Camtree CH-RSE-SRK User manual

Instruction Manual
Shoulder Rig Kit for Red
Scarlet/Epic (CH-RSE-SRK )

2
Subject Page
Foreword 3
Introducon 4-5
Assembling 5-11
Warranty 12
At Proaim, our goal is to ensure 100% Customer Sasfacon in all that we do.
We back our sales with a 1 year warranty from the date of purchase and work hard
to resolve any problems in the unlikely event one should arise.
With our commitment to connuous improvement and your Feedback, building on
our reputaon of providing aordable, quality products is
PRIORITY #1.
Table of Contents

3
Dear Client,
On behalf of all the people that work so hard to provide you with the most
up-to-date, exible and cost-ecient producon gear, we would like to welcome
you into the Proaim family.
By purchasing your Proaim Shoulder Rig Kit for Red Scarlet/Epic, you have just
joined a host of designers, engineers, machinists, assembly, customer service and
oce sta that take great pride in all that they do. Our mantra of connuous
improvement has been the guiding principle of how we conduct our business since
day one.
Once you have the opportunity to experience your new Proaim Shoulder Rig Kit for
Red Scarlet/Epic, we hope you will agree that we cra quality products at a
compeve price. Products designed to meet and exceed the standards of today’s
real producon world.
Standards set by our valued clients and standards we strive to maintain.
With Best Wishes,
Proaim Team
Welcome To Proaim!

4
Introducon
Our Camtree Hunt Camera cage Shoulder Rig Kit for Red Scarlet /Epic (CH-RSE-SRK)
not only it protects the camera from the rigors of producon but also converts it
into a full edge producon tool. This Robust rig enables easy & comfortable
handheld operaon and allows aaching various accessories for more possibilies
on the professional front. This package includes a high-grade mae box for
cinemac eects, durable follow focus for accurate focus pulls & EVF mount for
connecng View Finder or LCD.
What’s In The Box
Please inspect the contents of your shipped package to ensure you have received
everything that is listed below.
Shoulder Pad
C-MB-20 mae box Cage Brackets Top Plate + 15mm
Rod Adapter
EVF Mount Top plate Base plate
Flip Follow Focus Gear Belt Speed crank
2x 300mm female rods 2x 200mm female rods
Dovetail plate for
shoulder mount
Dovetail Plate for
tripod mounng
Rosee handle set

5
Assembling
 Aach your Red Scarlet / Epic camera with Base Plate. Then aach Dovetail Plate for tripod
mounng to Base Plate. Tighten both with provided screws to secure them.
Storage Box
 Now aach Quick Release Plate to Dovetail Plate and mount it on tripod. Tighten the knobs
to secure it well.

6
 Aach the four Cage Brackets to Base Plate and x them ghtly using allen key. Then mount
Top Plate with 15mm rod adapter on Cage Brackets.
 Aer aaching the Top Plate, ghten all
screws on Cage Brackets.
 Now slide-in Top Handle on 15mm rod adapter and ghten the knob to secure it.

7
 Insert the two 200mm aluminium rods into 15mm adapter holes on top of the Cage and
ghten the knob properly.
 Similarly, insert the two 300mm aluminium rods into 15mm rod adapter of Base Plate and
ghten the knob correctly.
 In order to mount an EVF to your cage, aach it on top with 200mm aluminum rods and
ghten the knob.

8
 Mount Gear Belt over camera lens focusing ring and aach Follow Focus on 300mm rods.
Align the drive gear with Gear Belt and secure the knob ghtly.
NOTE: You can use Speed Crank for precise
focusing.
 Aach Mae Box on 300mm rods and
ghten the knob properly.
Aaching the Follow Focus
Aaching the Mae Box

9
 Align knicker to Mae Box, mount it over
the front lens and ghten its thread.
 Aach Rosee Handle Brackets to Cross Bar and ghten with provided knobs to secure as
shown.
NOTE: To use your setup as Shoulder Mount Rig, consider following steps to assemble:
 Loosen red knobs of Base Plate and press the red buon of Dovetail Plate. Then remove the
Dovetail Plate from Base Plate.
Aaching the Handle Set & Shoulder Pad

10
 Now aach Handle Grips to Handle Brackets and ghten the knobs to secure. You can also
adjust the angle of Handles by using these knobs.
 Then aach this Dovetail Plate to the Base Plate, along with Handle Set and ghten the
 Now slide-in Dovetail Plate for shoulder mounng onto the Cross Bar and secure with
provided knob.

11
 Finally, aach Shoulder Pad towards the back of Dovetail Plate and ghten the knob.
YOUR CAMTREE HUNT CAMERA CAGE SHOULDER RIG KIT
ALL DRESSED UP AND GOOD TO GO
(SHOWN WITH OPTIONAL ACCESSORIES)

12
WARRANTY
We oer a one year warranty for our products from the date of purchase.
We will repair or replace your product, free of charge, in the event of a defect in materials or
crasmanship obtained during normal use or handling based on the user manual. Please note
that we will not cover any shipping costs for returning the product to us. If any VAT or import
dues are applied to the return, we will also charge these costs to the customer.
The warranty does not include, by the way of example, damage caused by products that we do
not supply or from mishandling in transit, accident, misuse, neglect, lack of care of the product ,
or service by anyone other than our company.
We are not liable for incidental or consequenal damages resulng from the use of the unit or
occurring due to any breach of this warranty.
Replacement parts of the product will be provided at nominal cost (covering the cost price of the
replacement parts only) to the customers aer the Warranty Period has expired. We will cover
the complete cost of sending replacement parts within the warranty period. Aer that, Nominal
cost of the product & Actual shipping cost will be charged.
Do not send the unit to us without rst geng a response and geng the approval to send back
the item.
In case of any kind of dissasfacon, we urge you to Contact us immediately and we shall do our
Best to help you out. For any other assistance you can reach us via email.
