Canon WX6000 User manual

WX6000(1/14)
Canon LCOS Projector WX6000
■Outline of Product
This device is a 3-plate LCOS projector adopting the 0.7-type Liquid Crystal on Silicon (LCOS).
In addition to video footage, the projection of video data up to WXGA+ size (1,440 dots x 900 dots) is possible.
*The “projection lens” for this product is sold separately. Please select and purchase the optimal projection lens suitable for your
installation location and system.
■Product specifications (Specifications and appearance may change without prior notice for reasons
such as manufacturing and changes of components.)
Used power
Consumed power
Picture element
Projection lens
Light source lamp
Projected image size
Light output*
Peripheral contrast*
Contrast ratio*
Input signal resolution
Corresponding
scanning frequency
lens shift
Keystone correction range
Projection method
Video signal /
Connection terminal
AC100 - 240 V 50Hz/60Hz
435W, Standby: 1.7W / Standby (LAN-off): 0.35W
0.70-type LCOS panel (aspect ratio 16:10)
Number of pixels: 1,296,000 pixels (1,440 dots x 900 dots, WXGA+)
(Separately sold) *A lens is not provided with this device.
<Standard Zoom Lens (RS-IL01ST)>
Lens configuration: 11 groups, 14 elements, F value: 1.89 - 2.65, Focus distance: 23.0 - 34.5mm,
Projection distance range: 1.3 – 29.7m, 100-inch projection distance: 3.3 - 4.9m, Zoom ratio: 1.5 x
(electric), Focus: electric
<Long Zoom Lens (RS-IL02LZ)>
Lens configuration: 11 groups, 15 elements, F value: 1.99 - 2.83, Focus distance: 34.0 - 57.7mm,
Projection distance range: 1.9 – 49.7m, 100-inch projection distance: 4.8 - 8.3m, Zoom ratio: 1.7 x
(electric), Focus: electric
<Short Fixed Lens (RS-IL03WF)>
Lens configuration: 11 groups, 14 elements, F value: 2.0, Focus distance: 12.8mm, Projection distance
range: 0.7 - 5.3m, 100-inch projection distance: 1.77m, Zoom ratio: 1.0 x (electric), Focus: electric
<Ultra long zoom lens (RS-IL04UL)>
Lens configuration: 11 groups, 16 elements, F value: 2.34 - 2.81, Focus distance: 53.6 – 105.6mm,
Projection distance range: 4.8 – 91.3m, 100-inch projection distance: 7.8 – 15.3m, Zoom ratio: 1.95
x (electric), Focus: electric
<Wide Zoom Lens (RS-IL05WZ)>
Lens configuration: 11 groups, 15 elements, F value: 2.09 - 2.34, Focus distance: 15.56 – 23.44mm,
Projection distance range: 0.9 – 19.9m, 100-inch projection distance: 2.2 – 3.2m, Zoom ratio: 1.5 x
(electric), Focus: electric
330-NSHA lamp (Output 336W)
40-inch (0.86m x 0.54m) - 600-inch (12.9m x 8.1m) (16 : 10)
5700lm
88%
1000:1 (All white / All black)
UXGA to VGA
DVI input time (digital PC): (horizontal) 31KHz - 75KHz (vertical) 50Hz - 60Hz (dot clock) 162MHz or less
HDMI input time (digital PC): (horizontal) 31KHz - 75KHz (vertical) 59Hz - 60Hz (dot clock) 162MHz or less
HDMI input time (digital video):(horizontal) 31.469KHz (vertical) 59.940Hz [480p]
(horizontal) 31.250KHz (vertical) 50.000Hz [576p]
(horizontal) 37.500KHz/45.000KHz (vertical) 50.000Hz/60.000Hz [720p]
(horizontal) 56.250KHz/67.500KHz (vertical) 50.000Hz/60.000Hz [1080i]
(horizontal) 56.250KHz/67.500KHz (vertical) 50.000Hz/60.000Hz [1080p]
Analog RGB input time: (horizontal) 31KHz to 75KHz (vertical) 50Hz to 60Hz (dot clock) 162MHz or less
Component video input time: (horizontal) 15.734KHz (vertical) 59.940Hz [480i]
(horizontal) 31.469KHz (vertical) 59.940Hz [480p]
(horizontal) 15.625KHz (vertical) 50.000Hz [576i]
(horizontal) 31.250KHz (vertical) 50.000Hz [576p]
(horizontal) 37.500KHz/45.000KHz (vertical) 50.000Hz/60.000Hz [720p]
(horizontal) 28.125KHz/33.750KHz (vertical) 50.000Hz/60.000Hz [1080i]
(horizontal) 56.250KHz/67.500KHz (vertical) 50.000Hz/60.000Hz [1080p]
Standard Zoom Lens, Long Zoom Lens, Ultra Long Zoom Lens, Wide Zoom Lens: Up +50% to
down +12% and left 10% to right 10% from screen center
Short Fixed Lens: Up +5% to down +5% and left 2% to right 2% from screen center
V ±20°, H ±20°
Front ceiling / floor-mounted front / rear ceiling / floor-mounted rear
<Video signal>
Analog PC input:
UXGA/WSXGA+/SXGA+/WXGA+/WXGA/SXGA/XGA/SVGA/VGA
Digital PC input:
UXGA/WSXGA+/SXGA+/WXGA+/WXGA/SXGA/XGA/SVGA/VGA
Digital video input: 1080p/1080i/720p/576p/480p
Component video input: 1080p/1080i/720p/576p/576i/480p/480i
<Connection terminal>
DVI-I: Digital PC input , HDMI: Digital PC / Digital video input (supports Deep color)
Mini D-sub 15: Analog PC/Component video input
Mini jack x4: Audio input x 2, Audio output x 1, Wired remote controler connection x 1
Dsub9: RS-232 connection , RJ-45: 100BASE-TX / 10BASE-T
PJ link support
* This indicates the overall average value of the product at the time of shipping, and it is listed in accordance with pattern for
data projectors JIS X 6911:2003. The measurement method and measurement conditions are based on the Annex.

WX6000(2/14)
* This is the average. It may vary for each product.
Accessories ●Power cord ... 1●Computer connection cable (Mini Dsub 15-pin) ... 1
●Wireless/Wired remote connector ... 1●AA size batteries ... 2
Sold separately ●Ceiling mounting brackets (RS-CL11) ●Ceiling pipe [400 - 600mm] (RS-CL08) ●Ceiling pipe [600 - 1000mm]
(RS-CL09)
Replacement products ●Replacement-use lamp [1 light, Recommended replacement time; 3000H] (RS-LP06)
●Replacement air filter (RS-FL01)
* When it has a 50% survival rate and can maintain a 50% light retention ratio.

■External dimensions diagram
(Unit : mm)
<Side terminals>
Cabinet
External dimensions
Weight
Environmental
conditions
Supplied remote
control
Molded plastic
Width 380mm Height 170mm (with legs at minimum height) Depth 430mm (excluding lens)
About 8.5kg (excluding projection lens)*
Use environment: 5℃to 35℃
Storage environment: -10℃to 60℃, 5%RH to 90%RH
Power supply used: DC 3V (2 AA type batteries)
Operation distance (for wireless): About 8m (receiver front ±25°), Supports 4 channels
Terminal
Signal
Video input
(1)
Mini Dsub 15-pin
Analog PC/ Component video
(2)
DVI-I
Analog PC/Digital PC
(3)
HDMI
HDMI（with audio signals , supports Deep color）
Audio input
(4)
Mini jack
Stereo audio: Corresponds to video input (1)
(5)
Mini jack
Stereo audio: Corresponds to video input (3)
Audio output
(6)
Mini jack
Stereo audio
Control
(7)
Dsub9
RS-232C connection (supports AMX Device Discovery)
(8)
RJ-45
100BASE-TX/10BASE-T
(9)
Mini jack
Wired remote controler connection

WX6000(3/14)

■Names

Projector operation unit
Intake vent
Remote control light receiving unit
Air filter
I/O
Exhaust vent
Lamp cover
Remote control light receiving
Screw holes for attaching ceiling
mounting brackets
Adjustable feet
Lock hole for theft
prevention
Fall-prevention wire
attachment bar
Fall-prevention wire
attachment bar
Power cord connection
Lens

WX6000(4/14)

■Projection-related dimensions
(Note) This diagram is not drawn to scale.
<Request>
●Have the work done by technical experts.
●When attaching to the ceiling, use the dedicated mounting brackets. Also, to prevent swaying or falling, stretch the wire supplied with the projector
between the ceiling mounting brackets and ceiling.
Projection distance (L)
Side view
Front view
Top view
Screw holes
(M4 X 6) for
attaching
ceiling
mounting

WX6000(5/14)
■Projection distance per projection lens
Obtain the projection distance by the following formula.
○When screen aspect ratio is 16:10
Projection lens product number
Projection distance (L) calculation formula
Standard Zoom Lens
(RS-IL01ST)
Wide lens
L(m)=(Projection screen size [Type]- 0.4442)÷30.2662
Tele lens
L(m)=(Projection screen size [Type]- 0.2962)÷20.1775
Long Zoom Lens
(RS-IL02LZ)
Wide lens
L(m)=(Projection screen size [Type]- 0.8473)÷20.4742
Tele lens
L(m)=(Projection screen size [Type]- 0.5124)÷12.0511
Short Fixed Lens
（RS-IL03WF）
(Fixed)
L(m)=(Projection screen size [Type]- (-0.2699)) ÷56.6274
Ultra Long Zoom Lens
(RS-IL04UL)
Wide lens
L(m)=(Projection screen size [Type]- (-1.6418)) ÷12.9672
Tele lens
L(m)=(Projection screen size [Type]- (-0.8261)) ÷6.5793
Wide Zoom Lens
（RS-IL05WZ）
Wide lens
L(m)=(Projection screen size [Type]- 0.0453)÷45.2489
Tele lens
L(m)=(Projection screen size [Type]- (-0.0201))÷30.1811
* The values obtained by the above formula have a slight margin of error.

WX6000(6/14)
■Projection distance per projection lens
（Unit：m）
Image size (16:10)
Projection distance (L)[Screen to lens tip]
Type
Width
Height
Standard Zoom
Lens（RS-IL01ST）
Long Zoom Lens
（RS-IL02LZ）
Short Fixed Lens
（RS-IL03WF）
Ultra Long Zoom
Lens（RS-IL04UL）
Wide Zoom Lens
（RS-IL05WZ）
Wide
lens
Tele
lens
Wide
lens
Tele
lens
Wide
lens
Tele
lens
Wide
lens
Tele
lens
40
0.9
0.5
1.3
2.0
1.9
3.3
0.71
-
-
0.9
1.3
45
1.0
0.6
1.5
2.2
2.2
3.7
0.80
-
-
1.0
1.5
50
1.1
0.7
1.6
2.5
2.4
4.1
0.89
-
-
1.1
1.7
55
1.2
0.7
1.8
2.7
2.6
4.5
0.98
-
-
1.2
1.8
60
1.3
0.8
2.0
3.0
2.9
4.9
1.06
4.8
9.2
1.3
2.0
65
1.4
0.9
2.1
3.2
3.1
5.4
1.15
5.1
10.0
1.4
2.2
70
1.5
0.9
2.3
3.5
3.4
5.8
1.24
5.5
10.8
1.5
2.3
75
1.6
1.0
2.5
3.7
3.6
6.2
1.33
5.9
11.5
1.7
2.5
80
1.7
1.1
2.6
4.0
3.9
6.6
1.42
6.3
12.3
1.8
2.7
85
1.8
1.1
2.8
4.2
4.1
7.0
1.51
6.7
13.0
1.9
2.8
90
1.9
1.2
3.0
4.4
4.4
7.4
1.59
7.1
13.8
2.0
3.0
95
2.0
1.3
3.1
4.7
4.6
7.8
1.68
7.5
14.6
2.1
3.1
100
2.2
1.3
3.3
4.9
4.8
8.3
1.77
7.8
15.3
2.2
3.3
105
2.3
1.4
3.5
5.2
5.1
8.7
1.86
8.2
16.1
2.3
3.5
110
2.4
1.5
3.6
5.4
5.3
9.1
1.95
8.6
16.8
2.4
3.6
115
2.5
1.5
3.8
5.7
5.6
9.5
2.04
9.0
17.6
2.5
3.8
120
2.6
1.6
4.0
5.9
5.8
9.9
2.12
9.4
18.4
2.7
4.0
125
2.7
1.7
4.1
6.2
6.1
10.3
2.21
9.8
19.1
2.8
4.1
130
2.8
1.8
4.3
6.4
6.3
10.7
2.30
10.2
19.9
2.9
4.3
135
2.9
1.8
4.4
6.7
6.6
11.2
2.39
10.5
20.6
3.0
4.5
140
3.0
1.9
4.6
6.9
6.8
11.6
2.48
10.9
21.4
3.1
4.6
145
3.1
2.0
4.8
7.2
7.0
12.0
2.57
11.3
22.2
3.2
4.8
150
3.2
2.0
4.9
7.4
7.3
12.4
2.65
11.7
22.9
3.3
5.0
155
3.3
2.1
5.1
7.7
7.5
12.8
2.74
12.1
23.7
3.4
5.1
160
3.4
2.2
5.3
7.9
7.8
13.2
2.83
12.5
24.4
3.5
5.3
165
3.6
2.2
5.4
8.2
8.0
13.6
2.92
12.9
25.2
3.6
5.5
170
3.7
2.3
5.6
8.4
8.3
14.1
3.01
13.2
26.0
3.8
5.6
175
3.8
2.4
5.8
8.7
8.5
14.5
3.10
13.6
26.7
3.9
5.8
180
3.9
2.4
5.9
8.9
8.8
14.9
3.18
14.0
27.5
4.0
6.0
185
4.0
2.5
6.1
9.2
9.0
15.3
3.27
14.4
28.2
4.1
6.1
190
4.1
2.6
6.3
9.4
9.2
15.7
3.36
14.8
29.0
4.2
6.3
195
4.2
2.6
6.4
9.6
9.5
16.1
3.45
15.2
29.8
4.3
6.5
200
4.3
2.7
6.6
9.9
9.7
16.6
3.54
15.6
30.5
4.4
6.6
205
4.4
2.8
6.8
10.1
10.0
17.0
3.62
15.9
31.3
4.5
6.8
210
4.5
2.8
6.9
10.4
10.2
17.4
3.71
16.3
32.0
4.6
7.0
215
4.6
2.9
7.1
10.6
10.5
17.8
3.80
16.7
32.8
4.8
7.1
220
4.7
3.0
7.3
10.9
10.7
18.2
3.89
17.1
33.6
4.9
7.3
225
4.8
3.0
7.4
11.1
10.9
18.6
3.98
17.5
34.3
5.0
7.5
230
5.0
3.1
7.6
11.4
11.2
19.0
4.07
17.9
35.1
5.1
7.6
235
5.1
3.2
7.7
11.6
11.4
19.5
4.15
18.2
35.8
5.2
7.8
240
5.2
3.2
7.9
11.9
11.7
19.9
4.24
18.6
36.6
5.3
8.0
245
5.3
3.3
8.1
12.1
11.9
20.3
4.33
19.0
37.4
5.4
8.1
250
5.4
3.4
8.2
12.4
12.2
20.7
4.42
19.4
38.1
5.5
8.3
255
5.5
3.4
8.4
12.6
12.4
21.1
4.51
19.8
38.9
5.6
8.4
260
5.6
3.5
8.6
12.9
12.7
21.5
4.60
20.2
39.6
5.7
8.6
265
5.7
3.6
8.7
13.1
12.9
21.9
4.68
20.6
40.4
5.9
8.8
270
5.8
3.6
8.9
13.4
13.1
22.4
4.77
20.9
41.2
6.0
8.9
275
5.9
3.7
9.1
13.6
13.4
22.8
4.86
21.3
41.9
6.1
9.1
280
6.0
3.8
9.2
13.9
13.6
23.2
4.95
21.7
42.7
6.2
9.3
285
6.1
3.8
9.4
14.1
13.9
23.6
5.04
22.1
43.4
6.3
9.4
290
6.2
3.9
9.6
14.4
14.1
24.0
5.13
22.5
44.2
6.4
9.6
295
6.4
4.0
9.7
14.6
14.4
24.4
5.21
22.9
45.0
6.5
9.8
300
6.5
4.0
9.9
14.9
14.6
24.9
5.30
23.3
45.7
6.6
9.9
* As for the value of L, a margin of error within ± 5% may be generated depending on the projection lens. The numbers in the table are
rounded approximations.

WX6000(7/14)
（Unit：m）
Image size (16:10)
Projection distance (L)[Screen to lens tip]
Type
Width
Height
Standard Zoom
Lens（RS-IL01ST）
Long Zoom Lens
（RS-IL02LZ）
Short Fixed Lens
（RS-IL03WF）
Ultra Long Zoom
Lens（RS-IL04UL）
Wide Zoom Lens
（RS-IL05WZ）
Wide
lens
Tele
lens
Wide
lens
Tele
lens
Wide
lens
Tele
lens
Wide
lens
Tele
lens
305
6.6
4.1
10.1
15.1
14.9
25.3
-
23.6
46.5
6.7
10.1
310
6.7
4.2
10.2
15.3
15.1
25.7
-
24.0
47.2
6.8
10.3
315
6.8
4.2
10.4
15.6
15.3
26.1
-
24.4
48.0
7.0
10.4
320
6.9
4.3
10.6
15.8
15.6
26.5
-
24.8
48.8
7.1
10.6
325
7.0
4.4
10.7
16.1
15.8
26.9
-
25.2
49.5
7.2
10.8
330
7.1
4.4
10.9
16.3
16.1
27.3
-
25.6
50.3
7.3
10.9
335
7.2
4.5
11.1
16.6
16.3
27.8
-
26.0
51.0
7.4
11.1
340
7.3
4.6
11.2
16.8
16.6
28.2
-
26.3
51.8
7.5
11.3
345
7.4
4.6
11.4
17.1
16.8
28.6
-
26.7
52.6
7.6
11.4
350
7.5
4.7
11.5
17.3
17.1
29.0
-
27.1
53.3
7.7
11.6
355
7.6
4.8
11.7
17.6
17.3
29.4
-
27.5
54.1
7.8
11.8
360
7.8
4.8
11.9
17.8
17.5
29.8
-
27.9
54.8
8.0
11.9
365
7.9
4.9
12.0
18.1
17.8
30.2
-
28.3
55.6
8.1
12.1
370
8.0
5.0
12.2
18.3
18.0
30.7
-
28.7
56.4
8.2
12.3
375
8.1
5.0
12.4
18.6
18.3
31.1
-
29.0
57.1
8.3
12.4
380
8.2
5.1
12.5
18.8
18.5
31.5
-
29.4
57.9
8.4
12.6
385
8.3
5.2
12.7
19.1
18.8
31.9
-
29.8
58.6
8.5
12.8
390
8.4
5.3
12.9
19.3
19.0
32.3
-
30.2
59.4
8.6
12.9
395
8.5
5.3
13.0
19.6
19.3
32.7
-
30.6
60.2
8.7
13.1
400
8.6
5.4
13.2
19.8
19.5
33.1
-
31.0
60.9
8.8
13.3
405
8.7
5.5
13.4
20.1
19.7
33.6
-
31.4
61.7
8.9
13.4
410
8.8
5.5
13.5
20.3
20.0
34.0
-
31.7
62.4
9.1
13.6
415
8.9
5.6
13.7
20.6
20.2
34.4
-
32.1
63.2
9.2
13.7
420
9.0
5.7
13.9
20.8
20.5
34.8
-
32.5
64.0
9.3
13.9
425
9.2
5.7
14.0
21.0
20.7
35.2
-
32.9
64.7
9.4
14.1
430
9.3
5.8
14.2
21.3
21.0
35.6
-
33.3
65.5
9.5
14.2
435
9.4
5.9
14.4
21.5
21.2
36.1
-
33.7
66.2
9.6
14.4
440
9.5
5.9
14.5
21.8
21.4
36.5
-
34.1
67.0
9.7
14.6
445
9.6
6.0
14.7
22.0
21.7
36.9
-
34.4
67.8
9.8
14.7
450
9.7
6.1
14.9
22.3
21.9
37.3
-
34.8
68.5
9.9
14.9
455
9.8
6.1
15.0
22.5
22.2
37.7
-
35.2
69.3
10.1
15.1
460
9.9
6.2
15.2
22.8
22.4
38.1
-
35.6
70.0
10.2
15.2
465
10.0
6.3
15.3
23.0
22.7
38.5
-
36.0
70.8
10.3
15.4
470
10.1
6.3
15.5
23.3
22.9
39.0
-
36.4
71.6
10.4
15.6
475
10.2
6.4
15.7
23.5
23.2
39.4
-
36.8
72.3
10.5
15.7
480
10.3
6.5
15.8
23.8
23.4
39.8
-
37.1
73.1
10.6
15.9
485
10.4
6.5
16.0
24.0
23.6
40.2
-
37.5
73.8
10.7
16.1
490
10.6
6.6
16.2
24.3
23.9
40.6
-
37.9
74.6
10.8
16.2
495
10.7
6.7
16.3
24.5
24.1
41.0
-
38.3
75.4
10.9
16.4
500
10.8
6.7
16.5
24.8
24.4
41.4
-
38.7
76.1
11.0
16.6
505
10.9
6.8
16.7
25.0
24.6
41.9
-
39.1
76.9
11.2
16.7
510
11.0
6.9
16.8
25.3
24.9
42.3
-
39.5
77.6
11.3
16.9
515
11.1
6.9
17.0
25.5
25.1
42.7
-
39.8
78.4
11.4
17.1
520
11.2
7.0
17.2
25.8
25.4
43.1
-
40.2
79.2
11.5
17.2
525
11.3
7.1
17.3
26.0
25.6
43.5
-
40.6
79.9
11.6
17.4
530
11.4
7.1
17.5
26.3
25.8
43.9
-
41.0
80.7
11.7
17.6
535
11.5
7.2
17.7
26.5
26.1
44.4
-
41.4
81.4
11.8
17.7
540
11.6
7.3
17.8
26.7
26.3
44.8
-
41.8
82.2
11.9
17.9
545
11.7
7.3
18.0
27.0
26.6
45.2
-
42.2
83.0
12.0
18.1
550
11.9
7.4
18.2
27.2
26.8
45.6
-
42.5
83.7
12.2
18.2
555
11.9
7.5
18.3
27.5
27.1
46.0
-
42.9
84.5
12.3
18.4
560
12.1
7.5
18.5
27.7
27.3
46.4
-
43.3
85.2
12.4
18.6
565
12.2
7.6
18.7
28.0
27.6
46.8
-
43.7
86.0
12.5
18.7
570
12.3
7.7
18.8
28.2
27.8
47.3
-
44.1
86.8
12.6
18.9
575
12.4
7.7
19.0
28.5
28.0
47.7
-
44.5
87.5
12.7
19.0
580
12.5
7.8
19.1
28.7
28.3
48.1
-
44.9
88.3
12.8
19.2
585
12.6
7.9
19.3
29.0
28.5
48.5
-
45.2
89.0
12.9
19.4
590
12.7
7.9
19.5
29.2
28.8
48.9
-
45.6
89.8
13.0
19.5
595
12.8
8.0
19.6
29.5
29.0
49.3
-
46.0
90.6
13.1
19.7
600
12.9
8.1
19.8
29.7
29.3
49.7
-
46.4
91.3
13.3
19.9
* As for the value of L, a margin of error within ± 5% may be generated depending on the projection lens. The numbers in the table are
rounded approximations.

WX6000(8/14)
■Adjustable range of optical axis shift
A motorized lens shift function that can shift the image position vertically and horizontally is installed on
this product. The lens shift specification per lens is as follows.
Lens
Standard Zoom Lens, Long Zoom Lens, Ultra Long Zoom
Lens, Wide Zoom Lens
Short Fixed Lens
Lens shift amount
Vertical -15% to 55% , Vertical -10% to 10%
Vertical -5% to 5% , Vertical -2% to 2%
Lens shift ratio
Vertical 3.5:6.5 to 10.5:0.5 , Horizontal 6:4 to 4:6
Vertical 4.5:5.5 to 5.5:4.5
Horizontal 5.2:4.8 to 4.8:5.2
Home position *
Vertical 50%(10:0) , Horizontal 0%(5:5)
Vertical 0%(5:5) , Horizontal 0%(5:5)
*Set the lens shift so that the keystone feature functions properly.
Examples of the Standard Zoom Lens, Long Zoom Lens, Ultra Long Zoom Lens, Wide Zoom Lens are shown below
Shift upward, maximum 55%
Displayable area
Lens center
Shift leftward, maximum 10%Image center aligns with lens center Shift rightward, maximum 10%
Shift downward, maximum 15%
As shown in the diagram, the upward maximum shift and left/right maximum shift cannot be used simultaneously.
<Lens shift range of motion>
RS-IL01ST/RS-IL02LZ/RS-IL04UL/RS-IL05WZ
RS-IL03WF

WX6000(9/14)
■Installable angle
* This product can be installed to allow for free rotation in all directions of 360 degrees as shown in the diagram.
* When the projector is installed and used upward or downward, the lamp life may be shortened.
Do not stand it on its
side.*
When installing
on a ceiling or
floor, do not tilt it
more than 10°
leftward/rightwar
* The lamp may become damaged.

WX6000(10/14)
■List of supported signals
The video signals that can be input in this product are described in the table below. They can be input in
the range of the horizontal scanning frequency=15KHz to 75KHz, vertical scanning frequency=50Hz to
60Hz, and dot clock frequency=162MHz or less.
●Analog RGB input *1 ●HDMI input
<Digital PC>
Resolution
[dots]
Signal
format
Horizontal
frequency
[KHz]
Vertical
frequency
[Hz]
Resolution
[dots]
Signal
format
Horizontal
frequency
[KHz]
Vertical
frequency
[Hz]
640×480
VGA
31.469
59.940
640×480
VGA
31.469
59.940
720×480
-
31.469
59.940
800×600
SVGA
37.879
60.317
720×576
-
31.250
50.000
1024×768
XGA
48.363
60.004
800×600
SVGA
37.879
60.317
1280×800
WXGA
49.702
59.810
848×480
-
31.020
60.000
49.306
59,910
1024×768
XGA
48.363
60.004
1280×1024
SXGA
63.981
60.020
1280×720
-
37,500
50.000
1400×1050
SXGA+
64.744
59.948
45.000
60.000
65.317
59.978
1280×768
WXGA
47,776
59.870
1440×900
WXGA+
55.935
59.887
47.396
59.995
55.469
59.901
1280×800
49.702
59.810
1600×1200
UXGA
75.000
60.000
49,306
59.910
1680×1050
WSXGA+
64.674
59.883
1280×960
MAC
60.000
60.000
65.290
59.954
1280×1024
SXGA
63,981
60.020
1920×1200
WUXGA
74.038
59.950
1360×768
-
47.712
60.015
<Digital video>
1366×768
-
47.712
59.790
480p
31.469
59.940
27.000
1440×1050
SXGA+
64,744
59.948
576p
31.250
50.000
27.000
65.317
59.978
720p
37.500
50.000
74.250
1440×900
WXGA+
55,935
59.887
45.000
60.000
74.250
55.469
59.901
1080i
56.250
50.000
74.250
1600×1200
UXGA
75.000
60.000
67.500
60.000
74.250
1680×1050
WSXGA+
64.674
59.883
1080p
56.250
50.000
148.500
65.290
59.954
67.500
60.000
148.500
1920×1080
-
56.250
50.000
67.500
60.000
1920×1200
WUXGA
74.038
59.950

WX6000(11/14)
●DVI input (digital PC) ●Component video input
Resolution
[dots]
Signal
format
Horizontal
frequency
[KHz]
Vertical
frequency
[Hz]
Resolution
[dots]
Signal
format
Horizontal
frequency
[KHz]
Vertical
frequency
[Hz]
640×480
D-VGA
31.469
59.940
480i
15.734
59.940
13.500
720×480
-
31.469
59.940
480p
31.469
59.940
27.000
720×576
-
31.250
50.000
576i
15.625
50.000
13.500
800×600
D-SVGA
37.879
60.317
576p
31.250
50.000
27.000
1024×768
D-XGA
48.363
60.004
720p
37.500
50.000
74.250
1280×720
-
37.500
50.000
45.000
60.000
74.250
45.000
60.000
1080i
28.125
50.000
74.250
1280×800
D-WXGA
49.702
59.810
33.750
60.000
74.250
49.306
59.910
1080p
56.250
50.000
148.500
1280×1024
D-SXGA
63.981
60.020
67.500
60.000
148.500
1400×1050
D-SXGA+
64.744
59.948
65.317
59.978
1440×900
D-WXGA+
55.935
59.887
55.469
59.901
1600×1200
D-UXGA
75.000
60.000
1680×1050
D-WSXGA+
64.674
59.883
65.290
59.954
1920×1080
-
56.250
50.000
67.500
60.000
1920×1200
74.038
74.038
59.950
*1 If the analog PC signal of the dot clock is greater than 162MHz, the images are not projected correctly.
*2 24Hz (24P) is not supported.

WX6000(12/14)
■List of supported signals
The serial terminals conform to RS-232C. To control the projector with a PC, prepare communication
software and input data based on the following communication conditions and basic format.
<Serial input terminals>
●Pin array
Pin number
Signal
1
OPEN
2
RxD
3
TxD
4
OPEN
5
GND
6
OPEN
7
OPEN
8
OPEN
9
OPEN
●Communication format
Communication method: RS-232-C asynchronous half-duplex communication
Communication speed: 19200bps
Character length: 8-bit
Stop bit: 2-bit
Parity: No
Flow control: No
●List of control commands (continues on next page)
Command type
ASCII notation
Binary notation
Power supply
Power ON
POWER ON<CR>
50h 4Fh 57h 45h 52h 20h 4Fh 4Eh 0Dh
Power OFF
POWER OFF<CR>
50h 4Fh 57h 45h 52h 20h 4Fh 46h 46h 0Dh
Power supply
status
acquisition
GET POWER<CR>
47h 45h 54h 20h 50h 4Fh 57h 45h 52h 0Dh
Input source
DigitalPC
INPUT=D-RGB<CR>
49h 4Eh 50h 55h 54h 3Dh 44h 2Dh 52h 47h 42h 0Dh
DigitalVideo
INPUT=HDMI<CR>
49h 4Eh 50h 55h 54h 3Dh 48h 44h 4Dh 49h 0Dh
AnalogPC
INPUT=A-RGB<CR>
49h 4Eh 50h 55h 54h 3Dh 41h 2Dh 52h 47h 42h 0Dh
Component
INPUT=COMP<CR>
49h 4Eh 50h 55h 54h 3Dh 43h 4Fh 4Dh 50h 0Dh
Input source
acquisition
GET INPUT<CR>
47h 45h 54h 20h 49h 4Eh 50h 55h 54h 0Dh
Image mode
STANDARD
IMAGE=STANDARD<CR>
49h 4Dh 41h 47h 45h 3Dh 53h 54h 41h 4Eh 44h 41h 52h 44h 0Dh
PRESENTATION
IMAGE=PRESENTATION<CR>
49h 4Dh 41h 47h 45h 3Dh 50h 52h 45h 53h
45h 4Eh 54h 41h 54h 49h 4Fh 4Eh 0Dh
VIVID PHOTO
IMAGE=VIVID_PHOTO<CR>
49h 4Dh 41h 47h 45h 3Dh 56h 49h 56h 49h 44h 5Fh
50h 48h 4Fh 54h 4Fh 0Dh
PHOTO sRGB
IMAGE=PHOTO_SRGB<CR>
49h 4Dh 41h 47h 45h 3Dh 50h 48h 4Fh 54h 4Fh 5Fh
53h 52h 47h 42h 0Dh
DYNAMIC
IMAGE=DYNAMIC<CR>
49h 4Dh 41h 47h 45h 3Dh 44h 59h 4Eh 41h 4Dh 49h 43h 0Dh
VIDEO
IMAGE=VIDEO<CR>
49h 4Dh 41h 47h 45h 3Dh 56h 49h 44h 45h 4Fh 0Dh
CINEMA
IMAGE=CINEMA<CR>
49h 4Dh 41h 47h 45h 3Dh 43h 49h 4Eh 45h 4Dh 41h 0Dh

WX6000(13/14)
●List of control commands (continued)
Command type
ASCII notation
Binary notation
Image mode
USER1
IMAGE=USER_1<CR>
49h 4Dh 41h 47h 45h 3Dh 55h 53h 45h 52h 5Fh 31h 0Dh
USER2
IMAGE=USER_2<CR>
49h 4Dh 41h 47h 45h 3Dh 55h 53h 45h 52h 5Fh 32h 0Dh
USER3
IMAGE=USER_3<CR>
49h 4Dh 41h 47h 45h 3Dh 55h 53h 45h 52h 5Fh 33h 0Dh
USER4
IMAGE=USER_4<CR>
49h 4Dh 41h 47h 45h 3Dh 55h 53h 45h 52h 5Fh 34h 0Dh
USER5
IMAGE=USER_5<CR>
49h 4Dh 41h 47h 45h 3Dh 55h 53h 45h 52h 5Fh 35h 0Dh
Image mode
acquisition
GET IMAGE<CR>
47h 45h 54h 20h 49h 4Dh 41h 47h 45h 0Dh
Brightness
Brightness value
setting
BRI=< Numerical
value><CR>
42h 52h 49h 3Dh < Numeric code> 0Dh
Brightness
acquisition
GET BRI<CR>
47h 45h 54h 20h 42h 52h 49h 0Dh
Sharpness
Sharpness value
setting
SHARP=< Numerical
value><CR>
53h 48h 41h 52h 50h 3Dh < Numeric code> 0Dh
Sharpness
acquisition
GET SHARP<CR>
47h 45h 54h 20h 53h 48h 41h 52h 50h 0Dh
Contrast
Contrast value
setting
CONT=< Numerical
value ><CR>
43h 4Fh 4Eh 54h 3Dh < Numeric code> 0Dh
Contrast
acquisition
GET CONT<CR>
47h 45h 54h 20h 43h 4Fh 4Eh 54h 0Dh
Aspect
Auto
ASPECT=AUTO<CR>
41h 53h 50h 45h 43h 54h 3Dh 41h 55h 54h 4Fh 0Dh
4:3
ASPECT=4:3<CR>
41h 53h 50h 45h 43h 54h 3Dh 34h 3Ah 33h 0Dh
16:9
ASPECT=16:9<CR>
41h 53h 50h 45h 43h 54h 3Dh 31h 36h 3Ah 39h 0Dh
Zoom
ASPECT=ZOOM<CR>
41h 53h 50h 45h 43h 54h 3Dh 5Ah 4Fh 4Fh 4Dh 0Dh
Real
ASPECT=TRUE<CR>
41h 53h 50h 45h 43h 54h 3Dh 54h 52h 55h 45h 0Dh
Full
ASPECT=FULL<CR>
41h 53h 50h 45h 43h 54h 3Dh 46h 55h 4Ch 4Ch 0Dh
Aspect
GET ASPECT<CR>
47h 45h 54h 20h 41h 53h 50h 45h 43h 54h 0Dh
Lamp mode
LAMP=NORMAL<CR>
4Ch 41h 4Dh 50h 3Dh 4Eh 4Fh 52h 4Dh 41h 4Ch 0Dh
Lamp mode
acquisition
GET LAMP<CR>
47h 45h 54h 20h 4Ch 41h 4Dh 50h 0Dh
Blank
Execute
BLANK=ON<CR>
42h 4Ch 41h 4Eh 4Bh 3Dh 4Fh 4Eh 0Dh
Cancel
BLANK=OFF<CR>
42h 4Ch 41h 4Eh 4Bh 3Dh 4Fh 46h 46h 0Dh
Blank acquisition
GET BLANK<CR>
47h 45h 54h 20h 42h 4Ch 41h 4Eh 4Bh 0Dh

WX6000(14/14)
■Precautions when installing/using
High wattage lamps are used in the projector, and it becomes very hot. Take care as follows.
(1) Do not set anything on top of the projector. Also do not project with projectors stacked directly on top of each other.
(2) Secure space of at least 0.5 meter from the exhausts vents of the projector.
(3) When using stack projection, secure the following space. Open up the lens side as shown below.
Secure the same space also when operating any one of them and stacking and installing one for backup.
(4) Do not block the intake and exhaust vents of the projector.
Also, install the projector so that the intake and exhaust vents are not subjected directly to warm air and cold air of air conditioning.
(5) When operating the projector inserted in a box, ensure that the ambient temperature within the box during operation is within
the range of 5℃to 35℃. Also, do not block the intake and exhaust vents. Even when the ambient temperature is 35℃or lower,
the protection circuit of the projector may function and shut down the projector due to internal retention of the exhaust heat.
Sufficiently consider the ambient temperature environment when installing the projector.
■Concerning the direction of intake/exhaust vents, attachment of optional
2 rear mounting feet
■Concerning replacement of the filter unit
The estimated replacement time for the filter unit is about hours.
However, that time is only an estimate, and you may need to replace the filter unit sooner depending on
your usage environment.
When replacing the filter unit, please purchase RS-FL01.
500mm or
more
500 mm
or more
500mm
or more
Intake vent
Exhaust vent
Hot air
100mm
or more
500mm
or more
500mm
or more
500mm
or more
100 mm
or more
To improve installation stability of the projector
when installing it on a shelf, etc., feet are available
for installing in the 2 screw holes for attaching the
ceiling mounting brackets at both ends of the rear
of the projector. These feet are optional.
Do not stack the
projectors
themselves on top of
each other and use
them.
100 mm
or more
100mm
or more
