TECHNICAL
DOCUMENTS
MFP LARGE-FORMAT IMAGING
imagePROGRAF

DesignedforAEC,CAD,andGIStechnical
documentsandgeneraluse,the36”
imagePROGRAFMFPlarge-formatimaging
systemshelpunlockthefullpotentialof
yourproductivity.TheseiPFMFPsystems
haveascannerstandthatconnectsdirectly
totheprinterstandtocreateaone-piece
structure.And,younowhaveoptionsto
congurethemonitor’sposition.
36” imagePROGRAF
iPF765/760 MFP Systems
Large-format scan-to-copy/file/e-mail solutions
for technical document environments.
FEATURES
•Acompleteworkowsolutionincludeslarge-format
scanner,printer,integrated stand,computer,and
intuitivetouch-screeninterface.
•Thescannerstandconnectsdirectly to the printer
standtocreateaone-piecestructure.
•Monitor configuration optionsincludeswingarm,
height,andleft-orright-sidemounting.
•HorizontalFlat Stacker/Basketneatlystacksupto
twenty24”x36”plainpaperprints.
•Achievemaximumscanspeedsofuptoten inches
per secondformonochromedocuments.
•EconomyPrintModeallowsfor lower cost of
operation.

TECHNICAL INNOVATIONS
Builtwiththeuserinmind,theimagePROGRAFiPF765/760MFPSystems
includefeaturesthatmakethemeasyandpracticaltouse.
imagePROGRAF MFP
HARDWARE DESIGN
Thescannerstandisdesignedtoconnectdirectlytothe
printerstandtocreateaone-piece structurethathelps
reducethetotalfootprintoftheiPFMFP.Thestandgivesyou
theexibilitytouseasan“all-in-one”congurationorbeset
upasanindependentscannerstand.Therealsoareoptions
forthemonitorpositionincorporatedintothenewdesign.
Youcanchoosewhichsideofthestandtoplacethemonitor
andwhethertouseastraightoraswingarm.Whenusingthe
swingarm,youcanchoosebetweentwoheightoptions.This
single-standdesigneliminatestheneedtomovetheprinterand
scanner,piecebypiece,whensettinguporrelocatingtheMFP.
TheintegratedFlat Stacker/Basketprovidesthecapability
toneatlystackuptotwenty24”x36”plainpaperprints.The
basketcanbeconguredasaregularbasket,asmallstacker,
oralargeratstacker/basket.
EMBEDDED SECURITY
Anewinterface lock systemenhancesthesecurityfunctions
oftheprinter.Thisfeatureprovidesanoptionforadministrative
controltorestrictusagetotheprinter.TheimagePROGRAF
iPF765printerisequippedwithaharddriveerasefeature
thatcompletelyerasesdatasenttotheprinterfromthe
printer’sharddisk.Thishighest level of erasuremeetsthe
U.S.DepartmentofDefenserequirements(DoD5220.22-M)
forerasureofdiskmedia.
CIS SCANNING TECHNOLOGY
TheimagePROGRAFiPFMFPusesCIStechnologytocapture
thenestimagedetailintechnicaldocuments,maps,sketches,
hand-annotateddrawings,andcomplexschematics.With
true 600-dpi optical resolution,youcanachieveexceptional
monochromeperformancewithverysharp,cleanimagesas
wellashigh-denitioncolorreproduction.Anddynamicpreview
ensuresthatscansandcopiesmatchoriginalhard-copy
documentseverytime.
INNOVATIVE SOFTWARE
TheincludedSmartWorksMFPsoftwareprovidesuserswith
aneasy-to-useinterfacethatrequireslessinteractionbetween
theuserandthesoftware.Thiswillreducethetimespent
preparingeachprintandstreamlinetheprocessaswell.The
interfaceincludeslabelsforeachbutton,makingprintingale
orscanningtocopyorle/e-mailaseasyas1-2-3.Thelarge
previewscreenmakesiteasierforuserstomakeeditsandsee
dynamicchangeson-screen.
Large preview screen
•Makeeditsandseedynamicchangeson-screen
•Pressgreenbuttonandapplyallchangestooriginal
scannedle
Image Editing Capabilities
•ManualDeskewFeature
•BrightenFeature
•CropFeature
•ZoomIn/OutFeature
HIGH-QUALITY OUTPUT
Printcomplexschematicswithsuper-clearsmalltextfontsand
crisplinesovercolorbackgrounds,evenonuncoatedtechnical
papers.Asuper-high-densityprint-headejectstiny4pldroplets
ofinkthatconsistentlyproduce2400 x 1200 dpi output with
fine lines within +/- 0.10% accuracyandasthinas0.02mm.
AndCanon’sunique5-colorReactiveink-setdeliversdurable,
smudge-resistantprintswithsharplinesandtext,boldcolors,
andsmoothlls.
WithfourlinesofimagePROGRAFlarge-formatsolutions…
whateveryourneeds,Canonhastheanswer.

Scan Speed*
 •24-bitFullColor@200dpi:1.67”(persecond)
 •8-bitGrayscaleandMonochrome@200dpi:
10”(persecond)
Scan Modes
 •16.7-millionColorRGB(24-bit)
 •256colorRGBadaptiveindexedcolorpalette(8-bit)
 •256-levelGrayscale(8-bit)
 •BlackandWhite(1-bit)
Color Space
 NormalizedRGB
Resolution
 •2400dpi(maximum)
 •600dpi(optical)
Scan Accuracy**
 +/-0.1%;+/-1pixel
Maximum Image Width
 40Inches
Maximum Media Width
 41Inches
Maximum Scan Length
 96Inches
Maximum Media Thickness
 0.012Inches(0.3mm)
Media Feed System
 Singlelargediameterprecisiongrounddriveroller;
adaptiveCISmediafocusmanagementandmedia
guidemechanism;intuitiveface-up,front-loading,and
front-exitmediapathwithsidejustication;automatic
mediasizedetectionwithreliableopticalmediasensors
Digital Imaging Technology
 ContactImageSensor(CIS)Technology
 •5xclose-spaced“deepfocus”CIS(25,000pixels)
 •48-bitRGBdigitalcolorimagecapture
 •16-bitgrayscaleimagecapture
 •Panchromaticmonochromeandblackandwhite
 •Bi-directionalextralong-lifeLEDlightsystemfor
optimumobjectilluminationandinstant-on
scanningcapability
Digital Image Processing
 •2DIntelligentAdaptiveThresholding(IAT)(1-bitmode)
 •FixedThresholdBlackandWhite(1-bitmode)
 •DynamicNormalizationApplication(DNA)with
16-bitsupersampling
User Status and One-Touch Operation
 CentermountedLCDscannercontrolpanel;
 walk-upoperationanduserselectionofscannermode
 withstop,forward,rewind,scan,andcopybuttons;
 locallanguageoptions,paneloverlay,andMagnetic
 MediaGuide
Included Software
 SmartWorksMFPscan-to-le,copy,e-mailwith
 real-timeimageviewer.SupportsTIFF,JPEG,TIFFG4,
andPDF.
Operating System
 Windows7Professional(64-bit)
User Maintenance
 Installableplug-n-playscanner;simplecleaning
Scanner Interface Kit
 USB2Hi-speed
Operating Environments
 10–30°C,35-80%RH,non-condensing
External Power Supply
 100-250VACautosensing+/-10%,50-60Hz
Scanner Power Consumption
 •40Wh(Scanning)
 •4.2Wh(Stand-by)
Compliances
 CB,CE,FCC,UL,RoHS,ENERGYSTAR
®
MFP Dimensions
 Height: Swingarmhigh:63”
  Swingarmlow:56.2”
  Straightarm:68.2”
 Width: Withswingarmextended:78.5”
  Withstraightarm:61.2
 Depth: Flatstacker:47.3”
  Regularbasket:38.4”
  Closed:31.2”
What’s In The Box?
 •imagePROGRAFPrinter***
 •CiC40ScannerwithpowercordandUSB2.0Cable
(ScannertoServer)
 •2MeterUSBCable(ServertoPrinter)
 •CiC40MFPStand
 •CiC40MFPStandAssemblyInstructions
 •SmartWorksMFPSoftware
 •Computer
 •FlatPanelTouch-screenDisplay
 •InstallationandOperationManual
 •OperatorManualonCD-ROM
 *  Thescanrateisproportionalacrossthefullrangeof
resolutionssupportedbythescanner.Actualscantimes
willdependonthehostsystemperformance.Quoted
topspeedsmaybelimitedbytheeffectivebandwidth
oftheUSB2andisnotguaranteedforallmediatypes.
 ** Thequotedscanaccuracymayvarydependingonthe
operatingenvironmentandthethicknessofthemedia.
*** Pleaserefertowww.usa.canon.com/imageprograffor
specicationsforimagePROGRAFprintermodels.
As an ENERGY STAR®Partner, Canon U.S.A., Inc. has determined that this product meets the ENERGY STAR guidelines for energy
efficiency. ENERGY STAR and the ENERGY STAR mark are registered U.S. marks. CANON, IMAGEPROGRAF, and the GENUINE logo are
registered trademarks of Canon Inc. in the United States and may also be registered trademarks or trademarks in other countries.
IMAGEANYWARE is a trademark of Canon. All other referenced product names and marks are trademarks of their respective owners
and are hereby acknowledged. Some items may not be available at this time; please check for availability. Specifications and
availability subject to change without notice. All printer output images are simulated. MFP shown with iPF765 printer.
©2012 Canon U.S.A., Inc. All rights reserved.
