LV-7555 （for MR3P series）
Basic Serial Command Specification

MR3P Series Basic Serial Command Function Specification Soft Engineer Division
Page 1/26
-CONTENT-
1. Overview
2. Serial Interface Specification
2.1 Communication Specification
2.2 Connection
3. Notes for Communications
4. Functional Execution Command Table
4.1 Statue Read Command Table
5. Functional Execution Command
5.1 Format
5.2 When the command pipelining is needed
5.3 Transfer Example
5.4 Necessary Condition for Operation
5.5 POWER ON Command
5.6 POWER OFF Command (Quick Power OFF)
5.7 POWER OFF Command
5.8 INPUT 1 Command
5.9 INPUT2 Command
5.10 INPU3 Command
5.11 Network Viewer Command
5.12 VOLUME + Command
5.13 VOLUME – Command
5.14 AUDIO MUTE ON Command
5.15 AUDIO MUTE OFF Command
5.16 VIDEO MUTE ON Command
5.17 VIDEO MUTE OFF Command
5.18 REGURLAR VIDEO IMAGE Command
5.19 WIDE VIDEO IMAGE Command
5.20 MENU ON Command
5.21 MENU OFF Command
5.22 DISPLAY CLEAR Command
5.23 BRIGHTNESS + Command
5.24 BRIGHTNESS – Command
5.25 INPUT 2 VIDEO Command
5.26 INPUT 2 Y, Pb/Cb, Pr/Cr Command
5.27 INPUT 2 RGB Command
5.28 IMAGE Command

MR3P Series Basic Serial Command Function Specification Soft Engineer Division
Page 1/26
5.29 ON START SETTING Command
5.30 ON START CONCELATION Command
5.31 POWER MANAGEMENT SETTING Command
5.32 POWER MANAGEMENT CANCELATION Command
5.33 D.ZOOM + Command
5.34 D.ZOOM – Command
5.35 INPUT 3 VIDEO Command
5.36 INPUT 3 S-VIDEO Command
5.37 INPUT 3 Y, Pb/Cb, Pr/Cr Command
5.38 POINTER RIGHT Command
5.39 POINTER LEFT Command
5.40 POINTER UP Command
5.41 POINTER DOWN Command
5.42 MOUSE RIGHT CLICK Command
5.43 ENTER Command
5.44 FREEZE ON Command
5.45 FREEZE OFF Command
5.46 ZOOM + Command
5.47 ZOOM – Command
5.48 FOCUS + Command
5.49 FOCUS- Command
5.50 COLOR. MANAGEMENT Command
5.51 INPUT 1 Analog RGB Command
5.52 INPUT 1 SCART Command
5.53 INPUT 1 DVI (PC Digital) Command
5.54 INPUT1 DVI (AV HDCP) Command
5.55 INPUT 1 Monitor OUT command
5.56 LENES SHIFT + Command
5.57 LENS SHIFT – Command
5.58 AUTO PC ADJ. Command
5.59 PRESENTATION TIME Command
5.60 KEYSTONE UP Command
5.61 KEYSTONE Down Command
5.62 KEYSTONE RIGHT Command
5.63 KEYSTONE LEFT Command
6. State Read Command
6.1 Format
6.2 Transfer Example

MR3P Series Basic Serial Command Function Specification Soft Engineer Division
Page 1/26
6.3 Status Read Command
6.4 Input Mode Read Command
6.5 Lam Time Read command
6.6 Setting Read Command
6.7 Temp Read Command

MR3P Series Basic Serial Command Function Specification Soft Engineer Division
Page 5 / 24
１.Overview
1.1 This Specification defines projector control commands for MR3P series (1.3 “XGA
V-4LV-7555).
1.2 The projector control commands are for controlling projector through RS232C from a
computer.
２.Serial Interface Specification
2.1 Communication Specification
Specification
Synchro system Asynchronou
Transmission Speed 9600 / 19200
Date Length 8 bit
Parity None
Stop Bit 1
Flow Control None
１.Transfer rate: initial setting value is 19200.
２.Transfer rate can be changed by service mode
2.2 Connection
Dedicated serial cable that comes with the projector must be used for a connection
to a computer and a projector.
PC Projector
COM No.1 Control Port
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
8
CD
SG
RXD
TXD
DTR
DSR
RTS
CTS
RING
（D-Sub 9 Pin）（Mini 8 Pin）

MR3P Series Basic Serial Command Function Specification Soft Engineer Division
Page 6 / 24
3. Notes for Communications
3.1 The projector command is defined one command/one line that starts “C” and
ends carriage return (0x0D).
3.2 When a projector receives carriage return (0x0D), it starts decoding.
3.3 There are two type commands, functional execution commands and state read
commands. Functional execution commands works as a remote control and key on
the projector, and State read command works to know the projector status.
Example of Functional Execution Command ：”C05” [CR]
Example of State Read Command ：”CR0” [CR]
3.4 When it takes more than one second to receive on command, it clears information of
buffer.
(until the projector receives the carriage return since the projector has received the
first data.)
3.5 When control command pipelining, after the response, wait interval of time as below.
3.5.1 “VOLUME +/-“ ”ZOOM UP/DOW””FOCUS UP/DOWN” ”LENS-SHIF
UP/DOWN/LEFT/RIGHT” Commands →100ms
3.5.2 Other Commands →500 ms
3.6 Wait at least 500ms after the response, when status read command pipelining.
3.7 Do not issue command before the Response in the situation as below, except no
response after 5 seconds.
3.8 It takes about 7 seconds for internal initialization after plugging in AC. During this
time, it cannot process command. Do not issue any commands.
3.9 7 seconds after Stand By or Power ON, Even when a projector receives a command, a
computer receives acceptable response, but it does not execute for internal
initialization and lamp lighting process. However, Status Read Commands are
executed after 500ms when they receive acceptable response.
3.10 About performance during processing count down or cooling down.
When a projector receives After Stand By or Power ON, Even when a projector
receives a command, a computer receives response to accept the command, but it
does not execute for internal initialization and lamp lighting process. However,
Status Read Commands are executed after 500ms when a computer receives
acceptable response.
3.11 When a projector receives a command while processing count down after Power ON
or cooling down after Power Off, a computer receives response to accept the
command but the command is not executed.
However, Status Read Commands are executed.

MR3P Series Basic Serial Command Function Specification Soft Engineer Division
Page 7 / 24
3.12 About performance when changing INPUT
After receiving INPUT switching command, when receiving commands between 5
seconds from starting the switching to completing the switching, a computer receives
acceptable command, but it is not executed.
However, status read commands are executed after a computer receives response to
accept the command, after 500ms. Response command characters for status read
success are different. See “7, State Read Command” for the details.
3.13 Command are shown in a capital letter (A 〜Z). Lower case letters are not
available.
4. Functional Execution Command Table
Command Item Command Item
C00 POWER ON C33 INPUT 3 VIDEO
C01 POWER OFF (Quick Power OFF) C34 INPUT 3 S-VIDEO
C02 POWER OFF C35 INPUT 3 Y,Pb/Cb,Pr/Cr
C05 INPUT 1 C3A POINTER RIGHT
C06 INPUT 2 C3B POINTER LEFT
C07 INPUT 3 C3C POINITER UP
C08 NETWORK C3D POINITER DOWN
C09 VOLUME + C3E MOUSE RIGHT CLICK
C0A VOLUME - C3F ENTER
C0B AUDIO MUTE ON C43 FREEZE ON
C0C AUDIO MUTE OFF C44 FREEZE OFF
C0D VIDEO MUTE ON C46 ZOOM -
C0E VIDEO MUTE OFF C47 ZOOM +
C0F REGULAR VIDEO IMAGE(4:3）C4A FOUCS -
C10 WIDE VIDEO IMAGE(16:9) C4B FOUCS +
C1C MENU ON C4E COLOR MANAGEMENT
C1D MENU OFF C50 INPUT 1 Analog RGB
C1E DISPLAY CLEAR C51 INPUT 1 SCART
C20 BRIGHTNESS + C52 INPUT 1 DVI (PC Digital)
C21 BRIGHTNESS - C53 INPUT 1 DVI (AV HDCP)
C23 INPUT 2 VIDEO C54 INPUT 1 Monitor OUT
C24 INPUT 2 Y,Pb/Cb,Pr/Cr C5D LENS SHIFT +
C25 INPUT 2 RGB C5E LENS SHIFT -
C27 IMAGE C89 AUTO PC ADJ.
C28 ON START Enable C8A PRESENTATION TIMER
C29 ON START Disable C8E KEYSTONE ↑
C2A POWER MANAGEMENT Enable C8F KEYSTONE ↓
C2B POWER MANAGEMENT Disable C90 KEYSTONE →
C30 D.ZOOM + C91 KEYSTONE ←
C31 D.ZOOM -

MR3P Series Basic Serial Command Function Specification Soft Engineer Division
Page 8 / 24
３ 1. State Read Command Table
Command FUNCTION RENARKS
CR0 Status Read
CR1 Input Mode Read
CR3 Lamp Time Read
CR4 Setting Read
CR6 Temp Read
４ Functional Execution Command
４.1 Format
１.PC issues a command as below format.
“Ｃ” Command [CR]
Command：2 characters（See Functional Execution Command Table）
２.A projector changes received data to decode and send a return result after
being ready to receive next command.
[ACK]［CR］：（0x06、0x0D）When a projector receives a functional execution
command.
“？”［CR］：When cannot read receiving data
４.2 When the command pipelining is needed
When some functions need command pipelining, the performance is the same as
the remote control’s performance.
１.System: issue command every 100ms
２.When receiving any relevant command, the function is executed continuously
for 120ms.
３.When receiving the same command continuously with 120ms, the function is
executed for 120ms from that moment.
４.After 120ms, the next command is not issued, the execution is stopped.
５.If the projector receives other incoming commands within 120ms, the
execution is stopped.
４.3 Transfer Example
Change to Video mode with Basic Command
Command
PC →Projector “C” “0” “7” CR
Projector →PC ACK CR
Commandprocessing
（A few ms 〜1s）

MR3P Series Basic Serial Command Function Specification Soft Engineer Division
Page 9 / 24
４.4 Necessary Condition for Operation
When the projector ‘s status in this below, functional execution commands and
state read commands are limited.
Also, state read commands are available in the below the status.
Projector Status AVAILABLE FUNCTIONAL EXECUTION
COMMANDS
Standby Mode C00：POWER ON
Processing Countdown
C00：POWER ON
（Terminate Processing Countdown）
C01: POWER OFF
C02: POWER OFF
(Terminate Processing Countdown)
C46: ZOOM-
C47: ZOOM+
C4A: FOCUS-
C4B: FOCUS+
C5D: LENS SHIFT +
C5E: LENS SHIFT-
Note) When executing ZOOM+/-, FOCUS+/-.
LENS SHIFT +/- during Countdown,
C3C/C3D that are Pointer UP/DOWN will
be available. C3C/C3D commands can
control ZOOM/FOCUS/LENS SHIFT.
Processing Cooling Down NONE
Processing Cooling Down due to
abnormal temperature NONE
Abnormal Temperature Status NONE
Processing Mode Change NONE
Processing Power Save・Cooling Down NONE
Processing Power Save C00：POWER ON
C01：POWER OFF
Other commands: POWER ON
Processing cooling down after
turning off automatically due to a
lamp failure
NONE (Even if the projector receives
commands, it does not execute it)
Notice）When the status is above, even if the projector receives other command in the above
status, the projector returns [ACK]［CR］.
4.5 POWER ON Command
Command “C00” [CR]
Detail
Power ON
When already Power ON, no need to do.
When sending this command during processing Count Down, Count Down is
terminated.
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]

MR3P Series Basic Serial Command Function Specification Soft Engineer Division
Page 10 / 24
４.6 POWER OFF Command（Quick Power OFF）
Command “C01” [CR]
Detail
Power OFF (Stand By)
When Power OFF with ON-OFF button of the projector or the remote control,
“Power OFF” will be displayed. However, as soon as this command is sent,
Quick Power OFF is executed.
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]
４.7 POWER OFF Command
Command “C02” [CR]
Detail
Power OFF (Stand By)
When Power OFF with ON-OFF button of the projector or the remote control,
“Power OFF” will be displayed. However, as soon as this command is sent,
Power OFF is executed.
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]
４.8 INPUT 1 Command
Command “C05” [CR]
Detail Select Input 1
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]
４.9 INPUT 2 Command
Command “C06” [CR]
Detail Select Input 2
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]
４.10 INPUT 3 Command
Command “C07” [CR]
Detail Select Input 3
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]

MR3P Series Basic Serial Command Function Specification Soft Engineer Division
Page 11 / 24
４.11 Network Viewer Command
Command “C08” [CR]
Detail Select Input Network
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]
４.12 VOLUME + Command
Command “C09” [CR]
Detail Volume Up This Command works same as “VOLUME +” of the projector and the remote
control.
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]
４.13 VOLUME - Command
Command “C0Ａ” [CR]
Detail Volume Down
This Command works same as “VOLUME +” of the projector and the remote
control.
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]
４.14 AUDIO MUTE ON Command
Command “C0B” [CR]
Detail Sound Mute ON
This command works same as “MUTE” of the projector and the remote control,
but this command does not work for MUTE OFF.
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]
４.15 AUDIO MUTE OFF Command
Command “C0C” [CR]
Detail Sound Mute OFF This command works the same as “MUTE” of the Remote Control button for
MUTE OFF, but does not work for “MUTE ON”
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]

MR3P Series Basic Serial Command Function Specification Soft Engineer Division
Page 12 / 24
４.16 VIDEO MUTE ON Command
Command “C0D” [CR]
Detail VIDEO MTUE ON This command works same as “NO SHOW” of the remote control, but does not
work for “NO SHOW OFF”.
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]
４.17 VIDEO MUTE OFF Command
Command “C0E” [CR]
Detail VIDEO MUTE OFF This command works the same as “NO SHOW” of remote control button for
VIDEO MUT OFF, but does not work for No Show ON”.
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]
４.18 REGULAR VIDEO IMAGE Command
Command “C0F” [CR]
Detail Set video screen size to Regular（4：3）.
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]
４.19 WIDE VIDEO IMAGE Command
Command “C10” [CR]
Detail Set video screen size to Wide（16:9）.
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]
４.20 MENU ON Command
Command “C1C” [CR]
Detail Display Menu of On Screen Display
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]
４.21 MENU OFF Command
Command “C1D” [CR]
Detail Off Menu of On Screen Display
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]

MR3P Series Basic Serial Command Function Specification Soft Engineer Division
Page 13 / 24
４.22 DISPLAY CLEAR Command
Command “C1E” [CR]
Detail Clear the On Screen Display.
Clear the On Screen Display unconditionally
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]
４.23 BRIGHTNESS + Command
Command “C20” [CR]
Detail Brightness of user control +1
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]
４.24 BRIGHTNESS - Command
Command “C21” [CR]
Detail Brightness of user control -1
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]
４.25 INPUT 2 VIDEO Command
Command “C23” [CR]
Detail Select Video Input for Input 2.
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]
４.26 INPUT 2 Y,Pb/Cb,Pr/Cr Command
Command “C24” [CR]
Detail Select Y, Pb/Cb, Pr/Cr Input for Input2
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]
４.27 INPUT 2 RGB Command
Command “C25” [CR]
Detail Select RGB Input for Input 2.
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]

MR3P Series Basic Serial Command Function Specification Soft Engineer Division
Page 14 / 24
４.28 IMAGE Command
Command “C27” [CR]
Detail Change IMAGE setting status.
Works same as the remote control’s “image button”.
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]
４.29 ON START SETTING Command
Command “C28” [CR]
Detail Set to Power ON Start setting status
This setting status is stored in EEPROM, even if the power is ON/OFF.
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]
４.30 ON START CANCELATION Command
Command “C29” [CR]
Detail Cancel Power ON Start
This status is stored in EEPROM even when power is ON or OFF.
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]
４.31 POWER MANAGEMENT SETTING Command
Command “C2A” [CR]
Detail Set Power Management.
This status is stored in EEPROM even when power is ON or OFF.
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]
４.32 POWER MANAGEMENT CANCELATION Command
Command “C2B” [CR]
Detail Cancel Power Management Setting.
This status is stored in EEPROM even when power is ON or OFF.
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]

MR3P Series Basic Serial Command Function Specification Soft Engineer Division
Page 15 / 24
４.33 D.ZOOM + Command
Command “C30” [CR]
Detail Digital Zoom Mode: Zoom in
This command works same as the remote control “D.ZOOM UP” button.
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]
４.34 D.ZOOM _ Command
Command “C31” [CR]
Detail Digital Zoom Mode: Zoon out
This command works same as the remote control “D.ZOOM DOWN” button.
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]
４.35 INPUT 3 VIDEO Command
Command “C33” [CR]
Detail Select Video Input for Input 3
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]
４.36 INPUT 3 S-VIDEO Command
Command “C34” [CR]
Detail Select S-Video Input for Input 3.
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]
４.37 INPUT 3 Y,Pb/Cb,Pr/Cr Command
Command “C35” [CR]
Detail Select Y, Pb/Cb, Pr/Cr Input for Input 3.
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]
４.38 POINTER RIGHT Command
Command “C3A” [CR]
Detail Move the pointer on Menu of ON Screen Display to the right.
This command is different from point buttons “>” of the projector. There is no
Volume +/- function.
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]

MR3P Series Basic Serial Command Function Specification Soft Engineer Division
Page 16 / 24
４.39 POINTER LEFT Command
Command “C3B” [CR]
Detail Move the pointer on Menu of On Screen Display to the left. This command is different from point buttons “<” of the projector. There is no
Volume +/- function.
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]
４.40 POINTER UP Command
Command “C3C” [CR]
Detail Move up the pointer on Menu of On Screen Display.
This command works the same as point buttons “UP ” of the projector.
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]
４.41 POINTER DOWN Command
Command “C3D” [CR]
Detail Move down the pointer on Menu of On Screen Display.
This command works the same as point buttons “DOWN ” of the projector.
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]
４.42 MOUSE RIGHT CLICK Command
Command “C3E” [CR]
Detail Works same as “Mouse right click” of the remote control.
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]
４.43 ENTER Command
Command “C3F” [CR]
Detail This command works the same as “Select” button of the projector.
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]
４.44 FREEZE ON Command
Command “C43” [CR]
Detail Make the screen Freeze. This command works the same as the remote control’s FREEZE” button not for
Freeze OFF but for Freeze ON.
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]

MR3P Series Basic Serial Command Function Specification Soft Engineer Division
Page 17 / 24
４.45 FREEZE OFF Command
Command “C44” [CR]
Detail Return to Freeze OFF screen. This command works the same as the remote control’s “FREEZE” button for
Freeze off.
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]
４.46 ZOOM＋Command
Command “C47” [CR]
Detail Make the screen bigger.
This command works the same as the remote control’s “ZOOM UP” button.
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]
４.47 ZOOM- Command
Command “C46” [CR]
Detail Make the screen smaller.
This command works the same as the remote control’s “ZOOM DOWN” button.
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]
４.48 FOCUS＋Command
Command “C4B” [CR]
Detail Focus on the screen image (sharp and clear) with a long- focal- length (∽)
(the lens direction is backward)
This command works the same as the remote control’s “FOCUS UP” button.
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]
４.49 FOCUS- Command
Command “C4A” [CR]
Detail
Focus on the screen image (sharp and clear) with a short- focal- length (the
lens direction is forward)
This command works the same as the remote control’s “FOCUS DOWN”
button.
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]

MR3P Series Basic Serial Command Function Specification Soft Engineer Division
Page 18 / 24
４.50 COLOR. MANAGEMENT Command
Command “C4E” [CR]
Detail Set Color management to ON.
This command works the same as the remote control’s “COLOR.M” button.
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]
４.51 INPUT 1 Analog RGB Command
Command “C50” [CR]
Detail Select Analog RGB Input for Input 1
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]
４.52 INPUT 1 SCART Command
Command “C51” [CR]
Detail Select Scart Input for Input1
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]
４.53 INPUT 1 DVI（PC Digital）Command
Command “C52” [CR]
Detail Select DVI (PC Digital) Input for Input 1.
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]
４.54 INPUT 1 DVI（AV HDCP）Command
Command “C53” [CR]
Detail Select DVI (AV HDCP) Input for Input 1.
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]
４.55 INPUT 1 Monitor OUT Command
Command “C54” [CR]
Detail Set Input 1 to Monitor OUT.
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]

MR3P Series Basic Serial Command Function Specification Soft Engineer Division
Page 19 / 24
４.56 LENS SHIFT＋Command
Command “C5D” [CR]
Detail Move up the screen.
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]
４.57 LENS SHIFT- Command
Command “C5E” [CR]
Detail Move down the screen.
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]
４.58 AUTO PC ADJ. Command
Command “C89” [CR]
Detail
Execute Auto PC Adj.
This command works the same as the remote control’s “AUTO PC ADJ” of the
remote control’s button.
While Auto PC Adj is working and a computer issue another command, Auto PC
Adj. Stops.
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]
４.59 PRESENTATION TIMER Command
Command “C8A” [CR]
Detail Set a presentation timer to active
This command works the same as the remote control “P-TIMER” button.
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]
４.60 KEYSTONE ↑Command
Command “C8E” [CR]
Detail Adjust keystone. Make the screen image length at the top edge shorter.
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]
４.61 KEYSTONE ↓Command
Command “C8F” [CR]
Detail Adjust keystone. Make the screen image length at the bottom edge shorter.
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]

MR3P Series Basic Serial Command Function Specification Soft Engineer Division
Page 20 / 24
４.62 KEYSTONE →Command
Command “C90” [CR]
Detail Adjust keystone. Make the screen image length at the right edge shorter.
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]
４.63 KEYSTONE ←Command
Command “C91” [CR]
Detail Adjust keystone. Make the screen image length at the left edge shorter.
Acceptable [ACK] [CR]
Response Unacceptable “？” [CR]
５ State Read Command
５.6 Format
５.6.1 A PC issues Command as below format
“CR” Command [CR]
Command：1character（See Status Read Command Table）
５.6.2 When projector receives the appropriate command, it returns a
character line as the required data.
Required Data [CR]
Required Data：a character line
５.6.3 When receiving data cannot be decode, the projector returns”？”［CR］.
５.7 Transfer Example
Get input mode for the projector by basic commands.
Command （current input mode command issue）
PC →Projector “C” “R” “1” CR
Projector →PC “1” CR
←---→
Response
（A few ms 〜1s）
（shows Computer 1 is selected now.）
