Canon MX720 Series Setup guide

MX720 series
Online Manual
Printing
Copying
English

Printing
Printing from a Computer
Printing with Application Software that You are Using (Printer Driver)
Printing Using the Operation Panel of the Machine
Printing Photo Data
Printing Template Forms Such As Lined Paper or Graph Paper
Printing Documents (PDF File) Saved on a USB Flash Drive
Using Web Service Printing
Notice for Web Service Printing
Printing Photos in Online Photo Album
Downloading and Printing Template Forms
Settings for Web Service
Printing with Google Cloud Print
Preparations for Printing with Google Cloud Print
Printing from Computer or Smartphone with Google Cloud Print
Printing from a Digital Camera
Printing Photographs Directly from a PictBridge Compliant Device
About PictBridge Print Settings
Printing from a Bluetooth Compliant Device
Printing from Mobile Phone via Bluetooth Communication
About Bluetooth Communication
Handling Precautions
Preparation to Use the Bluetooth Unit
Printing Data via Bluetooth Communication
Basic Procedure for Printing via Bluetooth Communication
Bluetooth Settings
Specifications

Printing from a Computer
Printing with Application Software that You are Using (Printer Driver)

Printing Using the Operation Panel of the Machine
Printing Photo Data
Printing Template Forms Such As Lined Paper or Graph Paper
Printing Documents (PDF File) Saved on a USB Flash Drive

Using Web Service Printing
Notice for Web Service Printing
Printing Photos in Online Photo Album
Downloading and Printing Template Forms
Settings for Web Service

About Bluetooth Communication
Handling Precautions
Preparation to Use the Bluetooth Unit
Printing Data via Bluetooth Communication
Basic Procedure for Printing via Bluetooth Communication
Bluetooth Settings
Specifications

Copying
Making Copies Basic
Displaying the Preview Screen
Setting Items
Reducing or Enlarging a Copy
Two-Sided Copying
About Other Copy Functions
Copying Two Pages to Fit onto a Single Page
Copying Four Pages to Fit onto a Single Page
Copying Thick Originals Such as Books
Copying without Borders
Collated Copying
Copying Photos

Printing with Application Software that You are Using (Printer
Driver)
Printing with Easy Setup Basic
Various Printing Methods
Changing the Print Quality and Correcting Image Data
Overview of the Printer Driver
Updating the MP Drivers

Printing with Easy Setup
This section describes a simple procedure for specifying Quick Setup tab settings that allow you to
perform printing suited to this machine.
For details about the Quick Setup tab, see "Quick Setup Tab."
1. Check that the machine is turned on
Confirming that the Power Is On
2. Load paper on the machine
Loading Paper
3. Open the printer driver setup window
How to Open the Printer Driver Setup Window
4. Select a frequently used profile
In Commonly Used Settings on the Quick Setup tab, select a printing profile suited for the purpose.
When you select a printing profile, the Additional Features, Media Type, and Printer Paper Size
settings are automatically switched to the values that were preset.
5. Select the print quality
For Print Quality, select High, Standard, or Fast according to your purpose.

Important
The print quality settings that can be selected may differ depending on a printing profile.
6. Check the paper source
Check that Paper Source is set to Cassette.
Important
The paper size determines whether the upper or lower cassette is used. The cassette to be
used is displayed below Paper Source.
7. Complete the setup
Click OK.
When you execute print, the document is printed with settings that match your purpose.

Important
When you select the Always Print with Current Settings check box, all settings specified on the
Quick Setup, Main, and Page Setup tabs are saved, and you can print with the same settings from
the next time as well.
In the Commonly Used Settings window, click Save... to register the specified settings.
Registering a Frequently Used Printing Profile.

Quick Setup Tab
The Quick Setup tab is for registering commonly used print settings. When you select a registered setting,
the machine automatically switches to the preset items.
Related Topics
Printing with Easy Setup
Setting a Page Size and Orientation
Setting the Number of Copies and Printing Order
Execute Borderless Printing
Duplex Printing
Setting Up Envelope Printing
Printing on Postcards
Displaying the Print Results before Printing
Setting Paper Dimensions (Custom Size)
Printing a Color Document in Monochrome
Specifying Color Correction
Adjusting Color Balance
Adjusting Color Balance Using Sample Patterns (Printer Driver)
Adjusting Brightness
Adjusting Intensity
Adjusting Contrast
Adjusting Intensity/Contrast Using Sample Patterns (Printer Driver)
Registering a Frequently Used Printing Profile

Setting the Media Type with the Printer Driver
When you use this machine, selecting a media type that matches the print purpose will help you achieve
the best print results.
You can use the following media types on this machine.
Commercially available papers
Media name Media Type in the printer driver
Plain Paper (including recycled paper) Plain Paper
Envelopes Envelope
Canon genuine papers (Photo Printing)
Media name <Model No.> Media Type in the printer driver
Photo Paper Pro Platinum <PT-101> Photo Paper Pro Platinum
Glossy Photo Paper "Everyday Use" <GP-501> Glossy Photo Paper
Photo Paper Glossy <GP-502> Glossy Photo Paper
Photo Paper Plus Glossy II <PP-201> Photo Paper Plus Glossy II
Photo Paper Pro Luster <LU-101> Photo Paper Pro Luster
Photo Paper Plus Semi-gloss <SG-201> Photo Paper Plus Semi-gloss
Matte Photo Paper <MP-101> Matte Photo Paper
Canon genuine papers (Business Letter Printing)
Media name <Model No.> Media Type in the printer driver
High Resolution Paper <HR-101N> High Resolution Paper
Canon genuine papers (Original Products)
Media name <Model No.> Media Type in the printer driver
T-Shirt Transfers <TR-301> T-Shirt Transfers
Photo Stickers <PS-101> Glossy Photo Paper

Various Printing Methods
Setting a Page Size and Orientation
Setting the Number of Copies and Printing Order
Setting the Stapling Margin
Execute Borderless Printing
Fit-to-Page Printing
Scaled Printing
Page Layout Printing
Tiling/Poster Printing
Booklet Printing
Duplex Printing
Stamp/Background Printing
Registering a Stamp
Registering Image Data to be Used as a Background
Setting Up Envelope Printing
Printing on Postcards
Displaying the Print Results before Printing
Setting Paper Dimensions (Custom Size)
Editing the Print Document or Reprinting from the Print History

Setting a Page Size and Orientation
The paper size and orientation are essentially determined by the application software. When the page size
and orientation set for Page Size and Orientation on the Page Setup tab are same as those set with the
application software, you do not need to select them on the Page Setup tab.
When you are not able to specify them with the application software, the procedure for selecting a page
size and orientation is as follows:
You can also set page size and orientation on the Quick Setup tab.
1. Open the printer driver setup window
2. Select the paper size
Select a page size from the Page Size list on the Page Setup tab.
3. Set Orientation
Select Portrait or Landscape for Orientation. Check Rotate 180 degrees check box when you want
to perform printing with the original being rotated 180 degrees.
4. Complete the setup
Click OK.
When you execute print, the document will be printed with the selected page size and the orientation.
Note
If Normal-size is selected for Page Layout, then Automatically reduce large document that the
printer cannot output is displayed.
Normally, you can leave the Automatically reduce large document that the printer cannot output
check box checked. During printing, if you do not want to reduce large documents that cannot be
printed on the printer, uncheck the check box.

Setting the Number of Copies and Printing Order
The procedure for specifying the number of copies and printing order is as follows:
You can also set the number of copies on the Quick Setup tab.
1. Open the printer driver setup window
2. Specify the number of copies to be printed
For Copies on the Page Setup tab, specify the number of copies to be printed.
3. Specify the print order
Check the Print from Last Page check box when you want to print from the last page in order, and
uncheck the check box when you want to print from the first page.
Check the Collate check box when you are printing multiple copies of a document and want to print
out all pages in each copy together. Uncheck this check box when you want to print all pages with the
same page number together.
•Print from Last Page: /Collate:
•Print from Last Page: /Collate:
•Print from Last Page: /Collate:

•Print from Last Page: /Collate:
4. Complete the setup
Click OK.
When you execute print, the specified number of copies will be printed with the specified printing order.
Important
When the application software that you used to create the document has the same function, specify
the settings on the printer driver. However, if the print results are not acceptable, specify the function
settings on the application software. When you specify the number of copies and the printing order
with both the application software and this printer driver, the number of copies may be multiplied
numbers of the two settings or the specified printing order may not be enabled.
Print from Last Page appears grayed out and is unavailable when Tiling/Poster is selected for
Page Layout.
When Booklet is selected for Page Layout, Print from Last Page and Collate appear grayed out
and cannot be set.
When Duplex Printing is selected, Print from Last Page appears grayed out and cannot be set.
Note
By setting both Print from Last Page and Collate, you can perform printing so that papers are
collated one by one starting from the last page.
These settings can be used in combination with Normal-size, Borderless, Fit-to-Page, Scaled, Page
Layout, and Duplex Printing.

Setting the Stapling Margin
The procedure for setting the staple side and the margin width is as follows:
1. Open the printer driver setup window
2. Specify the side to be stapled
Check the position of the stapling margin from Stapling Side on the Page Setup tab.
The printer analyzes the Orientation and Page Layout settings, and automatically selects the best
staple position. When you want to change the setting, select from the list.
3. Set the margin width
If necessary, click Specify Margin... and set the margin width, and then click OK.
Note
The printer automatically reduces the print area depending on the staple position margin.

4. Complete the setup
Click OK on the Page Setup tab.
When you execute print, the data is printed with the specified staple side and margin width.
Important
Stapling Side and Specify Margin... appear grayed out and are unavailable when:
Borderless, Tiling/Poster, or Booklet is selected for Page Layout
Scaled is selected for Page Layout (When Duplex Printing is also selected, only Stapling Side
can be specified.)

Execute Borderless Printing
The borderless printing function allows you to print data without any margin by enlarging the data so that it
extends slightly off the paper. In standard printing, margins are created around the document area.
However, in borderless printing function, these margins are not created. When you want to print data such
as a photo without providing any margin around it, set borderless printing.
The procedure for performing borderless printing is as follows:
You can also set borderless printing in Additional Features on the Quick Setup tab.
Setting Borderless Printing
1. Open the printer driver setup window
2. Set borderless printing
Select Borderless from the Page Layout list on the Page Setup tab.
Click OK when the confirmation message appears.
When a message prompting you to change the media type appears, select a media type from the list
and click OK.
3. Check the paper size
Check the Page Size list. When you want to change it, select another page size from the list. The list
displays only sizes that can be used for borderless printing.
