Campanola Global Art Collection Y392 User manual

Global Art Collection Y392
取扱説明書
INSTRUCTION
MANUAL

12 13
ABOUT MECHANICAL WATCHESBEFORE USING THIS WATCH
A mechanical watch keeps its accuracy best when its mainspring is sufficiently wound.
We recommend seeking the assistance of an experienced watch technician for sizing of
your watch. If adjustment is not done correctly, the bracelet may unexpectedly become
detached leading to loss of your watch or injury. Consult the shop where you purchased
the watch. In the event that you have moved or have received your watch as a gift, and
after-sales-support of the retailer is not available, please consult the authorized service
center.
Be sure to remove any protective stickers that may be on your watch (case back, band,
clasp, etc.). Otherwise, perspiration or moisture may enter the gaps between the protective
stickers and the parts, which may result in a skin rash and/or corrosion of the metal parts.
Accuracy of a mechanical watch varies affected by gravity. The accuracy varies as the result
that the watch may take various attitude while worn and gravitate to a different direction
every moment.
Metal parts are used for the part for keeping accuracy in a mechanical watch. The accuracy
varies affected by their thermal expansion and contraction and change of physical
characteristics of a spring owing to temperature variation.
The mechanical watch may be magnetized once it is placed near magnetism. Magnetism
remains in the watch even after it is distanced from the source of magnetism and may
degrade the watch accuracy. In that case, the watch needs to be repaired. Please beware not
to place your watch near magnetism.
Smartphone / Television / Portable music player / Audio speaker / Headphone / Notebook PC
Magnetic health device / Coded electric shaver / Handbag clasp / Refrigerator door (magnetic) etc.
＊The watch is strongly affected by magnetism when they are in close contact; however, when the
watch is distant around 5cm away from the source of magnetism, it is almost not affected by it at all.
Accuracy of a mechanical watch is owing to evenness of rotation of the balance. Strong
shocks and continuous shocks strongly affect movement of the balance and give very bad
effect to accuracy of it. Strong shocks may even deform or break the balance. Take care not
to drop the watch and not to play sports which may give strong shocks to your wrist such as
golf or tennis.
The accuracy of a mechanical watch in this instruction manual is static accuracy. Accuracy
of a mechanical watch may not be kept within a normal accuracy range due to using
conditions such as below.
Winding amount of the mainspring
Band adjustment
Protective stickers
Posture of the watch
Temperature
Magnetism
Impact and others

14 15
OPERATION PROCEDURE
Winding direction
Hour hand Minute hand
Crown
Parts and names Winding the mainspring
This watch is a mechanical watch driven by mainspring.
1. Push the crown in to position .
2. Rotate the crown to wind the mainspring.
・ The movement can be wound by turning the crown to the right when it is in position .
・ Turn the crown slowly to minimize the bad effects on the watch parts.
・ When the movement is fully wound, the crown will not be turned to the right anymore.
If you try to further turn the crown, watch parts may be damaged.
・
To keep the watch accuracy, it is recommended to wind the movement every day.
1. Pull the crown out to position .
2. Rotate the crown to adjust the time.
3. Push the crown in to position to finish the procedure
Mechanical watches may become inaccurate due to insufficient lubrication or worn parts.
Have the watch disassembled and cleaned (overhaul) every 2-3 years (charge basis).
It may be difficult to restore the watch from degradation after long-term use to its initial
performance even after repairs.
Adjusting the time
Maintenance
Second indication
on the tourbillon
Specifications
Model : Cal. Y392
Type : Manual winding mechanical watch
Number of jewels : 29
Timekeeping Accuracy : -4 seconds to +20 seconds per day (static accuracy)
Time display : hour and minute, and the second indication on the tourbillon
Rough indication of maximum run time : about 90 hours (when fully wound)
Beats : 21,600 times per hour (6 beats)
Note
Accuracy was measured statically. As the characteristics of the mechanical watch, its
accuracy may be affected by actual usage conditions (continuous wearing time, watch
orientation, arm movement, winding condition of the main spring, etc.) and may be
deteriorated more than the stated daily accuracy. Maximum run time stated is a rough
indication.

16 17
WARNING Can cause serious injury or death
CAUTION Can or will cause minor or moderate injury or damage
Warning (caution) symbol followed by prohibited matters.
Warning (caution) symbol followed by instructions that should be followed or
precautions that should be observed.
HANDLING PRECAUTIONS
This leaflet contains instructions that should be strictly followed at all times not only for
optimal use, but to prevent any injuries to yourself, other persons or property. We encourage
you to read the entire leaflet and understand the meaning of the following symbols:
○Safety advisories are categorized and depicted in this leaflet as follows:
○Important instructions are categorized and depicted in this manual as follows:
(Following symbols are examples of Pictograms.)
Water resistance indication Usage
WATER RESIST (W.R.) Splash and rain
・ Confirm water resistance performance of the watch and avoid to use it in environments
beyond its performance.
Water resistance performance is indicated on the case back and/or the dial of the watch.
・ Do not use or keep the watch in a place of extremely high or low temperature. Especially,
environment with high temperature as follows may cause damage and/or malfunction
of the watch:
- In a sauna, near a halogen lamp (within 50 cm (20 inches)), on the dashboard of a car.
・ Take off the watch when you do hard exercise or physical work.
・ Do not operate the crown when the watch is wet.
・ Do not contact the watch with or bring it near the things below:
Chemicals (gasoline, nail-polish remover, cresol, bathroom cleaners, adhesives, water
repellent), magnetism (magnets, speakers), static electricity.
・ Do not apply strong shock to the watch.
・ Keep the watch clean.
CAUTION
WARNING
• Do not use watches other than those specified for diving for scuba or saturation diving.
