Canon BJC-50 Instruction Manual

BJC-50
PARTS
CATALOG
Canon

Parts Catalog BJC-50
NUM. PART # DESCRIPTION NUM. PART # DESCRIPTION
1 of 3
FIGURE 1 PRINTER SET FIGURE 2 UPPER CASE
1 - 1 NPN BLACK BJ CARTRIDGE PACK
COLOR BJ CARTRIDGE PACK
2 NPN CARTRIDGE CONTAINER
3 QH3-3788-000 AC ADAPTOR: 100V~240V 50/60HZ
(OUTPUT 13VDC, 1.8A)
4 NPN COLOR INK CARTRIDGE
5 NPN BLACK INK CARTRIDGE
6 NPN LITHIUM ION BATTERY
7 QH8-0080-000 I/F CABLE
2 - 1 QG5-1125-000 HEAD COVER UNIT
2 QB1-3225-000 COVER, HEAD
3 QB1-3226-000 FILM, INSTRUCTION
4 QG5-1124-000 UPPER CASE UNIT
5 QB1-3218-000 UPPER CASE
6 QB1-3224-000 COVER, CONNECTOR
7 QB1-3223-000 FILTER, IRDA
8 QB1-3221-000 SWITCH 2
9 QB1-3220-000 SWITCH 1
10 QB1-3234-000 COVER, ASF
11 QB1-3190-000 STOPPER, BIG
12 QB1-3191-000 STOPPER, SMALL
13 QB1-3192-000 SWITCH, LOCK (NOT SHOWN)

Parts Catalog BJC-50
NUM. PART # DESCRIPTION NUM. PART # DESCRIPTION
2 of 3
FIGURE 3 CONTROL BOARD FIGURE 4 PRINT UNIT & LOWER CASE UNIT
3 - 1 QB1-3193-000 FILM, PROTECTION
2 QG2-2982-000 CONTROL PCB ASS’Y
3 QG2-2981-000 IRDA UNIT
4 QH7-8947-000 CONNECTOR, ASF
4 - 1 QG5-1117-000 PRINT UNIT
2 QF5-0373-000 LOWER CASE UNIT
3 QG5-1126-000 TRAY UNIT
4 QB1-1135-000 FOOT, RUBBER (B)
NOT SHOWN
5 QB1-3240-000 BUSHING, LEFT
6 QB1-1058-000 CLIP, BUSHING

Parts Catalog BJC-50
NUM. PART # DESCRIPTION NUM. PART # DESCRIPTION
3 of 3
FIGURE 5 PRINTER BASE UNIT FIGURE 6 AC ADAPTER
6 - 1 QH3-3349-000 AC ADAPTOR: 100V~240V 50/60HZ
(OUTPUT 13VDC, 1.8A)
2 WT3-5079-000 CORD, POWER (220V-240V)
3 WT3-5080-000 CORD, POWER (220V-240V,UK)
4 WT3-5081-000 CORD, POWER (220V-240V, AUST)
5 WT3-5082-000 CORD, POWER (100V )
WT3-5085-000 CORD, POWER (250V, CHN)
WT3-5086-000 CORD, POWER
5 - 1 NPN CHASSIS UNIT
2 QG5-1122-000 PRINTER BASE UNIT
3 QG5-1130-000 PINCH ROLLER UNIT
4 QB1-3207-000 SPRING, COIL
