Canon imagePROGRAF W6200 User manual

AY3-4308-002
OCT. 2003
COPYRIGHT  2003 CANON INC. CANON W6200 N 1003 0.00-0 PRINTED IN JAPAN (IMPRIME AU JAPON)
REVISION 0

1003 N 0.00-0

Target Readers
This manual is published by Canon Inc. for qualified persons and contains the necessary
technical information for technical theory, installation, maintenance, and repair of
products. This manual covers all localities where the products are sold. For this reason, it
may contain information that does not apply to your locality.
Revisions
This manual may include technical inaccuracies or typographical errors due to
improvements or changes in the products. When amendments are made to the content of
this manual, Canon will issue technical information as the need arises. In the event of
major alterations to the content of this manual over a long or short period, Canon will
publish a revised version of the manual.
The following paragraph does not apply to any countries where such provisions are
inconsistent with local law.
Trademarks
The product names and company names appearing in this manual are the registered
trademarks or trademarks of the individual companies.
Copyright
This manual is copyrighted and all rights reserved. Under the copyright laws, this
manual may not be copied, reproduced, or translated into other languages, in whole or in
part, without the express written consent of Canon Inc. except in the case of internal
business use.
Copyright 2003 by Canon Inc.
CANON INC.
L Printer Quality Support Division
16-1, Shimonoge 3-chome, Takatsu-ku, Kawasaki-shi, Kanagawa 213-8512, Japan
This manual was produced on an Apple®Power Macintosh®G3 personal computer and
Canon LASER SHOT LBP-730PS laser beam printer; final pages were printed on Genasett
3100Q.
All logos graphics were produced with MACROMEDIA FREEHAND7.0J.
All documents and all page layouts were created with QuarkXPress3.3J.

I. ABOUT THIS MANUAL
This manual is divided into five parts containing the information required for
servicing the W8200 printer.
Part 1: Safety and Precautions
This part contains information on how to service the unit safety. It is very
important, and must be read.
Part 2: Product Specifications
This part outlines the product and its specifications.
Part 3: Operating Instructions
This part explains how to operate the unit properly, how it is installed, and how
to use the service mode.
Part 4: Technical Reference
This part outlines the unit operation giving a technically.
Part 5: Maintenance
This part explains maintenance of the unit. It includes details of disassembly /
assembly, adjustments required when assembling, troubleshooting procedures, and
wiring / circuit diagrams, etc.
This manual does not contain complete information required for
disassembling and assembling the printer. Please also refer to the
separate Parts Catalog.
REF.
I

II. TABLE OF CONTENTS
Page Part 1: SAFETY AND PRECAUTIONS
1 - 1 1. SAFETY PRECAUTIONS
1 - 1 1.1 Moving Parts
1 - 2 1.2 Ink
1 - 2 1.2.1 Ink passages
1 - 4 1.2.2 Ink mist
1 - 5 1.3 Electrical Parts
1 - 6 2. OTHER PRECAUTIONS
1 - 6 2.1 Printhead
1 - 6 2.1.1 How to handle the printhead
1 - 7 2.1.2 Capping
1 - 7 2.1.3 When the printer is not used for a long time
1 - 7 2.1.4 Conductivity of ink
1 - 8 2.2 Ink Tank
1 - 8 2.2.1 Opening the ink tank
1 - 8 2.2.2 Handling the ink tank
1 - 9 2.3 Handling the Printer
1 - 9 2.3.1 Precautions against static electricity
1 -10 2.3.2 Fixing the carriage
1 -11 2.3.3 Replacing the maintenance cartridge
1 -11 2.3.4 Refilling the ink
1 -12 3. PRECAUTIONS WHEN SERVICING THE PRINTER
1 -12 3.1 Stored Data
1 -13 3.2 Firmware Confirmation
1 -13 3.3 Precautions Against Static Electricity
1 -13 3.4 Precautions for Disassembly/Assembly
1 -13 3.5 Self-Diagnostic Feature
1 -13 3.6 Disposing of Waste Ink
1 -13 3.7 Disposing of Lithium Battery
Part 2: PRODUCT SPECIFICATIONS
2 - 1 1. PRODUCT OVERVIEW
2 - 1 1.1 Product Overview
2 - 2 1.2 Features
2 - 3 1.3 Printhead
2 - 3 1.4 Ink Tank
2 - 4 1.5 Cutter Unit
2 - 4 1.6 Roll Holder
2 - 5 1.7 Consumables
2 - 5 1.7.1 Printhead
2 - 5 1.7.2 Ink tank
2 - 5 1.7.3 Cutter unit
2 - 6 2. SPECIFICATIONS
2 - 6 2.1 General Specifications
2 -10 2.2 Interface Specifications
2 -10 2.2.1 Network
2 -11 2.2.2 USB (option)
2 -12 2.2.3 IEEE1394 (option)
2 -13 2.3 Printer Driver Types
2 -13 2.3.1 Printer driver
2 -13 2.3.2 Printer utility
II

Page Part 3: OPERATING INSTRUCTIONS
3 - 1 1. NAMES AND FUNCTIONS OF COMPONENTS
3 - 1 1.1 Names and Functions of Components
3 - 1 1.1.1 Front
3 - 2 1.1.2 Rear
3 - 2 1.1.3 Carriage unit
3 - 3 1.1.4 Internal part
3 - 4 2. TRANSPORTING THE PRINTER
3 - 4 2.1 Transporting the Printer
3 - 5 2.1.1 Moving the printer on the same floor
3 - 6 2.1.2 How to transport the printer to a different floor
3 - 8 2.1.3 Manual capping
3 - 9 2.2 Reinstalling the Printer
3 - 9 2.2.1 Installing the printer on the same floor
3 - 9 2.2.2 Installing the printer on a different floor
3 -10 3. OPERATION
3 -10 3.1 Operation Panel
3 -12 3.2 Change of Printer Status
3 -13 3.3 Main Menu
3 -13 3.3.1 Main menu operations
3 -14 3.3.2 Map of the main menu
3 -18 3.3.3 Contents of main menu
3 -24 4. PRINTER SERVICING FUNCTIONS
3 -24 4.1 Service Mode
3 -24 4.1.1 Service mode operation
3 -25 4.1.2 Map of the service mode
3 -28 4.1.3 Details of service mode
3 -39 4.2 Error Indicators
3 -40 4.2.1 Overview of warning and error codes
3 -41 4.2.2 Warning and error codes
3 -44 4.2.3 Description of warning and error codes
3 -50 5. PRINTER SPECIAL MODE
3 -50 5.1 Controller Replace Mode
3 -50 5.2 Download Mode
3 -51 6. PRINTER SERVICE SOFTWARE
3 -51 6.1 Overview of Service Software
3 -51 6.1.1 Firmware updating tool
3 -51 6.1.2 Firmware recovery tool
3 -51 6.1.3 Service information access software
3 -52 6.2 Firmware Updating Tool
3 -52 6.3 Firmware Recovery Tool of the System Controller
3 -52 6.3.1 Firmware recovery procedure
3 -56 6.4 Service Information Access Software
3 -59 6.4.1 Service information access procedure
Part 4: TECHNICAL REFERENCE
4 - 1 1. OVERVIEW
4 - 1 1.1 Printer Block Diagram
4 - 2 1.2 Print Signal Sequence
4 - 5 1.3 Print Driving
4 - 5 1.3.1 Print drive control
4 - 6 1.3.2 Print drive timing
4 - 7 2. FIRMWARE
4 - 7 2.1 Power On/Off
4 - 7 2.1.1 Power On
III

Page
4 - 8 2.2 Power Off
4 - 8 2.2.1 Power Off sequence
4 - 9 2.3 Print Control
4 - 9 2.3.1 Print mode
4 -10 2.4 Print Position Adjustment
4 -10 2.4.1 Print position adjustment
4 -11 2.5 Overheating Protection Control of Printhead
4 -11 2.6 Pause between Pages
4 -11 2.7 White Raster Skip
4 -11 2.8 Sleep Mode
4 -13 3. PRINTER MECHANICAL SYSTEM
4 -14 3.1 Ink Passage
4 -14 3.1.1 Overview of the ink passage
4 -16 3.2 Ink Tank Unit
4 -16 3.2.1 Structure of ink tank unit
4 -18 3.3 Carriage Unit
4 -18 3.3.1 Carriage functions
4 -19 3.3.2 Structure of carriage
4 -22 3.4 Printhead
4 -22 3.4.1 Structure of printhead
4 -26 3.5 Purge Unit
4 -26 3.5.1 Functions of purge unit
4 -28 3.5.2 Structure of purge unit
4 -31 3.6 Maintenance Cartridge
4 -31 3.6.1 Maintenance cartridge
4 -32 3.7 Air Flow
4 -32 3.7.1 Air flow
4 -33 3.8 Paper Path
4 -33 3.8.1 Overview of paper path
4 -37 3.9 Structure of Paper Path
4 -37 3.9.1 Structure of feed rollers
4 -38 3.9.2 Structure of cutter unit
4 -39 4. PRINTER ELECTRICAL SYSTEM
4 -39 4.1 Overview
4 -41 4.2 System Controller
4 -41 4.2.1 System controller components
4 -44 4.3 Engine Controller
4 -44 4.3.1 Engine controller components
4 -48 4.4 Carriage Relay PCB
4 -48 4.4.1 Carriage relay PCB components
4 -49 4.5 Head Relay PCB
4 -49 4.5.1 Head relay PCB components
4 -50 4.6 Power Supply
4 -50 4.6.1 Power supply block diagram
4 -51 5. DETECTION FUNCTIONS
4 -51 5.1 Detection Functions Based on Sensors
4 -51 5.1.1 Sensors for covers
4 -53 5.1.2 Ink passage system
4 -56 5.1.3 Carriage system
4 -58 5.1.4 Paper path system
IV

Page Part 5: MAINTENANCE
5 - 1 1. MAINTENANCE
5 - 1 1.1 List of Regular Replacement Parts
5 - 1 1.2 List of Consumables
5 - 1 1.3 List of Regular Maintenance
5 - 2 2. SERVICE TOOLS
5 - 2 2.1 List of Tools
5 - 3 2.2 Using the Cover Switch Tool
5 - 4 3. APPLYING THE GREASE
5 - 6 4. SERVICE PARTS
5 - 6 4.1 Service Parts
5 - 6 4.1.1 Keep all packages with the warning not to turn over.
5 - 6 4.1.2 Feed roller
5 - 7 5. DISASSEMBLY/REASSEMBLY
5 - 7 5.1 Disassembly/Reassembly
5 - 8 5.1.1 Disassembly/assembly flowcharts for major parts
5 -10 5.2 Points to Note on Disassembly and Reassembly
5 -10 5.2.1 Note on locations prohibited from disassembly
5 -11 5.2.2 Manual carriage movement
5 -12 5.2.3 Units required for draining the ink
5 -13 5.2.4 Outer covers
5 -19 5.2.5 Driving unit
5 -20 5.2.6 Ink tube unit
5 -25 5.2.7 Carriage unit
5 -30 5.2.8 Feeder unit
5 -31 5.2.9 Purge unit
5 -32 5.2.10 Ink tank unit
5 -33 5.2.11 Boards
5 -36 5.3 Opening the Caps and Moving the Wiper Unit
5 -36 5.3.1 Opening the caps and releasing the carriage lock pins
5 -37 5.3.2 Retracting the cap
5 -38 5.3.3 Moving the wiper unit
5 -38 5.4 Opening and Closing the Ink Supply Valve
5 -39 5.5 Draining the Ink
5 -39 5.5.1 Automatic ink drainage
5 -39 5.5.2 Manual ink drainage
5 -43 6. ADJUSTMENT AND SETUP
5 -43 6.1 Adjustment and Setup Items
5 -43 6.1.1 Adjustment of head holder tilt lever
5 -43 6.2 Adjustment and Setup Procedures
5 -43 6.2.1 Adjustment of the head holder tilt lever
5 -44 7. TROUBLESHOOTING
5 -44 7.1 Outline of Troubleshooting
5 -44 7.1.1 Outline
5 -44 7.1.2 Notice for Troubleshooting
5 -45 7.2 Troubleshooting When Warnings Occur
5 -45 7.2.1 Ink Check
(W01000, W01001, W01002, W01003, W01004, W01005)
5 -45 7.2.2 MTCart Full Soon
(W01006)
5 -46 7.2.3 Memory Overflow
(W0100C)
5 -46 7.2.4 Feed Limit..
(W0100F)
5 -46 7.2.5 Incorrect Media
(W01021)
V

Page
5 -47 7.2.6 No full bleed
(W01022)
5 -47 7.2.7 W01030/W01031/W01032/W01033/W01034/W01035/W01036/
W01037/W01038/W01039: GARO W0103x (number is indicated by x)
5 -48 7.3 Troubleshooting When Errors Occur
5 -48 7.3.1 E02000
Roll media end error
5 -48 7.3.2 E0200D/E02016
Cut sheet end error
5 -49 7.3.3 E0200A/E0200B/E0200C/E0200E/E0200F/E02010/E02017/E02018
Media sensor error
5 -50 7.3.4 E02015
Cutter error
5 -50 7.3.5 E02400/E02401/E02402/E02403
Path mismatch error
5 -51 7.3.6 E02404/E02405
Borderless printing error
5 -51 7.3.7 E02500/E02501/E02502/E02503/E02504/E02505
Ink empty error
5 -52 7.3.8 E02506/E02507/E02508/E02509/E0250A/E0250B
Ink tank uninstalled error (during ink tank replacement)
5 -53 7.3.9 E02520
Ink level unknown error
5 -53 7.3.10 E02521/E02522/E02523/E02524/E02525/E02526
Ink level low error
5 -54 7.3.11 E02800/E02801/E02802/E02803/E02811
Printhead error
5 -54 7.3.12 E02804/E02805/E02806/E02807/E02808/E02809/E0280A/
E0280B/E0280C/E0280D/E0280E/E0280F
Ink tank error
5 -55 7.3.13 E02812/E02A00/E02A01/E02A02/E02A03
Engine controller internal error
5 -55 7.3.14 E02815/E02816/E02817/E02818
Maintenance cartridge error
5 -56 7.3.15 E02B04
Upper cover sensor error
5 -56 7.3.16 E02B05
Right cover sensor error
5 -57 7.3.17 E02B06
Carriage cover sensor error
5 -57 7.3.18 E02D00/E02D01
Sensor error in purge unit
5 -58 7.3.19 E02D02
Carriage homeposition error
5 -58 7.3.20 E02D03
Feed motor error
5 -59 7.3.21 E02D05
Air flow fan error
5 -59 7.3.22 E02D06
Ink supply valve switching error
5 -60 7.3.23 E02E01/E02E05/E02E06
Carriage motor error
5 -61 7.3.24 E02E10
IEEE1394 error
VI

Page
5 -61 7.3.25 E02F00
System controller internal error
5 -62 7.4 Troubleshooting When Service Call Errors Occur
5 -62 7.4.1 Printhead error!
(E04000)
5 -63 7.4.2 Scale read error!
(E04002)
5 -63 7.4.3 Turn Power Off!!
(S04010/S04011/S04012)
5 -64 7.4.4 Turn Power Off!!
(E02777)
5 -65 7.5 Troubleshooting for Other Problems Indicated on the Display
5 -65 7.5.1 Incorrect Value: Check Value
5 -65 7.5.2 Offline: Load Roll Media
5 -66 7.5.3 Offline: Load Cut Sheet
Offline: Remove Cut Sheet
5 -66 7.5.4 Offline: Open Upper Cover
5 -67 7.5.5 Printer Setup: Open Upper Cover
5 -67 7.5.6 Printer Setup: Open Right Cover
5 -68 7.6 Troubleshooting for Problems Not Indicated on the Display
5 -68 7.6.1 Printer does not turn on
5 -68 7.6.2 Network is not connected
5 -69 7.6.3 Right cover does not open
5 -70 7.6.4 Printing problems (ink is full)
5 -71 7.6.5 Printing problems (ink is not full)
5 -71 7.6.6 Other printing problems
5 -72 8. CONNECTOR POSITIONS AND PIN ARRANGEMENT
5 -72 8.1 System Controller
5 -77 8.2 Engin Controller
5 -87 8.3 Carriage Relay PCB
5 -92 8.4 Head Relay PCB
5 -96 8.5 Power Supply
5 -98 9. CIRCUIT DIAGRAM
5 -100 9.1 General Circuit Diagram
5 -104 9.2 System Controller
5 -119 9.3 Engine Controller
5 -132 9.4 Carriage Relay PCB
5 -139 9.5 Head Relay PCB
5 -142 9.6 Power Supply
VII

VIII
III. ILLUSTRATION INDEX
Page Part 1: SAFETY AND PRECAUTIONS
1 - 1 Figure 1- 1 Moving Parts of the Printer
1 - 3 Figure 1- 2 Ink Passages
1 - 4 Figure 1- 3 Ink Mist
1 - 5 Figure 1- 4 Electrical Parts
1 - 6 Figure 1- 5 Printhead
1 - 8 Figure 1- 6 Installing the Ink tank
1 - 9 Figure 1- 7 Precautions Against Static Electricity
1 -10 Figure 1- 8 Capping Position
Part 2: PRODUCT SPECIFICATIONS
2 - 1 Figure 2- 1 External View of Printer
2 - 3 Figure 2- 2 Printhead
2 - 3 Figure 2- 3 Ink Tank
2 - 4 Figure 2- 4 Cutter Unit
2 - 4 Figure 2- 5 Roll Holder
2 - 5 Figure 2- 6 Printhead
2 - 5 Figure 2- 7 Filter x 2
2 - 5 Figure 2- 8 Ink Tank
2 - 5 Figure 2- 9 Cutter Unit
Part 3: OPERATING INSTRUCTIONS
3 - 1 Figure 3- 1 Front View of the Printer
3 - 2 Figure 3- 2 Rear View of the Printer
3 - 2 Figure 3- 3 Carriage Unit
3 - 3 Figure 3- 4 Internal Parts of the Printer
3 - 8 Figure 3- 5 Position of the Carriage During Manual Capping
3 -10 Figure 3- 6 Operation Panel
3 -12 Figure 3- 7 Change of Printer States
3 -12 Figure 3- 8 Correlation Diagram for Each Mode
3 -14 Figure 3- 9 Map of the Main Menu (1/3)
3 -15 Figure 3- 10 Map of the Main Menu (2/3)
3 -16 Figure 3- 11 Map of the Main Menu (3/3)
3 -17 Figure 3- 12 Map of the Media Type
3 -19 Figure 3- 13 Pattern A (Image)
3 -20 Figure 3- 14 Pattern B (Image)
3 -22 Figure 3- 15 Status Print (Image)
3 -23 Figure 3- 16 Nozzle Check Pattern (Image)
3 -23 Figure 3- 17 Viewing the Software Version
3 -25 Figure 3- 18 Map of the Service Mode (1/3)
3 -26 Figure 3- 19 Map of the Service Mode (2/3)
3 -27 Figure 3- 20 Map of the Service Mode (3/3)
3 -28 Figure 3- 21 PRINT INF (Image)
3 -29 Figure 3- 22 WARNING
3 -29 Figure 3- 23 ERROR
3 -30 Figure 3- 24 P-SETTING
3 -30 Figure 3- 25 INK CHECK
3 -31 Figure 3- 26 I/O DISPLAY
3 -32 Figure 3- 27 NOZZLE (Image)
3 -33 Figure 3- 28 SCALE (Image)

IX
Page
3 -34 Figure 3- 29 LF ACCURACY (Image)
3 -53 Figure 3- 30 com_fut.exe (Startup)
3 -53 Figure 3- 31 com_fut.exe (Setup 1)
3 -54 Figure 3- 32 com_fut.exe (Setup 2)
3 -54 Figure 3- 33 com_fut.exe (Send Image)
3 -54 Figure 3- 34 com_fut.exe (Transmission is completed)
3 -55 Figure 3- 35 com_fut.exe (Completed Image)
3 -56 Figure 3- 36 ssw (Image)
3 -57 Figure 3- 37 ssw_head (Image)
3 -58 Figure 3- 38 ssw_ink (Image)
3 -59 Figure 3- 39 Service Information Access Software (Startup 1)
3 -59 Figure 3- 40 Service Information Access Software (Startup 2)
3 -60 Figure 3- 41 Service Information Access Software (Setup 1)
3 -60 Figure 3- 42 Service Information Access Software (Setup 2)
3 -61 Figure 3- 43 Service Information Access Software (Code Input)
3 -61 Figure 3- 44 Service Information Access Software (Access Information Image)
Part 4: TECHNICAL REFERENCE
4 - 1 Figure 4- 1 Printer Block Diagram
4 - 2 Figure 4- 2 Print Signal Sequence
4 - 5 Figure 4- 3 Conceptual Diagram of Nozzle Blocks
4 - 6 Figure 4- 4 Example of Print Drive Timing (Nozzle Array Bk in Forward Printing)
4 - 7 Figure 4- 5 Flow chart after Power On
4 - 8 Figure 4- 6 Power Off Flow Chart
4 -13 Figure 4- 7 Printer Mechanical System
4 -14 Figure 4- 8 Schematic Diagram of the Ink Passage (for One Color)
4 -16 Figure 4- 9 Ink Tank
4 -17 Figure 4- 10 Ink Supply Valve
4 -19 Figure 4- 11 Carriage Unit (1)
4 -20 Figure 4- 12 Carriage Unit (2)
4 -22 Figure 4- 13 Nozzle Configuration
4 -23 Figure 4- 14 Nozzle Structure
4 -24 Figure 4- 15 Signal Contact Points
4 -27 Figure 4- 16 Purge Unit
4 -28 Figure 4- 17 Caps
4 -29 Figure 4- 18 Wiping Operation (Image)
4 -30 Figure 4- 19 Pumps
4 -31 Figure 4- 20 Maintenance Cartridge
4 -32 Figure 4- 21 Air Flow
4 -33 Figure 4- 22 Paper Path
4 -34 Figure 4- 23 Roll Media feed Sequence
4 -35 Figure 4- 24 Cut Sheet feed Sequence
4 -37 Figure 4- 25 Manual Feed Tray/Paper Feed Unit
4 -38 Figure 4- 26 Cutter Unit
4 -40 Figure 4- 27 Printer Electrical Section
4 -41 Figure 4- 28 System Controller
4 -44 Figure 4- 29 Engine Controller
4 -48 Figure 4- 30 Carriage Relay PCB
4 -49 Figure 4- 31 Head Relay PCB
4 -50 Figure 4- 32 Power Supply Block Diagram
4 -51 Figure 4- 33 Layout of Sensors for Covers
4 -53 Figure 4- 34 Layout of Sensors for Ink Passage System
4 -54 Figure 4- 35 Cap Sensor Flag
4 -54 Figure 4- 36 Pump Sensor Flag
4 -55 Figure 4- 37 Valve Cam Sensor
4 -56 Figure 4- 38 Layout of Sensors for Carriage System
4 -57 Figure 4- 39 Media Sensor (Image)
4 -58 Figure 4- 40 Layout paperpath sensor

Page Part 5: MAINTENANCE
5 - 3 Figure 5- 1 Using the Cover Switch Tool
5 - 4 Figure 5- 2 Applying the grase of carriage
5 - 4 Figure 5- 3 Applying the grease of pinch roller unit
5 - 5 Figure 5- 4 Applying the grease of feed roller
5 - 5 Figure 5- 5 Paper Release Lever Gear
5 - 6 Figure 5- 6 "Right side up" Sign
5 - 8 Figure 5- 7 Disassembly/Assembly Flowcharts for Major Parts
5 -10 Figure 5- 8 Units Needing to be Drained of Ink When the Printer is Disassembled
5 -11 Figure 5- 9 Manual Carriage Movement
5 -12 Figure 5- 10 Units Required for Draining the Ink
5 -13 Figure 5- 11 Upper Cover
5 -14 Figure 5- 12 Side Covers (1/2)
5 -14 Figure 5- 13 Side Covers (2/2)
5 -15 Figure 5- 14 Right Upper Cover
5 -15 Figure 5- 15 Right Cover
5 -16 Figure 5- 16 Front Cover
5 -17 Figure 5- 17 Upper Rear Cover
5 -17 Figure 5- 18 Rear Cover
5 -18 Figure 5- 19 Paper Release Lever
5 -19 Figure 5- 20 Drive Belt (for driving the feed roller)
5 -20 Figure 5- 21 Tube Holder
5 -21 Figure 5- 22 Removing Valve Motor Unit Cover
5 -21 Figure 5- 23 Joints
5 -22 Figure 5- 24 Prevention of ink leaks
5 -23 Figure 5- 25 Cable Mount
5 -24 Figure 5- 26 Ink Tube Unit
5 -25 Figure 5- 27 Prevention of ink leaks
5 -26 Figure 5- 28 Ink Tube Unit
5 -26 Figure 5- 29 Carriage Unit
5 -27 Figure 5- 30 Belt Stopper
5 -28 Figure 5- 31 Prevention of ink leaks
5 -28 Figure 5- 32 Lock Pin of Head Holder
5 -29 Figure 5- 33 Removing the Head Holder
5 -29 Figure 5- 34 Checking the Printhead Height Adjustment Lever
5 -30 Figure 5- 35 Feed Roller
5 -31 Figure 5- 36 Removing the Purge Unit
5 -32 Figure 5- 37 Ink Tank Unit
5 -32 Figure 5- 38 Valve Motor Unit
5 -34 Figure 5- 39 Replacing System Controller Lithium Battery
5 -36 Figure 5- 40 Opening the Caps and Releasing the Carriage Lock Pins
5 -37 Figure 5- 41 Rotation of the Purge Unit
5 -38 Figure 5- 42 Opening and Closing the Ink Supply Valve
5 -40 Figure 5- 43 Overview of Manual Ink Drainage (single color)
5 -41 Figure 5- 44 Top View of Ink Tank Unit
5 -42 Figure 5- 45 Manual Ink Drainage
5 -43 Figure 5- 46 Adjusting the Head Holder Tilt Lever
5 -72 Figure 5- 47 System Controller
5 -77 Figure 5- 48 Engin Controller
5 -87 Figure 5- 49 Carriage Relay PCB
5 -92 Figure 5- 50 Head Relay PCB
5 -96 Figure 5- 51 Power Supply
X

IV. TABLE INDEX
Page Part 4: TECHNICAL REFERENCE
4 -10 Table 4- 1 PRINT MODES
4 -24 Table 4- 2 SIGNALS AND PIN NUMBERS OF THE SIGNAL CONTACT POINTS
XI

XII
This page is intentionaly left blank

Part 1
SAFETY AND
PRECAUTIONS
Page
1 - 1 1. SAFETY PRECAUTIONS
1 - 1 1.1 Moving Parts
1 - 2 1.2 Ink
1 - 5 1.3 Electrical Parts
1 - 6 2. OTHER PRECAUTIONS
1 - 6 2.1 Printhead
1 - 8 2.2 Ink tank
1 - 9 2.3 Handling the Printer
1 -12 3. PRECAUTIONS WHEN SERVICING THE PRINTER
1 -12 3.1 Stored Data
1 -13 3.2 Firmware Confirmation
1 -13 3.3 Precautions Against Static Electricity
1 -13 3.4 Precautions for Disassembly/Assembly
1 -13 3.5 Self-Diagnostic Feature
1 -13 3.6 Disposing of Waste Ink
1 -13 3.7 Disposing of Lithium Battery

1-1
W6200 Part 1: Safety and Precautions
1. SAFETY PRECAUTIONS
1.1 Moving Parts
Be careful not to get your hair, clothes, or accessories caught in the moving parts of the
printer.
These include the carriage unit, carriage belt, ink tube and flexible cable activated by
the carriage motor; feed motor-driven feed roller and pinch roller; and purge motor-
driven purge unit.
To prevent accidents, the upper cover of the printer is locked during printing so that it
does not open. If the upper cover is opened in the online/offline mode, the carriage
motor, feed motor, and other driving power supplies are turned off.
Carriage motor
Feed roller
Pinch roller Purge unit
Carriage unit
Carriage belt
Feed motor
Ink tube
Flexible cable
Delivery unit
Figure 1-1 Moving Parts of the Printer

1.2 Ink
1.2.1 Ink passages
Be careful not to touch the ink passages of the printer or to allow ink to stain the
workbench, hands, clothes or the printer under repair.
The ink flows through the ink tank unit, carriage unit, purge unit, maintenance-jet
tray maintenance cartridge and the ink tubes that relay ink to each unit.
Although the ink is not harmful to the human body, it contains organic
solvents.
Avoid getting the ink in your mouth or eyes.
Flush well with water and see a doctor if contact occurs.
In case of accidental ingestion of a large quantity, call a doctor
immediately.
Black ink
Glycerin 56-81-5, Carbon black
Photo Cyan/Photo Magenta/Yellow inks
Glycerin 56-81-5, Ethylene glycol 107-21-1
Cyan ink
Glycerin 56-81-5, Ethylene glycol 107-21-1, Copper compound
Magenta ink
Glycerin 56-81-5
Since this ink contains pigment, stains will not come out of clothing.
Part 1: Safety and Precautions
1-2
CAUTION
W6200

1-3
W6200 Part 1: Safety and Precautions
Ink tank unit Purge unit
Carriage unit
Maintenance cartridge
Maintenance-jet tray
Figure 1-2 Ink Passages
