ethernet Cable Electrical Requirements .............................................................................4-11
Table 16 Outdoor DC Cable Electrical Requirements ........................................................................4-12
Table 17 Glands kit................................................................................................................................4-14
Table 18 Materials for preparing Ethernet Data Cables.....................................................................4-27
Table 19 Required items for Wall Mount PoE Injector.........................................................................5-4
Table 20 Required item for 19” Rack Installation PoE Injector ...........................................................5-6
Table 21 Required items PoE Injector ETSI Rack..................................................................................5-8
Table 22 Required items for 1+1 Direct Mount configuration.............................................................6-3
Table 23 Required items for 1+1 Direct Mount configuration.............................................................7-2
Table 24 Required items for 2+0 Dual polarization direct mount configuration ...............................7-5
Table 25 Required items for 2+0 Dual polarization direct mount configuration ...............................7-8
Table 26 Required items for 1+1HSB/2+0 Single Polarization Direct Mount configuration ...........7-14
Table 27 Required items for 1+1HSB/2+0 Single Polarization Remote Mount configuration ........7-17
Table 28 PTP 820S Mediation Device Losses .....................................................................................7-21

phn-3972 004v000
Page 1
About This User Guide
This guide describes the PTP 820S installation procedures and provides additional information
concerning system parts and frequency bands
This guide contains the following chapters:
•Chapter 1: Product description
•Chapter 2: Pre-Installation Instructions
•Chapter 3: Product Hardware Description
•Chapter 4: Cable Installation and Grounding
•Chapter 5: PoE Injector Installation and Connection
•Chapter 6: Generic Installation Procedures and Notes
•Chapter 7: PTP 820S Detailed Configurations Description
•Chapter 8: Acceptance and Commisioning Procedures
Contacting Cambium Networks
Support website:
https://support.cambiumnetworks.com
Main website:
http://www.cambiumnetworks.com
Sales enquiries:
[e-mail]
Support enquiries:
https://support.cambiumnetworks.com
Repair enquiries
https://support.cambiumnetworks.com
Telephone number list:
http://www.cambiumnetworks.com/support/contact-support
Address:
Cambium Networks Limited,
Linhay Business Park,
Eastern Road,
Ashburton,
Devon, UK,
TQ13 7UP

About This User Guide
Problems and warranty
phn-3972 004v000
Page 2
Purpose
Cambium Networks Point-To-Point (PTP) documents are intended to instruct and assist personnel
in the operation, installation and maintenance of the Cambium PTP equipment and ancillary
devices. It is recommended that all personnel engaged in such activities be properly trained.
Cambium disclaims all liability whatsoever, implied or express, for any risk of damage, loss or
reduction in system performance arising directly or indirectly out of the failure of the customer, or
anyone acting on the customer's behalf, to abide by the instructions, system parameters, or
recommendations made in this document.
Cross references
References to external publications are shown in italics. Other cross references, emphasized in
blue text in electronic versions, are active links to the references.
This document is divided into numbered chapters that are divided into sections. Sections are not
numbered, but are individually named at the top of each page, and are listed in the table of
contents.
Feedback
We appreciate feedback from the users of our documents. This includes feedback on the structure,
content, accuracy, or completeness of our documents. Send feedback to
[e-mail].

About This User Guide
Problems and warranty
phn-3972 004v000
Page 3
Problems and warranty
Reporting problems
If any problems are encountered when installing or operating this equipment, follow this
procedure to investigate and report:
1
Search this document and the software release notes of supported releases.
2
Visit the support website.
3
Ask for assistance from the Cambium product supplier.
4
Gather information from affected units, such as any available diagnostic downloads.
5
Escalate the problem by emailing or telephoning support.
Repair and service
If unit failure is suspected, obtain details of the Return Material Authorization (RMA) process from
the support website.
Hardware warranty
Cambium’s standard hardware warranty is for one (1) year from date of shipment from Cambium
Networks or a Cambium distributor. Cambium Networks warrants that hardware will conform to
the relevant published specifications and will be free from material defects in material and
workmanship under normal use and service. Cambium shall within this time, at its own option,
either repair or replace the defective product within thirty (30) days of receipt of the defective
product. Repaired or replaced product will be subject to the original warranty period but not less
than thirty (30) days.
To register PTP products or activate warranties, visit the support website. For warranty assistance,
contact the reseller or distributor.
Caution
Using non-Cambium parts for repair could damage the equipment or void warranty.
Contact Cambium for service and repair instructions.
Portions of Cambium equipment may be damaged from exposure to electrostatic
discharge. Use precautions to prevent damage.

About This User Guide
Security advice
phn-3972 004v000
Page 4
Security advice
Cambium Networks systems and equipment provide security parameters that can be configured
by the operator based on their particular operating environment. Cambium recommends setting
and using these parameters following industry recognized security practices. Security aspects to
be considered are protecting the confidentiality, integrity, and availability of information and
assets. Assets include the ability to communicate, information about the nature of the
communications, and information about the parties involved.
In certain instances, Cambium makes specific recommendations regarding security practices,
however the implementation of these recommendations and final responsibility for the security of
the system lies with the operator of the system.

About This User Guide
Warnings, cautions, and notes
phn-3972 004v000
Page 5
Warnings, cautions, and notes
The following describes how warnings and cautions are used in this document and in all
documents of the Cambium Networks document set.
Warnings
Warnings precede instructions that contain potentially hazardous situations. Warnings are used to
alert the reader to possible hazards that could cause loss of life or physical injury. A warning has
the following format:
Warning
Warning text and consequence for not following the instructions in the warning.
Cautions
Cautions precede instructions and are used when there is a possibility of damage to systems,
software, or individual items of equipment within a system. However, this damage presents no
danger to personnel. A caution has the following format:
Caution
Caution text and consequence for not following the instructions in the caution.
Notes
A note means that there is a possibility of an undesirable situation or provides additional
information to help the reader understand a topic or concept. A note has the following format:
Note
Note text.

About This User Guide
Caring for the environment
phn-3972 004v000
Page 6
Caring for the environment
The following information describes national or regional requirements for the disposal of
Cambium Networks supplied equipment and for the approved disposal of surplus packaging.
In EU countries
The following information is provided to enable regulatory compliance with the European Union
(EU) directives identified and any amendments made to these directives when using Cambium
equipment in EU countries.
Disposal of Cambium equipment
European Union (EU) Directive 2002/96/EC Waste Electrical and Electronic Equipment (WEEE)
Do not dispose of Cambium equipment in landfill sites. For disposal instructions, refer to
http://www.cambiumnetworks.com/support
Disposal of surplus packaging
Do not dispose of surplus packaging in landfill sites. In the EU, it is the individual recipient’s
responsibility to ensure that packaging materials are collected and recycled according to the
requirements of EU environmental law.
In non-EU countries
In non-EU countries, dispose of Cambium equipment and all surplus packaging in accordance with
national and regional regulations.

phn-3972 004v000
Page 1-1
Chapter 1: Product description
Cambium’s PTP 820S represents a new generation of radio technology, capable of high bit rates
and longer reach, and suitable for diverse deployment scenarios.
PTP 820S supports cutting edge capacity-boosting techniques, such as QPSK to 2048 QAM and
Header De-Duplication, to offer a high capacity solution for every network topology and every site
configuration. Its green, compact, all-outdoor configuration makes PTP 820S ideal for any location.
This chapter includes:
•Important Notes
•Safety Precautions & Declared Material

Chapter 1: Product description
Important Notes
phn-3972 004v000
Page 1-2
Important Notes
•For the warranty to be honored, install the unit in accordance with the instructions in this
manual.
•Any changes or modifications of equipment not expressly approved by the manufacturer could
void the user’s authority to operate the equipment and the warranty for such equipment.
•PTP 820S is intended for installation in a restricted access location.
•PTP 820S must be installed and permanently connected to protective earth by qualified service
personnel in accordance with applicable national electrical codes.

Chapter 1: Product description
Safety Precautions & Declared Material
phn-3972 004v000
Page 1-3
Safety Precautions & Declared Material
General Equipment Precautions
Caution
To avoid malfunctioning or personnel injuries, equipment or accessories/kits/plug-in
unit installation, requires qualified and trained personnel. Changes or modifications
not expressly approved by Cambium Networks can void user's authority to operate
the equipment.
Caution
Where special cables, shields, adapters and grounding kits are supplied or described
in this manual, these items must be used to comply with the FCC regulations.
Caution
Use of controls, adjustments, or performing procedures other than those specified
herein, may result in hazardous radiation exposure.
Caution
When working with a PTP 820S, note the following risk of electric shock and energy
hazard:
Disconnecting one power supply disconnects only one power supply module. To
isolate the unit completely, disconnect all power supplies.
Caution
Machine noise information order: 3. GPSGV, the highest sound pressure level
amounts to 70 dB (A) or less, in accordance with ISO EN 7779.
Antistatic
Static electricity may cause body harm, as well as harm to electronic components
inside the device. Anyone responsible for the installation or maintenance of the PTP
820S must use an ESD Wrist Strap. ESD protection measures must be observed when
touching the unit. To prevent damage, before touching components inside the device,
all electrostatic must be discharged from both personnel and tools.
Caution
In Norway and Sweden:

Chapter 1: Product description
Safety Precautions & Declared Material
phn-3972 004v000
Page 1-4
Equipment connected to the protective earthing of the building installation through
the mains connection or through other equipment with a connection to protective
earthing –and to a cable distribution system using coaxial cable, may in some
circumstances create a fire hazard. Connection to a cable distribution system has
therefore to be provided through a device providing electrical isolation below a certain
frequency range (galvanic isolator, see EN 60728-11).
Utstyr som er koplet til beskyttelsesjord via nettplugg og/eller via annet jordtilkoplet
utstyr –og er tilkoplet et kabel-TV nett, kan forårsake brannfare. For å unngå dette skal
det ved tilkopling av utstyret til kabel-TV nettet installeres en galvanisk isolator
mellom utstyret og kabel- TV nettet.
Utrustning som är kopplad till skyddsjord via jordat vägguttag och/eller via
annan utrustning och samtidigt är kopplad till kabel-TV nät kan i vissa fall medfőra risk
főr brand. Főr att undvika detta skall vid anslutning av utrustningen till kabel-TV nät
galvanisk isolator finnas mellan utrustningen och kabel-TV nätet.
Précautions générales relatives à l'équipement
Caution
L’utilisation de commandes ou de réglages ou l'exécution de procédures autres que
celles spécifiées dans les présentes peut engendrer une exposition dangereuse aux
rayonnements.
Caution
L’usage de PTP 820S s’accompagne du risque suivant d'électrocution et de danger
électrique : le débranchement d'une alimentation électrique ne déconnecte qu'un
module d'alimentation électrique. Pour isoler complètement l'unité, il faut débrancher
toutes les alimentations électriques.
Caution
Bruit de machine d’ordre - 3. GPSGV, le plus haut niveau de pression sonore s'élève à
70 dB (A) au maximum, dans le respect de la norme ISO EN 7779.
Allgemeine Vorsichtsmaßnahmen für die Anlage
Caution
Wenn andere Steuerelemente verwendet, Einstellungen vorgenommen oder
Verfahren durchgeführt werden als die hier angegebenen, kann dies gefährliche
Strahlung verursachen.

Chapter 1: Product description
Safety Precautions & Declared Material
phn-3972 004v000
Page 1-5
Caution
Beachten Sie beim Arbeiten mit PTP 820S das folgende Stromschlag- und
Gefahrenrisiko: Durch Abtrennen einer Stromquelle wird nur ein
Caution
Stromversorgungsmodul abgetrennt. Um die Einheit vollständig zu isolieren, trennen
Sie alle Stromversorgungen ab.
Maschinenlärminformations-Verordnung - 3. GPSGV, der höchste Schalldruckpegel
beträgt 70 dB(A) oder weniger gemäß EN ISO 7779.

phn-3972 004v000
Page 2-1
Chapter 2: Pre-Installation Instructions
This chapter describes the Pre-Installation instructions for PTP 820S.
This chapter includes:
•Packing
•Transportation and Storage
•Unpacking
•Inspection

Chapter 2: Pre-Installation Instructions
Inspection
phn-3972 004v000
Page 2-2
Packing
The equipment must be packed and sealed in moisture absorbing bags.
Transportation and Storage
The equipment cases are prepared for shipment by air, truck, railway and sea, suitable for
handling by forklift trucks and slings. The cargo must be kept dry during transportation, in
accordance with ETS 300 019-1-2, Class 2.3. For sea-transport, deck-side shipment is not permitted.
Carrier-owned cargo containers must be used.
It is recommended that the equipment be transported to the installation site in its original packing
case.
If intermediate storage is required, the packed equipment must be stored in a dry and cool
environment, and out of direct sunlight, in accordance with ETS 300 019-1-1, Class 1.2.
Unpacking
The equipment is packed in sealed plastic bags and moisture absorbing bags are inserted. Any
separate sensitive product such as printed boards, are packed in anti-static handling bags. The
equipment is further packed in special designed cases.
Marking is done according to standard practice unless otherwise specified by customers. The
following details must be marked:
•Customer’s address
•Contract No
•Site name (if known)
•Case Number
Inspection
Check the packing lists and ensure that correct parts numbers quantities of goods have arrived.
Inspect for any damage on the cases and equipment. To report any damage or discrepancy to a
Cambium Networks representative, use e-mail or fax.
