Canon PIXMA mini260 User manual

PIXMA mini260
Service Manual
Revision 0
QY8-13BF-000
COPYRIGHT©2006 CANON INC. CANON PIXMAmini260 082006 XX 0.00-0
Scope
This manual has been issued by Canon Inc., to provide the service technicians of this product with the information necessary for
qualified persons to learn technical theory, installation, maintenance, and repair of products. The manual covers information
applicable in all regions where the product is sold. For this reason, it may contain information that is not applicable to your
region.
Revision
This manual could include technical inaccuracies or typographical errors due to improvements or changes made to the product.
When changes are made to the contents of the manual, Canon will release technical information when necessary. When
substantial changes are made to the contents of the manual, Canon will issue a revised edition.
The following do not apply if they do not conform to the laws and regulations of the region where the manual or product is
used:
Trademarks
Product and brand names appearing in this manual are registered trademarks or trademarks of the respective holders.
Copyright
All rights reserved. No parts of this manual may be reproduced in any form or by any means or translated into another language
without the written permission of Canon Inc., except in the case of internal business use.
Copyright © 2006 by Canon Inc.
CANON INC.
Inkjet Device Quality Assurance Div. 1
451, Tsukagoshi 3-chome, Saiwai-ku, Kawasaki-shi, Kanagawa 212-8530, Japan

I. MANUAL OUTLINE
This manual consists of the following three parts to provide information necessary to service the PIXMA mini260:
Part 1: Maintenance
Information on maintenance and troubleshooting of the PIXMA mini260
Part 2: Technical Reference
New technology and technical information such as FAQ's (Frequently Asked Questions) of the PIXMA mini260
Part 3: Appendix
Block diagrams and pin layouts of the PIXMA mini260
PIXMA mini260
Reference This manual does not provide sufficient information for disassembly and reassembly procedures.
Refer to the graphics in the separate Parts Catalog.
<I. MANUAL OUTLINE>

II. TABLE OF CONTENTS
Part 1: MAINTENANCE
1. MAINTENANCE
1-1. Adjustment, Periodic Maintenance, Periodic Replacement Parts, and Replacement Consumables by Service Engineer
1-2. Customer Maintenance
1-3. Product Life
1-4. Special Tools
1-5. Serial Number Location
2. LIST OF ERROR DISPLAY / INDICATION
2-1. Operator Call Errors
2-2. Service Call Errors
2-3. Other Error Messages
2-4. Warnings
2-5. Troubleshooting by Symptom
3. REPAIR
3-1. Notes on Service Part Replacement
3-2. Special Notes on Repair Servicing
3-3. Adjustment / Settings
(1) Paper feed motor adjustment
(2) Grease application
(3) Ink absorber counter setting
(4) User mode
(5) Service mode
Service test print, EEPROM initialization, Ink absorber counter resetting
Destination settings
Button and LCD test
LF / Eject correction
3-4. Verification Items
(1) Service test print
(2) EEPROM information print
4. PRINTER TRANSPORTATION
Part 2: TECHNICAL REFERENCE
1. NEW TECHNOLOGIES
2. CLEANING MODE AND AMOUNT OF INK PURGED
3. PRINT MODE
4. FAQ (Problems Specific to the mini260 and Corrective Actions)
Part 3: APPENDIX
1. BLOCK DIAGRAM
2. CONNECTOR LOCATION AND PIN LAYOUT
2-1. Logic Board
2-2. Card Slot Board
2-3. Operation Panel Board
2-4. PE Sensor Board
2-5. Print Beam / PictBridge Board
3. PIXMA mini260 SPECIFICATIONS
PIXMA mini260

Part 1
MAINTENANCE
PIXMA mini260 TABLE OF CONTENTS

1. MAINTENANCE
1-1. Adjustment, Periodic Maintenance, Periodic Replacement Parts, and Replacement Consumables by
Service Engineer
(1) Adjustment
Caution: DO NOT loosen the red screws at both ends of the carriage shaft, securing the print head position, as they are not
re-adjustable.
The red screws securing the paper feed motor may be loosened only at replacement of the paper feed motor unit.
(2) Periodic maintenance
No periodic maintenance is necessary.
(3) Periodic replacement parts
There are no parts in this printer that require periodic replacement by a service engineer.
(4) Replacement consumables
There are no consumables that require replacement by a service engineer.
Part 1: MAINTENANCE TABLE OF CONTENTS
Adjustment Timing Purpose Tool Approx.
time
Destination settings
(EEPROM settings) - At logic board replacement To set destination. None.
Perform in the
service mode.
1 min.
Ink absorber counter
resetting
(EEPROM settings)
- At logic board replacement
- At ink absorber replacement
To reset the ink absorber counter. None.
Perform in the
service mode.
1 min.
Paper feed motor
position adjustment - At paper feed motor replacement To adjust the belt tension.
(Position the paper feed motor so that the
belt is stretched tight.)
None. 2 min.
LF / Eject correction - At logic board replacement
- At LF roller replacement
- At eject roller replacement
- At guide rail replacement
- At spur base replacement
- At platen unit replacement
- At pressure roller replacement
To correct line feeding and paper ejection
accuracy. None.
Perform in the
service mode.
3 min.
Grease application - At carriage unit replacement - To the carriage shaft sliding portion
- To the carriage oil pad
EU-1 1 min.
- At LF roller replacement - To the LF roller groove IF-20
- At AP motor replacement - To the reduction gear MOLYKOTE
PG641
- At paper thickness lever
replacement - To the paper thickness lever sliding portion FLOIL KG-107
- At idle gear replacement - To the idle gear contact
- At guide rail replacement - To the carriage slider
Ink system function
check - At logic board replacement
- At carriage unit replacement
To maintain detection functionality for
presence and position of the ink tank. None.
Perform in the
service mode.
1 min.
1-1

1-2. Customer Maintenance
1-3. Product Life
(1) Printer
Specified print volume (I) or the years of use (II), whichever comes first.
(I) Print volume: 2,880 pages (L size, borderless printing of a standard photo)
Reference: Approx. 2,100 pages (4 x 6, borderless printing of a standard photo, calculated based on the amount of 4 x 6 size pages)
(II) Years of use: 5 years of use
(2) Print head
Print volume: 2,880 pages (L size, borderless printing of a standard photo)
(3) Ink tank (actual measurement value)
* When printing Canon standard patterns on 4" x 6" Photo Paper Plus Glossy continuously with the default settings of Photo Paper Plus
Glossy using Windows XP printer driver in borderless printing mode and Windows XP Photo Printing Wizard. Declared yield value
determined based on Canon standard method referring to ISO/IEC FCD24712.
Note: Ink yield may vary depending on texts/photos printed, applications software used, print mode and type of paper used.
(4) Battery (actual measurement value)
- Charging: 300 times
- Storage period: 2.5 years
* When printing Canon standard patterns on 4" x 6" Photo Paper Plus Glossy continuously with the default settings of Photo Paper Plus
Glossy using Windows XP printer driver in borderless printing mode and Windows XP Photo Printing Wizard. Declared yield value
determined based on Canon standard method referring to ISO/IEC FCD24712.
Note: Ink yield may vary depending on texts/photos printed, applications software used, print mode and type of paper used.
Adjustment Timing Purpose Tool Approx.
time
Print head
alignment - At print head replacement To ensure accurate dot placement. - Printer buttons
- Computer (printer
driver)
3 min.
Print head
cleaning When print quality is not satisfying. To improve nozzle conditions. - Printer buttons - Computer (printer
driver)
1 min.
Print head deep
cleaning When print quality is not satisfying, and not improved by print head cleaning. To improve nozzle conditions. - Computer (printer driver) 2 min.
Ink tank
replacement When the ink tank becomes empty. ("No ink error" displayed on the monitor or on the printer LCD, or
short flashing of the ink tank LED)
――2 min.
Paper feed roller
cleaning - When paper does not feed properly. - When the front side of the paper is smeared. To clean the paper feed rollers. - Printer buttons 2 min.
Bottom plate
cleaning When the back side of the paper is smeared. To clean the platen ribs. - Plain paper - Printer buttons 1 min.
Average yield CLI-36
Photo (4" x 6")*109 pages
Average yield CLI-36
Photo (4" x 6")*85 pages
1-2

1-4. Special Tools
* In Europe, purchase Grease EU-1 from the following company:
- Company name: NTN WALZLAGER (EUROPA) GmbH
- Contact person: Mr. Hideji Todo, Manager, [email protected]
1-5. Serial Number Location
On the bottom of the printer.
Name Tool No. Price
(JPY) Application Remarks
Grease MOLYKOTE PG-641 QK-0562 820 To the reduction gear.
In common with other
models.
Grease FLOIL KG-107A QY9-0057 225
To the following items:
- Platen lever plate sliding portion
- Idle gear contact
- Eject pulley holder cover shaft joint
- Guide rail sliding portion
Grease ELECTRICITY IF-20 CK-8006 630 To the LF roller groove
Oil EU-1*QY9-0037 210 To the carriage shaft sliding portion and
carriage oil pad
<Part 1: 1. MAINTENANCE>
1-3

2. LIST OF ERROR DISPLAY / INDICATION
Errors and warnings are displayed by the following ways:
1) Operator call errors are indicated by the Alarm LED lit in orange, and the error and its solution are displayed on the LCD in text and
by icon.
2) Messages during printing from a computer are displayed on the printer driver Status Monitor.
3) Error codes are printed in the "operator call/service call error record" area in EEPROM information print.
Buttons valid when an operator call error occurs:
1) ON/OFF button: To turn the printer off and on again.
2) OK button: To clear and recover from an error. In some operator call errors, the error will automatically be cleared when the cause
of the error is eliminated, and pressing the OK button may not be necessary.
3) Stop/Reset button: To cancel the job at error occurrence, and to clear the error.
2-1. Operator Call Errors (by Alarm LED Lit in Orange)
Part 1: MAINTENANCE TABLE OF CONTENTS
Error Error
code Message on the LCD Solution
No paper in the ASF. [1000] Auto sheet feeder.
There is no paper. Load paper and
press [OK].
Confirm that the ASF is selected as the paper source. Set
the paper in the ASF, and press the OK button.
Paper jam. [1300] The paper is jammed. Clear the paper
and press [OK]. Remove the jammed paper, and press the OK button.
Ink may have run out. [1600] The following ink may have run out.
Replacing the ink tank is recommended.
(U041)
Replace the ink tank, or press the OK button to clear the
error without ink tank replacement. When the error is
cleared by pressing the OK button, ink may run out
during printing.
Ink tank not installed. [1660,
1687] The following ink tank cannot be recognized. (U043)
(Applicable ink tank icon)
Install the ink tank properly, and confirm that the ink tank
LED lights red.
Print head not installed, or
not properly installed. [1401] Print head is not installed. Install the print head. Install the print head properly.
Print head temperature
sensor error. [1403] The type of print head is incorrect. Install the correct print head. Re-set the print head. If the error is not cleared, the print head may be defective. Replace the print head.
Faulty EEPROM data of
the print head. [1405, 1682]
Warning: The ink
absorber becomes almost
full.
[1700,
1701] Contact the support center or service center for ink absorber replacement.
Press [OK] to continue printing.
Replace the ink absorber, and reset its counter. [See 3-3.
Adjustment / Settings, (5) Service mode.]
Pressing the OK button will exit the error, and enable
printing without replacing the ink absorber. However,
when the ink absorber becomes full, no further printing
can be performed unless the applicable ink absorber is
replaced.
The connected digital
camera or digital video
camera does not support
Camera Direct Printing.
[2001] The device may be incompatible.
Remove the device and check the
manual supplied with the connected
device.
Remove the cable between the camera and the printer.
Failed in automatic print
head alignment. [2500] Auto head align has failed. Press [OK] and repeat
operation. <See manual>
Press the OK button to clear the error, then perform the
automatic print head again.
Low battery [1810] No battery. Turn printer off and use the
AC adapter or install a charged battery. Use the AC adapter, or attach a charged battery.
Ink tank not recognized. [1684] The following ink tank cannot be
recognized. (U140)
(Applicable ink tank icon)
A non-supported ink tank is installed (the ink tank LED is
turned off). Install the supported ink tank.
1-4

2-2. Service Call Errors (by Cyclic Blinking in Orange (Alarm LED) and Blue (Power LED))
Service call errors are indicated by the number of cycles the Alarm and Power LEDs blink, and the corresponding error code is displayed on
the LCD.
Ink tank not recognized. [1410
to
1419]
The following ink tank cannot be
recognized. (U150)
(Applicable ink tank icon)
Replace the ink tank.
No ink (no raw ink in a
new ink tank). [1688] Printer detected ink out condition of the following ink. Replace the ink tank. Replace the ink tank, and close the printer cover. By pressing the Stop/Reset button, printing can be
continued without replacing the ink tank, however, ink
may run out during printing.
No ink (a used ink tank). [1689] The following ink tank cannot be
recognized. Replace the ink tank, and close the printer cover. By pressing the Stop/Reset button, printing can be
continued without replacing the ink tank, however, ink
may run out during printing.
Cycles of
blinking in
orange (Alarm
LED) and blue
(Power LED)
Error Error
code Conditions Solution
Replacement of listed parts,
which are likely to be faulty)
2 times Carriage error [5100] An error occurred in the carriage encoder
signal. - Carriage unit (QM2-3987) - Timing slit strip film (QC2-3208)
- Logic board ass'y (QM3-0110)*1
- Carriage motor ass'y (QM3-
0142)
3 times Line feed error [6000] An error occurred in the LF encoder signal. - Paper feed encoder unit (QM3-
0118)
- Timing slit disk (QC2-0211)
- Paper feed roller ass'y (QL2-
1691)
- Platen unit (QM2-3976)
- Logic board ass'y (QM3-0110)*1
- Paper feed motor ass'y (QM3-
0143)
4 times Purge cam sensor error [5C00] An error occurred in the purge unit. - Purge unit (QM2-3980)
- Logic board ass'y (QM3-0110)*1
5 times ASF (cam) sensor error [5700] This error takes place when feeding paper
from the ASF after an error occurred in the
ASF cam sensor.
- Sheet feed unit (QM2-3992)
- PE PWB unit (QM3-0128)
- Logic board ass'y (QM3-0110)*1
6 times Internal temperature error [5400] The internal temperature is not normal. - Carriage unit (QM2-3987)
- Logic board ass'y (QM3-0110)*1
7 times Ink absorber full [5B00,
5B01] The ink absorber is supposed to be full. Message on the LCD:
Ink absorber full. Service required.
Error codes:
5B00: Main ink absorber is full
(overseas).
5B01: Main ink absorber is full
(Japan).
- Absorber kit (QY5-0182)
8 times Print head temperature rise
error [5200] The print head temperature exceeded the specified value. - Print head (QY6-0069)
- Logic board ass'y (QM3-0110)*1
9 times EEPROM error [6800] A problem occurred in writing to the
EEPROM. - Logic board ass'y (QM3-0110)*1
10 times VH monitor error [B200] The internal temperature exceeded the
specified value. - Print head (QY6-0069) - Carriage unit (QM2-3987)
- Logic board ass'y (QM3-0110)*1
12 times AP position error [6A00] The AP motor does not move because the
ASF unit, purge unit, or AP motor is faulty. - Sheet feed unit (QM2-3992)
- Logic board ass'y (QM3-0110)*1
- Purge unit (QM2-3980)
1-5

*1: Before replacement of the logic board ass'y, check the ink absorber counter value (by service test print or EEPROM information
print). If the counter value is 7% or more, also replace the ink absorber kit (QY5-0182) when replacing the logic board ass'y. If
the counter value is less than 7%, register the current ink absorber counter value to the replaced new logic board instead. [See 3-
3. Adjustment / Settings, (5) Service mode, for details.]
2-3. Other Error Messages
15 times USB Host VBUS
overcurrent [9000] The USB Host VBUS is overloaded. - Logic board ass'y (QM3-0110)*1
16 times Battery error [A100] The thermistor is faulty, or the battery
temperature exceeded the specified value. - Portable Kit LK-60
- Logic board ass'y (QM3-0110)*1
17 times Battery error [A000] The microcomputer built in the battery got
faulty due to short circuit, etc. - Portable Kit LK-60
- Logic board ass'y (QM3-0110)*1
20 times Other hardware error [6500] The PCI bus error is detected by the ASIC. - Logic board ass'y (QM3-0110)*1
Alarm LED lit ROM error The check sum value is incorrect in the
ROM check at hard-power-on. - Logic board ass'y (QM3-0110)*1
Alarm LED lit RAM error An error is detected in the RAM check at
hard-power-on. - Logic board ass'y (QM3-0110)*1
Message on the LCD Cause Solution
The print head lock lever is not properly
applied. Open the cover and press the
lock buttons on both ends of the lever.
The print head lock lever was not completely
lowered, contacting the printer cover. Push the lever to fit it in place, and close the printer cover.
Read/write attribute is not available
during battery operation. To prevent data loss (in case the printer power turns off due to exhaustion of the battery
power), writing to a memory card cannot be
performed.
Connect the printer to the AC power supply.
Cannot print via wireless
communication.
- No photo data
- Unsupported photo data
- Photo data too large
The image size was too large, or the image file
was not supported. Change the image, and try wireless communication again.
There are no photos in memory card. Supported image files are not in the memory
card. A temporary error. - Confirm that supported image files are in the
memory card.
- Images with double-byte characters used in
the file name (or folder name) may not be
recognized. Change the file (or folder) name
so that it contains only single-byte
alphanumeric characters.
- If images are edited on the computer, print
them from the computer.
The value exceeds the number of copies
you can print. During selecting images or specifying the number of copies, the total print quantity
exceeds the prescribed value of 999.
A temporary error. The last operation before
the error is cancelled, and the total print
quantity returns to the value before the error.
Memory card is not set. Insert the card
after checking the direction. The memory card is not inserted in the slot properly. Set a memory card properly.
DPOF information is not saved in the
memory card. DPOF print was selected in the menu, but no DPOF files are contained in the memory card. A temporary error. The LCD automatically returns to the display before the error
occurrence.
Change the setting after removing the
card. With a memory card inserted in the slot, change of the Read/Write attribute was
attempted.
A temporary error. Remove the memory card,
then change the Read/Write attribute.
The card is currently write-enabled. Set
to read-only mode before performing
operation.
With the memory card set to the Read/write
mode, Card Direct printing operation was
attempted from the menu.
A temporary error. Remove the memory card,
change the memory card setting to Read-only,
then perform Card Direct printing.
1-6

2-4. Warnings
2-5. Troubleshooting by Symptom
Warning Message on the LCD Solution
Print head alignment
(recommendation on
arrival)
Head alignment required. Load paper and press [OK].
Yes - Select Yes, and press the OK button. => Automatic print head alignment is performed.
Cancellation of image
select information Reset the selected photo information? Yes No In Layout print, the message will be displayed when a user attempts to display the menu or sub-menu after
selecting one or more photos.
- Select Yes, and press the OK button.
=> The image selection is cancelled, and the menu
or sub-menu is displayed.
- Select No, and press the OK button.
=> The LCD returns to the display immediately
before the message was displayed.
Symptom Solution
Faulty operation The power does not turn on.
The power turns off immediately after
power-on.
- Confirm the connection of
- the power cord, and
- between the logic board and the power supply unit.
- Replace the
- AC adapter,
- logic board ass'y'*1, or
- Portable Kit LK-60.
A strange noise occurs. - Remove foreign material.
- Attach a removed part if any.
- Check the operation of the moving parts (such as purge unit,
carriage unit, and paper feeding mechanism)
- Replace a faulty part, if any.
Nothing is displayed on the LCD. - Confirm the connection between the operation panel, the LCD
viewer unit, and the logic board.
- Replace the
- LCD viewer unit, or
- logic board ass'y*1.
A portion of the LCD is not displayed. - Perform the button and LCD test in the service mode, and
confirm that the LCD is displayed without any segments
missing.
- Confirm the connection between the operation panel and the
logic board.
- Replace the
- LCD viewer unit, or
- logic board ass'y*1.
Paper feed problems (multi-feeding,
skewed feeding, no feeding). - Examine the inside to confirm that no parts are damaged, and the rollers are clean.
- Remove foreign material.
- Adjust the paper guide properly.
- Set the paper properly.
- Confirm the connection between each harness and the logic
board.
- Replace the
- sheet feeder unit, or
- logic board ass'y*1.
Carriage movement problems (contact to
other parts, strange noise). - Confirm that the timing slit strip film is free from damage or grease.
- Clean the timing slit strip film (with ethanol and lint-free
paper).
- Remove foreign material.
- Replace the
1-7

*1: Before replacement of the logic board ass'y, check the ink absorber counter value (by service test print or EEPROM information
print). If the counter value is 7% or more, also replace the ink absorber kit (QY5-0182) when replacing the logic board ass'y. [See
3-3. Adjustment / Settings, (5) Service mode, for details.]
*2: Replace the print head only after the print head deep cleaning is performed 2 times, and when the problem persists.
*3: Use Matte Photo Paper (MP-101) or Photo Paper Plus Glossy (PP-101) for print head alignment.
- timing slit strip film, or
- carriage unit.
Unsatisfactory print quality No printing, or no color ejected. - Confirm that the ink tank is installed properly.
- Perform print head maintenance.
- Replace the
- ink tank, or
- print head*2.
- Remove foreign material from the purge unit caps, if any.
- Replace the
- purge unit, or
- logic board ass'y*1.
Printing is faint, or white lines appear on
printouts even after print head cleaning.
Line(s) not included in the print data
appears on printouts.
- Remove and re-install the print head.
- Confirm that the ink tank is installed properly.
- Perform print head maintenance.
- Replace the
- ink tank,
- print head*2,
- purge unit, or
- logic board ass'y*1.
Paper gets smeared. - Feed several sheets of paper.
- Perform bottom plate cleaning.
- Clean the paper path with cotton swab or cloth.
- Clean the ASF paper feed rollers.
A part of a line is missing on printouts. - Replace the
- ink tank, or
- print head*2.
Color hue is incorrect. - Confirm that the ink tank is installed properly.
- Perform print head maintenance.
- Replace the
- ink tank, or
- print head*2.
- Perform print head alignment*3.
Printing is incorrect. Replace the logic board ass'y*1.
No ejection of black ink. - Confirm that the ink tank is installed properly.
- Perform print head maintenance.
- Replace the
- ink tank, or
- print head*2.
- Remove foreign material from the purge unit caps, if any.
- Replace the purge unit.
Graphic or text is enlarged on printouts. When enlarged in the carriage movement direction:
- Clean grease or oil off the timing slit strip film.
- Replace the
- timing slit strip film,
- carriage unit, or
- logic board ass'y*1.
When enlarged in the paper feed direction:
- Clean grease or oil off the timing slit disk.
- Replace the
- timing slit disk,
- paper feed encoder unit,
- LF roller, or
- logic board ass'y*1.
<Part 1: 2. LIST OF ERROR DISPLAY / INDICATION>
1-8

3. REPAIR
3-1. Notes on Service Part Replacement (and Disassembling / Reassembling)
Part 1: MAINTENANCE TABLE OF CONTENTS
Service part Notes on replacement*1 Adjustment / settings Operation check
Logic board ass'y
QM3-0110 - Before removal of the logic board ass'y, remove the power cord, and
allow for approx. 1 minute (for
discharge of capacitor's
accumulated charges), to prevent
damages to the logic board ass'y.
- Before replacement, check the ink
absorber counter value (by
service test print or EEPROM
information print). If the counter
value is 7% or more, also replace
the ink absorber kit (QY5-0182)
when replacing the logic board
ass'y. [See 3-3. Adjustment /
Settings, (5) Service mode, for
details.]
After replacement:
1. Initialize the EEPROM.
2. Set the ink absorber counter
value.
3. Set the destination in the
EEPROM.
4. Check the ink system function.
[See 3-3. Adjustment / Settings, (5)
Service mode, for details of 1 to 4.]
5. Perform print head alignment in
the user mode*1.
6. Perform LF / Eject correction in
the service mode.
- EEPROM information print
- Service test print
- Printing via USB connection
- Direct printing from a digital
camera
Absorber kit
QY5-0182 After replacement:
1. Reset the ink absorber counter.
[See 3-3. Adjustment / Settings, (5)
Service mode, for details.]
- Service test print
- EEPROM information print
Carriage unit
QM2-3987 At replacement:
1. Apply oil to the sliding portions.
[See 3-3. Adjustment / Settings, (2)
Grease application.]
After replacement:
1. Check the ink system function.
[See 3-3. Adjustment / Settings, (5)
Service mode, for details.]
2. Perform the print head
alignment in the user mode*1.
- Service test print (Confirm ink
system function.)
Paper feed motor
QM3-0143 - The red screws securing the paper feed motor are allowed to be
loosened only for paper feed
motor replacement. (DO NOT
loosen them in any other cases.)
At replacement:
1. Adjust the paper feed motor.
[See 3-3. Adjustment / Settings, (1)
Paper feed motor adjustment.]
Paper feed roller ass'y
QL2-1698 - After replacement, perform LF / Eject correction. After replacement:
1. Perform LF / Eject correction in
the service mode.
[See 3-3. Adjustment / Settings, (5)
Service mode, for details.]
- Service test print
Eject roller ass'y
QL2-1699
Platen unit
QM2-3976 - Do not bend the bridge sheet on the bottom of the platen. After replacement:
1. Confirm that the ink path for the
platen ink absorber is secured.
[See 3-3. Adjustment / Settings, (5)
Service mode, for details.]
Timing slit strip film
QC2-0142 - Upon contact with the film, wipe the film with ethanol.
- Confirm no grease is on the film.
(Wipe off any grease thoroughly
with ethanol.)
- Do not bend the film
After replacement:
1. Perform print head alignment in
the user mode*1.
- Service test print
Timing slit disk
QC2-0211
Print head
QY6-0069 After replacement:
1. Perform print head alignment in
the user mode*1.
- Service test print
1-9

*1: For print head alignment, use Matte Photo Paper (MP-101) or Photo Paper Plus Glossy (PP-101).
General notes:
- Make sure that the flexible cables and wires in the harness are in the proper position and connected correctly.
See 3-2. Special Notes on Repair Servicing, (1) Flexible cable and harness wiring, connection.
- Do not drop the ferrite core, which may cause damage.
- Protect electrical parts from damage due to static electricity.
- Before removing a unit, after removing the power cord, allow the printer to sit for approx. 1 minute (for capacitor discharging to
protect the logic board ass'y from damages).
- Do not touch the timing slit strip film and timing slit disk. No grease or abrasion is allowed.
- Protect the units from soiled with ink.
- Protect the housing from scratches.
- Exercise caution with the screws, as follows:
i. The screws of the paper feed motor may be loosened only at replacement of the paper feed motor unit (DO NOT
loosen them in other cases).
ii. DO NOT loosen the red screws on both sides of the main chassis, securing the carriage shaft positioning (they are
not adjustable in servicing)
For Germany:
A lithium battery is installed in the mini260. Please be cautious of the following:
- At repair:
Risk of explosion if battery is replaced by an incorrect type.
Explosionsrisiko, falls Batterie nicht mit vorgeschriebenem Baterrietypus ersetzt wird.
- At disposal:
Dispose of used batteries according to the local regulations.
Batterienentsorgung gemaess lokalen Vorschriften.
When the Service Manual issued by CINC is localized, be sure to include the above cautions (at repair and disposal) in German.
For California, U.S.A.:
Included battery contains Perchlorate Material-special handling may apply.
See http://www.dtsc.ca.gov/hazardouswaste/perchlorate/ for detail.
<Part 1: 3-1. Notes on Service Part Replacement>
1-10

3-2. Special Notes on Repair Servicing
Be sure to protect the machine, especially the LCD, operation panel unit, scanner unit, and logic board, from static
electricity in repair servicing.
(1) Flexible cable and harness wiring, connection
Be cautious of wiring of the flexible cables and harness. Improper wiring or connection may cause breakage of a line,
leading to ignition or emission of smoke.
(I) Logic board ass'y wiring
Logic board ass'y wiring (front side):
Logic board ass'y wiring (back side):
Part 1: MAINTENANCE TABLE OF CONTENTS
1-11

(II) Panel cable wiring
1-12

(III) Coin battery unit wiring
(IV) Purge unit wiring
(V) LF motor cable, paper feed encoder cable, and platen sensor cable wiring
1-13

(VI) Platen sensor unit wiring
(2) Main cover assembly
Be cautious not to fasten the main cover ass'y (QL-1700) screws too tight.
If the screws are fastened too tight, the main cover may be forced down, contacting the carriage.
1-14

(3) Carriage unit replacement
When replacing the carriage unit (QM2-3897), confirm the carriage flexible cable position.
Incorrect positioning of the carriage flexible cable will cause malfunction due to contact of the cable to other parts, or
deformation of the cable itself.
(I) Carriage flexible cable position
Confirm that the carriage flexible cable is not seen in the concave-shaped space of the carriage FCC holder.
(II) Carriage FCC holder sheet position
Attach the carriage FCC holder sheet in the red rectangle-indicated position.
1-15

(4) Platen unit assembly
When replacing the platen unit (QM2-3976), confirm that the bridge sheets at the bottom of the platen unit do not curl or
bend.
Curled or bent sheets may prevent ink flow from the borderless ink absorber to the main ink absorber, causing ink leakage
from the absorbers.
Bridge sheet position:
Insert the sheets in the holes of the chassis.
<Part 1: 3-2. Special Notes on Repair Servicing>
1-16
