Canvas BLACKCOMB 085-1569-0 User manual

Production Number: xxxxxxxx
ASSEMBLY INSTRUCTIONS
Toll-free: 1-888-670-6684
IMPORTANT: Please read this manual carefully before beginning assembly of this product.
Keep this manual for future reference.
085-1569-0
BLACKCOMB
OUTDOOR FIRE TABLE

WARNING: For Outdoor Use Only.
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
odour
property
flammable vapours
odour.
3.
Propane tank not included
WARNING:
DANGER
BLACKCOMB OUTDOOR FIRE TABLE
.

3MODEL N0.
()
TABLE OF CONTENTS
GENERAL INFORMATION
General information
Specifications
Important safety information and precautions
Expanded view
Parts list
Assembly
Location
Setup
Gas connection
Leak test
Lighting
Storage and maintenance
Troubleshooting
Limited warranty
3
4
4
6
7
11
12
11
12
13
10
8
10
10
IMPORTANT
Please take time to read these instructions thoroughly and follow each step carefully for safe and easy
operation. Keep this manual for installer and consumer future reference/use. We would like to hear from
you with any comments or suggestions.
085-1569-0

Product name
Model No.
Rated Heat Output
Fuel
Gas Supply
Manifold Pressure
Orifice Size (diameter)
Gas Supply Pressure
Blackcomb Outdoor Fire Table
4
SPECIFICATIONS
IMPROTANT SAFETY INFORMATION AND PRECAUTIONS
Propane—LP
20 lb (9 kg) LP-Gas cylinder
11" W.C.
1.57 mm
25 PSI (minimum) to 250 PSI (maximum)
The installation must comply with local codes, or in the absences of local codes with the
National Fuel Gas Code, ANSI Z223.1/NF-PA54; The international Fuel Gas Code, Natural Gas
and Propane Installation Code, CSA B149.1; or the Propane Storage and Handling Code, B149.2,
as applicable.
The LP gas supply cylinder to be used must be:
1-Constructed and marked in accordance with the U.S. Department of Transportation (D.O.T.)
Specifications for LP-Gas Cylinders, or the Standard for Cylinders, Spheres and Tubes for
trans portation of Dangerous Goods and Commission, CAN/CSA-B339 as applicable;
2-Provided with a listed overfilling prevention device;
3-Provided with a cylinder connection device compatible with the connection for the appliance.
Always place the appliance on a firm and level surface.
Solid fuels must not be burned in this gas appliance. When using decorative lava rocks, use
only lava rocks (INCLUDED).
The appliance must be used only outdoors in a well-ventilated space and shall not be used in a
building, garage or any other enclosed area.
When in use, keep the appliance area clear and at least 40" (101.6 cm) side, back and top
clearance from combustible materials, gasoline and other flammable liquid and vapours. Do
not use the appliance under overhead combustible surfaces. Certain items or materials, when
stored under the appli
ance or nearby, will be subjected to radiant heat and could be damaged.
When in use, keep cylinder area clear and at least 30" (76.2 cm) side clearance from combusti-
ble materials, gasoline and other flammable liquid and vapours. Do not use the appliance under
overhead combustible surfaces. Certain items or materials, when stored under the appliance or
nearby, will be subject to radiant heat and could be damaged.
085-1569-0 L-FT1346PST-A
26,000 BTU/HR

5MODEL N0. 085-1569-0
()
IMPROTANT SAFETY INFORMATION AND PRECAUTIONS
The minimum distance between the brazier and the
cylinder is 30" (76.2 cm).
WARNING: The cylinder poses a tripping hazard.
Open the door and inspect the hose assembly and burner
prior to each use. If there is evidence of excessive abrasion
or wear or if the hose or burner is damaged, it must be
replaced by an appropriate part from the manufacturer.
Inspect the gas connections of the appliance prior to each
use. Do not operate the unit if there is a gas leak. Have the
appliance inspected annually by a qualified service person.
The pressure regulator and hose assembly provided with the appliance must be used. The replace-
ment part must be the same as the part specified by manufacturer.
For instructions on how to connect the LP-Gas tank and check for leaks, please refer to the “Gas
Connection” on page 9 and “Leak Test” on page 9.
Children and adults should be alerted to the hazards of high surface temperatures and should stay
away to avoid burns and prevent clothing ignition.
Young children and pets should be carefully supervised when they are in the area of the appliance.
Any guard or other protective device removed for servicing the appliance must be replaced prior
to operation.
Clothing or other flammable materials should not be hung from the appliance or placed on or near
the appliance.
Do not use this appliance if any part has been under water. Immediately call a service technician to
inspect the appliance and to replace any part of the control system which has been under water.
LP-Gas supply cylinder to be used must be constructed and marked in accordance with the specifi-
cations for LP-Gas cylinders of the U.S. Department of Transportation (DOT).
The cylinder supplies system must be arranged for vapour withdrawal and the cylinder must include
a collar to protect the cylinder valve.
Use only 20 lb (9 kg) LP-Gas cylinders.
Do not burn wood or any other materials in this appliance.
The appliance must be isolated from the gas supply piping system by closing its individual manual
shutoff valve during any pressure testing of the gas supply piping system at test pressure equal to or
less than 1/2 PSI (3.5 kPa).
Other cylinders may be acceptable for use with the appliance provided they are compatible with
the appliance retention means and accompanied by illustration(s) depicting the cylinder mounted on
the appliance using the cylinder retention means and the point of contact between the cylinder and
the retention means.
Properly place the hose out of pathways where people may trip over it or
in areas where they may be subject to accidental damage.
The burner must be replaced prior to the appliance being put into
operation if it is clear that the burner is damaged. The replacement
burner must be the same as the part specified by the manufacturer.
To clean the appliance, including the burner, please refer to “Storage and
Maintenance” on page 1 .
30"
(76.2 cm)
18" (46 cm)
12 1/2" (32 cm)

6
EXPANDED VIEW
EXPANDED VIEW

7MODEL N0.
(L-FT1346PST-A)
PARTS LIST
Hardware Pack
Label Part Number Description Qty. Add Part Image
AA H02015C11 Bolt M6*15 8 1
BB H19001C11 Flat washer
M6 8 1
CC H00001C12 Wrench M6 1 0
If you want to replace the parts listed, please contact Customer Service Centre: 1-888-670-6684
Parts List
Label Part Number Description Qty. Part Image
A 1
B 1
C 1
D 1
E 3
F 1
2 kg
G
085-1569-0

ASSEMBLY
8x 8x
1x
3x 1x

ASSEMBLY
MODEL N0.
()
1x
1x
1x
085-1569-0
L-FT1346PST-A

Your gas appliance must be installed on a flat, stable surface, away from any
combustible materials or construction.
1-Remove the appliance from container box and place it on any level, outdoor,
non-combustible surface.
NOTE: Do not place this appliance on grass or dirt area. This may prevent proper
safety venting.
2-Open the gas door and put the cylinder inside.
1) Clean the valve and ensure thetank holder is situated in an appropriate location (Fig. 1).
2) Loosen the tank holder retainer bolt by turning counter-clockwise(Fig. 2). Place the
propane tank on the tank holder(Fig. 3) and tighten the retainer bolt securing the tank to
the tank holder(Fig. 4).
3) Connect the regulator to the propane tank as shown (Fig. 5). Perform a leak test as
described on page11.
4) Disconnect the regulatorfrom the tank as shown (Fig. 6).
LOCATION
SETUPGas Connection
Fig. 1
Fig. 2 Fig. 3 Fig 4
Fig. 5 Fig. 6

Do not use an open flame to check for leaks.
Do not smoke during testing.
Do not test indoors.
A leak test must be performed whenever the gas cylinder is replaced.
WARNING!!!
NOTE: While in use, the burner flame should be mainly blue in appearance with a small
amount of yellow. The flame can be identified by the following figure.
1. Make sure the control knob is in the “OFF” position.
2. Make sure the gas cylinder is correctly and securely connected to the pressure regulator,
without over-tightening.
3. Turn on the gas cylinder valve. Apply 50% soap and 50% water solution to thegas hose
and connections between the control knob and gas cylinder.
4. If something is leaking, you will see bubbles form. Incase of leaks, turn off the gas supply,
undo the leaking connection, re-connect it and try again. If the leak persists, consult
Customer Service Centre for assistance at 1-888-670-6684.
5. If the connection does not leak, continue to the next step.
1. Push in and turn control knob to LOW.
2.
If the burner is not lit, turn the knob back to "OFF" ait 5 minutes
3.
If burner is lit, continue to depress control knob for 1-2 minutes
until the thermocouple is hot.
4. Release control knob and the burner should stay lit.
5. Turn control knob to desired heat setting: LOW – HIGH.
6.
(L-FT1346PST-A)
LEAK TEST
11 MODEL N0.085-1569-0
LIGHTING
LEAK TEST
Turn control knob to OFF to shut down. Turn off gas supply at
cylinder. Allow a 5-minute complete shut off period before relighting
the appliance.
and repeat step 1.
Press and turn the control valve knob clockwise to OFF to shut down the fire pit.
Close the gas cylinder valve when the fire pit is not in use.
(CAUTION: Do not kink flexible gas hose. If it is kinked, a gas leak could occur.)
7.
Warning: Lighting the fire table improperly could lead to an unsafe condition.

To obtain the best performance from your fire table, you must perform the following
storage and maintenance activities on a regular basis:
Allow at least 35 minutes for the fire table to cool down after
use, before disconnecting and removing the gas cylinder.
Store the gas cylinder in a dry, well-ventilated and
sheltered area protected from inclement weather and dust,
out of the reach of children, and not in a building, garage or
any other closed area.
The fire table may be stored indoors only if the cylinder is
disconnected and removed.
Keep the fireplace area clear and free from combustible materials,
gasoline and other flammable vapours and liquids.
Installation and repair should be done by a qualified service person. The fire table
should be inspected before use and at least annually by a qualified service person.
More frequent cleaning may be required as necessary. It is imperative that the control
compartment, burner, and circulating air passageways of the fire table be kept clean.
If you disassemble the burner when cleaning the fire table, please reassemble it
according to the picture on the right to make sure the burner induction tunnel is on
and exactly covers the orifice base. It is imperative that the control compartment,
burner, and circulating air passageways of the fire table be kept clean. It is recommended
not to disassemble the burner.
Permanent installation and repair should be done by a qualified service person. The
fire table should be inspected annually by a qualified service person.
1
STORAGE AND MAINTENANCETROUBLESHOOTING
PROBLEM OBSERVED POSSIBLE CAUSE CORRECTIVE MEASURES
G as odour G as l
Low gas pressure
Clogged or dirty burner
ports
Blocked orifice
Spent battery
Incorrect gas supply or
pressure
Blocked orifice
Clogged or dirty burner ports
eak See “If you smell gas:” on page 2
of manual.
Check all gas connections.
.erusserpylppussagkcehCnoitingideyaleD
Clean burner ports—see manual
section.
Check orifice opening.
Replace battery.
.erusserpylppussagkcehCemalfrenrubtcerrocnI
Check and clean orifice opening.
Clean burner ports.

13 MODEL N0.
()
LIMITED WARRANTY
Made in China
Subject to the conditions set out below, this product is warranted to the original purchaser
to be free from defects in workmanship and materials for one (1) year from the date of pur-
chase.
Satisfactory proof of the purchase date must be furnished at the time of notification of the
defect for any claim under the warranty to be enforceable.
This warranty covers all parts found defective in workmanship and/or materials during the
warranty period and can be repaired or replaced at the discretion of the manufacturer at no
cost to the original purchaser.
This warranty will be void if the product has not been assembled, installed or operated
according to the instructions, or subjected to abuse, improperly treated, neglected, rusted
by exposure to the elements, misused and/or if any repairs, maintenance, or service has
been done by an unauthorized person.
Returns must be properly packaged and returned to the dealer from whom the product
was acquired.
The manufacturer, distributor and retailer will not be liable for any incidental or conse-
quential loss or damage arising from the installation or operation of the product and/or the
failure of any part for any reason.
There are no other express or implied warranties, except for those stipulated herein. This
warranty gives specific rights and the original purchaser may have additional rights and
remedies in law.
This warranty does not cover commercial use.
Imported by Trileaf Distribution Trifeuil Toronto, Canada M4S 2B8
085-1569-0
L-FT1346PST-A
