Cannon Tools NEILSEN CT3404 User manual

DIGITAL BREATH ALCOHOL TESTER CT3404
Ref no. AD3000
USER MANUAL
SAVE THESE INSTRUCTIONS AND PRECAUTIONS.
READ ALL PRECAUTONS AND INSTRUCTIONS BEFORE USE.
Cannon Tools Limited
Address: 20 Station Road, Rowley Regis, West Midlands, B65 0JU.U.K.

EC DECLARATION OF CONFORMITY
We CANNON TOOLS LTD
20 Station road, Rowley Regis, West Midlands,B65 0JU.U.K.
Declare that the following machine complies with the appropriate
basic safety and health requirements of the EC Directive based on
its design and type, as brought into circulation by us.
In case of alteration of the machine, not agreed upon by us, this
declaration will lose its validity.
Product description: DIGITAL BREATH ALCOHOL TESTER
Model: CT3404 (Ref no. AD3000)
Applicable EC Directives:
EMC Directive 2014/30/EU
Harmonized standards
EN 61326-1:2013
20 Station Road, Rowley Regis, West Midlands, B65 0JU.U.K.
Mr. Gurcharan Tony Singh Sanghera
Managing Director
CANNON TOOLS LTD
2020-12-28

1. SEPECIFICATIONS
* Sensor : advanced semiconductor oxide alcohol sensor
* Range : 0.00%-0.19%BAC(0.0-1.9g/l)
* Accuracy : ± 0.01%BAC（0.1g/l）
* Power input : 2 x 1.5V “AAA”alkaline battery
* Operating time : warm up:10s, response: <5s
* Auto power off : 1 minute approx
* Dimension : 115 x 68 x 29mm(approx)
* Environmental temperature : 50C - 400C
Features
1. Digital alcohol tester with audible alert
(When the test results more than 0.05% BAC or 0.5 g/l,it will warn you.)
2.Range : 0.00-0.19 % BAC & 0.0-1.9 g/l
3.Quick response and resume
4.Auto power off
5.Use mouthpiece
6.Key chain
7.Use 2 “AAA”alkaline batteries
Reference
BAC : Blood Alcohol Concentration
0.05% Bac : refers to there is 0.05g alcohol in each 100ml of blood
2. IMPORTANT INSTRUCTIONS
! DO NOT DRIVE AFTER DRINKING ALCOHOL !
We can’t emphasize enough how dangerous it is for you to drink
and drive. Your vision and your brain are the most important
factors in driving safely. If you jeopardize either by drinking, and
then you drive, you are likely to be involved in a serious or fatal
collision.
! WAIT at least 20 minutes, without drinking or smoking before
testing.Rinse your mouth with water before testing!

! The alcohol level in yourblood can keep increasingup to2 hours
after drinking your last alcoholic beverage. A continuous negative
test-result cannot be guaranteed !
!ONLY perform tests in a temperature range between 5-40°C as
This may affect the results!
! DO NOT blow smoke, liquid or food residue into the device !
! Conditions that increase the amount of ketones on your breath,
such as diabetes or low calorie intake may cause false results !
! This test and your test-result cannot be held as juridical proof in
case of law encounters !
The BAC results are for reference only and the test-results cannot
be used as a tool to determinate whether you should operate a
vehicle or not !
The manufacturer, distributer and importer disclaims any legal
responsibility for the measured test-result.
3. TECHNICAL DESCRIPTION
1.Mouthpiece
2.Power button
3.LCD display
4.Battery
compartment
5.Key chain
4. HOW TO USE THE ALCOHOL TESTER

Installing battery
1.Slide open the battery compartment lid from the back of the unit.
2.Insert two“AAA”（UM-4) alkaline batteries with correct polarity as
indicated.
3.Replace the battery compartment lid.
Warm up
1. Press and hold the power button for 1 second,the alcohol
tester LCD will turn on with one beep sound.
2.The “warm up” symbol is displayed,and the 10 to 00 countdown
is started that indicate the tester is in warm-up mode.
Note
It always has a large number of gas & impurity adsorbed on the
surface of alcohol tester,when first time taking out the tester from
the packaging,or after long time no using for the tester, it need
more time for cleaning and warm up the sensor,you should
repress the power button and retry several time if possible.
Test

1.The “Blow”symbol is displayed when warm-up is succeed, and
the 10 to 00 countdown is started that indicate the tester is in
testing mode.
2.Blow into the breath inhaler for 3-5 seconds with normal power
after a deep inhalation..
3.Read the teat result from the alcohol tester LCD.
4.The“Caution” symbol is displayed if the alcohol concentration is
the level:
√0.02% BAC (or 0.2g/I) to 0.05% BAC (or 0.5g/l)
0.05% BAC (or 0.5g/I) to 0.08% BAC (or 0.8g/l)
5.The“Danger”symbol is displayed with beep audible alert if the
alcohol concentration is the level:
√Over&equal 0.05% BAC (or 0.5g/l)
Over&equal 0.08% BAC (or 0.8g/l)
6.If no blow into the breath inhaler at the test mode,the LCD will
display“0.00% BAC& 0.0g/l”value.
Note

To obtain more accurate result,manufacturer recommend you to
check repeatedly 2 or 3 times.
Auto power off
After the result be display for about 10 seconds,the “OFF”symbol
will appear for 2-3 seconds and the alcohol tester be turned off.
Replace mouthpiece
1.Contrarotate once,the mouthpiece will be loosened.
2. Replace the new mouthpiece on the right place, clockwise
rotation,it will be OK.
Backlight
when the tester is turned on,the LCD backlight will light until tester
auto power off.
Replace battery
The LCD filckering indicates low power of batteries, please
replace 2 “AAA”alkaline batteries.
5. PRECAUTION

-When after drinking,it is recommended to last after 20 minutes ,it
is because 20 minutes is approximately for alcohol to be absorbed
into blood from the digestive organs,and residual alcohol
remaining in the mouth takes this long to dissipate:
--For accurate result,do not repeat next testing with in 3 minutes
after last time.
--Do not smoke and eat for 20 minutes prior testing.
--Do not use chemicals to clean the tester directly.
--Do not blowing liquid into the breath pipe.
--Do not use any excitant substances near the tester,such as
paint,insecticides,alcohol.
--Do not place the tester in the closed environment with
contaminated air.
--Modifying or tampering with the unit’s internal components may
cause a malfunction.
--The unit is designed to be used as an aid to promote reasonable
driving,It should not,be used in anticipation of the use or operation
of vehicles,machinery,or equipment. The unit makes no
references whatsoever to blood alcohol content or other such
measures of intoxication promulgated by government,medical or
other agencies or bodies.
Notes
1.Regardless of whether the product is used,manufacturers and
vendors will not bear any responsibility for the violations,for
example: drunk driving and high-altitude operations.
2.Each person reacts differently to alcohol, so the test results are
for reference only, which cannot serve as the criteria in
determining the outcome.
6. COMMON FAULTS AND SOLUTIONS

7. DISPOSAL
At the end of the machine's working life, or when it can no longer
be repaired, ensure that it is disposed of according to national
regulations.
Contact your local authority for details of collection schemes in
your area.
In all circumstances:
Do not dispose of this tool with domestic waste.
Do not incinerate.
Different country alcohol units
Faults
Possible Faults Reason
Solution
Power on failing
Put batteries
incorrectly
Installing batteries in
correct polarity
Very low power
batteries
Replacing the new
alkaline batteries
Circuit Fault
Contacting after-sale
service
Blowing no response
Warm up not
completing
Warm up for more
time
Circuit Fault
Contacting after-sale
service
Blowing no result
Residual gas in tester
Warm up again
Not blowing in
Schedule time
Blowing during
"BLOW"countdown
time
No blowing with test
result
Residual gas in tester
Warm up for more
times
Different result after
several testing
Testing as soon as
drinking
Testing 20 minutes
after drinking
Blowing time different
Deep breath for 3-5
seconds

Common units: %BAC-----USA
g/l-----European
mg/l-----Janpan
mg/100ml-----China
NO.
BAC
(Blood Alcohol Concentration)
BAC
(Breath Alcohol
Concentration)
%
%0
g/l
mg/100ml
mg/l
ppm
1
0.01
0.1
0.1
10
0.05
25
2
0.02
0.2
0.2
20
0.10
50
3
0.03
0.3
0.3
30
0.15
75
4
0.04
0.4
0.4
40
0.20
100
5
0.05
0.5
0.5
50
0.25
125
6
0.06
0.6
0.6
60
0.30
150
7
0.07
0.7
0.7
70
0.35
175
8
0.08
0.8
0.8
80
0.40
200
9
0.09
0.9
0.9
90
0.45
225
10
0.10
1.0
1.0
100
0.50
250
11
0.11
1.1
1.1
110
0.55
275
12
0.12
1.2
1.2
120
0.60
300
13
0.13
1.3
1.3
130
0.65
325
14
0.14
1.4
1.4
140
0.70
350
15
0.15
1.5
1.5
150
0.75
375
16
0.16
1.6
1.6
160
0.80
400
17
0.17
1.7
1.7
170
0.85
425
18
0.18
1.8
1.8
180
0.90
450
19
0.19
1.9
1.9
190
0.95
475
20
0.20
2.0
2.0
200
1.00
500

CANNON TOOLS LTD
Add: 20 station road, Rowley Regis, west midlands,B65 0JU.U.K.
Made in China
