Canon LV-8227A User manual

Wired Setting
Projector Set-up and Operation
User’s Manual
Network Set-up and Operation
This is the manual for the Network function.
Read this manual thoroughly to operate the Network function.
First, read the user's manual of the projector to understand the basic
operation of the projector and the safety instructions.
The safety instructions in the user's manuals should be followed strictly.
for LV-7292A/7297A/7392A/8227A

2
Compliance
CAUTION IN USING THE PROJECTOR VIA NETWORKS
●When you find a problem with the projector, remove the power cable immediately and
inspect the unit. Using the projector with failure may cause fire or other accidents.
●If you remotely use the projector via networks, carry out a safety check regularly and
take particular care to its environment. Incorrect installation may cause fire or other
accidents.
CAUTION IN USING NETWORK FUNCTION
●We assume no responsibility for the loss or damage of data, or damage of the computer
caused by using this projector. Making back-up copies of valuable data in your
computer is recommended.
Federal Communications Commission Notice
Model: LV-7292A, LV-7297A, LV-7392A, LV-8227A
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equip-
ment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.
Use of shielded cable is required to comply with class B limits in Subpart B of Part of FCC
Rules.
Do not make any changes or modifications to the equipment unless otherwise specified in
the instructions. If such changes or modifications should be made, you could be required to
stop operation of the equipment.
Canon U.S.A., Inc.
One Canon Plaza, Lake Success, NY 11042-1198, U.S.A.
Tel No. [phone]
Canadian Radio Interference Regulations
This class B digital apparatus complies with Canadian ICES-003.

3
ENGLISH
Indicates a potentially hazardous situation which, if not avoided, may
cause death or serious injury.
Indicates a potentially hazardous situation which, if not avoided, may
cause minor or moderate injury.
Indicates a potentially hazardous situation which, if not avoided, may cause elec-
tric shock.
Indicate actions that you are not allowed to perform. The figure shown in the
circle with a diagonal line through it denotes the specific prohibited action.
Indicates other prohibited actions.
Indicates an action that you must perform. The figure shown in the filled black
circle denotes the specific prohibited action.
Safety instructions
Please read and understand all instructions thoroughly before using.
Safety information
WARNING
CAUTION
Always mount and operate the product in accordance with the safety instructions specified
by the projector and peripheral equipment makers.
●Do not attempt to disassemble or service the product yourself. Doing so may
result in a fire, an electric shock, or product damage.
●If the projector emits a strange odor, or makes a strange noise, immediately
turn the power and peripheral equipment off, unplug these devices, and
contact your dealer.
●Do not drop the projector or subject it to strong shocks. Doing so may result
in damage to the internal parts, an electric shock, a fire, or product damage.
About safety symbols
The following symbols are used in this manual to alert you to important safety information.
Always observe the instructions to reduce the risk of injury and property damage.
●
The disk which comes with the product is a CD-ROM. As CD-ROM cannot be
played back on an audio CD player, never play back on it. Paying back the disc
will generate loud noise, resulting in damage to your hearing or the speakers.
●Do not touch the projector with wet hands when the power cord plugs of
the projector or peripheral equipment inserted into the electrical outlet.
Otherwise, an electric shock may result.
WARNING
CAUTION

4
Compliance....................................................................................................................................................................................2
Safety instructions.....................................................................................................................................................................3
Table of contents........................................................................................................................................................................4
Chapter 1 Preparation ................................................................................................5
Features...................................................................................................................................................................................6
Required operating environment for computers ........................................................................................7
Network specifications of the projector............................................................................................................7
Flow of installation...........................................................................................................................................................9
Chapter 2 Setup Procedures..................................................................................11
Connecting to the LAN line.................................................................................................................................... 12
Network configuration............................................................................................................................................... 12
Network PIN code .........................................................................................................................................................14
Network information................................................................................................................................................... 14
Network factory default ............................................................................................................................................ 15
Wired LAN factory default settings....................................................................................................................16
Chapter 3 Basic Setting and Operation............................................................. 17
Login the setting page of the projector.........................................................................................................18
[1] Enter the IP address......................................................................................................................................18
[2] Login ..................................................................................................................................................................... 18
[3] Display of main setting page................................................................................................................. 19
How to use the setting page .................................................................................................................................20
Initial setting .....................................................................................................................................................................22
Network PIN code setting ..............................................................................................................................23
PJLink and Password setting.........................................................................................................................23
Network configuration...............................................................................................................................................24
E-mail setting ...................................................................................................................................................................25
Examples: Type and contents of alert mail..........................................................................................28
SNMP setting....................................................................................................................................................................29
Chapter 4 Controlling the Projector ...................................................................31
Power control and status check...........................................................................................................................32
PC Adj....................................................................................................................................................................................34
Control..................................................................................................................................................................................35
Input.............................................................................................................................................................................35
System.........................................................................................................................................................................36
Sound .........................................................................................................................................................................37
Image adj................................................................................................................................................................... 37
Setting up the projector ...........................................................................................................................................38
Aspect setting ......................................................................................................................................................38
Setting 1.....................................................................................................................................................................39
Setting 2.....................................................................................................................................................................40
Setting 3.....................................................................................................................................................................40
Information........................................................................................................................................................................ 41
Chapter 5 Appendix ................................................................................................ 43
Examples of connection ...........................................................................................................................................44
Use of telnet......................................................................................................................................................................46
Web browser setting...................................................................................................................................................48
Examples: OS/Browsers .............................................................................................................................................49
Q&A ........................................................................................................................................................................................53
Menu Tree...........................................................................................................................................................................58
Table of contents

ENGLISH
5
ENGLISH
1
Chapter 1
Preparation
Describes features and operating environment of this projector.

6
Chapter 1 Preparation
Features
E-Mail Alert function (+p.25)
The projector sends messages
to the registered e-mail
addresses when a lamp
abnormality or power failure
occurs with the projector. This
message describes how to solve
the cause of the problems. You
can take efficient action for
quick recovery.
Web Management function (+p.31-42)
With this function, you can
monitor projector functions
such as power status, lamp
status, input mode, signal
condition, lamp-use time, etc.
through the network by using
the web browser installed on
your computer.
PC4PC3 PC6
PC5
PC1 PC2
Yo u’ve got
Mail.
PJ2 PJ1
PC4PC3 PC6
PC5
PC1 PC2
Turn ON PJ2
PJ2 PJ1

7
ENGLISH
Features
Required operating environment for computers
When operating the projector via networks, computers should meet the operating envi-
ronment below.
LAN Terminal
Data communication standards 10/100/1000Base-T compatible
Physical layer 10Base-T
Protocol TCP/IP
Network specifications of the projector
Operating System
Windows XP (32bit version),
Windows Vista (32bit version), Windows 7 (32bit version)
Mac OS X v 10.4 , 10.5 or 10.6
Computer environment
Recommended CPU
Windows: Pentium III 900MHz or more
Macintosh : 800 MHz PowerPC G4 or faster,or 1.8 GHz Intel Core
Processor or faster
Memory
Windows : 64MB (Minimum)/ 128MB or more (Recommended)
128MB or more for Windows XP
1GB or more for Windows Vista or Windows 7
Macintosh : 256MB or more (512MB is recommended)
Free disk space 100MB or more
Drive equipment CD-ROM drive
Display settings
Support one of following resolutions;
VGA (640 x 480), SVGA(800 x 600), XGA(1,024 x 768) Number of col-
ors: Either of 16 bit (65,536 color 24/32 bit (16.77 million colors))
Network card The computer must provide a 10Base-T or 100Base-TX network
card.
Web Browser*
Internet Explorer version 6.0, 7.0 or 8.0
Safari 4 or 5
* Used to control and set up the projector. The layout of pages in
the browser may slightly differ from each type of application or
operating system you use.
Recommended Internet
Mailer*
- Microsoft Outlook - Microsoft Outlook Express
* Required the internet e-mail application software to receive an
e-mail alert sent from this projector. If you do not use the func-
tion E-mail Alert, this application is not required.

8
Chapter 1 Preparation
Cabling Between the Projector and a Hub or computer*1
Use an appropriate cable when connecting the projector and a hub or computer.
Connection Ethernet cable type Max. cable length
Projector - Hub STP straight-through category 5 *2cable 100m (328feet)
Projector - Computer STP crossover category 5*2cable 100m (328feet)
*1 There may be other limitations depending on your network environment or LAN specification.
Please consult your network administrator for further details.
*2 Cable category indicates cable quality.
Notice
Expression/Abbreviation
The OS of the computer and the Web browser described in this manual are Windows XP
Professional and Internet Explorer 6.0. In case of another OS or Web browser, some instruc-
tion procedures may differ from the actual operation depending on your computer envi-
ronment.
Use of this manual
This manual does not provide the detailed description of basic operation and functions
for computer, web browser, projector and network. For instructions about each piece of
equipment or application software, please refer to the respective manual.
Trademarks
Ethernet is a registered trademark of Xerox Corporation. Microsoft, Windows, Windows
NT, Windows XP, Windows Vista and Windows 7 are registered trademarks of Microsoft
Corporation in the United States and other countries. Internet Explorer is a regis-
tered trademark of Microsoft Corporation. JavaScript is a registered trademark of Sun
Microsystems, Inc.
Mac, Mac OS and Macintosh are registered trademarks of Apple, Inc. in the USA and other
countries. PowerPC is a registered trademark of IBM Corporation. Intel Core is a registered
trademark of Intel Corporation in the USA and other countries.
Other product or brand names in this manual are registered trademarks or trademarks of
their respective owners.
* Unauthorized use of a part or whole of the contents in this manual is prohibited.
* The contents of this manual are subject to change without notice.

9
ENGLISH
Flow of installation
Flow of installation
To use the projector via the networks, follow the setup procedures below.
STEP 1 Connect the LAN and set the configuration.
STEP 2 Network Configuration has completed.
Decide depending on the LAN environment.
➔“2. Setup Procedures”(pp.11–16).
Detailed LAN configurations need to be done with a browser later.
First, complete the Wired LAN connection between computers and projec-
tors, then start browser configurations.
➔“3. Basic setting and operation”(pp.17–30).
Follow each chapter to operate the projector.
■Operate and manage the projector ➔“4. Controlling the projector”(pp.31-42)
➔“Power Control and status check”(p.32-33)
➔“PC Adj.”(p.34)
➔“Control”(p.35-37)
➔“Setting up the projector”(p.38-40)
➔“Projector information”(p.41)

10
Chapter 1 Preparation

ENGLISH
11
ENGLISH
Chapter 2
Setup Procedures
2
Describes how to configure the network.

12
Chapter 2 Setup Procedures
Setting procedures and contents differ depending on the LAN installation location.
When installing, consult your system administrator to set up the LAN appropriately.
Connect the LAN cable to the LAN connection terminal of the projector.
Network configuration
Set the Wired LAN network through the projector menu. Detailed network settings will be
made with browser. Refer to “3. Basic setting and operation” (pp.17-30). First, complete the
settings described in this chapter before performing steps in “3. Basic setting and opera-
tion.”
Connecting to the LAN line
Setting Procedure
1. Select “LAN mode select” in the Network menu, and press Point ►or OK button.
2. Select similar LAN environment among LAN1, LAN2 and LAN3 with the Point ▲▼
buttons, and press OK button. Then the Menu will disappear, the “Please wait...”
message will appear, and switching operation will start. Switching will take a while and
the projector’s LINK/ACT Lamp will be on or blink, and after completing the operation,
the “Please wait...” message will disappear.
LAN Cable
LAN Connection
Terminal
LINK Lamp (Green)
Light green when the
projector is connected to
the network correctly.
ACT Lamp (Orange)
Blink orange when the
projector is sending or
receiving the data.
* Please use a shielded LAN cable.

13
ENGLISH
Network configuration
*1 Set "On" only when the DHCP server is available on your network environment.
*2 Set [255.255.255.255] if the network does not provide the gateway (router).
*3 Set [255.255.255.255] if you do not use the function E-mail alert.
3. Select "Network setting" in the Network menu and press OK button, and then the LAN
setting screen will appear and selected LAN settings will be displayed. Adjust each
item to the setting environment. Consult your system administrator about the detailed
settings.
Press OK button in a row where you want to adjust, and adjust the figures with the Point
▲▼ buttons and move among the items with the Point ◄► buttons, and then press
OK button to fix. Move to the next row with the Point ▲▼ buttons to adjust.
4. After completing all the settings, select “Set” and press OK button. Now, all procedures
have been done. To cancel the adjusted settings, select "Cancel" and press OK button.
You can confirm the LAN settings you have made from “Network information” (p.14). In
such cases that the LAN cannot be connected, see this screen.
DHCP: On
Item Description
DHCP....................Sets DHCP function On or Off. When you setup the network setting manually, select
"Off". When it is set On, IP address, Subnet, Gateway and DNS are automatically set
according to your network environment *1.
IP address .............Sets IP address of the projector
Subnet ....................Sets Subnet mask according to your network environment.
Gateway*2.............Sets IP address of the default gateway (Router)
DNS*3.......................Sets IP address of the DNS server.
DHCP: Off
Network setting
* The numerical value is a setting example.

14
Chapter 2 Setup Procedures
The Network PIN code is to restrict the access to the projector through the network.
After setting the Network PIN code, you need to enter it to operate the projector via the
networks.
Network PIN code
Network information
1. Select "Network PIN code" in the Network menu, and press OK button.
The Network PIN code screen will appear.
2. Set the Network PIN code.
Set the figures with the Point ▲▼ buttons and move to the next items with the Point
◄► buttons. Select “Set” and press OK button to set. To cancel the preset Network PIN
code, select “Cancel”. When you do not want to set the Network PIN code, set "0000".
It is recommended to set the Network PIN code if you use the projector via the networks.
The Network PIN code can be set also through the networks. See “3. Basic setting and
operation” ➔“Initial setting” ➔“Network PIN code setting”(p.23).
Select "Network information" in the Network menu and press Point ►or OK button to
show LAN setting environment of the currently selected projector. (The description below
is an example and different from what will be shown.)
Network PIN code
Network PIN code screen
Network Information

15
ENGLISH
Network factory default
Network factory default
1. Select “Network factory default” in the Network menu and press OK button.
2. A confirmation box appears and select "Yes" and then press OK button.
3. Another confirmation box appears and select "Yes" and then press OK button.
4. All the wired LAN settings will go back to the factory default settings. For details, refer to
“Wired LAN factory default settings” (p.16).

16
Chapter 2 Setup Procedures
Wired LAN factory default settings
Parameter
SELECTED LAN
LAN 1 LAN 2 LAN 3
DHCP OFF ON OFF
IP ADDRESS 169.254.100.100 192.168.100.100 192.168.100.100
SUBNET MASK 255.255.0.0 255.255.255.0 255.255.255.0
GATEWAY ADDRESS 255.255.255.255 255.255.255.255 255.255.255.255
DNS ADDRESS 255.255.255.255 255.255.255.255 255.255.255.255
[Note]
Because DHCP is ON at "LAN 2", the values of IP ADDRESS, SUBNET, GATEWAY ADDRESS, DNS
will be changed through DHCP. The above values of "LAN2" are displayed when the projector
is not connected to the network or DHCP is not available.

ENGLISH
17
ENGLISH
Chapter 3
Basic Setting and Operation
3
Describes basic operations and settings for controlling the projec-
tor by using the web browser. It is required that computer and
projector is connected to the network and the network address is
properly configured.

18
Chapter 3 Basic Setting and Operation
Login the setting page of the projector
[1] Enter the IP address
Launch the web browser installed in your
computer, enter the IP address into the
"Address" on the browser and then press
"Enter" key.
Enter the address that you configured in
item "Network configuration" (+p.12).
[2] Login
If the setting page has set the password, the authentication window will appear. In this
case type "user" onto the User name text area and the login Network PIN code onto the
Password text area and then click OK (Log in) button.
* The entering User Name must be "user" and it can not be changed.
[Note]
When accessing the projector for the first time or the Network PIN code "0000" is set, the auto-
login will be performed and the next main setting page is displayed.
* The numerical value is a setting example.
Windows Mac

19
ENGLISH
[3] Display of main setting page
The following main setting page will be displayed according to your display mode
selection. Perform various kinds of settings through this page. Click on the menus to dis-
play the control and setting pages.
Main setting page in the display
Setting page
Displays the control and
setting items according to
the selected menu.
Main menu
For selection of control and
setting items of the projector.
Sub menu tab
Switches the sub
menu tab.
Login the setting page of the projector

20
Chapter 3 Basic Setting and Operation
How to use the setting page
To control and set up the projector, use the setting menus on the web browser. Describes the
basic operation and procedures commonly used on this manual.
The setting menu appears when
clicking the sub menu tab.
* Each item has a valid setting range
respectively.
Example of the setting page
✐The value in the text box indicates current value.
✐Each item has a valid setting range. The setting value exceeding this becomes invalid. Some
control items can not be used depending on the selecting input mode or functions of the
projector you use. In this case, the values of those items are indicated with "---".
Text box setting
Enter a number or text and then click
Set button.
or
Change a value with – or +button.
Pull-down menu setting
Select an item with pull-down menu
button and then click Set button.
Types of setting
