C&C TECHNIC PG-HD1X User manual

1
PATTERN GENERATOR
PG-HD1X
USER MANUAL
V.2011PGHD1X100.00
Copyright and Trademarks:
All rights reserved by C&C TECHNIC TAIWAN CO., LTD. No part of this
document may be reproduced in any form or by any means without written
permission from the product manufacturer. Changes are periodically
made to the information in this document. They will be incorporated in
subsequent editions. The product manufacturer may make improvements
and /or changes in the product described in this document at any time.
All the registered trademarks referred to this manual are belonging to their
respective companies.

2
Chapter 1 Introduction ..............................................3
Package Contents .................................................3
Resolution.............................................................4
Features ................................................................4
Specifications .......................................................5
Top Panel..............................................................6
Side Panels ...........................................................7
HD-SDI A Output /HD-SDI B Output .........7
Power Jack....................................................7
Chapter 2 Connection ...............................................8
Connect PG to Monitor ........................................8
Chapter 3 Troubleshooting.......................................9
Appendix A: Pattern Chart......................................10

3
Chapter 1 Introduction
PG-HD1X is an advanced SDI pattern generator for
checking the transmission of the coaxial cable laid in a
HD-SDI system and designing to be a useful tool for the
new generation of digital video/monitor products. It supports
multi-format (HD/SD) and multi-pattern up to 8 patterns for
you to test and calibrate a digital video/monitor. Further, it
also can help you to improve the quality of digital
video/monitor with side-by-side comparisons. Through the
friendly interface and smart design, not only you can easy
and quick to use the device but also you can reduce your
test expenditure.
Caution
To avoid and minimize the risk of damage to the device,
please pay attention to the safety instructions even though
the device had been tested for conformance to safety
requirements and certified for international using.
Follow all instructions marked on the device during using.
Do not attempt to maintain the device by yourself, any
faults, please contact your vendor.
Provide proper ventilation and air circulation and do not
use near water.
It is better to keep it in a dry environment.
Only using the power adapter and connection cables that
are supported with the device.
Please use the Pile Alkaline and the working time for the
battery is about 2~4.5hours.
It is better to charge the battery when the battery power
indicator becomes low.
Do not use liquid or aerosol cleaners to clean the device.
Always unplug the power to the device before cleaning.
Package Contents
1 Dual Link HD-SDI Pattern Generator PG-HD1X
1 power adapter DC 9V
1 user manual
1 SDI 1.2M cable (BNC Male to Male)
1 9V Pile Alkaline
All packages have been checked carefully for their
completeness and functionality before shipped. Please
contact with your vendor if any items listed as above are
missed or damaged.

4
Resolution
Using to test and calibrate a TV/Monitor.
Using to test and calibrate an SDI image input device.
Using to test and maintain studio equipment as monitors,
cabling and recording equipment.
Using to test the arrangement of the circuit layout during
the process of construction.
Features
Intelligent functionality.
Built-in HD-SDI Signal Generator
Video Output: Dual SDI Output.
Support total 7 timings. (up to 1080p@60Dual Link).
Cost-down and single interface and easily to use.
Portable design, inside 9.0Volts Alkaline battery.
Provide total 8 video patterns, Include: GRID_16x12,
COLOR_GRID, BLOCK 16x12, GRAY_8,
COLORGRAY64, COLORBAR, WINDOW, RGB.
Embedded audio tone is a 1KHz.

5
Specifications
Functions Description
Serial Digital BNC Connectors 2
BNC Connector 75ΩInterlocking Socket
Select Switch 2
Unit Description HD/SD-SDI
Pattern Generator
Audio Support YES
Supported Protocols
SMPTE 274M + 372M
SMPTE 296M,
ITU-R BT.601
SDI Standards SD-SDI & HD-SDI
Max. Resolution 1080p@ 60(Dual Link)
Bit Rate 1.485G (2.97G Dual Link)
Cable Distance 5M~
Power Adapter (Min.) DC 9V
Housing Plastic
Weight 180g
Dimensions (LxWxH) 144.5*93*33 mm

6
Top Panel
1. Power/Battery Status:
“●”“ ”LED light ÆPower on.
“” “ ”LED Flash ÆThe battery is in low voltage
status.
)Using the 9V battery singly without a 9V transformer, the
power LED status will flash when the voltage of battery go
down to about Low Voltage. (That is indicating the power
of batter will use up.)
2. Power On/Off: Push the Power SW up to power on your
device (The Power LED is light). Push the Power SW
down to power off your device (The Power LED is dark)
3. Resolution Switch: Support you at least 7 kinds of
resolution for choice. Please refer to “HD-SDI A Output
/HD-SDI B Output”
4. Pattern Switch Button: Switch the Pattern Mode that
you want to test. Please refer to “Appendix A: Pattern
Chart.”
)After you press the Pattern Switch Button, the sequence
of the pattern mode is from upper left to upper right then
from bottom left to bottom right.
1. Power/Battery Status
2. Power On/Off
3. Resolution Switch
4. Pattern Switch Button

7
Side Panels
The PG-HD1X supports SDI interface. The SDI standard
transfers signals are uncompressed and are
self-synchronizing between the source (transmitter) and
destination (receiver). Most errors caused by noise or
interference can be detected, and the lost data recovered
by means of a specialized code called the Hamming code. A
signal in SDI can contain up to four independent digital
audio signals along with the video signal.
HD-SDI A Output /HD-SDI B Output
Use for SDI 1.2M cable (BNC Female to Female).
List of SDI Video Formats:
Format Standard Clock Notes
720 x 576 i 50 ITU-R
BT.601 13.5MHz 625-line “PAL”
720 x 486 i 59.94 ITU-R
BT.601 13.5MHz 525-line
“NTSC”
1280 x 720 p 60 SMPTE
296M 74.25MHz
1920 x 1080 i 60 SMPTE
274M 74.25MHz
1920 x 1080 p 25 SMPTE
274M 74.25MHz
1920 x 1080 p 30 SMPTE
274M 74.25MHz
1920 x 1080 p 60
SMPTE
274M +
372M
74.25MHz Dual Link
Power Jack
Use for the DC 9V power adapter. The Power Jack is on
the side of the device.
Power Jack

8
Chapter 2 Connection
Caution
Please power off the digital monitor and the device before
you begin the connection.
Connect PG to Monitor
Connect the attached adapter cable from your device to
the power source (outlet).
Switch off the monitor.
Connect the BNC extension cord from your device to the
Digital monitor/TV.
Switch on the power of the Digital monitor/TV.
Push the Power SW of your device to power on/off your
device.
Caution
Please use the Pile Alkaline to the device.
SDI Cable
One or Two Digital
monitor/TV

9
Chapter 3 Troubleshooting
1. If there is no reaction when using the device, please
ensure the following matters:
a. If it is unable to power onÆthere is a possibility of
fault battery or inferior battery. Please connect it with
the transformer.
b. If it is able to power on but there is no reactionÆ
Lower the resolution or change the resolution and
vertical frequency.
Please ensure the compatibility the mode of the
monitor.
2. What is the Pattern Generator’s function?
a. Use to test and maintain studio equipment, such as
monitor, cabling, and recording equipment.
b. For a TV engineer or technician wants to test and
calibrate a DTV monitor during repair.
c. A home-theater user wants to get the best results out
of the DTV equipment.
d. A studio installer wants to test cables and equipment
so that can get the best effect.
e. For the DTV sets seller to show side-by-side
comparisons of quality.
f. For teacher to train their students about the latest
DTV quality test technologies.
g. To test a new DTV set whether compatibility with the
ATSC standards.
3. When should I have to charge the battery?
We suggest you to charge the battery when the battery
power indicator has become low; it is not appropriate to
charge the battery when the battery is consumed
thoroughly.
4. What is SDI?
Serial Digital Interface (SDI) is a standard for digital
video transmission over coaxial cable. The most
common data speed is 270 megabits per second
(Mbps). However, speeds of up to 540 Mbps are
theoretically possible. Standard 75-ohm cable is used.
This is the same type of coaxial cable used in most
home television (TV) installations.

10
Appendix A: Pattern Chart
1. 2. 3. 4.
5. 6. 7. 8.
