Camtree C-Kit-201 User manual

All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any
means, electronic, mechanical, photocopying, recording, or otherwise, except as may be expressly permied
by the applicable copyright statutes or in wring by the Publisher.
I N S T R U C T I O N M A N U A L
Camera Shoulder Mount Kit 201
(C-Kit-201)

CAMTREE Shoulder Kit 201 2
I N T RO D U C T I O N
Customer demand for support equipment to match today’s sophiscated and smaller DSLR’s
connues to grow as the technology for image capture evolves along with the intended use.
Smaller, lighter, faster, more exible, applies not only to modern cameras, these terms can also
be used to describe the support equipment that enhances a shooters cra. Our CAMTREE
Shoulder Kit-201 is a prime example of that support.
I N T H E B OX
Please inspect the contents of your shipped package to ensure you have received all that is
pictured and listed below. The grey foam shipping /storage container has been especially
designed to protect your purchase while in transit and is a good place to keep your CAMTREE
Shoulder Kit 201 when not in use.
Camshade Mae Box
Top Handle
9" Camera Cage
Counter Weight
Camera /Tripod Mount
Quick Release
Telescopic handle
9 X 300mm Female threaded rods
Straight Bracket Juncon Rod
Adapter
Shoulder Pad
2 X 150mm Male threaded rods
Speed Crank
6pc Gear Ring Set
X5 Follow Focus
Accessories
Mic Suspension 15mm Adapter

CAMTREE Shoulder Kit 201 3
A S S E M B LING YO U R C A M S H A D E M AT T E B OX
 Insert the french ag in to the mae box and ghten the screws. Using the same approach,
insert the side ags into the (big) slots provided in the hinges and secure with the screws.
 Fit one side (the broad side) of the knicker into the back clamp of the knicker ring. The knicker
can be easily loosened or ghtened by pressing the clip provided. The fabric can be stretched
over your lens to completely prevent light leaks.
 Insert the lter holders as shown in the
image.
Note: For beer gripping of the lter in
the lter holder, reghten the lter tray
knob to secure the lter properly.

CAMTREE Shoulder Kit 201 4
A S S E MB L I N G Y O U R SH O U L D E R K I T 2 0 1
 Attach the quick release plate of your tripod head with base plate & mount the
base plate on fluid head and secure it properly.
 Now insert the rods into 15mm rod adapter and ghten the knob to secure properly.
 Aach the camera with camera plate and ghten the screw with the help of screw driver .
Now slide the setup onto tripod stand & the ghten the knob to secure it properly.

CAMTREE Shoulder Kit 201 5
 Now insert 300mm rods into cage brackets while inserng you can add 15mm adapter in
the middle to aach other accessories.
 Insert the 300mm long rods into the front and back 15mm slots on the cage bracket & Secure
Properly.
 Then insert the set of 300mm rods into the top rod holder of cage. Then aach the top handle
on the front bracket of cage and secure properly.

CAMTREE Shoulder Kit 201 6
 Insert the shoulder pad & counter weight to the rods, ghten the knob to secure properly.
 Now screw-in the 150mm male rods
into the front of 300mm female rods.
 Aach the straight bracket to the back side of rods, then insert 300mm rods into it and
ghten with provided knob to secure properly.
AT TA C H I N G T H E F O L L O W FO C U S

CAMTREE Shoulder Kit 201 7
 Attach gear ring to camera lens and tighten properly. Insert X5 follow focus to
front of rods and secure it properly with the help of provided knob.
 Now attach the matte box to the front of rods, align the knicker with the lense
barrel and tighten the knot.
 Attach the junction rod adapters and slide-in the rod through it in order to
attach the handles & tighten the knobs to secure properly.

CAMTREE Shoulder Kit 201 8
CA MT RE E SH OULD ER K IT 201 SE T UP I S R EA DY TO US E
WARRANTY
We oer a limited me warranty for our products. For Mechanical products we provide a 6
month warranty & for electronic products we provide a 3 month warranty from the date of
purchase.
We will repair or replace your product, free of charge, in the event of a defect in materials or
crasmanship obtained during normal use or handling based on the user manual. Please note
that we will not cover any shipping costs for returning the product to us. If any VAT or import
dues are applied to the return, we will also charge these costs to the customer.
The warranty does not include, by the way of example, damage caused by products that we do
Exclusive of Camera, Head, Mic and Tripod Stand
 Attach the handles at both sides and tighten the knobs to secure properly.

CAMTREE Shoulder Kit 201 9
not supply or from mishandling in transit, accident, misuse, neglect, lack of care of the product ,
or service by anyone other than our company.
We are not liable for incidental or consequenal damages resulng from the use of the unit or
occurring due to any breach of this warranty.
Replacement parts of the product will be provided at nominal cost (covering the cost price of the
replacement parts only) to the customers aer the Warranty Period has expired. We will cover
the complete cost of sending replacement parts within the warranty period. Aer that, Nominal
cost of the product & Actual shipping cost will be charged.
Do not send the unit to us without rst geng a response and geng the approval to send back
the item.
In case of any kind of dissasfacon, we urge you to Contact us immediately and we shall do our
best to help you out.
For any other assistance you can reach us via email.
