SAFETY CONDITIONS. IMPORTANT INSTRUCTIONS ON SAFETY OF USE
PLEASE READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
The warranty conditions are different, if the device is used for commercial purpose.
1. Before using the product please read carefully and always comply with the following
instructions. The manufacturer is not responsible for any damages due to any misuse.
2. The product is only to be used indoors. Do not use the product for any purpose that is
not compatible with its application.
3. The appliacable voltage is 230V ~50Hz. For safety reasons it is not appropriate to
connect multiple devices to one power outlet.
4. Please be cautious when using around children. Do not let the children to play with the
product. Do not let children or people who do not know the device to use it without
supervision.
5. WARNING: This device may be used by children over 8 years of age and persons with
reduced physical, sensory or mental capabilities, or persons without experience or
knowledge of the device, only under the supervision of a person responsible for their
safety, or if they were instructed on the safe use of the device and are aware of the
dangers associated with its operation. Children should not play with the device.
Cleaning and maintenance of the device should not be carried out by children, unless
they are over 8 years of age and these activities are c arried out under supervision.
6. After you are finished using the product always remember to gently remove the plug
from the power outlet holding the outlet with your hand. Never pull the power cable!!!
7. Never leave the product connected to the power source without supervision.
8. Never put the power cable, the plug or the whole device into the water. Never expose
the product to the atmospheric conditions such as direct sun light or rain, etc.. Never
use the product in humid conditions.
9. Periodically check the power cable condition. If the power cable is damaged the product
should be turned to a professional service location to b e replaced in order to avoid
hazardous situations.
10. Never use the product with a damaged power cable or if it was dropped or damaged
in any other way or if it does not work properly. Do not try to repair the defected product
yourself because it can lead to electric shock. Always turn the damaged device to a
professional service location in order to repair it. All the repairs can be done only by
authorized service professionals. The repair that was done incorrectly can cause
hazardous situations for the user.
11. Never put the product on or close to the hot or warm surfaces or the kitchen
appliances like the electric oven or gas burner.
12. Never use the product close to combustibles.
Even when
use is interrupted for a short time, turn it off from the network, unplug the power.
13. Do not let cord hang over edge of counter.
14. Do not immerse the motor unit in water.
15. Before you turn on the appliance, make sure that all parts have been installed properly.
16. Use only the accessories provided by the manufacturer.
17. Do not put your hands or any objects into the feed hole (1.2) when the appliance is in
operation. For this purpose, use only the pusher (1.1).
18. Put fruit into the feed hole when the appliance is in operation. The feed hole must not
be filled with fruit or vegetables during a standstill.
19. Be careful not to overload the juice extractor. Do not use too much force when pushing
ENGLISH
3

the products through the feed (1.2).
20. If the appliance is not used or you want to clean it, always disconnect it from the mains
and disconnect the feeder cable from the juice extractor.
21. Do not dismantle the appliance if it is connected to a power socket.
22. Do not use abrasive cleaning sponges or caustic cleaning agents for cleaning the
appliance.
23. The appliance may not be operated for more than 20 minutes without a break.
24. Do not put any hard material, large seeds, ice or frozen products into the feed hole of
the juice extractor.
25. It is recommended to dismantle the juice extractor and thoroughly wash parts (1.1) to
(1.6) immediately after use.
DEVICE DESCRIPTION (Figure 1)
1. Pusher 2. Feed
3. Worm 4. Mesh filter
5. Rotary drivers 6. Bowl
7. Body 8. Pulp container
9. Juice container 10. Cleaning brush
ASSEMBLING THE APPLIANCE
1. Wash those parts of the appliance that are going to have a direct contact with the fruit and juice.
2. Place the worm (1.3) inside the mesh filter (1.4). Rotate the worm, pressing it slightly down the mesh filter.
The worm will fit into its place. Then, place them in part (1.5). Make sure that the rubber drivers are properly secured in place.
3. Place the 3 joined above-mentioned parts in the bowl (1.6). Rotate parts (1.3), (1.4) and (1.5), pressing them slightly down to make
them fit in the right place.
4. Place the parts assembled in this way in the base of the appliance (1.7), in accordance with Figure 2.
Place the feed (1.2) on the top and attach it to the juice extractor by turning it clockwise (Figure 4).
5. Place the pulp and juice containers under the holes (Figure 5).
USE
1. Place the juice extractor on a smooth, flat and stable surface. Make sure that the appliance is turned off (the "0" position) before
inserting the plug into the socket.
2. Wash the fruit or vegetables that you want to use. If they do not fit into the feed, (2) cut them into smaller pieces.
3. Start the juice extractor by setting the switch on the cover to "ON".
The juice extractor should not be operated without any products in the feed longer than for 30 seconds.
4. If the juice extractor gets blocked during operation as a result of too much product between the worm and the mesh filter, turn off the
appliance by setting the switch to "0". Then, set the switch to the "R" position to start reverse rotation. If this does not help to unblock
the juice extractor, unplug the device from the power supply, remove parts (1.2) to (1.6) and clean them manually.
5. When you have finished extracting the juice, turn off the appliance by setting the switch to the '0' position and
unplug it from the socket.
CLEANING AND MAINTENANCE
1. For easier cleaning, rinse removable parts under running water immediately after every washing. After rinsing, leave the parts to dry.
2. After dismantling, all removable parts can be cleaned in warm water with dishwashing liquid.
3. The stainless steel mesh filter (1.4) must be rinsed in warm water with a little dishwashing liquid not later than 10 minutes after the
end of operation.
4. Do not immerse the mesh filter (1.4) in bleaching preparations.
5. The mesh filter (1.4) is a part that can be easily damaged. Always handle it carefully.
6. Use the included cleaning brush (1.10) to thoroughly clean the mesh filter (1.4).
7. In the lower part of the bowl there is a rubber plug. It can be gently removed in order to facilitate the washing of the rectangular pulp
outlet. After washing, the rubber plug should be replaced in the bowl outlet.
8. Wipe the body (1.7), which contains the juice extractor motor, with a soft cloth.
9. Juice may cause discolouration of plastic parts. Wash plastic parts immediately after you have used the juice extractor.
10. All metal parts should be thoroughly washed and dried.
NOTE: Never immerse the motor unit in water, nor rinse under the tap.
TECHNICAL DATA
Supply voltage: 220-240V ~ 50Hz
Maximum power: 150W
Maximum operating time: 20-minutes' operation - 60-minutes' break
4
To protect your environment: please separate carton boxes and plastic bags and dispose them in corresponding waste
bins. Used appliance should be delivered to the dedicated collecting points due to hazarsous components, which may
effect the environment. Do not dispose this appliance in the common waste bin.
