Canon imageRUNNER ADVANCE DX C3800 Series User manual

C an o n
Service Guide

C an o n imageRUNNER ADVANCE DX C3800 Series Service Guide
imageRUNNER ADVANCE DX C3800 Series Service Guide March 2023
Revision 4 Page i
Published by
Canon U.S.A., Inc.
One Canon Park
Melville, NY 11747
1-800-OK-CANON
E-Mail: [e-mail]
Canon U.S.A. Homepage: http://www.usa.canon.com
Canon U.S.A. Internet e-Support Center Website: http://www.support.cusa.canon.com
Canon U.S.A. Partner Portal Website: https://partners.usa.canon.com
Distributed in the United States by Canon U.S.A., Inc.
IMPORTANT
THIS SERVICE GUIDE INCLUDES THE INFORMATION RELATING TO THE imageRUNNER
ADVANCE DX C3835, C3830i and C3826i.
SPECIFICATIONS AND OTHER INFORMATION CONTAINED HEREIN MAY VARY SLIGHTLY FROM
ACTUAL DEVICE VALUES OR THOSE FOUND IN ADVERTISING AND OTHER PRINTED MATTER.
USE OF THIS SERVICE GUIDE SHOULD BE STRICTLY SUPERVISED TO AVOID DISCLOSURE OF
CONFIDENTIAL INFORMATION.
ALL PRICES LISTED ARE SUBJECT TO CHANGE WITHOUT NOTICE.
PART NUMBERS LISTED MAY BE CHANGED WITHOUT NOTICE TO REFLECT ENGINEERING
REVISIONS.
REVISION HISTORY
Revision
Date
Sections
Details
— July 2021 All
Release of the imageRUNNER ADVANCE DX C3800 Series
Service Guide.
1 February 2022 I NFC option is no longer available for purchase
2 April 2022 I Introduce Unified Firmware Platform V3.13 and its features
3 September 2022 I Introduce Unified Firmware Platform V3-13.2 and its features
4 March 2023 I
Updates references of the Unified Firmware Platform to the
UFP Features Reference Manual.

C an o n imageRUNNER ADVANCE DX C3800 Series Service Guide
imageRUNNER ADVANCE DX C3800 Series Service Guide March 2023
Revision 4 Page ii
COPYRIGHTS AND TRADEMARKS
This Service Guide is the property of Canon U.S.A., Inc.
© Canon U.S.A., Inc. 2023. All rights reserved.
Canon, imageRUNNER ADVANCE, and Always Ask for Canon Genuine Toner, Parts & Supplies are registered
trademarks of Canon Inc. imageWARE is a registered trademark of Canon U.S.A., Inc.
All other company names and product names may be trademarks or registered trademarks of their respective
owners, and are hereby acknowledged.
LEGAL NOTICES
The information contained in this Service Guide constitutes confidential information of Canon U.S.A., Inc.
Pursuant to the authorized Service Agreement with Canon U.S.A., Inc., this Service Guide is solely for reference
purposes and may be used only by an authorized Service Provider of Canon U.S.A., Inc. No part of this Service
Guide may be reproduced or transmitted in any form by any means, electronic or mechanical, for any purpose
without the prior written consent of Canon U.S.A., Inc., except as expressly permitted herein.
Pursuant to the authorized Service Agreement with Canon U.S.A., Inc., the Service Provider agrees to indemnify
Canon U.S.A., Inc. and to hold it harmless from and against all claims arising out of Service Provider’s possession,
use, or misuse of this Service Guide.
As an authorized Canon dealership for the imageRUNNER ADVANCE DX C3800 Series you agree that the
imageRUNNER ADVANCE DX C3800 Series and its related hardware/software accessories will not be exported
from the United States except in strict accordance with the Export Administration Regulations of the U.S.
Department of Commerce and other U.S. laws and regulations controlling exports from the United States.
Canon U.S.A., Inc. from time to time updates this online Service Guide and may modify the information and/or
specifications contained in it at any time without notice. Additionally, all prices and availability dates listed herein are
subject to change without notice. The latest version is available online at the Canon Partner Portal and e-Support
Websites noted above. Please make certain that you are using the latest version. Specimens of Web pages
included herein are for illustration purposes only.
DISCLAIMER
NEITHER CANON NOR ITS SUPPLIERS NOR ANY AUTHORIZED SERVICE PROVIDER SHALL BE
LIABLE FOR PERSONAL INJURY OR PROPERTY DAMAGE (UNLESS CAUSED SOLELY AND
DIRECTLY BY THE NEGLIGENCE OF CANON OR ANY AUTHORIZED SERVICE PROVIDER), LOSS
OF REVENUE OR PROFIT, FAILURE TO REALIZE SAVINGS OR OTHER BENEFITS,
EXPENDITURES FOR SUBSTITUTE EQUIPMENT OR SERVICES, LOSS OR CORRUPTION OF
DATA, INCLUDING, WITHOUT LIMITATION, DATA STORED ON THE PRODUCT’S STORAGE
DRIVE, STORAGE CHARGES OR OTHER SPECIAL, INCIDENTAL OR CONSEQUENTIAL
DAMAGES CAUSED BY THE USE, MISUSE OR INABILITY TO USE THE PRODUCT, REGARDLESS
OF THE LEGAL THEORY ON WHICH THE CLAIM IS BASED AND EVEN IF CANON OR ITS
SUPPLIERS OR ANY AUTHORIZED SERVICE PROVIDER HAS BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES. NOR SHALL RECOVERY OF ANY KIND AGAINST CANON OR
ITS SUPPLIERS OR ANY AUTHORIZED SERVICE PROVIDER BE GREATER IN AMOUNT THAN
THE PURCHASE PRICE OF THE PRODUCT CAUSING THE ALLEGED DAMAGE. WITHOUT
LIMITING THE FOREGOING, THE PURCHASER ASSUMES ALL RISKS AND LIABILITY FOR LOSS,
DAMAGE OR INJURY TO PERSONS AND THE PROPERTY OF THE PURCHASER OR OTHERS
ARISING OUT OF THE POSSESSION, USE, MISUSE, OR INABILITY TO USE THE PRODUCT NOT
CAUSED SOLELY AND DIRECTLY BY THE NEGLIGENCE OF CANON OR ANY AUTHORIZED
SERVICE PROVIDER.

C an o n imageRUNNER ADVANCE DX C3800 Series Service Guide
imageRUNNER ADVANCE DX C3800 Series Service Guide March 2023
Revision 4 Page iii
Contents
I. Product Overview, New Features, Configuration, and Monthly Print/Copy Volume - 1
A. Overview ------------------------------------------------------------------------------------------------------------- 1
B. Unified Firmware Platform-------------------------------------------------------------------------------------- 2
C. Data Backup Service --------------------------------------------------------------------------------------------- 3
D. Configuration ------------------------------------------------------------------------------------------------------- 4
E. Monthly Copy/Print Volume ------------------------------------------------------------------------------------ 9
II. Hardware Accessory Options--------------------------------------------------------------------------10
A. Platen Cover-Y3--------------------------------------------------------------------------------------------------- 10
B. Cassette Feeding Unit-AW1----------------------------------------------------------------------------------- 10
C. Staple Finisher-AE1---------------------------------------------------------------------------------------------- 10
D. Booklet Finisher-AE1-------------------------------------------------------------------------------------------- 10
E. 2/3 Hole Puncher Unit-A1 -------------------------------------------------------------------------------------- 10
F. Inner Finisher-L1-------------------------------------------------------------------------------------------------- 11
G. Inner 2Way Tray-M1---------------------------------------------------------------------------------------------- 11
H. Card Reader-F1---------------------------------------------------------------------------------------------------- 11
I. Numeric Keypad-A2 --------------------------------------------------------------------------------------------- 11
J. IC Card Reader Box for Numeric Keypad-A2------------------------------------------------------------11
III. System Options---------------------------------------------------------------------------------------------12
A. Copy and Print Options ---------------------------------------------------------------------------------------- 12
1. PCL International Font Set-A1----------------------------------------------------------------------------- 12
2. Barcode Printing Kit-D1 ------------------------------------------------------------------------------------- 12
B. Fax Options -------------------------------------------------------------------------------------------------------- 13
1. Super G3 FAX Board-BH1 --------------------------------------------------------------------------------- 13
2. Super G3 2nd Line Fax Board-BH1 ----------------------------------------------------------------------13
3. IP FAX Expansion Kit-B1 ----------------------------------------------------------------------------------- 13
4. Remote Fax Kit-A1 ------------------------------------------------------------------------------------------- 13
C. Data Security and Wireless Options -----------------------------------------------------------------------14
1. 1 TB SSD-A1 -------------------------------------------------------------------------------------------------- 14
2. Connection Kit-A3 for Bluetooth LE ---------------------------------------------------------------------- 14
3. NFC Kit-E2 ----------------------------------------------------------------------------------------------------- 14
D. Accessibility Options ------------------------------------------------------------------------------------------- 15
1. Voice Guidance Kit-G1 -------------------------------------------------------------------------------------- 15
2. Voice Operation Kit-D1 -------------------------------------------------------------------------------------- 15
3. ADF Access Handle-A1 ------------------------------------------------------------------------------------- 15
4. Braille Label Kit-F1 ------------------------------------------------------------------------------------------- 15
IV. Storage Capabilities---------------------------------------------------------------------------------------16
A. Mail Box ------------------------------------------------------------------------------------------------------------- 16
B. Advanced Box ----------------------------------------------------------------------------------------------------- 17
1. Shared Folders ------------------------------------------------------------------------------------------------ 17
2. Personal Folders---------------------------------------------------------------------------------------------- 17
C. Network -------------------------------------------------------------------------------------------------------------- 18
D. Memory Media ----------------------------------------------------------------------------------------------------- 18

C an o n imageRUNNER ADVANCE DX C3800 Series Service Guide
imageRUNNER ADVANCE DX C3800 Series Service Guide March 2023
Revision 4 Page iv
V. Security Features ------------------------------------------------------------------------------------------19
A. Device Authentication ------------------------------------------------------------------------------------------ 19
1. ULM (Universal Login Manager) --------------------------------------------------------------------------19
2. Department ID Management-------------------------------------------------------------------------------19
3. UA (Universal Authentication) -----------------------------------------------------------------------------20
4. Access Management System------------------------------------------------------------------------------20
5. uniFLOW Online Express----------------------------------------------------------------------------------- 20
B. Device Security---------------------------------------------------------------------------------------------------- 21
1. Verify System at Startup ------------------------------------------------------------------------------------ 21
2. SIEM (Security Information and Event Management) Integration --------------------------------21
3. McAfee Embedded Control--------------------------------------------------------------------------------- 21
4. Security Policy Function------------------------------------------------------------------------------------- 22
C. Data Security------------------------------------------------------------------------------------------------------- 23
1. Initialize All Data/Settings Function-----------------------------------------------------------------------23
2. TPM (Trusted Platform Module)--------------------------------------------------------------------------- 24
3. Data Encryption Kit------------------------------------------------------------------------------------------- 25
4. Digital User Signature PDF---------------------------------------------------------------------------------25
5. Encrypted Secure Print-------------------------------------------------------------------------------------- 25
D. Document Security----------------------------------------------------------------------------------------------- 26
1. PDF Visible Digital Signature ------------------------------------------------------------------------------26
2. Adobe LiveCycle Rights Management ES Server Integration -------------------------------------26
3. Secure Watermark-------------------------------------------------------------------------------------------- 27
E. Network Security ------------------------------------------------------------------------------------------------- 28
1. IPSec ------------------------------------------------------------------------------------------------------------ 28
2. Filtering by Port Number ------------------------------------------------------------------------------------28
3. Encryption and Authentication----------------------------------------------------------------------------- 28
4. Network Port and Application Access Control ---------------------------------------------------------29
VI. Software Solutions ----------------------------------------------------------------------------------------30
A. Document Management and Binding Software--------------------------------------------------------- 30
1. Therefore ------------------------------------------------------------------------------------------------------- 30
B. Scan Management Software ---------------------------------------------------------------------------------- 31
1. Authorized Send ---------------------------------------------------------------------------------------------- 31
2. uniFLOW (Scanning)----------------------------------------------------------------------------------------- 31
3. eCopy ShareScan -------------------------------------------------------------------------------------------- 31
C. Print/Output Management Software ------------------------------------------------------------------------32
1. uniFLOW-------------------------------------------------------------------------------------------------------- 32
2. uniFLOW Online ---------------------------------------------------------------------------------------------- 33
3. AA-PRINT (Advanced Anywhere-Print) -----------------------------------------------------------------33
4. EFI PrintMe----------------------------------------------------------------------------------------------------- 34
5. Canon Mobile Printing --------------------------------------------------------------------------------------- 34
D. Device Security and Management Software ------------------------------------------------------------- 35
1. uniFLOW Device Security & Management -------------------------------------------------------------35
2. uniFLOW Serverless Secure Print------------------------------------------------------------------------ 35
3. imageWARE Secure Audit Manager Express ---------------------------------------------------------35
4. MEAP Web ----------------------------------------------------------------------------------------------------- 35
E. Business Workflow Software---------------------------------------------------------------------------------36
1. Enterprise Imaging Platform ------------------------------------------------------------------------------- 36
VII. Dealer Sales/Service Authorization ------------------------------------------------------------------37

C an o n imageRUNNER ADVANCE DX C3800 Series Service Guide
imageRUNNER ADVANCE DX C3800 Series Service Guide March 2023
Revision 4 Page v
VIII. Educational Training --------------------------------------------------------------------------------------37
A. Training Program Overview -----------------------------------------------------------------------------------37
B. Foundational Prerequisites -----------------------------------------------------------------------------------38
C. Certification -------------------------------------------------------------------------------------------------------- 38
D. Who Should Attend ---------------------------------------------------------------------------------------------- 39
E. Course Format----------------------------------------------------------------------------------------------------- 39
F. Training Facilities ------------------------------------------------------------------------------------------------ 39
G. Course Equipment ----------------------------------------------------------------------------------------------- 39
H. Service Materials ------------------------------------------------------------------------------------------------- 39
I. uniFLOW Online Training-------------------------------------------------------------------------------------- 40
J. uniFLOW Online Express Training ------------------------------------------------------------------------- 40
K. Data Backup Service Training-------------------------------------------------------------------------------- 40
IX. Servicing Notes ---------------------------------------------------------------------------------------------41
A. Power and Plug Requirements------------------------------------------------------------------------------- 41
B. Installation Space Requirements---------------------------------------------------------------------------- 43
C. Estimated Installation Times --------------------------------------------------------------------------------- 45
D. Serviceability ------------------------------------------------------------------------------------------------------ 46
E. Less Maintenance Strategy -----------------------------------------------------------------------------------47
F. Remote Services-------------------------------------------------------------------------------------------------- 48
1. imageWARE Remote ---------------------------------------------------------------------------------------- 48
2. Content Delivery System------------------------------------------------------------------------------------ 50
3. Remote Services Suite -------------------------------------------------------------------------------------- 53
G. Device Configuration Management------------------------------------------------------------------------- 55
1. DCM (Device Configuration Manager)------------------------------------------------------------------- 55
2. Device Migration Navigator--------------------------------------------------------------------------------- 55
H. LMS (License Management System) -----------------------------------------------------------------------56
I. Content Delivery System Website -------------------------------------------------------------------------- 57
J. Recommended System Engineer Requirements------------------------------------------------------- 58
K. Firmware Upgrades Using the Service Support Tool------------------------------------------------- 59
L. Solid State Drive Handling ------------------------------------------------------------------------------------ 60
M. Special Tools, Solvents and Oils ----------------------------------------------------------------------------60
N. Consumables ------------------------------------------------------------------------------------------------------ 61
O. Consumable Parts------------------------------------------------------------------------------------------------ 63
P. Periodic Replacement Parts ----------------------------------------------------------------------------------66
Q. Periodic Maintenance ------------------------------------------------------------------------------------------- 67
R. Counters------------------------------------------------------------------------------------------------------------- 69
1. Soft Counters -------------------------------------------------------------------------------------------------- 69
2. MEAP Counter ------------------------------------------------------------------------------------------------ 71
3. Toner Bottle Counters --------------------------------------------------------------------------------------- 72
X. Limited Warranty Support-------------------------------------------------------------------------------73
A. Limited Warranty Conditions --------------------------------------------------------------------------------- 73
B. GPR-53 Drum Unit Limited Warranty-----------------------------------------------------------------------73
C. Warranty Programs ---------------------------------------------------------------------------------------------- 74
1. Flat-Rate Program-------------------------------------------------------------------------------------------- 74
2. Warranty Parts for Repair----------------------------------------------------------------------------------- 74
3. e-Tag------------------------------------------------------------------------------------------------------------- 74
4. Parts Support Program -------------------------------------------------------------------------------------- 74

C an o n imageRUNNER ADVANCE DX C3800 Series Service Guide
imageRUNNER ADVANCE DX C3800 Series Service Guide March 2023
Revision 4 Page vi
XI. Product Technical Support Offerings ---------------------------------------------------------------75
A. Canon USA Technical Support Center -------------------------------------------------------------------- 75
B. Technical Support Escalation -------------------------------------------------------------------------------- 76
C. Internet Support--------------------------------------------------------------------------------------------------- 77
D. Canon USA’s Partner Portal Website ----------------------------------------------------------------------77
XII. Appendix ------------------------------------------------------------------------------------------------------78
A. Specifications------------------------------------------------------------------------------------------------------ 78
B. Canon imageRUNNER ADVANCE DX C3800 Series Limited Warranty ----------------------- 103
C. List of Tables----------------------------------------------------------------------------------------------------- 104
D. List of Figures --------------------------------------------------------------------------------------------------- 105

C an o n imageRUNNER ADVANCE DX C3800 Series Service Guide
imageRUNNER ADVANCE DX C3800 Series Service Guide March 2023
Revision 4 Page 1
I. Product Overview, New Features, Configuration, and Monthly Print/Copy
Volume
A. Overview
The Canon imageRUNNER ADVANCE DX C3800 Series consists of the
imageRUNNER ADVANCE DX C3835i, C3830i, and C3826i.
The imageRUNNER ADVANCE DX C3800 Series machines come
standard-equipped with UFP V3.12, and bring the capabilities to users in a
mid- to low-volume office environment:.
•Prints in color and B&W (Black-and-White) in speeds of up to 35 ppm
(pages-per-minute) for the imageRUNNER ADVANCE DX C3835i, 30 ppm
for the imageRUNNER ADVANCE DX C3830i, and up to 26 ppm for the
imageRUNNER ADVANCE DX C3826i (using LTR (letter-sized) paper).
•Standard Universal Send, ULM (Universal Login Manager)1, UFR II, PCL6,
Adobe PostScript 3, PDF/XPS/TIFF/JPEG Direct Printing, Remote
Operator’s Software Kit, Wireless LAN support, and Scan to Word and
PowerPoint (OOXML).
•A standard 200-sheet (LTR) capacity, single-pass, automatic duplex,
document feeder with two-sided B&W and color scanning speeds of up to
270 ipm (images per minute), at a scanning resolution of 300 dpi.
•A 10.1” WSVGA with soft keys, flat, adjustable control panel with flick and
pinch and drag-and-drop actions, similar to the technology used on
smartphones. The flat control panel supports video guidance for
maintenance.
•A maximum paper size of 12 5/8” x 18” is supported. Multiple paper sources
can hold a maximum of 2,300 sheets.
•Standard 250 GB storage drive, with an option to expand the machine’s
storage drive to 1 TB.
•Standard Remote Operator's Software Kit, which enables the control panel
screens to be emulated on a networked computer, so users (with a physical
impairment, for example), can specify settings, and access the control panel
remotely.
•uniFLOW Online and uniFLOW Online Express support.
•An Authentication System that enables users to personalize and customize
their displays, settings, and functions.
•Direct connection to the machine from mobile devices through the
Wireless LAN.
1 ULM is available as a download, and the customer must have an Internet connection. To download
ULM, contact a local authorized Canon dealer.

C an o n imageRUNNER ADVANCE DX C3800 Series Service Guide
imageRUNNER ADVANCE DX C3800 Series Service Guide March 2023
Revision 4 Page 2
B. Unified Firmware Platform
The UFP (Unified Firmware Platform) provides a common firmware base
across all imageRUNNER ADVANCE DX devices. This makes it possible to
unify development, and reflect the same functions and the latest specifications
in all supported imageRUNNER ADVANCE DX devices.
UFP updates are performed on a regular basis, and include new specifications
and enhancements. Critical bug fix firmware updates are released as needed.
The UFP offers the following features and benefits to the imageRUNNER
ADVANCE DX devices.
•Consistent firmware updates across the imageRUNNER ADVANCE DX
devices in your fleet.
•New features and error fixes are applied to all imageRUNNER ADVANCE
DX devices in your fleet at one time.
See the Unified Firmware Platform Features Reference Manual available on
the Partner Portal and e-Support for the latest UFP release available for this
model series, and the new features introduced with that release.

C an o n imageRUNNER ADVANCE DX C3800 Series Service Guide
imageRUNNER ADVANCE DX C3800 Series Service Guide March 2023
Revision 4 Page 3
C. Data Backup Service
The Data Backup Service automatically backs up data to a cloud-based server
that is hosted by Canon Business Imaging Online. The end-user administrator
can execute the Data Backup Service. The Data Backup Service backs up the
imageRUNNER ADVANCE DX Series device’s User mode settings, Address
Book, Registration Settings, Quick Menu Settings, Main Menu Settings, Box
Settings, Universal Data Settings, Personal Settings, and Service Mode
Settings. Customer data is not backed up to the Data Backup Service, with the
exception of the Address Book.
The service technician can restore the address book and settings listed above
from the cloud-based server to the existing or replaced storage drive of the
imageRUNNER ADVANCE DX Series device.
Training is required for the servicing dealer to enroll in the Data Backup
Service, and for the service technician to receive support from the Technical
Support Center. Refer to the Canon USA’s e-Support Center Website Training
Center for details.

C an o n imageRUNNER ADVANCE DX C3800 Series Service Guide
imageRUNNER ADVANCE DX C3800 Series Service Guide March 2023
Revision 4 Page 4
D. Configuration
Note: All configurations shown are for reference purposes only, and are
subject to change without notice. Please refer to the Dealer Price List on the
Partner Portal for the most up-to-date item numbers.
Table 1 – Configuration
Item
Part Number 2
imageRUNNER ADVANCE DX C3835i with the optional Cassette Feeding Unit and
Inner Finisher
imageRUNNER ADVANCE DX C3835i 3
4912C002AA
imageRUNNER ADVANCE DX C3830i3
4913C002AA
imageRUNNER ADVANCE DX C3826i3
4914C002AA
2 Part numbers are subject to change without notice.
3 Ships standard with 200-sheet Single Pass Duplexing Automatic Document Feeder, Envelope Feeder
Attachment, 100-sheet stack bypass, 2 x 550-sheet Paper Cassettes, UFRII/PCL/PS Printing, Direct PDF/XPS
Printing, Color Universal Send with PDF High Compression, Encrypted PDF, Digital Signature PDF (Device and
User Signature), Trace and Smooth PDF, Searchable PDF/XPS, OOXML (Scan to PPT and Word), Universal
Login Manager(Requires Download),uniFLOW Online Express, Access Management System, SSD Data Initialize,
Data Encryption (FIPS-140-2), IP Sec, Encrypted Secure Print, Secure Watermark, Web Browser, 3.5GB RAM,
256GB SSD, Color Image Reader, Ethernet 1000Base-T/100Base-TX/10Base-T,USB 2.0/3.0 Connectivity, Wifi
Connectivity, Remote Operator's Software Kit, Color Network ScanGear and Drum Units.

C an o n imageRUNNER ADVANCE DX C3800 Series Service Guide
imageRUNNER ADVANCE DX C3800 Series Service Guide March 2023
Revision 4 Page 5
Table 2 – Hardware Accessories
Item
Part Number2
Platen Cover-Y34
3818C003AA
Cassette Feeding Unit-AW1 5
4917C002AA
Cabinet Type-W56
5634C001AA
Staple Finisher-AE1
7 8 9
4921C001AA
Booklet Finisher-AE17 8 10
4922C001AA
2/3 Hole Puncher Unit-A1
11
0126C001AA
Inner Finisher-L179
4000C002BA
Inner 2-Way Tray-M1
7
4034C001AA
Utility Tray-B112
0165C001AA
Copy Tray-T1
13
4918C001AA
Copy Card Reader-F1 14
4784B001AA
Copy Card Reader Attachment-B7
3684B009AA
Canon Card Set-A1 (1-30)
4781B001AA
Canon Card Set-A2 (31-100)
4781B002AA
Canon Card Set-A3 (101-200)
4781B003AA
Canon Card Set-A4 (201-300)
4781B004AA
Canon Card Set-A5 (301-500)
4781B005AA
Canon Card Set-A6 (501-1000)
4781B006AA
Braille Label Kit-F1
7518A004AA
ADF Access Handle-A1
1095B001AA
Copy Control Interface Kit-A1 15
3726B001AA
USB Keyboard (Cherry)
16
1266V426
Universal Keyboard Stand-A1
2212V477
Card Reader Assembly for Universal Keyboard Stand
2212V478
Convenience Stapler-A1 17
1348V957
Attachment Kit for Reader
4067C002AA
Numeric Keypad-A2
4036C002AA
IC Card Reader Box for Numeric Keypad-A2
4040C001AA
2 Part numbers are subject to change without notice.
4 Requires removing the standard Single Pass Duplexing ADF.
5 The Cassette Feeding Unit-AW1 and Cabinet Type-W cannot be installed at the same time.
6 The Cabinet Type-W cannot be installed with the Staple Finisher-AE1 or Booklet Finisher-AE1
7 The Staple Finisher-AE1, Booklet Finisher-AE1, Inner Finisher-L1, and Inner 2Way Tray-M1 cannot be installed at
the same time.
8 Includes the Buffer Pass Unit.
9 Includes one (1) staple cartridge that contains 5,000 staples.
10 Includes one (1) staple cartridge that contains 5,000 staples, and two (2) cartridges for booklet finishing that
contain 2,000 staples per cartridge.
11 Requires the Staple Finisher-AE1 or Booklet Finisher-AE1.
12 Requires the Option Attachment Kit for Reader.
13 Cannot be installed with the Staple Finisher-AE1 or Booklet Finisher-AE1.
14 Requires the Copy Card Reader Attachment Kit-B7.
15 Cannot be installed if the Card Reader-F1 is installed.
16 If the USB Keyboard is installed, it is recommended to install the Utility Tray-B1 or Universal Keyboard Stand-A1.
17 A standalone stapler that corner or double staples up to 50 sheets. Uses Staple-P1 (1008B001AA), which
includes two (2) cartridges per case, and 5,000 staples per cartridge.

C an o n imageRUNNER ADVANCE DX C3800 Series Service Guide
imageRUNNER ADVANCE DX C3800 Series Service Guide March 2023
Revision 4 Page 6
Table 3 – System Connectivity Accessories
Item
Box Part
Number
2
eLAN Number 18
Super G3 FAX Board-BH1
4919C001AA
-
Super G3 2nd Line Fax Board-BH119
4920C002AA
-
IP FAX Expansion Kit-B119,20
-
0170C004AA
Remote Fax Kit-A1 21
-
3679B005AA
PCL International Font Set-A1
-
4821B003AA
Barcode Printing Kit-D1
-
3999B004AA
1 TB SSD-A1
-
4874C001BA
Voice Guidance Kit-G1 22 23
0171C001AA
-
Voice Operation Kit-D1
22 23
0172C002AA
-
NFC Kit-E224
-
-
Connection Kit-A3 for Bluetooth LE
4041C002AA
-
2 Part numbers are subject to change without notice.
18 The eLAN (Electronic License Access Number) is delivered via the CNA (Canon Network Access) section of the
Partner Portal.
19 Requires the optional Super G3 FAX Board-BH1.
20 Cannot be installed with the Super G3 2nd Line Fax Board-BH1.
21 Cannot be installed with the Super G3 FAX Board-BH1.
22 The Voice Guidance Kit-G1 and Voice Operation Kit-D1 cannot be installed together.
23 Requires the optional Numeric Keypad-A2 and Option Attachment Kit for Reader.
24 No longer available for purchase.

C an o n imageRUNNER ADVANCE DX C3800 Series Service Guide
imageRUNNER ADVANCE DX C3800 Series Service Guide March 2023
Revision 4 Page 7
Table 4 – imageRUNNER ADVANCE DX Integrated Solutions
Item
Box Part Number
2
eLAN Number
18
Authorized Send V7.2 (1 License)
25, 26
-
4224C062AA
Authorized Send V7.2 (10 Licenses)
25, 26
-
4224C063AA
Authorized Send V7.2 (100 Licenses)
25, 26
-
4224C064AA
Authorized Send V7.2 (1 License NFR)
27 25, 26
-
4224C065AA
Authorized Send to Fax V7.2 (1 License)
25, 26
-
4224C066AA
Authorized Send V7.2 Add-On Option (1 License)
25, 26
-
4224C015AA
Authorized -Send V7.2 Worldox Add-On Option (1 License)
25, 26
-
4224C016AA
Authorized Send V7.2 Barcode Recognition Option (1 License)
25, 26
-
4224C017AA
Authorized Send V7.2 Fax Server Add-On Option (1 License)
25, 26
-
4224C018AA
AA-PRINT V1.5 Gen3
25
-
4164BT59AA
AA-PRINT V1.5 1L Gen3 NFR
27
-
4164BT60AA
MiCard PLUS SC
24 28
-
-
MEAP Web Connection Kit V5.7
-
4848B120AA
MEAP for PaperCut Gen3+ License
-
4224C027AA
Object Generator (for AS400 Printing) License with 3 Year
Maintenance
29
- 4223C001AA
Object Generator Additional 1 Year Maintenance
-
4223C002AA
mxHero Secure Scan to Email30 31 32 33 2659C060AA
2 Part numbers are subject to change without notice.
18 The eLAN (Electronic License Access Number) is delivered via the CNA (Canon Network Access) section of the
Partner Portal.
24 No longer available for purchase.
25 The Jar file can only be attained via download from http://www.canon.com/fau/downloads.
26 The software or kit must be installed via CDS.
27 One NFR license per dealer showroom.
28 Supports 35 different proximity card types. Go to the Partner Portal for a complete list of supported card frequencies.
29 Software provided via e-Support.
30 mxHero license is only available for purchase on the Canon Business Services.
31 mxHero Secure Scan to Email licenses are sold per device, per year, while prorated by month. All purchases are paid up-front.
32 Minimum license purchase term is 1 year, and Maximum License purchase term is 5 years.
33 This item can be ordered by any Dealership without engaging Canon U.S.A. Professional Services (CIIS), as long as at least
one Systems Engineer from the Dealership has completed the mxHero Training course and passed the certification test.

C an o n imageRUNNER ADVANCE DX C3800 Series Service Guide
imageRUNNER ADVANCE DX C3800 Series Service Guide March 2023
Revision 4 Page 8
Table 5 – Supplies and Consumables
Item
Part Number
2
GPR-53 Drum Unit 8528B004AA
GPR-53 Black Toner
8524B003AA
GPR-53 Cyan Toner
8525B003AA
GPR-53 Magenta Toner
8526B003AA
GPR-53 Yellow Toner
8527B003AA
GPR-53L Cyan Toner
1391C003AA
GPR-53L Magenta Toner
1392C003AA
GPR-53L Yellow Toner
1393C003AA
Staple Cartridge-Y1 (for the Booklet Finisher-AE1 only) 34
0148C001AA
Staple-P135
1008B001AA
2 Part numbers are subject to change without notice.
34 Used for booklet finishing only. Contains two cartridges per case and 2,000 staples per cartridge.
35 Used for corner and double stapling only. Contains two cartridges per case and 5,000 staples per cartridge.

C an o n imageRUNNER ADVANCE DX C3800 Series Service Guide
imageRUNNER ADVANCE DX C3800 Series Service Guide March 2023
Revision 4 Page 9
E. Monthly Copy/Print Volume
The maximum print/copy monthly volume is the maximum number of pages
the machine can produce within a one-month period (based on letter size
paper). However, the device should not be used to produce the maximum
number of pages, or a greater volume, on a consistent monthly basis.
The optimum performance range is the volume range that the equipment was
intended to run on a regular basis to maintain a high-level of performance and
print/copy quality.
Table 6 – Monthly Copy/Print Volume
Model Optimum Performance Range Maximum Monthly Copy/Print
Volume
imageRUNNER ADVANCE DX C3835i Approximately 2,000 to 30,000 Up to 150,000 copies/prints
imageRUNNER ADVANCE DX C3830i Approximately 2,000 to 16,000 Up to 130,000 copies/prints
imageRUNNER ADVANCE DX C3826i Up to 115,000 copies/prints

C an o n imageRUNNER ADVANCE DX C3800 Series Service Guide
imageRUNNER ADVANCE DX C3800 Series Service Guide March 2023
Revision 4 Page 10
II. Hardware Accessory Options
This chapter provides an overview of the optional hardware accessories that can
be attached to the machine. For more detailed information on these accessories,
see “Specifications,” on p. 78.
A. Platen Cover-Y3
•Option for scanning from the platen glass.
•Holds an original in place on the platen glass.
B. Cassette Feeding Unit-AW1
•Holds up to 550 sheets x 2 cassettes (20 lb bond (80 g/m2))
•Maximum paper size: 12 x 18”
•Paper weight: 16 lb bond to 80 lb cover (60 to 220 g/m2))
C. Staple Finisher-AE1
•Contains two trays, which hold approximately 1,675 sheets total.
•Corner- or double-staples approximately 50 sheets of paper (LTR, 14 to
24 lb bond (52 to 90 g/m2)).
•Attach the optional 2/3 Hole Puncher Unit-A1 to provide hole punch
capabilities.
•Supports Staple-free stapling and Staple On Demand (up to 8 sheets).
D. Booklet Finisher-AE1
•Contains two trays, which hold approximately 3,250 sheets total.
•Corner- or double-staples approximately 50 sheets of paper (LTR, 14 to
24 lb bond (52 to 90 g/m2)).
•Supports Staple-free stapling and Staple On Demand (up to 8 sheets).
•Can saddle stitch booklets containing 20 sheets x 10 sets (22 lb bond
(81 g/m2)), including one cover sheet up to 140 lb index (256 g/m2).
E. 2/3 Hole Puncher Unit-A1
•Provides 2- to 3-hole punch capabilities for the optional Staple
Finisher-AE1 or Booklet Finisher-AE1.
•Can only be attached to either the optional Staple Finisher-AE1 or Booklet
Finisher-AE1.

C an o n imageRUNNER ADVANCE DX C3800 Series Service Guide
imageRUNNER ADVANCE DX C3800 Series Service Guide March 2023
Revision 4 Page 11
F. Inner Finisher-L1
•Contains two trays, which hold approximately 600 sheets total.
•Corner- or double-staples approximately 50 sheets of paper (LTR,
24 lb bond (90 g/m2)).
•Supports Staple-free stapling and Staple On Demand (up to 8 sheets).
•Supports optional Internal 2/3 Hole Puncher-D1.
G. Inner 2Way Tray-M1
Provides two trays with a capacity of up to 350 sheets (14 lb bond to
80 lb cover (52 to 220 g/m2)). The upper tray can hold approximately 100
sheets, and the lower tray holds up to 250 sheets.
H. Card Reader-F1
•Supports up to 1,000 departments or users.
•Performs Department ID Management automatically. Users must insert a
control card to access the machine.
•Requires the optional Copy Card Reader Attachment-B7.
I. Numeric Keypad-A2
•Provides a hard alphanumeric keypad to enter characters and numbers,
adjust the volume, reset the machine, and start machine operations.
•Required to use the Voice Navigation mode.
J. IC Card Reader Box for Numeric Keypad-A2
Enables the customer to use IC cards for authentication when the optional
Numeric Keypad-A2 is attached.

C an o n imageRUNNER ADVANCE DX C3800 Series Service Guide
imageRUNNER ADVANCE DX C3800 Series Service Guide March 2023
Revision 4 Page 12
III. System Options
The functionality of the imageRUNNER ADVANCE DX C3800 Series can be
expanded by installing the following system related optional accessories.
A. Copy and Print Options
1. PCL International Font Set-A1
•Provides Andalé font support for the PCL driver.
•Enables the user to print in four Asian languages: Japanese, Chinese,
Korean, and Taiwanese.
•Requires license activation via the LMS.
2. Barcode Printing Kit-D1
•Provides the ability to print 1D and 2D barcodes on output.
•Requires license activation via the LMS

C an o n imageRUNNER ADVANCE DX C3800 Series Service Guide
imageRUNNER ADVANCE DX C3800 Series Service Guide March 2023
Revision 4 Page 13
B. Fax Options
1. Super G3 FAX Board-BH1
•Provides a single line to send and receive fax documents.
•Documents that have been created in applications can also be sent
directly from a computer via a network.
2. Super G3 2nd Line Fax Board-BH1
•Provides two lines to send and receive fax documents.
•Requires the Super G3 FAX Board-BH1.
3. IP FAX Expansion Kit-B1
•Enables faxing over VoIP lines that support the T.38 Transmission
Control Protocol.
•Requires the Super G3 FAX Board-BH1.
•Cannot be installed with the Super G3 2nd Line Fax Board-BH1.
•Requires license activation via the LMS.
4. Remote Fax Kit-A1
•Enables the user to share the Fax function, if there is an
imageRUNNER ADVANCE DX machine (with the Remote Fax Kit
installed) and another imageRUNNER ADVANCE DX machine (that
has the Super G3 FAX Board-BH1 installed), on the same network.
•If the above condition is true, then fax documents can be sent and
received remotely between the two machines.
•The Remote Fax Kit-A1 requires license activation via the LMS.
•The Remote Fax Kit and the Super G3 FAX Board-BH1 cannot be
installed together.
