iPF710 / 610

Intro ucing the
imagePROGRAF iPF710
an iPF610 printers
Technology that works harder
so you can work smarter
Intro ucing the newest a itions
to Canon’s worl renown line of
imagePROGRAF large-format printing
solutions—the 36"-wi e iPF710 an
the 24"-wi e iPF610 printers.
These easy-to-use print systems deliver high-
quality output with precision, speed, and hassle-
free maintenance. Specifically designed for
general office printing and technical document
applications, these printers enable users to
produce a diverse range of output from
spectacular full-color posters to complex
technical documents—faster and easier
than ever before.
Canon imagePROGRAF iPF710 and iPF610
large-format printers are ideal for:
GENERAL USE
Large-format color output of presentations, signs,
posters, displays, and other oversize prints, along
with everyday, general color business documents—
all in bold, expressive color.
TECHNICAL DOCUMENTS
Fast and accurate printing of Computer-Aided
Design (CAD) drawings, architectural elevations,
Geographic nformation Systems (G S) maps,
marketing planograms, and other intricate
documents requiring fine sharp lines, smooth
curves, crisp text, fade/scratch resistance, and
incomparable detail.
Created in PosterArtist 2007

High- ensity print-hea
L-COA Image Processor
FEATURES
HIGH-QUALITY PRINTING
•High-resolution output up to 2400 x 1200 dpi
•Fine lines with a precise 4-picoliter
ink droplet
•Unique 5-color dye/pigment Reactive
nk technology optimizes imaging
•Colorfast dye-based inks for bold
expressive color
•Pigment Matte Black ink for durable
line drawings and text
MAXIMUM PRODUCTI ITY
•High-speed output on a wide
variety of media types
•Long-life, super-high-density print-
head with 15,360 nozzles
•Canon’s advanced L-COA high-speed proces-
sor optimizes performance
ERSATILITY
•One printer handles detailed
technical documents and full-
color graphics.
•Direct printing support
for HP-GL/2 and HP RTL
documents
•The HD Driver enables
direct printing from AutoCAD® .
•Point-and-click software
solutions from Canon make
printing your own posters,
presentations, and signs easy.
EASY TO USE
•Quiet operation for a more
comfortable working
environment
•Convenient media feed
options for everyday use
•Large LCD panel provides better
visibility and more information
•Easy access to user manuals,
product information, and software
applications
These easy-to-use printers are powered by advanced Canon technologies, seamlessly integrated into a
comprehensive large-format printing solution.
5-color Reactive Ink technology
iPF710 / 610

Printing made simple—so you
can get the results you want
CANON’S 5-COLOR DYE/PIGMENT
REACTI E INK TECHNOLOGY
From technical applications to general
office use, Canon’s 5-color dye/pigment
Reactive nk technology delivers precise
lines, smooth curves, and excellent graphic
images. Four colorfast dye-based inks
(Cyan, Magenta, Yellow, and Black) ensure
bold expressive color output, while two
channels of pigment-based Matte Black ink
enhance the quality of line drawings and
text-oriented office documents even on
uncoated papers. Canon’s advanced
Reactive nk technology helps prevent
colors and text from bleeding and improves
adhesion for more durable output. All inks
are loaded at the same time with automatic
switching of the black inks for best results
on the media being used.
A PRIORITY ON PRECISION
Precision counts in every business and is
especially important for technical document
applications like G S mapping, CAD designs,
and architectural drawings. Canon’s large-
format printing systems make precision a
priority. The embedded L-COA processor is
the system’s “brain” that handles complex
data and drives the super-high-density
print-head to lay ink down with precision.
FAST, HIGH-QUALITY, HIGH-
RESOLUTION OUTPUT
A large 1.07" super-high-density print-head
deposits tiny droplets of ink (4pl) through
15,360 nozzles to produce high-resolution
output up to 2400 x 1200 dpi. More nozzles
means that ink is ejected more efficiently
with each pass of the print-head. This
reduces the number of passes required to
produce a high-quality image and increases
throughput speed in all print modes.
MANAGE MEDIA EASILY
A variety of new enhancements make
the iPF710/610 easy to use. A media
detection and management system helps
conserve precious time and materials by
warning the user if there’s not enough
media to complete a job. And a new,
automatic media-switching feature on the
iPF610 enables media selection within the
printer driver, eliminating the need to walk
to the printer to make a change.
Created in PosterArtist 2007

iPF710 / 610
The iPF710 and iPF610 printers are
complete large-format printing solutions
designed to help all levels of users do
more—better, faster, and more efficiently.
Canon Printer Driver 2007*for Windows®
and Macintosh®systems provides intuitive
operation with Easy and Advanced settings.
Digital Photo Front-Access*** software
provides a utility to import, edit, and print
photos easily for large-format output.
The HDI Driver** lets you print directly
from AutoCAD/AutoCAD LT.
PosterArtist 2007,*** is an optional soft-
ware for PCs that makes it easy to create
full-color large-format posters, signage, and
banners. Upload your own images or tap
into more than a 1GB of customizable
templates, royalty-free images, and clip art.
The new Auto Design function now makes
it even easier—just specify your layout
elements and the software will automatically
generate draft designs for you!
PRINT WHAT YOU WANT—HOW YOU WANT IT
Office documents come in all sizes and
formats—from photos, graphics, and charts
to Microsoft®files. The iPF710/610 printers
can help you compose, edit, and enlarge
these documents—whether you have the
application file or just a printed original. The
Free Layout feature (PC) and Auto Layout
(Mac) enable digital documents of different
file formats to be composed onto a single
page and printed together. Or you can enlarge
documents directly from a printed original
by integrating with a Canon imageRUNNER®
device with Universal Send, to create a
seamless scan-to-print workflow.
INFORMATION AT YOUR FINGERTIPS
Web Link puts the information that you need
right at your fingertips. With this feature you
just point-and-click to access media informa-
tion, product manuals, and external Web
sites with the latest product information.
OFFICE COMPATIBLE AND READY TO WORK!
With low power consumption, easy media
feed options, and quiet operation, these
network ready printers are an out-of-
the-box large-format printing solution
designed to fit comfortably into virtually
any office environment.
Software and workflow solutions
to help you do more
* Operating Systems: Windows®98SE/Me/2000/XP/2003 Server, Windows Vista® , Macintosh®OS 9.1/X/10.2/10.3/10.4 (Power PC or ntel®)
** For AutoCAD or AutoCAD LT 2000, 2000i, 2002, 2003, 2004, 2005, 2006, 2007
*** PC only. Windows 2000/XP/Windows Vista
Created in PosterArtist 2007

YOU CAN DO IT WITH imagePROGRAF
With every imagePROGRAF solution,
Canon provides the tools and technologies
you need to create, process, and print
full-color, large-format graphics. The
iPF710/610 printers’ advanced printing
technologies, user-friendly features, and
easy maintenance make them ideal for
projects such as:
Posters, Presentations, an Signs: Print
what you need, when you need it, in bold,
expressive color.
CAD: ntricate 3-D renderings, multi-layer
circuit boards, exploded-view diagrams
of mechanical systems, parts diagrams,
manufacturing plans, product and
architectural renderings
GIS: Emergency response planning,
color-enhanced satellite imagery with
topographic overlays, land-use mapping,
demographic and geographic data overlaying
Floor plans an planograms: Layouts
for retail traffic flow, shelf division,
planning for promotional displays,
floor space optimization
An much more: From everyday office doc-
uments to oversize graphics and technical
documents, you can print it bigger and better
with an imagePROGRAF printer!

Print-Head
PF-03
Technology
F NE (Photolithography nkjet Nozzle Engineering)
Print Resolution (Max.)
2400 x 1200 dpi
Line Accuracy*
±0.1% or Less
Minimum Line Weight**
0.02mm
Number of Nozzles
Matte Black: 5,120 Nozzles
Other Colors: 2,560 Nozzles per Color
Droplet Size
4 Picoliter
Nozzle Pitch (Head Resolution)
1200 dpi x Two Rows
Print Head Swath
1.07 inch
Ink Type
Dye
Cyan (C), Magenta (M), Yellow (Y),Black (K)
Pigment
Matte Black (MBK) – Two Channels
Ink Tank
PF -102
Ink Tank Capacity***
130ml per Color
Number of Colors
5
Ink Supply Method
Tubing System
Nozzle Recovery System
Non-firing Nozzle Detection and Compensation
Printer Controller
L-COA Controller
Printer Memory
256MB
Media Feed
Front-loading Manual Feed, Rear-loading Roll Feed
Media Width
Roll Feed
10" – 36" (254mm – 914.4mm)
Cut Sheet
8" – 36" (203.2mm – 914.4mm)
Printable Margins
Roll Feed
All Sides: 0.12" (3mm) or 0" for Borderless
Minimum Printable Media Length
Roll Feed
8.0" (203mm)
Maximum Print Length†
Roll Feed
59' (18m)
Cut Sheet (Top)
5.2' (1.6m)
Borderless Printing Widths (Roll Media Only)
10", 14", 16", 24", 36",
B2 (20.28"/515mm), A1 (23.38"/594mm)
B1 (28.66"/728mm), AO(33.11"/841mm)
Media Cutter
Durable Rotary Blade
Media Thickness
Roll Feed
0.07 – 0.8mm (2.8 – 31.4mil)
Cut Sheet
0.07 – 0.8mm (2.8 – 31.4mil)
Media Core Sizes
2" or 3" Core (2/3" Core Adapter ncluded)
Maximum Roll Outer Diameter
5.9" (150mm)
Software
Printing Software
imagePROGRAF Printer Driver 2007, HD Driver for
AutoCAD®/AutoCAD LT 2000–2008,†† Printer Driver
Extra Kit
n
(Free Layout, imageRUNNER Linking Function)
Utilities
Media Configuration Tool
Applications
Digital Photo Front-Access, GARO Device Setup Utility,
PosterArtist 2007 (optional)
Device Status
GARO Status Monitor, Remote U
Printer Language
GARO (Canon Proprietary), HP-GL/2, HP RTL
Operating Systems
Windows 2000/XP/Server 2003/Windows Vista
Macintosh OS 9/10 (PowerPC or ntel)
Interface
Standard (Built-in)
USB 2.0 Hi-Speed, 10/100Base-T/TX
Optional
EEE1394 (FireWire)
Acoustic Noise
Operation
52dB (A) or Less
Standby
35dB (A) or Less
Acoustic Power
6.6 Bels or Less
Power Supply
AC 100–240V (50-60Hz)
Power Consumption
Maximum
140W or Less
Standby
5W or Less (10W or less
when EEE1394 is mounted)
Power Off
1W or Less (Executive Order Compliant)
Certifications
UL®, FCC Class B, ENERGY STAR®
Operational Environment
Temperature
59 – 86 F° (15 – 30 C°)
Relative Humidity
10 – 80% (No Condensation)
Printer Dimensions (H x W x D)
59.3" x 34.3" x 43.1"
1507mm x 871mm x 1094mm
Weight (with Stand)
Approx. 141 lb.
64kg
Options
EEE1394 Expansion Board (EB-05)
Roll Holder Set (RH2-32)
PosterArtist 2007
User Replaceable Items
Print-Head (PF-03)
nk Tanks (PF -102)
Maintenance Cartridge (MC-07)
Cutter Blade (CT-05)
What’s In The Box
Printer, User Software CD (Printer Driver, HD Driver,
Utilities), Application CDs, 6 Starter nk Tanks (MBK x 2,
Cyan, Magenta, Yellow, Black), 2" Core Media Spool
with 3" Adapter, Print-Head, Maintenance Cartridge,
Media Cutter, Built-in Ethernet/USB 2.0 nterface,
Quick Setup Guide (Poster), Printer Reference Guide
(Booklet), Power Cord, One-Year Onsite Warranty,
Registration Card, Stand, Basket, Hardware (For
Setting Up the Stand)
* After user adjustment and under the same
environmental conditions. Applies to media for
line drawing only.
** Theoretical value based on data resolution.
*** The starter ink tanks initially packaged with the printer
are not the same capacity as the replacement ink
tanks specified here.
†The maximum printable length varies depending on the
application, OS, and R P used.
†† For AutoCAD or AutoCAD LT 2000/2000i/2002/2004/
2005/2006/2007/2008
·
Windows 2000/XP and for Macintosh, Auto Layout,
and imageRUNNER Linking Function

For imagePROGRAF Printer Driver 2007. For printing
from PostScript®applications such as Adobe®llustrator®
or QuarkXPress™, please use a PostScript compatible
R P package. For a list of Canon recommended R P
packages, please consult with Canon Alliance and
ndustry Market program list of R P vendors.
iPF710
SPECIFICATIONS

0115W064
1212RA-iPF710/610-PDF-IH
Print-Head
PF-03
Technology
F NE (Photolithography nkjet Nozzle Engineering)
Print Resolution (Max.)
2400 x 1200 dpi
Line Accuracy*
±0.1% or Less
Minimum Line Weight**
0.02mm
Number of Nozzles
Matte Black: 5,120 Nozzles
Other Colors: 2,560 Nozzles per Color
Droplet Size
4 Picoliter
Nozzle Pitch (Head Resolution)
1200 dpi x Two Rows
Print Head Swath
1.07 inch
Ink Type
Dye
Cyan (C), Magenta (M), Yellow (Y),Black (K)
Pigment
Matte Black (MBK)
Ink Tank
PF -102
Ink Tank Capacity***
130ml per Color
Number of Colors
5
Ink Supply Method
Tubing System
Nozzle Recovery System
Non-firing Nozzle Detection and Compensation
Printer Controller
L-COA Controller
Printer Memory
256MB
Media Feed
Top-loading Manual Feed, Front-loading Manual Feed,
Cassette, Rear-loading Roll Feed
Media Width
Roll Feed, Manual Feed
8" – 24" (203mm – 610mm)
Cassette
8" – 17" (203mm – 432mm)
Printable Margins
Roll Feed
All Sides: 0.12" (3mm) or 0" for Borderless
Cassette
All Sides: 0.12" (3mm)
Manual Feed
Left, Right, Trailing: 0.12" (3mm),
Leading: 0.90" (23mm) or 0.12" (3mm)
Minimum Printable Media Length
Roll Feed
8.0" (203mm)
Cassette
11.0" (279mm)
Top-Loading Manual Feed
11.0" (279mm)
Front-Loading Manual Feed
20.5" (520mm)
Maximum Print Length†
Roll Feed
59' (18m)
Cassette
23.4" (594mm)
Manual Feed (Top)
5.2' (1.6m)
Manual Feed (Front)
36.0" (914mm)
Cassette Capacity (Plain Paper)
250 Sheets (Letter)
100 Sheets (up to 13" x 19")
50 Sheets (up to 17" x 22")
Borderless Printing Widths (Roll Media Only)
10", 13", 14", 16", 17", 24", B4 (10.12"/257mm),
A2 (16.54"/420mm), B2 (20.28"/515mm),
A1 (23.38"/594mm)
Media Cutter
Durable Rotary Blade
Media Thickness
Cassette
0.08 – 0.3mm (3.2 – 11.8mil)
Top-Loading Manual Feed
0.07 – 0.8mm (2.8 – 31.4mil)
Front-Loading Manual Feed
0.5 – 1.5mm (19.6 – 59.0mil)
Roll Feed
0.07 – 0.8mm (2.8 – 31.4mil)
Media Core Sizes
2" or 3" Core (2/3" Core Adapter ncluded)
Maximum Roll Outer Diameter
5.9" (150mm)
Software
Printing Software
imagePROGRAF Printer Driver 2007, HD Driver for
AutoCAD/AutoCAD, LT 2000–2008,†† Printer Driver Extra
Kit n(Free Layout, imageRUNNER Linking Function)
Utilities
Media Configuration Tool
Applications
Digital Photo Front-Access, GARO Device Setup Utility,
PosterArtist 2007 (optional)
Device Status
GARO Status Monitor, Remote U
Printer Language
GARO (Canon Proprietary), HP-GL/2, HP RTL
Operating Systems
Windows®2000/XP/Server 2003/Windows Vista
Macintosh®OS 9/10 (PowerPC or ntel)
Interface
Standard (Built-in)
USB 2.0 Hi-Speed, 10/100Base-T/TX
Optional
EEE1394 (FireWire®)
Acoustic Noise
Operation
52dB (A) or Less
Standby
35dB (A) or Less
Acoustic Power
6.6 Bels or Less
Power Supply
AC 100–120V (50-60Hz)
Power Consumption
Maximum
100W or Less
Standby
5W or Less (10W or less when EEE1394 is mounted)
Power Off
1W or Less (Executive Order Compliant)
Certifications
UL®, FCC Class B, ENERGY STAR®
Operational Environment
Temperature
59 – 86 F° (15 – 30 C°)
Relative Humidity
10 – 80% (No Condensation)
Dimensions (H x W x D)
39.3" x 39" x 38.4"
(997mm x 991mm x 989mm)
Weight (with Stand)
Approx. 149.9 lb. (68kg)
Options
EEE1394 Expansion Board (EB-05)
Roll Holder Set (RH2 - 24)
PosterArtist 2007
User Replaceable Items
Print-Head (PF- 03)
nk Tanks (PF -102)
Maintenance Cartridge (MC -16)
What’s In The Box
Printer, User Software CD (Printer Driver, HD Driver,
Utilities), Application CDs, 6 Starter nk Tanks (MBK x 2,
Cyan, Magenta, Yellow, Black), 2" Core Media Spool with
3" Adapter, Print-Head, Maintenance Cartridge, Media
Cutter, Built-in Ethernet/USB 2.0 nterface, Quick Setup
Guide (Poster), Printer Reference Guide (Booklet), Power
Cord, One-Year Onsite Warranty, Registration Card,
Stand, Basket, Hardware (For Setting Up the Stand)
* After user adjustment and under the same
environmental conditions. Applies to media for
line drawing only.
** Theoretical value based on data resolution
*** The starter ink tanks initially packaged with the printer
are not the same capacity as the replacement ink
tanks specified here.
†The maximum printable length varies depending on
the application, OS, and R P used.
†† For AutoCAD or AutoCAD LT 2000/2000i/2002/2004/
2005/2006/2007/2008
·
Windows 2000/XP/2003 Server and for Macintosh,
Auto Layout, and imageRUNNER Linking Function

For imagePROGRAF Printer Driver 2007. For printing
from PostScript®applications such as Adobe llustrator®
or QuarkXPress™, please use a PostScript compatible
R P package. For a list of Canon recommended R P
packages, please consult with Canon Alliance and
ndustry Market program list of R P vendors.
1-800-OK-CANON
www.usa.canon.com
Canon U.S.A., Inc.
One Canon Park
Melville,NY11747
As an ENERGY STAR®Partner, Canon U.S.A., Inc. as determined t at t ese products meet t e ENERGY STAR
guidelines for energy efficiency. ENERGY STAR and t e ENERGY STAR mark are registered U.S. marks. CANON,
IMAGEPROGRAF, and IMAGERUNNER are registered trademarks of Canon Inc. in t e United States and may also be
registered trademarks or trademarks in ot er countries. IMAGEANYWARE is a trademark of Canon. All referenced
product names and ot er marks are trademarks of t eir respective owners. Some items may not be available at t is
time; please c eck for availability. Specifications and availability subject to c ange wit out notice.
©2013Canon U.S.A., Inc. All rig ts reserved.
iPF610
SPECIFICATIONS
