imagePROGRAF
INFOGRAPHICS AND POSTERS
LARGE-FORMAT PRINTING

The imagePROGRAF iPF8400SE and
iPF6400SE printers are aimed specifically
at users who wish to produce colorful, eye-
catching sales promotion posters, banners,
and point-of-purchase materials for vibrant
displays at a low cost.
These 6-color, large-format solutions make
on-site poster printing quick and easy, and
they offer a variety of features to help
enhance workflows.
• iPF8400SE: 44"-wide, cost-effective printer
that's optimized for poster printing on a
variety of media. Ideal for producing
retail signs, posters, banners, and more.
• iPF6400SE: 24"-wide, compact solution
that's ideal for retailers, restaurants,
businesses, and schools.
FEATURES
•6-Color LUCIA EX Ink Set helps achieve the vibrant
color reproduction required for point-of-purchase and
poster output while helping to ensure high-quality
color printing that's scratch-resistant.
•Red Ink is included to help produce eye-catching
and vibrant prints.
•The compact design allows for placement in small
offices or stores.
•Sub-ink tank system and high-capacity ink tanks offer
continuous printing.
•Enhanced PosterArtist Lite software provides high-
quality poster creation in just four easy steps!
•Economy Print Mode helps reduce ink consumption
and minimize printing costs.
Infographics and Posters

EYE-CATCHING POSTERS
The SE Series is designed for the emerging
infographics market. Posters, banners, and
signage will stand out to your customers,
thanks to the Red ink that’s featured in this
6-color LUCIA EX ink set. The Red ink helps
make prints and posters more vibrant to the
eye and helps bring users a simple, low-cost
yet high-quality solution for poster printing that
hasn’t been offered before. And with various
print modes and the ability to use different
types of media, the SE Series offers an array of
customization options for poster creation needs.
Markets
• Retail Signage
• Education
• Government
The iPF SE Series is an ideal solution for anyone
looking to create eye-popping posters, banners,
and infographics. With these types of users in
mind, Canon has designed the iPF SE Series to
be integrated seamlessly with its PosterArtist
Lite software. This easy-to-use software is
template-driven and includes predesigned
templates, royalty-free images, and clip art.
Users can create professional posters, banners,
and signage in just four easy steps–for almost any
application! A new image correction function for
PosterArtist Lite automatically corrects image colors
and enables a "cut out" function where selected
areas of an image, such as backgrounds, can be
removed for enhanced customization. A free version
of PosterArtist Lite comes with every iPF8400SE
and iPF6400SE printer, and a full version of
PosterArtist is available for purchase. The full
version includes some added value features such
as an expanded library of templates and variable
data printing.
imagePROGRAF
• Restaurants
• Businesses
• And more
PosterArtist poster creation software

0183W776
0214-iPFSE-10M-LTM
imagePROGRAF
SPECIFICATIONS
Print-Head
PF-05 (One)
Technology
FINE (Full-Photolithography Inkjet Nozzle Engineering)
Print Resolution (Max.)
Up to 2400 x 1200 dpi
Ink Type
LUCIA EX Ink (Pigment-based)
Ink Tank
iPF8400SE
PFI-306 (330ml): BK, MBK, C, M, Y, R
PFI-706 (700ml): BK, MBK, C, M, Y, R
iPF6400SE
PFI-106 (130ml): BK, MBK, C, M, Y, R
PFI-206 (300ml): BK, MBK, C, M, Y, R
Colors
Cyan, Magenta,Yellow, Black, Matte Black, Red
Ink Tank Shipped with Printer
6 Colors (Full 330ml Each Color)
6 Colors (90ml Starter Tank Each Color)
Printer Memory
iPF8400SE: 384MB
iPF6400SE
: 256MB
Media Feed
iPF8400SE
Front-Loading Roll Feed: One Roll, Front Output
Front-Loading Manual Feed: One Sheet, Front
Output
iPF6400SE
Top-Loading Roll Feed: One Roll, Front Output
Top-Loading Manual Feed: One Sheet, Front
Output
Media Width
iPF8400SE
Cut Sheet: 8” – 44”
Roll Feed: 10” – 44”
iPF6400SE
8” – 24” (Cut Sheet and Roll)
Minimum Media Length
iPF8400SE:
8” (203mm)
iPF6400SE
Top-Loading Roll Feed: 8”(203mm)
Top-Loading Manual Feed: 11.0”(279mm)
Maximum Print Length
iPF8400SE
Manual Feed: 63”(1.6m)
Roll Feed: 59’(18m)*
iPF6400SE
Top-Loading Roll Feed: 59’(18m)*
Top-Loading Manual Feed: 63”(1.6m)
Borderless Printing Widths (Roll Media Only)
iPF8400SE
10”/14”/17”/24”/36”/42”/44”/B2
[20.28”(565mm)]/
A1 [23.38”(594mm)]/ A0 (33.11”/841mm)/
B0 [40.55”(1030mm)]
iPF6400SE
10”/14”/16”/17”/24”/B4 [9.84”(250mm)]/
A2 [16.54”(420mm)]/ B2 [20.28”(515mm)]/
A1 [23.38”(594mm)]
Printer Stand
Standard
Media Thickness
iPF8400SE
0.07mm - 0.8mm (2.8mil - 31.4mil)
iPF6400SE
0.07mm - 0.8mm (2.8mil - 31.4mil)
Media Core Sizes
2” or 3” Core (with Supplied Adapter)
Printable Margins (iPF8400SE)
Manual Feed (Front)
Leading and Left/Right Edges: 0.20“ (5mm)
Trailing Edge: 0.90“ (23mm)
Top: 0.79“ (20mm)
Roll Feed
All Sides: 0.20“ (5mm) or 0“ for Borderless
Printable Margins (iPF6400SE)
Manual Feed (Top/Front)
0.12" (3mm)
Maximum Media Roll Outer Diameter
5.9“ (150mm)
Bundled Software
Printing Software
Canon Printer Driver, Printer Driver Extra Kit
(Free Layout, imageRUNNER®Linking Function),
Print Plug-in for Microsoft Office (PC only),
Optimized Module for AutoCAD (PC only)
Applications
PosterArtist Lite (PC only)
Direct Print & Share
Utilities
imagePROGRAF Status Monitor (Windows®),
Print Monitor (Macintosh®), Media Configuration
Tool, Remote UI, Accounting Manager (PC only)
Printer Language
GARO (Canon Proprietary)
Operating Systemn
Windows XP (32/64 bit), Server 2003 (32/64 bit),
Server 2008 (32/64 bit), Windows Vista (32/64 bit),
Windows 7 (32/64 bit), Windows 8 (32/64 bit),
Macintosh OS X 10.5.8 -10.7x
Interface
Standard
USB 2.0 High-Speed
10/100Base-T/TX
Acoustic Noise
iPF8400SE: Operation 50dB or Less
iPF6400SE: Operation 49dB or Less
Power Supply
AC 100-240V (50-60Hz)
Power Consumption
iPF8400SE
Maximum: 190W or Less
Standby (100-120V): 5W or Less
Power Off: .5W or Less
iPF6400SE
Maximum: 100W or Less
Standby (100-120V): 5W or Less
Power Off: .5W or Less (Compliant with
Executive Order)
Certifications
UL, FCC Class B, ENERGY STAR®
Operational Environment
Temperature: 59 – 86 F° (15 – 30 C°)
Relative Humidity: 10 – 80% (No Condensation)
Dimensions with Stand (H x W x D)
iPF8400SE: 45” x 74.5” x 38.2”
iPF6400SE: 39.1” x 40” x 34.3”
Weight
iPF8400SE: Approx. 258 lb.
iPF6400SE: Approx. 119 lb.
User-Replaceable Items
iPF8400SE
Print-Head (PF-05)
Maintenance Cartridge (MC-08)
Durable Rotary Media Cutter (CT-06)
iPF6400SE
Print-Head (PF-05)
Maintenance Cartridge (MC-16)
Options
iPF8400SE
Roll Holder Set RH2-44
PosterArtist (PC Only)
iPF6400SE
Roll Holder Set RH2-25
PosterArtist (PC Only)
* The maximum printable length varies depending on the
application, OS, and RIP used. The maximum printable
length from Canon Printer Driver is 50 feet.
n
For imagePROGRAF Printer Driver. For printing from
PostScript®applications such as AdobeIllustrator®or
QuarkXPress,®please use a PostScriptcompatible RIP
package. For a list of Canon recommended RIP packages,
please consult with Canon Alliance and Industry Market
program list of RIP vendors.
As anENERGY STAR®Partner, Canon U.S.A., Inc. hasqualified these models as meeting the ENERGY
STAR energy efficiency criteria through an EPA recognized certification body. ENERGY STAR and the
ENERGY STAR markare registered U.S. marks. CANON, IMAGEPROGRAF, IMAGERUNNER, LUCIA, and the
GENUINE logo are registered trademarks of Canon Inc. in the United States and may also be registered
trademarks or trademarks in other countries. All other referenced product names and marks are
trademarks of their respective owners. Specifications and availability subject to change without
notice. All output images and eects are simulated.
©2014 Canon U.S.A., Inc. All rights reserved.
Large Format Solutions
100 Park Boulevard
Itasca, Illinois 60143
1-800-714-4427 | 1-773-714-4076
www.csa.canon.com
email: [email protected]
LFS-51307 DS 3/14 CC1/PDF
