1 TurningthePoweronandoff
Printingisenabledassoonasyouturnonthepower.Pleasenotethatalldatawillbelostwhenyou
turnofftheprinter.Theinstructionsbelowshowthecorrectwaytoturntheprinteronandoff.
TurningthePoweron
Followtheinstructionsbelowtoturnthepoweron.
Howtoturnthepoweron
1
Pressthepowerswitchonthelowerrightsideofthefrontpaneltoturnonthe
printer.
Pressthepowerswitchtothe｜position.
Thedisplayfillswiththe ■symbolandtheprinterrunsacheckontheoperationpanel
indicatorsasshownbelow.
qオンライン,印刷可,メッセージ
wジョブ,papertray,upperpapercassette
eMiddlepapercassette,lowerpapercassette,両面
オンライン
排出
両面
給紙選択
ジョブ
メッセージ
印刷可
① ②
③
Thenumberinthemessageandthe印刷可indicatorflash.
オンライン
排出
両面
給紙選択
ジョブ
メッセージ
印刷可
Theオンラインand印刷可indicatorsflashandprintingisenabled.
オンライン
排出
両面
給紙選択
ジョブ
メッセージ
印刷可
02ｼﾊﾞﾗｸｵﾏﾁｸﾀﾞｻｲ
00ｲﾝｻﾂｶﾉｳ A4

3
TurningthePoweroff
Followtheinstructionsbelowtoturnofftheprinter.Alwayscheckthatthereisnoprinting
dataremainingintheprinter’smemorybeforeyouturnofftheprinter.
• Ifthepoweristurnedoffwhentheジョブindicatorison,anyprintingdata
remainingintheprinter’smemoryislost.Pressthe 排出 keywhileoff-line
tooutputanyimportantprintingdatabeforeturningoffthepower.
•Donotturnoffthepowerwhentheprinterisstartingup.
Howtoturnthepoweroff
1
Checkthattheジョブindicatorisoff.

ジョブ
印刷可
メッセージ
2
Pressthepowerswitchonthelowerrightsideofthefrontpaneltoturnoffthe
printer.
Pressthepowerswitchtothe○position.
Powersaving(Paneloffmode)
Theprinterusesanon-demandfixingmethodsothepowerusedwhenthe
printerisinstand-bymodeisnegligible.Howevertheprinterwillturnoffall
operationpanelindicatorsexceptforthe印刷可indicator(paneloffmode)to
savepowerifnooperationsarecarriedoutandnodataissentfromthe
computerforasettime.
Thepaneloffmodeisautomaticallycanceledifdataissentfromthecomputer
oranoperationpanelkeyispressed.
Youcansetthepaneloffmodetime-outfromthemenu.

4
2 Paper
Usethecorrectpaperinordertogetthebestperformancefromyourprinter.Using
incompatiblepapercanleadtoreducedprintingqualityandpaperjamming.
CompatiblePaperTypesandPaperFeedMethods
Papercompatibleforthepapercassette
Youcanloadthefollowingstandardsizepaperintothepapercassette.
Papertype Size(Weight) Max.sheetno. Outputsheetno.
Plainpaper A3,A4,A5,B4,B5(64-90g/m2)approx.250 approx.150
/64g/m2
Secondaryoriginal
drawingpaper A3,A4,B4,B5 approx.250 1
(Tracingpaper)
•YoucanloadLedger-,Legal-,Letter-andExecutive-sizepaperintothe
optionalL-shapedpapercassette.
Papercompatibleforthepapertray
Youcanloadthefollowingsizesofpaperintothepapertray.
Papertype Size(Weight) Max.sheetno. Outputsheetno.
Plainpaper width:100-297mm, approx.100 approx.150
length:148-432mm(64-90g/m2) /64g/m2
Thickpaper width:100-297mm, approx.50 approx.150
length:148-432mm(90-128g/m2) /128g/m2
Secondaryoriginal
drawingpaper A3,A4,B4,B5 approx.100 1
(Tracingpaper)
Transparencies A4(CanondomesticLBP approx.50 approx.100
transparencies:8.7g)
Labelsheet A4( Canondomesticlabelsheet:7.8g ) approx.40 approx.100

5
Labelsheet
•Thefollowingtypesoflabelsheetcancausepaperjamsthatarehardto
removeordamagetheprinter.Donotusesheetthathasadhesive
surfacesexposedorsheetfromwhichlabelshavebeenremovedtoleave
thelowersurfaceexposed.
Transparencies
•Transparenciesmaybedifficulttoseparatefromeachother.Takeseveral
sheetsandloosenthembyflexingthemseveraltimesbeforeloadingthem
intotheprinter.
Secondaryoriginaldrawingpaper(Tracingpaper)
•Sheetsoftracingpapermaybedifficulttoseparatefromeachother.Take
severalsheetsandloosenthembyflexingthemseveraltimesbefore
loadingthemintotheprinter.
•Checkwhichsideofthepaperisfaceupandwhichsideisfacedown.
Whenyouloadtracingpaperintothepapercassette,loaditsothatthe
face-upsideisfacedown.Whenyouloadtracingpaperintothepapertray,
loaditsothattheface-upsideisfaceup.
•Whenyoufirstopenapacketoftracingpaper,thepapercouldbewarped.
Beforeloadingthepaperintotheprinter,leaveitinitspackagingforawhile
toallowittostraightenout.
•Removeeachsheetoftracingpaperfromtheoutputtrayassoonasitis
outputtedtopreventpaperjams.
− Ifyouwanttouserecycledpaperintheduplexunit −
Ifyouuserecycledpaperthathasbeenstoredinextremelyhumidconditions
suchasduringthewetseasonorinaroomwithoutair-conditioningduring
summerthiscouldcausethepapertocreaseorbendatthecorners.
Ifthishappens,itshouldbedealtwithinthefollowingways.
・Leavethepaperinanair-conditionedroomfortwohoursbeforeusingit
・Turnthepaperoversothattheothersideisfacingupwhenyouloadthe
paperintotheprinter
Ifthepaperstillcreasesorbendsatthecornersafteryouhavetriedtheabove
solutions,usenewpaper.

6
IncompatiblePaper
Inordertoavoidpaperjamsanddamagingtheprinter,donotusethefollowingkindsof
paper.
Paperthatjamseasily
•Paperthatistoothickortoothin
•Non-standardsizepaper
•Wetordamppaper
•Tornpaper
•Coarseorextremelysmoothpaper
•Labelsheetwithbinderholes,serratedpaper
•Curledpaper,creasedpaper
•Speciallycoatedpaper
•Labelsheetwithlabelsthatpeeloffeasily
•Paperwhichhasalreadybeenusedforphotocopyingorlaserprinting
(reversesidealsoincompatible)
Heat-sensitivepaper
•Paperwithinkthatmelts,burnsorgivesofftoxicvapoursintheheatofthe
fixingassembly(approx.150℃)
•Thermalpaper
•Colorpaperwithaprocessedsurface
•Speciallycoatedpaper
•Paperwithadhesiveonit
Paperthatcancauseprintermalfunctionordamage
•Carbonpaper
•Paperwithstaples,clips,ribbonsortapeattached
•Paperwhichhasalreadybeenusedforphotocopyingorlaserprinting
(reversesidealsoincompatible)
Paperonwhichtonercannotfixeasily
•CoarsepapersuchaspulppaperandJapanesewritingpaper
•Paperwithroughfibers
•Speciallycoatedpaper

7
PrintableAreas
Theareasthatcanbeprintedonthepaperaregivenbelow.
● Plainpaper,thickpaper,tracingpaper,transparencies,labelsheet
Plainpaper,thickpaper,tracingpaper,transparencies,andlabelsheetcanbeprintedinareas
withaminimummarginof5millimeters.
5mm
5mm
5mm
5mm

8
StoringPaper
Evenpaperthatmeetsyourprinter’sspecificationscandeteriorateifstoredimproperly.Such
papercancausemisfeedsorpaperjams,andcanleadtoreducedprintingquality.
Whenstoringpaper,observethefollowingprecautions:
•Paperisparticularlysensitivetomoisture,andshouldbekeptawayfrom
dampareas.
•Thepackagingthatthepaperissoldinisdesignedtoresistmoisture.Keep
paperinitsoriginalpackaginguntilyouarereadytouseit.Returnany
unusedpapertoitspackaging.
•Storepaperflat.
•Avoidstoringpaperonthefloor,becausefloorsareoftendamp.
•Donotpositionthepaperwhereitmightbecomecurledorcreased.
•Donotstorepapervertically,orinexcessivelyhighstacks.
•Donotstorepaperinlocationsthataredirectlyexposedtosunlightorhigh
humidity.
•Ifthereisaconsiderabledifferenceintemperaturebetweenwherethe
paperisstoredandwheretheprinteris,movethepaperinitspackagingto
theprinter’slocationforaboutadaybeforeusingthepaper.Thisallowsit
toadjusttothenewtemperature.Rapidchangesintemperatureand
humiditycancausethepapertocurlorcrease.

9
3 LoadingPaper
Thisprinterhasauniversal-typepapercassettethatcanbeloadedwithamaximumof250
sheetsofplainA3-,B4-,A4-,B5-orA5-sizepaper(64g/m2).
Loadthesetypesofpaperinthefollowingways.
A4
B5
A5
A3
B4
A4R
Widthwise  Lengthwise
LoadA4-sizepaperwidthwise.YoucanloadA4-sizepaperlengthwise(A4R),
butifyoudothisyoumustchangethe[ヨウシノムキ]setting.
Followtheprecautionsbelowinordertoavoidpaperjams.
•Alwaysturntheprinteronbeforeinsertingthepapercassetteforthefirst
timeafterpurchasingit.Ifyouloadthepapercassetteintotheprinter
withoutturningontheprinter,thiscouldcausetheprintertooutputblank
sheetsofpaperwhenitisturnedon.
•Donotremovethepapercassetteduringprinting.Doingsocanleadto
paperjammingordamage.
•Onlyloadplainpaper(64-90g/m2).
•Donotloadpaperthatiscreasedorseverelycurled.
•Makesurethatthestackisnothigherthanthepaperlimitmarkonthe
papersizeguide.
•Youcanloadapproximately250sheetsofplainpaper(64g/m2)intothe
printer.
•See2Paper(→p.4)formoredetailsoncompatiblepaper.
•Refillwithpaperaftertheloadedpaperhasrunout.Refillingwithpaper
beforeithasrunoutcanleadtoincorrectpaperfeeding.

10
Howtoloadpaperintothepapercassette
1
Readythepapercassettefromwhichyouhaveremovedthestopper,andthe
cassettecover.
● Ifthepapercassettehasalreadybeenloadedintotheprinter,removethepapercassettefromthe
printerandthenremovetheuppercassettecover.
A4
Papercassette
Cassettecover
2
Lineuptherearpapersizeguidewiththemarkindicatingthesizeofthepaper
youwanttoload.
Youcanremovethepapersizeguidebypushingitdowninthedirectionofthecenterofthe
cassetteasshowninthediagram.Lineuptheguidewiththemarkindicatingthesizeofthepaper
youwanttoloadandthenpositionit.
Pushthepapersize
guidedowntowardsthe
centerofthecassetteto
removeit.
Rubberpad
Withthepapersize
guidestillbenttowards
thecenterofthe
cassette,lineitupwith
theholesindicatingthe
sizeofthepaperyou
wanttoloadandraiseit
totheverticalposition.
A5 B5 A4 A4R B4 A3
•Nevertouchtherubberpadatthefrontofthepapercassette.Thiscould
leadtoafeedmalfunction.

11
3
Slidetheouterpapersizeguidestolinethemupwiththemarksindicatingthe
sizeofthepaperyouwanttoload.
Theouterpapersizeguidesmovetogether.
A3 / A4
11x17 / LTR
EXE
B4 / B5
LGL
A5/ A4R
Papersizeguides
Papersizeindicator
4
Lineuptherearedgeofthepaperstackwiththepapersizeguideandloadthe
paperintothecassette.Pressthefrontedgeofthepaperdownsothatboth
sidesareundertheretainingclips.
Papersizeguide
Paperlimitmark
Retainingclips
•Makesurethatthestackisnothigherthanthepaperlimitmarkonthe
papersizeguide.
5
Setthepapersizeindicatoraccordingtothesizeoftheloadedpaper.
Pa
p
ersizeindicator

12
6
Attachthecassettecoverandinsertthepapercassetteintotheprinter.
Insertitslowlyuntilitsfrontsurfaceisflushwiththefrontsurfaceoftheprinter.
•Makesureyoucorrectlyattachthecassettecovertothepapercassette.
Whenanoptionalduplexunitisattachedtotheprinter,youcannotduplex
printifthecassettecoverhasnotbeenattachedtothepapercassette,is
looseorhasslipped.
•Alwayscheckthattheloadedpapersizeisthesameasthatshownonthe
papersizeindicatorbeforeinsertingthepapercassetteintotheprinter.If
theindicatedsizeisdifferent,thiscouldcauseamalfunction.
•Ifthepaperoverlapswhenitissentthrough,turnthepaperaround(theend
thatcomesintocontactwiththerubberpadatthefrontofthepaper
cassette)inthepapercassetteandreloadthecassette.

13
4 PaperJams
(HowtoRemoveJammedPaper)
Ifapaperjamoccursinsidetheprinterforanyreasonduringprinting,analarmsounds,the
message[13 ヨウシガ ツマリマシタ]appearsinthefirstlineonthedisplayanda
messageindicatingthelocationofthepaperjam(themessages[キュウシブ],[ウエ カ
バー],[コウブ カバー]and[リョウメン ユニット](appearsonlywhenaduplexunit
isattached))appearsinthesecondlineonthedisplay.Ifapaperjamoccurs,checkthe
positionofthejamasgiveninthemessageandremoveanyjammedpaper.
•Leavetheprinterturnedonwhileremovingjammedpaper.Ifyouturnthe
poweroff,theprintingdatawillbedeleted.
•Ifthereismorethanonepaperjam,theyarealldisplayedinsequence.
Checkallthelocationsgiveninthemessage.
LocatingJammedPaper
Ifapaperjamoccurs,checkthepositionofthejamasgiveninthemessageonthedisplay.
Standardmodel
•Openthetopcoverandremovethetonercartridge.
•Pulloutthepapercassette.
•Opentherearcover.
•Ifitisgoingtotakesometimetoclearthepaperjam,wrapthetoner
cartridgeintheprotectivebagthatitcameinorwrapitinathickclothto
protectitfromthelight.
•Ifthetonercartridgegetsstuckinsidetheprinterandyoucannotremoveit
fromtheprinter,donottrytoforceitout.Contactthedealerfromwhomyou
purchasedtheprinter.

14
Paperflowduringsinglesideprinting
Paperpassesthroughtheprinterbytherouteindicatedinthediagrambelow.If
apaperjamoccurs,usethemessageonthedisplayandthediagrambelowas
aguidetocheckthepositionofthepaperjam.
Optionalpapercassette
ProceduresforRemovingPaperJams
Thefollowingproceduresshowhowtoremovepaperjamsdependingontheirlocation.
■[ウエ カバー][キュウシブ]
qWhenpaperjamsbeforeitgetstothefixingassembly
Followtheinstructionsbelowtoopenthetransferguide,(front)or(rear),andremoveany
jammedpaper.
1
Openthetransferguide(front)andslowlypulloutanyjammedpaperwithbothhands.

Transferguide(front)
• Theopeningandclosinganglesofthetransferguide(front)areapproximately
90｡.Theguidemaybecomedistortedifyouforceitopentoomuchandthis
couldleadtoreducedprintingqualityortheprinterbreakingdown.

15
2
Turnthegreenfixedscrewonthetransferguide(rear)inthedirectionofthe
arrowtoloosenit.
Loosenthefixedscrewuntilyoucanopenthetransferguide(rear).Youdonotneedtocompletely
removethescrew.
Transferguide(rear)
•Ifyoudoremovethescrew,makesurethatyoudonotdropitintothe
printer.
3
Holdthefixedscrewandopenthetransferguide(rear),thenslowlypulloutany
jammedpaperwithbothhands.
•Theopeningandclosinganglesofthetransferguide(front)areapproximately
90｡.Theguidemaybecomedistortedifyouforcethemopentoomuchandthis
couldleadtoreducedprintingqualityortheprinterbreakingdown.
•Makesurethatyoudonottouchthetransferchargingrollerwhenyouare
removingthepaperjam.

16
4
Closethetransferguide(rear)andturnthefixedscrewintheoppositedirection
tothearrowtotightenit.
Firmlytightenthefixedscrew.
•Whentheleadingedgeofthepaperhasalreadybeenfedasfarasthe
fixingassembly,alwaysremovethepaperfromthereardoorside.(→[③
Whenthepaperhasbeenfedasfarasthefixingassembly]p.18)
•Tonerfromthepartthathasbeentransferredhasnotbeenfixedonthe
paperyet.Ifyoutouchthispartofthepaperyouwillgettoneronyourhand.
Takeholdofapartofthepaperthathasnotbeentransferredtopulloutthe
papersothatyoudonotgettoneronyourhands.
•Ifyougettoneronyourhandsorclothingwashitoffwithwater
immediately.
•Afteryouhaveremovedthepaper,returnthetransferguidetoitsoriginal
positionbeforeyouloadthetonercartridge.

17
■[キュウシブ]
w Whenthepaperjamsassoonasithascomeoutofthepapercassette
Pulloutthepapercassetteandthencarryouttheinstructionsgivenin①toopenthetransfer
guide(front)or(rear).Afteryouhavedonethis,slowlypullthepapertowardsthepaper
cassettesidewithbothhandstoremoveit.
•Ifyoudonotopenthetransferguide,youmaynotbeabletoremovethe
paperfromthecassetteside.Ifyouuseforcetopulloutthepaperthiscould
tearthepaper,leavingscrapsofpaperthatyoucannotremoveinsidethe
printer.
•Whentheoptionalpapercassetteorduplexunitisattachedpulloutallthe
papercassettesandthejammingtreatmenttrayandremoveanyjammed
paperthatiseasytoremovefirst(→[Iftheoptionalduplexunitisattached]
p.19)

18
■[コウブ カバー]
eWhenthepaperhasbeenfedasfarasthefixingassembly
Opentherearcoveratthebackoftheprinterandlowertheleftandrightfixingassembly
pressurereleaselevers.Pullthegearreleaseleverforwardandpulloutthepaperwithboth
hands.
Fixingassembly
pressurereleaselever
Gearreleaselever
Fixingassembly
pressurereleaselever
•Afteryouhaveremovedthepaper,returntheleftandrightfixingassembly
pressurereleaseleversandthegearreleaselevertotheiroriginalpositions
beforeyouclosetherearcover.
•Whenthepaperhasbeenfed
asfarasthefixingassembly
andtherearpartofthepaper
isstuckinthetransferguide,
donotremovethepaperfrom
thefrontofthetransferguide.
Ifthetransferguideisdirty,
thiscouldleadtomarksbeing
printedonprintouts.
•Afteryouhaveremovedthepaperjam,marks,resultingfromtonerleftin
theprinter,maybeprintedonthefirstfewprintoutswhenprintingis
resumed.Feedafewsheetsofpaperthroughtheprintertocheckthatno
marksareprintedontheprintouts.
Transferguide(front)

19
Iftheoptionalduplexunitisattached
•Openthetopcoverandremovethetonercartridge.(→ p.13)
•Pulloutthepapercassette.(→ p.13)
•Separatetherearunitoftheduplexunitfromtheprinter.
•Openthetopcoveroftheduplexunit.
•Pulloutthejammingtreatmenttrayfromthefrontoftheduplexunitandremoveit.
Jammingtreatmenttray
Paperflowduringduplexprinting
Paperpassesthroughtheprinterbytherouteindicatedinthediagrambelow.If
apaperjamoccurs,usethemessageonthedisplayandthediagrambelowas
aguidetocheckthepositionofthepaperjam.
Optionalduplexunit
Optionalpapercassette
