Instruction Manual WRS-1060 Iphone 4 and 4s Viewfinder
1
WRS-1060
Viewfinder Iphone®4/4s Viewfinder
INSTRUCTION MANUAL
EN
Please read this manual carefully before using the Cambo WRS-1060 holder!
CAUTION: Tighten the clamping knob with care, do not over tighten the clamp!
CAUTION: Before use ensure that the Iphone®is mounted correctly!
The Cambo WRS-1060 holder is compatible with the Apple®Iphone®4 and 4s.
WRS-1095 shoe mount adapter
WRS-1096 WRS-AE adapter
The WRS-1090 can be mounted directly to the Cambo WRS-
1200 series.
For camera’s that feature a accessory shoe mount, the WRS-
1095 shoe adapter can be used.
For the Cambo Anniversary Edition camera the WRS-1096
WRS-AE adapter can be used.
The centring pins ensure a correct alignment of the Iphone®
holder.
First tighten the right screw
using a flat screw driver or a
long Allen key (3mm)
Flip the holder 90⁰by pressing
the “lock A”, please tighten the
second screw.
Before inserting the Iphone®4/4s in the holder please loosen
the clamp by turning “knob B” counter-clockwise. When the
clamp part is all the way up, now you can gently insert the
Iphone® 4/4s in the holder (as displayed in the image above).
When the Iphone®is fully inserted in the holder, please ensure
that the backside of the Iphone®is parallel to and touching the
holder. Now you can gently tighten “knob B”, don’t over tighten
the clamp!, this could damage your Iphone®.
Note: when the volume knobs are pressed, the Iphone is not parallel to the holder, please adjust the alignment of the Iphone®.
Lock A
Knob B

Instruction Manual WRS-1060 Iphone 4 and 4s Viewfinder
2
Fasten, turn counter-clockwise (CCW)
Loosen, turn clockwise (CW)
The WRS-1090 Iphone holder uses the
Schneider Optics®Century®wide angle
lens (0,65x). The Century iPro lens
system uses a bayonet mount.
Please align the bayonet and mount
shape of the holder and insert the lens.
To fix the lens please turn the lens
counter-clockwise (30° turn).
To loosen the lens please turn the lens
clockwise. After a 30° CW gently take out
the lens.
To change form “landscape” to “portrait” format, please press
“lock A”. While pressing the lock you can turn the Iphone®
holder CW.
At a 90⁰turn the lock snaps in the new position and is fixed. To
return to landscape position please press “lock A” again and turn
the Iphone®holder 90⁰CCW until the lock snaps into the new
position.
Viewfinder Pro (iOS App) www.direstudio.com/viewfinder
You can use the “Viewfinder Pro” App, designed by “DIRE Studio”. This App is available on the App Store. For
instructions please download the “Viewfinder Handbook” at “direstudio.com”.
Cambo Photographic Industry B.V.
Cambo R&D 11-6-2012
This instruction manual is prepared with care, although no responsibility, financial or otherwise, is accepted for any
consequences related the information stated in this instruction manual. All specifications in this instruction manual
are subject to change without notice.
For more information please visit the Cambo web site: www.cambo.com
