Cambium Networks PTP 820 RFU-E User manual

Installation Guide

phn-4026 003v000
Accuracy
While reasonable efforts have been made to assure the accuracy of this document, Cambium Networks assumes no
liability resulting from any inaccuracies or omissions in this document, or from use of the information obtained herein.
Cambium reserves the right to make changes to any products described herein to improve reliability, function, or
design, and reserves the right to revise this document and to make changes from time to time in content hereof with no
obligation to notify any person of revisions or changes. Cambium does not assume any liability arising out of the
application or use of any product, software, or circuit described herein; neither does it convey license under its patent
rights or the rights of others. It is possible that this publication may contain references to, or information about
Cambium products (machines and programs), programming, or services that are not announced in your country. Such
references or information must not be construed to mean that Cambium intends to announce such Cambium products,
programming, or services in your country.
Copyrights
This document, Cambium products, and 3rd Party software products described in this document may include or describe
copyrighted Cambium and other 3rd Party supplied computer programs stored in semiconductor memories or other
media. Laws in the United States and other countries preserve for Cambium, its licensors, and other 3rd Party supplied
software certain exclusive rights for copyrighted material, including the exclusive right to copy, reproduce in any form,
distribute and make derivative works of the copyrighted material. Accordingly, any copyrighted material of Cambium,
its licensors, or the 3rd Party software supplied material contained in the Cambium products described in this document
may not be copied, reproduced, reverse engineered, distributed, merged or modified in any manner without the
express written permission of Cambium. Furthermore, the purchase of Cambium products shall not be deemed to grant
either directly or by implication, estoppel, or otherwise, any license under the copyrights, patents or patent applications
of Cambium or other 3rd Party supplied software, except for the normal non-exclusive, royalty free license to use that
arises by operation of law in the sale of a product.
Restrictions
Software and documentation are copyrighted materials. Making unauthorized copies is prohibited by law. No part of
the software or documentation may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated
into any language or computer language, in any form or by any means, without prior written permission of Cambium.
License Agreements
The software described in this document is the property of Cambium and its licensors. It is furnished by express license
agreement only and may be used only in accordance with the terms of such an agreement.
High Risk Materials
Cambium and its supplier(s) specifically disclaim any express or implied warranty of fitness for any high risk activities or
uses of its products including, but not limited to, the operation of nuclear facilities, aircraft navigation or aircraft
communication systems, air traffic control, life support, or weapons systems (“High Risk Use”). Any High Risk is
unauthorized, is made at your own risk and you shall be responsible for any and all losses, damage or claims arising out
of any High Risk Use.
© 2019 Cambium Networks Limited. All Rights Reserved.

phn-4026 003v000
Page i
Contents
About This User Guide ...........................................................................................................................................1
Contacting Cambium Networks ......................................................................................................................1
Purpose ...........................................................................................................................................................2
Cross references..............................................................................................................................................2
Feedback .........................................................................................................................................................2
Problems and warranty ..........................................................................................................................................3
Reporting problems.........................................................................................................................................3
Repair and service ...........................................................................................................................................3
Hardware warranty .........................................................................................................................................3
Security advice........................................................................................................................................................4
Warnings, cautions, and notes ...............................................................................................................................5
Warnings .........................................................................................................................................................5
Cautions...........................................................................................................................................................5
Notes ...............................................................................................................................................................5
Caring for the environment ....................................................................................................................................6
In EU countries ................................................................................................................................................6
In non-EU countries.........................................................................................................................................6
Chapter 1: Before You Start............................................................................................................................1-1
Important Notes ................................................................................................................................................. 1-2
Safety Precautions & Declared Material............................................................................................................. 1-3
General Equipment Precautions ................................................................................................................. 1-3
Allgemeine Vorsichtsmaßnahmen für die Anlage ....................................................................................... 1-5
Pre-installation Instructions................................................................................................................................ 1-6
Packing ........................................................................................................................................................ 1-6
Transportation and Storage ........................................................................................................................ 1-6
Unpacking.................................................................................................................................................... 1-6
Inspection.................................................................................................................................................... 1-6
Antenna Types .................................................................................................................................................... 1-7
RFU-E Antenna Types .................................................................................................................................. 1-7
Power Specifications........................................................................................................................................... 1-8
Electrical Requirements .............................................................................................................................. 1-8
Important Notes!......................................................................................................................................... 1-8
Environmental Specifications ............................................................................................................................. 1-8
Chapter 2: Grounding the RFU-E.....................................................................................................................2-9
Chapter 3: Connecting the Data and Power Cables.......................................................................................3-11
Grounding the Cables ....................................................................................................................................... 3-12
Power Source.................................................................................................................................................... 3-15

Contents
phn-4026 003v000
Page ii
Surge Protection ............................................................................................................................................... 3-16
Available Cable Options .................................................................................................................................... 3-17
Fiber Optic Cables - Single Mode............................................................................................................... 3-17
Fiber Optic Cables - Multi Mode ...................................................................... Error! Bookmark not defined.
DC Cable and Connector............................................................................................................................ 3-17
Cat-5e Cable and Specifications ................................................................................................................ 3-17
Outdoor CAT-5e Cable Specifications........................................................................................................ 3-19
Outdoor DC Cable Specifications............................................................................................................... 3-20
Securing the Cables........................................................................................................................................... 3-20
Special Instructions for use of Glands............................................................................................................... 3-21
General Installation Procedure ................................................................................................................. 3-22
Connecting an Optical Fiber Cable and SFP ...................................................................................................... 3-27
Connecting a DC Power Cable........................................................................................................................... 3-31
Connecting a CAT-5e or CAT-6 Data Cable........................................................................................................ 3-34
Chapter 4: Generic Installation Procedures ..................................................................................................4-40
Torque Requirements ....................................................................................................................................... 4-40
Chapter 5: Installation Procedure and Antenna Alignment –1+0 with 43 dBi Flat Antenna and Alignment
Device ....................................................................................................................................................5-41
Pole Mount Assembly and Installation ............................................................................................................. 5-45
Procedure.................................................................................................................................................. 5-45
Wall Mount Assembly and Installation............................................................................................................. 5-47
Attaching the RFU-E to the Installation and Alignment Device ........................................................................ 5-49
Performing Antenna Alignment Using the Enhanced Alignment Kit ................................................................ 5-51
Adjusting the Antenna Azimuth ................................................................................................................ 5-51
Adjusting the Antenna Elevation............................................................................................................... 5-56
Chapter 6: 1+0 Direct Mount Installation......................................................................................................6-59
Chapter 7: RFU-E LEDs ..................................................................................................................................7-63
Electrical GbE Interface (RJ-45) LEDs......................................................................................................... 7-63
Optical GbE Interface (SFP) LED ................................................................................................................ 7-63

Contents
phn-4026 003v000
Page iii
List of Figures
Figure 1: RFU-E Data and Power Interfaces............................................................................................................. 3-11
Figure 2: Cable Design ............................................................................................................................................. 3-18
Figure 3: Tightening the Front Portion of the Gland ............................................................................................... 3-26
Figure 4: Tightening the Rear Portion of the Gland................................................................................................. 3-26
Figure 5: Installation and Alignment Device –Azimuth and Elevation Adjustment Tools....................................... 5-41
Figure 6: Installation and Alignment Device –Azimuth Range................................................................................ 5-43
Figure 7: Installation and Alignment Device –Extended Azimuth Range................................................................ 5-43
Figure 8: Installation and Alignment Device –Delivery Elevation (45° Downward)................................................ 5-44
Figure 9: Installation and Alignment Device –Highest Elevation (45° Upward)...................................................... 5-44
Figure 10: Horizontal Polarization –Radio and Installation and Alignment Kit....................................................... 5-49
Figure 11: Horizontal Polarization –Screws Location.............................................................................................. 5-49
Figure 12: Vertical Polarization –Radio and Installation and Alignment Kit ........................................................... 5-50
Figure 13: Vertical Polarization –Screws Location .................................................................................................. 5-50
Figure 14: Azimuth Screws –Top View (Azimuth 45° to the Right)......................................................................... 5-54
Figure 15: Removing the Azimuth Screws (Side View) ............................................................................................ 5-54
Figure 16: Azimuth Screws in New Placement –Top View (Azimuth 45° to the Right)........................................... 5-55
Figure 17: Repositioning the Azimuth Screws (Side View) ...................................................................................... 5-55
Figure 18: Horizontal / Vertical Pole........................................................................................................................ 6-60
Figure 19: RFU-E LEDs –RJ-45 Interface.................................................................................................................. 7-63
Figure 20: RFU-E LED –SFP Interface ...................................................................................................................... 7-64

Contents
phn-4026 003v000
Page iv
List of Tables
Table 1: RFU-E Integrated Antenna –Electrical Parameters ..................................................................................... 1-7
Table 2: Maximum Cable Length ............................................................................................................................. 3-11
Table 3: Cable Grounding Kit ................................................................................................................................... 3-12
Table 4: Fiber Optic Cables - Single Mode ............................................................................................................... 3-17
Table 5: Fiber Optic Cables - Multi Mode ....................................................................... Error! Bookmark not defined.
Table 6: DC Cable and Connector ............................................................................................................................ 3-17
Table 7: CAT-5e Cable and Specifications................................................................................................................ 3-17
Table 8: CAT-5e Cable Color Code ........................................................................................................................... 3-18
Table 9: Outdoor CAT-5e Cable Specifications –Electrical Requirements .............................................................. 3-19
Table 10: Outdoor CAT-5e Cable Specifications –Mechanical/ Environmental Requirements .............................. 3-19
Table 11: Outdoor DC Cable Specifications –Electrical Requirements ................................................................... 3-20
Table 12: Outdoor DC Cable Specifications –Mechanical/ Environmental Requirements ..................................... 3-20
Table 13: Cable Clamps................................................................................................... Error! Bookmark not defined.
Table 14: Glands Kit ................................................................................................................................................. 3-21
Table 15: Gland Caps ............................................................................................................................................... 3-21
Table 16: Materials for Preparing Ethernet Data Cables ......................................................................................... 3-34

phn-4026 003v000
Page 1
About This User Guide
This guide describes RFU-E installation procedures and provides additional information concerning system parts
and frequency bands.
This guide contains the following chapters:
•Chapter 1: Product description
•Error! Reference source not found.Error! Reference source not found.
•Error! Reference source not found.Error! Reference source not found.
•Error! Reference source not found.Error! Reference source not found.
•Error! Reference source not found. Error! Reference source not found.
•Error! Reference source not found.Error! Reference source not found.
Contacting Cambium Networks
Support website:
https://support.cambiumnetworks.com
Main website:
http://www.cambiumnetworks.com
Sales enquiries:
[e-mail]
Support enquiries:
https://support.cambiumnetworks.com
Repair inquiries
https://support.cambiumnetworks.com
Telephone number list:
http://www.cambiumnetworks.com/support/contact-support
Address:
Cambium Networks Limited,
Linhay Business Park,
Eastern Road,
Ashburton,
Devon, UK,
TQ13 7UP

About This User Guide
Problems and warranty
phn-4026 003v000
Page 2
Purpose
Cambium Networks Point-To-Point (PTP) documents are intended to instruct and assist personnel in the operation,
installation and maintenance of the Cambium PTP equipment and ancillary devices. It is recommended that all
personnel engaged in such activities be properly trained.
Cambium disclaims all liability whatsoever, implied or express, for any risk of damage, loss or reduction in system
performance arising directly or indirectly out of the failure of the customer, or anyone acting on the customer's
behalf, to abide by the instructions, system parameters, or recommendations made in this document.
Cross references
References to external publications are shown in italics. Other cross references, emphasized in blue text in
electronic versions, are active links to the references.
This document is divided into numbered chapters that are divided into sections. Sections are not numbered, but
are individually named at the top of each page, and are listed in the table of contents.
Feedback
We appreciate feedback from the users of our documents. This includes feedback on the structure, content,
accuracy, or completeness of our documents. Send feedback to [e-mail].

About This User Guide
Problems and warranty
phn-4026 003v000
Page 3
Problems and warranty
Reporting problems
If any problems are encountered when installing or operating this equipment, follow this procedure to investigate
and report:
1
Search this document and the software release notes of supported releases.
2
Visit the support website.
3
Ask for assistance from the Cambium product supplier.
4
Gather information from affected units, such as any available diagnostic downloads.
5
Escalate the problem by emailing or telephoning support.
Repair and service
If unit failure is suspected, obtain details of the Return Material Authorization (RMA) process from the support
website.
Hardware warranty
Cambium’s standard hardware warranty is for one (1) year from date of shipment from Cambium Networks or a
Cambium distributor. Cambium Networks warrants that hardware will conform to the relevant published
specifications and will be free from material defects in material and workmanship under normal use and service.
Cambium shall within this time, at its own option, either repair or replace the defective product within thirty (30)
days of receipt of the defective product. Repaired or replaced product will be subject to the original warranty
period but not less than thirty (30) days.
To register PTP products or activate warranties, visit the support website. For warranty assistance, contact the
reseller or distributor.
Caution
Using non-Cambium parts for repair could damage the equipment or void warranty. Contact
Cambium for service and repair instructions.
Portions of Cambium equipment may be damaged from exposure to electrostatic discharge. Use
precautions to prevent damage.

About This User Guide
Security advice
phn-4026 003v000
Page 4
Security advice
Cambium Networks systems and equipment provide security parameters that can be configured by the operator
based on their particular operating environment. Cambium recommends setting and using these parameters
following industry recognized security practices. Security aspects to be considered are protecting the
confidentiality, integrity, and availability of information and assets. Assets include the ability to communicate,
information about the nature of the communications, and information about the parties involved.
In certain instances Cambium makes specific recommendations regarding security practices, however the
implementation of these recommendations and final responsibility for the security of the system lies with the
operator of the system.

About This User Guide
Warnings, cautions, and notes
phn-4026 003v000
Page 5
Warnings, cautions, and notes
The following describes how warnings and cautions are used in this document and in all documents of the
Cambium Networks document set.
Warnings
Warnings precede instructions that contain potentially hazardous situations. Warnings are used to alert the reader
to possible hazards that could cause loss of life or physical injury. A warning has the following format:
Warning
Warning text and consequence for not following the instructions in the warning.
Cautions
Cautions precede instructions and are used when there is a possibility of damage to systems, software, or
individual items of equipment within a system. However, this damage presents no danger to personnel. A caution
has the following format:
Caution
Caution text and consequence for not following the instructions in the caution.
Notes
A note means that there is a possibility of an undesirable situation or provides additional information to help the
reader understand a topic or concept. A note has the following format:
Note
Note text.

About This User Guide
Caring for the environment
phn-4026 003v000
Page 6
Caring for the environment
The following information describes national or regional requirements for the disposal of Cambium Networks
supplied equipment and for the approved disposal of surplus packaging.
In EU countries
The following information is provided to enable regulatory compliance with the European Union (EU) directives
identified and any amendments made to these directives when using Cambium equipment in EU countries.
Disposal of Cambium equipment
European Union (EU) Directive 2002/96/EC Waste Electrical and Electronic Equipment (WEEE)
Do not dispose of Cambium equipment in landfill sites. For disposal instructions, refer to
http://www.cambiumnetworks.com/support
Disposal of surplus packaging
Do not dispose of surplus packaging in landfill sites. In the EU, it is the individual recipient’s responsibility to ensure
that packaging materials are collected and recycled according to the requirements of EU environmental law.
In non-EU countries
In non-EU countries, dispose of Cambium equipment and all surplus packaging in accordance with national and
regional regulations.

phn-4026 003v000
Page 1-1
Chapter 1: Before You Start
This chapter provides technical information about RFU-C installation. This chapter consists of the following
sections:
•Important Notes
•Safety Precautions & Declared Material
•Pre-installation Instructions
•Appendix Antenna Types
•Power Specifications

Chapter 1: Before You Start
Important Notes
phn-4026 003v000
Page 1-2
Important Notes
•For the warranty to be honored, install the unit in accordance with the instructions in this manual.
•Any changes or modifications of equipment not expressly approved by the manufacturer could void the user’s
authority to operate the equipment and the warranty for such equipment.
•RFU-E is intended for installation in a restricted access location.
•RFU-E must be installed and permanently connected to protective earth by qualified service personnel in
accordance with applicable national electrical codes

Chapter 1: Before You Start
Safety Precautions & Declared Material
phn-4026 003v000
Page 1-3
Safety Precautions & Declared Material
General Equipment Precautions
Caution
To avoid malfunctioning or personnel injuries, equipment or accessories/kits/plug-in unit
installation, requires qualified and trained personnel. Changes or modifications not expressly
approved by Cambium Networks could void the user's authority to operate the equipment.
Caution
Where special cables, shields, adapters and grounding kits are supplied or described in this manual,
these items must be used, to comply with the FCC regulations.
Caution
Use of controls, adjustments, or performing procedures other than those specified herein, may
result in hazardous radiation exposure.
Caution
When working with a RFU-C, note the following risk of electric shock and energy hazard:
Disconnecting one power supply disconnects only one power supply module. To isolate the unit
completely, disconnect all power supplies.
Caution
Machine noise information order - 3. GPSGV, the highest sound pressure level amounts to 70 dB (A)
or less, in accordance with ISO EN 7779.
Anti Static
Static electricity may cause body harm, as well as harm to electronic components inside the device.
Anyone responsible for the installation or maintenance of the RFU-C RFU must use an ESD Wrist
Strap. ESD protection measures must be observed when touching the unit. To prevent damage,
before touching components inside the device, all electrostatic must be discharged from both
personnel and tools.
Caution
In Norway and Sweden:
Equipment connected to the protective earthing of the building installation through the mains
connection or through other equipment with a connection to protective earthing –and to a cable
distribution system using coaxial cable, may in some circumstances create a fire hazard. Connection
to a cable distribution system has therefore to be provided through a device providing electrical
isolation below a certain frequency range (galvanic isolator, see EN 60728-11).
Utstyr som er koplet til beskyttelsesjord via nettplugg og/eller via annet jordtilkoplet utstyr –og er
tilkoplet et kabel-TV nett, kan forårsake brannfare. For å unngå dette skal det ved tilkopling av
utstyret til kabel-TV nettet installeres en galvanisk isolator mellom utstyret og kabel- TV nettet.

Chapter 1: Before You Start
Safety Precautions & Declared Material
phn-4026 003v000
Page 1-4
Utrustning som är kopplad till skyddsjord via jordat vägguttag och/eller via annan utrustning och
samtidigt är kopplad till kabel-TV nät kan i vissa fall medfőra risk főr brand. Főr att undvika detta
skall vid anslutning av utrustningen till kabel-TV nät galvanisk isolator finnas mellan utrustningen
och kabel-TV nätet.
Caution
Précautions générales relatives à l'équipement
Caution
L’utilisation de commandes ou de réglages ou l'exécution de procédures autres que celles spécifiées
dans les présentes peut engendrer une exposition dangereuse aux rayonnements.
Caution
L’usage de RFU-C s’accompagne du risque suivant d'électrocution et de danger électrique : le
débranchement d'une alimentation électrique ne déconnecte qu'un module d'alimentation
électrique. Pour isoler complètement l'unité, il faut débrancher toutes les alimentations électriques.
Caution
Bruit de machine d’ordre - 3. GPSGV, le plus haut niveau de pression sonore s'élève à 70 dB (A) au
maximum, dans le respect de la norme ISO EN 7779.

Chapter 1: Before You Start
Safety Precautions & Declared Material
phn-4026 003v000
Page 1-5
Allgemeine Vorsichtsmaßnahmen für die Anlage
Caution
Wenn andere Steuerelemente verwendet, Einstellungen vorgenommen oder Verfahren
durchgeführt werden als die hier angegebenen, kann dies gefährliche Strahlung verursachen.
Caution
Beachten Sie beim Arbeiten mit RFU-C das folgende Stromschlag- und Gefahrenrisiko: Durch
Abtrennen einer Stromquelle wird nur ein.
Caution
Stromversorgungsmodul abgetrennt. Um die Einheit vollständig zu isolieren, trennen Sie alle
Stromversorgungen ab.
Maschinenlärminformations-Verordnung - 3. GPSGV, der höchste Schalldruckpegel beträgt 70 dB(A)
oder weniger gemäß EN ISO 7779.

Chapter 1: Before You Start
Pre-installation Instructions
phn-4026 003v000
Page 1-6
Pre-installation Instructions
Packing
The equipment must be packed and sealed in moisture absorbing bags.
Transportation and Storage
The equipment should be prepared for public transportation. The cargo must be kept dry during transportation, in
accordance with ETS 300 019-1-2, Class 2.3.
It is recommended that the equipment be transported to the installation site in its original packing case.
If intermediate storing is required, the packed equipment must be stored in a dry and cool environment, and out
of direct sunlight, in accordance with ETS 300 019-1-1, Class 1.2.
Unpacking
The equipment is packed in sealed plastic bags and moisture absorbing bags are inserted. Any separate sensitive
product such as printed boards, are packed in anti-static handling bags. The equipment is further packed in special
designed cases.
Marking is done according to standard practice unless otherwise specified by customers. The following details
must be marked:
•Customers address
•Contract No
•Site name (if known)
•Case No
Inspection
Check the packing lists and ensure that correct parts numbers quantities of goods have arrived. Inspect for any
damage on the cases and equipment. Please report any damage or discrepancy to Cambium Networks support by
e-mailing to [e-mail].

Chapter 1: Before You Start
Antenna Types
phn-4026 003v000
Page 1-7
Antenna Types
RFU-E Antenna Types
RFU-E uses two types of antennas:
•Integrated 43 dBi Class 3 antenna
•Direct Mount antenna.
RFU-E Integrated Antenna
The following table describes the electrical parameters of the RFU-E integrated antenna.
Table 1: RFU-E Integrated Antenna –Electrical Parameters
Frequency coverage
71-86 GHz
Gain
43dBi
3dB beam width (azimuth and elevation)
1°
Polarization
Single Linear, V or H
Co/cross-polar ratio
>30dB
Side lobe suppression
ETSI EN 3020217-4 V2.1.1 (2017-05) | CLASS 3
Direct Mount Antenna
RFU-E can be mounted directly using the following antenna types (for integrated antennas, specific antennas are
required):
•CommScope: VHLP series
The Direct Mount antenna interface is according to:
Waveguide Standard
Antenna Flange
WR12
UG387/U
If a different antenna type (CPR flange) is used, a flange adaptor is required. Please contact your Cambium
Networks representative for details.
Note
Appropriate lubricant or grease can be applied to the screws that connect the RFU-E to the antenna
interface.

Chapter 1: Before You Start
Environmental Specifications
phn-4026 003v000
Page 1-8
Power Specifications
Electrical Requirements
•Maximum Power Consumption: 43W (RFU-only)
Important Notes!
•The unit must only be installed by service personnel.
•The unit must have a permanent connection to protective grounding.
•The RSL interface connector is intended for technician use only.
•When using an external power source, the disconnect device (circuit breaker) in the building installation:
oShall be readily accessible and incorporated external to the equipment.
oThe maximum rating of the overcurrent protection shall be up to 6 Amp.
Environmental Specifications
Operating: ETSI EN 300 019-1-4 Class 4.1
Temperature range for continuous operating temperature with high reliability:
-33°C (-27°F) to +55°C (131°F)
Temperature range for exceptional temperatures; tested successfully, with limited margins:
-45°C (-49°F) to +60°C (140°F)
Humidity: 5%RH to 100%RH
IEC529 IP66
Storage: ETSI EN 300 019-1-1 Class 1.2
Transportation: ETSI EN 300 019-1-2 Class 2.3
