Installing Your Multifunction
to Your Network for the First Time
PIXMA MG6120
Mac OS
1

<< Previous Next >>
Installing Your Multifunction
to Your Network for the First Time
PIXMA MG6120
Mac OS
2
Preparing to Connect My Multifunction To My Network
3
Connecting Your MG6120 To Your Network
5
Installing The MG6120 Software
12

Preparing to Connect My Multifunction
To My Network
Network Requirements
Before connecting the machine to the network, make sure that configuration of the computer and access point or router is
complete, and that the computer is connected to the network.
3
<< Previous Next >>

Preparing to Connect My Multifunction
To My Network
4
Notes on Network Connection
•The configuration, router functions, setup procedures and security settings of
the network device vary depending on your system environment. For details,
refer to your device's instruction manual or contact its manufacturer.
•In an office setup, consult your network administrator
•If you connect to a network that is not protected with security measures,
there is a risk of disclosing data such as your personal information to a third
party.
•If an error message appears or if you have trouble with the network
connection, refer to the printed manual: Network Setup Troubleshooting.
•Place the machine and computer on the same network segment.
An "Ad-hoc connection," which establishes a direct
connection to the computer over a wireless connection
without using an access point, is not supported.
Be sure to prepare an access point.
<< Previous Next >>

Connecting Your MG6120 To Your Network
5
Step 1
Use the ↑ or ↓ button (A) to display
Setup, then touch the right
FUNCTION button (B).
Step 2
Use the ← or → button (C) to select
Wireless LAN setup, then touch the
OK button.
<< Previous Next >>

Connecting Your MG6120 To Your Network
6
Step 3
Select Yes, then touch the OK button.
Step 4
Select Easy setup, then touch the OK
button.
When wireless connection is
enabled, the Wi-Fi lamp lights blue.
<< Previous Next >>

Connecting Your MG6120 To Your Network
7
Step 5
Select the access point name you
wrote down, then touch the OK
button.
Step 6
Make sure that one of the below
screens is displayed, then touch the
right FUNCTION button.
Note:
•Nearby access points may be detected.
•Access point names with 2-byte characters are not
displayed properly, however, they can be selected.
If neither is displayed, go to Step 9.
<< Previous Next >>

Connecting Your MG6120 To Your Network
8
Step 7
Enter the network key you wrote down on, then touch the left FUNCTION button (E).
1. Touch the center FUNCTION button (F) to switch
character entry modes.
2. Enter upper and lower case letters of the alphabet
correctly.
<< Previous Next >>

Connecting Your MG6120 To Your Network
9
Step 7 (continued) Character Entry
This machine allows you to enter characters when an on-screen keyboard is displayed.
Follow the procedure below.
1. When the on-screen keyboard
shown above is displayed,
touch the center FUNCTION
button (A) to switch to a
keyboard having the
characters you want to use.
Four character sets are available: Upper-case alphabets, lower-case alphabets, numbers, and
symbols. Each time you touch the center FUNCTION button, the on-screen keyboard is
switched among them.
<< Previous Next >>

Connecting Your MG6120 To Your Network
10
Step 7 (continued) Character Entry
2. Select a character on the on-
screen keyboard using the
↑↓←→ buttons (B) then
touch the OK button to enter
it. Entered characters are
displayed on the upper
section (C) of the on-screen
keyboard.
3. Repeat (1) and (2) to enter
more characters.
4. After you enter all characters
you need, touch the left
FUNCTION button (D).
•To insert a space, select Space on the on-screen keyboard and touch the
OK button.
•To insert characters, select the section (C) of the screen using the ↑ or ↓
button, move the cursor to the character on the right of the target position
using the ← or → button, then enter characters.
•To delete a character, select the section (C) of the screen using the ↑ or ↓
button, move the cursor to the character on the right of the target position
using the ← or → button , then touch the right FUNCTION button (E).
<< Previous Next >>

Connecting Your MG6120 To Your Network
11
Step 8
Make sure that the network key is
correct, then touch the OK button.
Step 9
When the screen below appears,
touch the OK button.
Your MG6120 is now connected to your network
Note:
•If Failed to connect to the access point. appears, touch the OK button, make sure that the network key is correct, then enter it
again. If a connection still cannot be established, refer to the printed manual: Network Setup Troubleshooting.
<< Previous Next >>

Installing The MG6120 Software
12
<< Previous Next >>
Now that your MG6120 is connected to your network, we need
to install the driver and the included software.
Before we begin:
•Log on as the administrator (or a member of the Administrators group).
•Quit all running applications before installation.
•If the firewall function of your security software is turned on, a warning message
may appear that Canon software is attempting to access the network. If such a
warning message appears, set the security software to always allow access.

Installing The MG6120 Software
13
<< Previous Next >>
Step 1
Turn on the computer, then insert the
Setup CD-ROM into the CD-ROM
drive. If you are using Windows, the
setup program starts automatically.
Note:
If the program does not start automatically, double-click
the CD-ROM icon in Computer or My Computer. When
the CD-ROM contents appear, double-click MSETUP4.EXE.
Step 2
Double-click the Setup icon of the
CD-ROM folder to proceed to the
following screen.
Enter your administrator name and
password, then click OK.
If the CD-ROM folder does not open automatically,
double-click the CD-ROM icon on the desktop.
If you do not know your administrator name or
password, click the help button
,then follow the on-screen instructions.

Installing The MG6120 Software
14
<< Previous Next >>
Step 3
Click Easy Install
The drivers, application software, and
on-screen manuals are installed.
Note: If you want to select particular
items to install, click Custom Install.
Step 4
Click Install

Installing The MG6120 Software
15
<< Previous Next >>
Step 5
Select Use the printer on network,
then click Next.
Step 6
When the Printer Detection screen
appears, click Next.
IMPORTANT
IF THE PRINTER CONNECTION SCREEN APPEARS INSTEAD OF THE
SCREEN ABOVE, THE CONNECTION METHOD IS NOT CORRECTLY
SELECTED IN 5.
CLICK CANCEL AND START AGAIN FROM STEP 1, THEN BE SURE TO
SELECT USE THE PRINTER ON NETWORK IN 5.

Installing The MG6120 Software
16
<< Previous Next >>
Step 7
On the Canon IJ Network Tool screen,
select MG6100 series in Printers, then
click Next.
Step 8
When the Register Printer and
Scanner screen appears, click
Register Printer.
Note:
The alphanumeric characters after Canon MG6100
series is the machine's Bonjour service name or MAC
address.
If the machine is not detected, refer to the printed
manual: Network Setup Troubleshooting. Make sure
there is no problem, then click Update

Installing The MG6120 Software
17
<< Previous Next >>
Step 9
For OS X v. 10.6.x and 10.5.x only
Select Canon MG6100 series
canonijnetwork and click Add.
Go to Step 11.
Note: It may take a minute or two before the printer
appears in the list
Step 10
For OS X v. 10.4.11 only
1. When the Printer List window
appears, click Add.
Note: When the “You have no printers available”.
screen appears, click Add.

Installing The MG6120 Software
18
<< Previous Next >>
Step 10 (continued)
2. Click More Printers in the Printer
Browser window.
Step 10 (continued)
3. Click More Printers in the Printer
Browser window.
4. Make sure that Canon MG6100
series is added to the list of
printers.

Installing The MG6120 Software
19
<< Previous Next >>
Step 11
When the Register Printer and
Scanner screen appears, click
Register Scanner.
Step 12
Select MG6100 series on the Scan-
from-Operation-Panel Settings
screen, then click OK.

Installing The MG6120 Software
20
<< Previous Next >>
Step 13
Click Next on the Register Printer and
Scanner screen.
Wireless setup is now complete
Step 14
Follow any on-screen instructions to
proceed with the remaining software
installation.
