I N S T R U C T I O N M A N U A L
CAMTREE HUNT Dovetail Shoulder Mount Rig With Plate
For Red One Camera - ARRi Standard

CAMTREE HUNT Dovetail Shoulder Rig For Red One Camera 2
INTRODUCTION
Taking into consideraon the requirements of our customers, Shoulder Rig for Red One is surely a
perfect example fullling all your producon needs. Featuring long comfortable base plate for
Red One with mulple mounng opons makes it a worth buy. Rendering awless cinematog-
raphy is the sole purpose of our product.
IN THE BOX
Please inspect the contents of your shipped package to ensure you have received all that is pic-
tured and listed below. The grey foam shipping /storage container has been especially designed
to protect your purchase while in transit and is a good place to keep your CAMTREE HUNT Dove-
tail Shoulder Mount Rig With Top Handle & Base Plate For Red One Camera when not in use.
 Aach top handle to camera and ghten the allen bolts properly to ensure slip free connec-
on as shown below.
Assembling of Shoulder Rig
Top Handle
Dovetail Tripod Plate
Dovetail Plate
Cross Bar
Rose Handles
Rosee handle Brackets
Dovetail shoulder mount
Base plate with quick
release
300mm rods

CAMTREE HUNT Dovetail Shoulder Rig For Red One Camera 3
 Insert 300mm rods to camera top handle and secure with the help of provided knobs.
 Now aach base plate with quick release to camera base and secure with the help of screw
driver.
 Aach dovetail tripod plate with your tripod plate and ghten with screw driver, now
mount tripod plate setup onto your tripod and secure with provided knob.

CAMTREE HUNT Dovetail Shoulder Rig For Red One Camera 4
 Slide the camera setup onto dovetail tripod plate and lock the base with the provided lever
on quick release.
YOUR CAMTREE HUNT TOP HANDLE & BASE PLATE FOR RED ONE CAMERA
ALL DRESSED UP AND READY TO GO
(SHOWN WITH OPTIONAL ACCESSORIES)

CAMTREE HUNT Dovetail Shoulder Rig For Red One Camera 5
Note: If you wish to use your setup as a shoulder mounted rig then you can use following steps to
assemble your rig.
 Aach handle brackets to cross bar and ghten with provided knobs to secure as shown
below.
 Now aach handles to handle brackets and ghten the knobs to secure. You can also adjust
angle of Handles by using these knobs.
 Slide in the dovetail plate onto the cross bar and secure with provided knob.
ASSEMBLING OF DOVETAIL SHOULDER MOUNT RIG

CAMTREE HUNT Dovetail Shoulder Rig For Red One Camera 6
 Loosen the knob on dovetail shoulder mount in order to aach it to dovetail plate.
 Loosen the lever of base plate, slide out the camera setup from tripod, then slide in the set-
up onto dovetail setup and again lock the base with lever as shown below.
YOUR CAMTREE HUNT DOVETAIL SHOULDER MOUNT RIG FOR RED ONE CAMERA
ALL DRESSED UP AND READY TO GO
 now ghten the knob to secure as
shown in image.

CAMTREE HUNT Dovetail Shoulder Rig For Red One Camera 7
(CAMERA IS NOT INCLUDED)
WARRANTY
We oer a limited me warranty for our products. For Mechanical products we provide a 6
month warranty & for electronic products we provide a 3 month warranty from the date of
purchase.
We will repair or replace your product, free of charge, in the event of a defect in materials or
crasmanship obtained during normal use or handling based on the user manual. Please note
that we will not cover any shipping costs for returning the product to us. If any VAT or import
dues are applied to the return, we will also charge these costs to the customer.
The warranty does not include, by the way of example, damage caused by products that we do
not supply or from mishandling in transit, accident, misuse, neglect, lack of care of the product ,
or service by anyone other than our company.
We are not liable for incidental or consequenal damages resulng from the use of the unit or
occurring due to any breach of this warranty.
Replacement parts of the product will be provided at nominal cost (covering the cost price of the
replacement parts only) to the customers aer the Warranty Period has expired. We will cover
the complete cost of sending replacement parts within the warranty period. Aer that, Nominal
cost of the product & Actual shipping cost will be charged.
Do not send the unit to us without rst geng a response and geng the approval to send back
the item.
