Canon Laser Shot LBP-950 User manual

1
TableofContents
1TurningthePoweronandoff ........................................................ 2
TurningthePoweron ........................................................................................ 2
TurningthePoweroff ....................................................................................... 3
2Paper ............................................................................................. 4
CompatiblePaper .............................................................................................. 4
IncompatiblePaper............................................................................................ 6
PrintableAreas .................................................................................................. 7
3PrintingfromthePaperCassette .................................................. 8
4PaperJams(HowtoRemoveJammedPaper) ...................................12
RemovingJammedPaper................................................................................ 13
5CancelingPrinting ....................................................................... 35
OutputtingtheData(ForcedPrinting) ..................................................................... 35
CancelingOperationsCurrentlyinProgress(SoftReset) ................................... 37
CancelingAllOperations(HardReset) .................................................................. 38
6CheckingOperations ................................................................... 39
TestPrint ......................................................................................................... 39
StatusPrint ...................................................................................................... 41

2
1 TurningthePoweronandoff
Whenyouturnthepoweron,thestatusoftheprinterandoptionaldevice(s)ischeckedbefore
printingisenabled.Whenthepoweristurnedoff,alloftheprintingdatainthememoryis
lost.Alwayscheckthattheジョブindicatorisoffbeforeturningthepoweroffinorderto
avoiddeletingimportantprintingdatabyaccidentordeletingprintingdatafromanother
computerwhenconnectedtoanetwork.
TurningthePoweron
Toturnonthepowerfollowtheinstructionsbelow.
1
Pressthepowerbuttonontheprinter.
▼ Thepowerbuttonwillnowbeinapressed-downstate.
Theoperationpanelindicatorsandthedisplaycomesonandthestatusoftheprinterandoptional
device(s)isself-diagnosed.
▼
Iftheresultsoftheself-diagnosisarenormal,theオンラインindicator,the印刷
可indicatorandtheselectedpaperfeedindicatorcomeonandprintingis
enabledwhenthemessage[00 インサツ カノウ]appearsonthedisplay.
印刷可
メッセージ
ジョブ
オンライン
排出
リセット/実行
両面
給排紙選択
ユーティリティ
動作モード
セットアップ
00ｲﾝｻﾂｶﾉｳ A4
ﾊｲｼﾄﾚｲ
Thefollowinginformationappearsonthedisplay.
Currentlyselected
paperfeedsize
Printingenabled,no
printingdatabeing
processed
Currentlyselected
outputtray
00ｲﾝｻﾂｶﾉｳ A4
ﾊｲｼﾄﾚｲ

3
TurningthePoweroff
Toturnoffthepowerfollowtheinstructionsbelow.
•Iftheprinterisconnectedtoanetwork,checkthatothercomputersarenot
printingbeforeyouturnoffthepower.
•
Ifyouturnoffthepowerwhentheジョブindicatorison,anyprintingdata
remainingintheprinter’smemorywillbelost.Gooff-line,pressthe 排出
keytooutputtheprintingdataandthenturnoffthepower. (→ p.35)
•Donotturnofftheprinterwhileprinting.
•Donotturnofftheprinterduringtheself-diagnosiscarriedoutimmediately
afterturningthepoweron.
1
Checkthattheジョブindicatorisoff.
Off
印刷可
メッセージ
ジョブ
オンライン
排出
リセット/実行
両面
給排紙選択
ユーティリティ
動作モード
セットアップ
00ｲﾝｻﾂｶﾉｳ A4
ﾊｲｼﾄﾚｲ
2
Pressthepowerbuttonontheprinter.
▼ Thepowerbuttonwillpopup.
Powersaving(Sleepmode)
Theprintercanbesettosleepmodeinordertoreducethepowerconsumed.
Whentheprinterissettosleepmode,alloftheindicatorsexceptthe印刷可
indicatorgooffifnooperationsarecarriedoutandnodataissentfromthe
computerforasettime.
Thesleepmodeisautomaticallycanceledifdataissentfromthecomputeror
anoperationpanelkeyispressed.
Thesleepmodeissetusingthemenufunction.

4
2 Paper
Theprinterhasthreepossiblepapersources,thepapercassette,thepapertrayandthe2000-
sheetpaperdeck(option).Thepaperthatcanbeloadedwilldifferaccordingtothepaper
source.Makesurethatyouloadtheproperpapertypeintotherespectiveholders.
CompatiblePaper
Usethecorrectpaperinordertogetthebestperformancefromyourprinter.Using
incompatiblepapercanleadtoreducedprintingqualityandpaperjamming.
●Standardstatus
Papersource Papertype Size Weight(g/m2) Max.sheetno.
Uppercassette Plainpaper A4,B4,Letter,Legal 64-105 approx.500
(64g/m2)
Lowercassette Plainpaper A4,B4,A3,Letter,Legal, 64-105 approx.500
Ledger (64g/m2)
Papertray Plainpaper width:100-297mm 64-105 approx.100
length190.5-432mm (64g/m2)
Thickpaper width:100-297mm 106-128 approx.50
length190.5-432mm (128g/m2)
Transparencies
A4(CanondomesticLBP − approx.50
transparencies:8.7g)
Labelsheet A4(Canondomesticlabel − approx.40
sheet:7.8g)
●Whenusingoptionaldevices
Papersource Papertype Size Weight(g/m2) Max.sheetno.
Optionallengthwise Plainpaper B5lengthwise 64-105 approx.500
upper(B5)cassette (64g/m2)
Optionallengthwise Plainpaper A5lengthwise 64-105 approx.500
upper(A5)cassette (64g/m2)
2000-sheetpaperdeck Plainpaper A4,B4,A3,Letter, 64-105 approx.2,000
(PD-82) Legal,Ledger (64g/m2)
● Plainpaper
Youcanuseplainpaperof100-297mmwidth,190.5-432mmlengthand64-105g/m2weight
withthisprinter.ThisincludesA5-,B5-,A4-,B4,A3,Executive,Letter,LegalandLedger-
sizepaper.Youcanloadstandard-sizeplainpaperintothepapercassetteand2000-sheet
paperdeck(exceptA5,B5andExecutive-size).Paperofothersizesshouldbeloadedintothe
papertray.Attachingtheoptionalduplexunitallowsyoutoautomaticallyduplexprinton
plainpaper.

5
● Thickpaper
Youcanusethickpaperof100-297mmwidth,190.5-432mmlengthand106-128g/m2
weightwiththisprinter.ThisincludesA5-,B4-,A3-,Letter-,Legal-andLedger-sizepaper.
Thickpapershouldbeloadedintothepapertray.
● Labelsheet
A4-sizelabelsheetcanbeusedinthisprinter.
Donotusethefollowingtypesoflabelsheet.Ifasheettypethatdoesnot
conformtospecificationsisused,paperjamsthatarehardtoremovemay
occurorprintermalfunctionsmaybecaused.
•Sheetwithlabelsthatarelikelytopeeloff,orsheetonwhichpartofthe
labelshavebeenused.
•Coatedsheetthatcaneasilypeelofffromthebackingsheet.
•Labelsheetwithsomeadhesivesurfacesexposed.
● Transparencies
A4-sizetransparenciescanbeusedinthisprinter.
•Sincetransparenciesarelikelytobedifficulttoseparate,usethemafter
fanningthemonesheetatatime.
•Whenoutputtingtransparenciesfaceup,removeeachtransparencyfrom
thetrayasitisoutput.Ifyouleavethetransparenciesonthetray,theywill
rollup,andapaperjamwilloccur.

6
IncompatiblePaper
Inordertoavoidpaperjamsanddamagingtheprinter,donotusethefollowingtypesof
paper.
Paperthatjamseasily
•Paperthatistoothickortoothin
•Non-standardsizepaper
•Wetordamppaper
•Tornpaper
•Coarseorextremelysmoothpaper
•Paperwithbinderholes,serratedpaper
•Curledpaper,creasedpaper
•Paperwithspecialcoatingsonit(suchascoatingsespeciallyforinkjet
printers)
•Labelsheetwithlabelsthatpeeloffeasily
•Paperthathasalreadybeenusedforphotocopyingorlaserprinting
(reversesidealsoincompatible)
Heat-sensitivepaper
•Paperwithinkthatmelts,burnsorgivesofftoxicvaporsintheheatofthe
fixingassembly(approx.180℃)
•Thermalpaper
•Colorpaperwithaprocessedsurface
•Speciallycoatedpaper(suchascoatingsespeciallyforinkjetprinters)
•Paperwithadhesiveonit
Paperthatcancauseprintermalfunctionordamage
•Carbonpaper
•Paperwithstaples,clips,ribbonsortapeattached
Paperonwhichtonercannotfixeasily
•CoarsepapersuchaspulppaperandJapanesewritingpaper,paperwith
roughfibers
•Paperwithspecialcoatingsonit(suchascoatingsespeciallyforinkjet
printers)

7
PrintableAreas
Theareasthatcanbeprintedonthepaperaregivenbelow.
● Plainpaper,thickpaper,transparencies,labelsheet
Plainpaper,thickpaper,transparenciesandlabelsheetcanbeprintedinareaswitha
minimummarginof5millimeters.
5mm
5mm
5mm
5mm

8
3PrintingfromthePaperCassette
Thepapercassetteholdsupto500sheets(64g/m2)ofplainpaper(60-105g/m2).Different
sizesofpapercanbeloadedintouppercassetteandlowercassettetoallowoperationsin
whichthepapersourceisautomaticallyswitched.
Loadingpaperintouppercassette,lowercassetteortheoptionallengthwiseuppercassetteis
doneinthesameway.Followtheinstructionsbelowtoloadpapercorrectly.
Thefollowingprecautionsshouldbetakentopreventpaperjams.
•Standardformpaperotherthanplainpaper,suchastransparenciesor
labelsheetandnon-standardformpapercannotbeloaded.
•Donotloadpaperthatiscreasedorseverelycurled.
•Donottouchtheblackrubberpadonthepapercassette.Thiswillcausea
paperfeedmalfunction.
1
Checkthattheジョブindicatorisnotflashing,pullthehandleofthepaper
cassettethatyouwanttoloadtopulloutthepapercassette.

9
2
Lineupthepapersizeguideswiththemarksindicatingthesizeofthepaperyou
wanttoload.
Papersizeguidesarelocatedontheleftandrightsidesofthepapercassettetray,atthefrontandback.
Liftthefrontoftheleftpapersizeguideandremovetheguidefromthepapercassette,thenlineupthe
guidewiththemarkindicatingthenewpapersize.
12
B4 LGL LTR A4
LTR A4 B4LGL
Fixthenewpapersizebyinsertingthepaper
sizeguideintothegrooveindicatingthenew
papersize.
Turnthelockleveroftherightpapersizeguidetotherighttounlockitq,thenlineuptheguide
withthemarkindicatingthenewpapersizew.Afteryouhavedonethis,turnthelocklevertothe
lefttolockthepapersizeguideintoposition.
A4/A3
LTR/11 17
LGL
B4
Lock
Unlock
2
1
LockLever Ifyoumovethefrontpapersizeguidetolineitupwiththe
papersizemarkontherightsideofthepapercassette,
thiswillalsoadjusttherearpapersizeguide.
3
Fanthepaper,thenstraightentheedges.
Setthepaperonaflatsurfacetolineupitsedges.
•Ifthepaperisnotstraightenedbeforeloading,thiscouldleadtoapaper
feedmalfunctionorpaperjam.

10
4
Placetheleftsideofthestackagainstthepapersizeguidethatshowsthepaper
limitmark,withthesurfacetobeprintedfacingdown.
A4-andLetter-sizepapermustbeplacedwidthwiseinthecassette.
Thepapercassettecanholdapproximately500sheetsofplainpaper(64g/m2).Makesurethatthe
stackisnothigherthanthepaperlimitmarkonthecassette.
Paperlimitmark
•IfthepaperisloadedsothatitfeedswidthwiselikeA4-orLetter-size
paper,theinsideedgewillbethepaper’sleadingedge.
ABC
Feeddirecton
•IfthepaperisloadedsothatitfeedslengthwiselikeB4-orA3-sizepaper,
thetopedgeofthepaperwillbetheleadingedge.
ABC
Feeddirection

11
5
Pressthepaperdownundertheclipsontherearandfrontguides.
6
Insertthepapersizecardthatconformswiththepapersizetobeloadedintothe
papersizecardholderonthefrontleftsurfaceofthepapercassette.
B4
A4
7
Pushthepapercassetteallthewayinuntilitlocksintopositionwithaclickingsound.
Whenthepapercassetteislockedintopositionandthepowerison,thesoundoftheprinterinoperation
willbeheard.Printingautomaticallyresumeswhenthemessage[ヨウシ ナシ]appearsonthedisplay.
•YoucanplaceA5-andB5-sizepaperlengthwiseinthepapercasetteifyou
areusinganoptionallengthwiseupperpapercassette.Contactyour
authorizedlocaldealerformoredetailsonoptionalequipment.

12
4 PaperJams
(HowtoRemoveJammedPaper)
Ifapaperjamoccursinsidetheprinterforanyreasonduringprinting,analarmsoundsand
themessage[13 ヨウシガ ツマリマシタ]appearsonthedisplay.
Paperpassesthroughtheprinterbytherouteindicatedinthediagrambelow.Thelocations
indicatedinthediagramareplaceswherepaperjamsmostcommonlyoccur.Ifapaperjam
occurs,checkthepositionofthejamasgiveninthemessageandremovethejamasshownin
thediagrambelow.
OutputTrayArea
OutputSub-Tray
Area
LeftCoverArea
DuplexUnit
Area(Option)
FrontCover
Area
StandardPaper
DeliveryRoute
PaperDelivery
Routewhen
Optional
Equipmentis
attached
TransferChargingArea
PaperTrayArea
PaperCassette
Area
RightCover
Area
PaperDeck
CoverArea
(Option)
2000-sheetPaperDeck
Area(Option)

13
RemovingJammedPaper
Whenapaperjamoccurs,followtheinstructionsbelowtoremoveit,thenprintagain.Ifthe
messagedoesnotdisappearevenwhenthejammedpaperisremovedaccordingtothis
procedure,theremaybesomescrapsofpaperleftinside.Inspecteachpartoftheprinteragain
andcompletelyremoveanyjammedpaper.
Returntheprintertoon-linestatusoncethemessage[00 インサツ カノウ]appearson
thedisplay.Printingisrestartedfromthepagewhichwasinterrupted.
•Leavetheprinterturnedonwhileremovingjammedpaper.Ifyouturnthe
poweroff,theprintingdatawillbedeleted.
•Ifyouusetoomuchforcewhenremovingjammedpaper,thepapermight
tearortheinternalpartsoftheprintermightbedamaged.Removejammed
paperbypullingitinthecorrectdirection.
•Ifthejammedpaperistorn,lookforanyremainingscrapsofpaperand
removethem.
ProcedureforRemovingJammedPaper
1
Locatethejammedpaperbyreferringtothemessageonthedisplay.
Apperaswhenpaperjams.
Thelocationofthepaperjamisdisplayed.
Ifthereismorethanonepaperjam,
theyarealldisplayedinsequence.
13ﾖｳｼｶﾞﾂﾏﾘﾏｼﾀ
ﾎﾝﾀｲﾐｷﾞｶﾊﾞｰ
2
Removethejammedpaper.
Removeanyjammedpaperfromeachofthevariouspossiblepaperjamlocationsaccordingtothe
instructionsonthefollowingpages.
3
Whenallthejammedpaperhasbeenremoved,closeallthecoversandcheck
thedisplaymessage.
Ifthereisstillanerrormessage,carryoutaninspectionagain.
Off
00ｲﾝｻﾂｶﾉｳ A4
ﾊｲｼﾄﾚｲ
印刷可
メッセージ
ジョブ
オンライン
排出
リセット/実行
両面
給排紙選択
ユーティリティ
動作モード
セットアップ
•Theerrormessagemightnotdisappearifpaperisremovedwithout
openingacover,forexamplefromthepapertrayarea,outputtrayareaor
outputsub-trayarea.Ifthishappens,alwaysopenthetopcoveronceand
thencloseitagain.

14
4
Pressthe オンライン keytoturnontheオンラインindicator.
▼ Printingisrestartedfromthepagewhereitwasinterrupted.
オンライン
排出
リセット/実行
ユーティリティ
動作モード
セットアップ
00ｲﾝｻﾂｶﾉｳ A4
ﾊｲｼﾄﾚｲ
PaperFeedArea
● [ホンタイ ミギカバー](RightCoverArea)
Checkthepapercassetteareaafteryouhaveremovedanyjammedpaper.
1
Iftheoptional2000-sheetpaperdeckisattached,openthepaperdeckcover.
2
Pullthelowerrightcoverhandleofthepapertraytoopentherightcover.

15
3
Ifthepaperjamisintheupperpapercassette,pressthegreenleverdownas
youremovethepaper.
Greenlever
4
Ifthepaperjamisinthelowerpapercassette,pulloutanyjammedpaper.

5
Closetherightcover.
Iftheoptional2000-sheetpaperdeckisattached,closethepaperdeckcover.

16
● Ifthemessages[ホンタイ ミギカバー]and[デッキ アクセスカバー]
arealternatelyflashingonthedisplay(PaperCassetteArea)
Checktherightcoverareaafteryouhaveremovedanyjammedpaper.
1
Pullthehandletopulloutthepapercassette.
2
Removeanyjammedpaper.
3
Straightenthepagesremaininginthepapercassette.
4
Pushinthepapercassetteuntilyouhearaclickingsoundasitlocksinto
position.

17
● Ifthemessages[ホンタイ ミギカバー]and[ホンタイ ウエカバー]are
alternatelyflashingonthedisplay(PaperTrayArea)
Checkthetransferchargingareaifanerrormessageisstilldisplayedafteryouhave
removedanyjammedpaper.
1
Pullouttheforwardedgeofthejammedpaperfromthepapertyayarea.
2
Straightenthepagesremaininginthepapercassette.
3
Openthetopcoverandthencloseitagain.

18
● [デッキ アクセスカバー](2000-SheetPaperDeckCoverArea)
Whenthereisapaperjaminsidetheoptional2000-sheetpaperdeckcover,followthe
instructionsbelowtoremoveanyjammedpaper.Checkthe2000-sheetpaperdeckandthe
rightcoverandremoveanyjammedpaper.
1
Openthe2000-sheetpaperdeckcover.
2
Holdthegreenlabeledareaandliftthemetalplate,thenpulloutanyjammed
paper.

19
3
Ifthepaperjamhasoccurredinthelocationshowninthediagram,pullthe
paperforward.
4
Closethe2000-sheetpaperdeckcover.
