Canon LX-MU700 User manual

ENGLISH
MULTIMEDIA PROJECTOR
User’s Manual

i
Copyright
This publication, including all photographs, illustrations and software, is protected under international
copyright laws, with all rights reserved. Neither this manual, nor any of the material contained herein,
may be reproduced without written consent of the author.
© Copyright 2016
Disclaimer
The information in this document is subject to change without notice. The manufacturer makes no
representations or warranties with respect to the contents hereof and specically disclaims any implied
warranties of merchantability or tness for any particular purpose. The manufacturer reserves the right
to revise this publication and to make changes from time to time in the content hereof without obligation
of the manufacturer to notify any person of such revision or changes.
Trademark Recognition
Kensington is a U.S. registered trademark of ACCO Brand Corporation with issued
registrations and pending applications in other countries throughout the world.
HDMI, the HDMI Logo, and High-Denition Multimedia Interface are trademarks
or registered trademarks of HDMI Licensing LLC in the United States and other
countries.
HDBaseT is a trademark of HDBaseT Alliance.
Crestron Connected and the Crestron logo are trademarks or registered
trademarks of Crestron Electronics, Inc. in the United States and other countries or
both.
All other product names used in this manual are the properties of their respective owners and are
acknowledged.
Copyright Notice
Please note that enlarging or reducing the size of an image for commercial purposes or public
presentation may infringe on the legally protected copyright or the copyright holder of the original
material.
About Trademarks
■Ethernet is a registered trademark of Xerox Corporation.
■Microsoft, Windows, Windows Vista, Windows 7, Windows 8 and Aero are registered trademarks or
trademarks of Microsoft Corporation in the United States and / or other countries.
■Mac, Mac OS and Macintosh are trademarks of Apple Inc., registered in the United States and / or
other countries.
■ HDMI, the HDMI logo and High-Denition Multimedia Interface are trademarks or registered
trademarks of HDMI Licensing, LLC.
■PJLink is a registered trademark, or an application has been submitted for trademark, in Japan, the
United States and / or other countries or regions.
■AMX is a trademark of AMX Corporation.
■Crestron®, Crestron RoomView®, and Crestron Connected™ are registered trademarks of Crestron
Electronics, Inc.

ii
♦Projector Installation Notice
■Place the projector in a horizontal position
If installing the projector on the oor or hanging from the ceiling, the left /right inclination of the
projector should be no more than 10 degrees. An inclination of more than 10 degrees may damage
the lamp.
■Allow at least 70 cm clearance around the exhaust vent.
■Ensure that the intake vents do not recycle hot air from the exhaust vent.
■When operating the projector in an enclosed space, ensure that the surrounding air temperature
within the enclosure does not exceed operation temperature while the projector is running, and the
air intake and exhaust vents are unobstructed.
♦Verify Installation Location
■Turn on Altitude Mode when located in high altitude areas.
■The projector can only be installed upright or inverted.
■ When installation the bracket, make sure the weight limit is not exceed and rmly secured.
■ Avoid installing at high temperature, insufcient cooling and heavy dust locations.
■ Keep your product away from uorescent lamps to avoid malfunction caused by IR interference.
■The VGA IN connector should be connected to the VGA IN port. Note that it should be inserted
tightly, with the screws on both sides securely fastened to ensure proper connection of the signal
wire for achieving optimal display effect.
■The power cord and signal cable should be connected before power on the projector. During the
projector starting and operating process, DO NOT insert or remove the signal cable or the power
cord to avoid damaging the projector.
♦Cooling notes
Air outlet
■Air outlet location should not be in front of the lens of other projector to avoid causing illusions.
■Keep the outlet at least 70 cm away from the inlets of other projectors.
■The projector generates a massive amount of heat during use. The internal fan dissipates the heat
of the projector when shutting down, and such process may continue for a certain period. After
the project enters STANDBY MODE status, press the AC power button to turn off the projector
and remove the power cord. DO NOT remove the power cord during the shutdown process, as it
may cause damage to the projector. In the meantime, the delayed heat radiating will also affect
the service life of the projector. The shutdown process may vary depending on the model used.
Whatever the case may be, be sure to disconnect the power cord till after the projector enters the
STANDBY status.
Air inlet
■Make sure there is no object blocking air input within 50 cm.
■Keep the inlet away from other heat sources.
■Avoided heavy dust area.
♦Power Safety
■Only use the supplied power cord.
■Do not place anything on the power cord. Place the power cord where it will not be in the way of
foot trafc.
■Remove the batteries from the remote control when storing or not in use for a prolonged period.
■The wall outlet must be able to meet the power demands of the device.

iii
♦Replacing the Lamp
Replacing the lamp can be hazardous if done incorrectly. See “Replacing the Projection Lamp” on page
58 for clear and safe instructions for this procedure. Before replacing the lamp:
■Unplug the power cord.
■Allow the lamp to cool for about 45 minutes.
Warnings:
Precautions when replacing lamps that stop working
■If illumination suddenly stops, either when you turn the projector on or after it has been on for a
while, the lamp may have ruptured. In this case, never attempt to replace the lamp by yourself.
Always request service from the Canon Customer Support Center.
■With ceiling-mounted projectors, the lamp may fall out when you open the lamp cover, or
during replacement. During replacement, stand to the side of the lamp cover, not directly under
it.
■If the lamp ruptures, dust and gas (containing mercury vapor) may come out of the exhaust
vents. If this happens, immediately open the windows and doors to provide ventilation to the
room.
■If you accidentally inhale gas from the lamp or get any pieces in your eyes or mouth, consult a
doctor immediately.
About this manual
This manual is intended for qualied technicians / end users and describes how to install and operate
the DLP projector. Wherever possible, relevant information—such as an illustration and its description—
has been kept on one page. This printer-friendly format is both for your convenience and to help save
paper, thereby protecting the environment. It is suggested that you only print sections that are relevant
to your needs.

iv
