Caple Di465 Manual

New product information sheet
Product name: Di465
Description: Slimline fully integrated dishwasher
Product code: Di465
Width 450mm
Performance
Energy class A
Wash class A
Drying performance A
7 Programmes:
3 in 1 -
normal - 55°C 155 minutes
intensive -60 °C 160 minutes
economy - 45°C 105 minutes
rinse - 45°C 85 minutes
glass - 40°C 110 minutes
rapid - 40ºC 30 minutes
Max. noise level 49dB
Energy consumption 0.80 kw/h
Water consumption (normal) 13L
Delayed timer 1-24hr
Half load
Features
9 Place settings
3 Spray levels
Max. plate diameter 26cm
Stainless steel inner door and interior
Electronic LED control panel
Stainless steel door top control panel
Titanium Grey baskets
Cold Water connection
Hidden heating element
Height adjustable upper basket
Easy clean filter system
3 Level water softening system
LED programme progress indicator
Electronic salt and rinse aid warning light
Water overflow protection system
Aquastop kit
Electrical connection
Voltage 230V
Rated load 1.93kW
Fuse rating 13A

1053

Item Part Code Description Qty
1001 673000900249 External pipe 1
1002 673001500005 O Ring I 31.5X3.55 2
1003 673001800364 Guide casing 1
1004 673001600021 External pipe nut 1
1005 673001900016 Water dispenser 1
1006 673000300050 Upper sprayer 1
1007 673000900171 Upper sprayer pipe 1
1009 673001300041 Upper sprayer holder block 1
1010 673002300002 Float support 1
1011 672000900012 Screw ST2.9x22 1
1012 673002300003 Float 1
1013 674000300060 Micro switch 1
1016 673002500047 Micro filter 1
1017 673001600022 Sump nut 1
1018 673001500016 Sump gasket 1
1019 673000700081 Sump 1
1020 672000700028 Clamp 12.7×1.8 1
1022 673000900160 PVC hose 1
1027 674000600106 drain pump 1
1029 673002200043 Salt filler 1
1030 673002800050 Softener cover assembly 1
1031 673001700053 Softener cover gasket 1
1032 673001600039 Softener nut 1
1033 673001700001 Softener gasket 1
1034 674000700021 Softener 1
DI465- Caple 45cm Fully Integrated Dishwasher

Item Part Code Description Qty
DI465- Caple 45cm Fully Integrated Dishwasher
1035 673000900224 Flexible hose 1
1036 672000700029 Clamp 14.5×1.8 5
1037 673006200003 Drain hose hook 1
1038 673001500002 Drain hose holder 1
1039 673000900186 Drain hose 1
1042 674000000194 Power cord 1
1045 673000900270 Inlet hose assembly 1
1046 673000900026 Regeneration hose 1
1047 673000900224 Outlet hose of air breather 1
1051 673001600055 Ring nut air breather 2
1053 673002600001 Air inlet 1
1054 673002700005 Air breather assembly 1
1064 672000600015 Lower sprayer 1
1070 674000600041 Washing pump 1
1073 673002400066 Motor insulation pan 1
1074 673000900182 Connect hose 2
1083 673000900045 Bend connect hose 1
1085 673001400025 Heating element support 1
1086 674001100039 Heating elements 1
1088 673001600024 Water inlet nut 1
1089 673001500019 Water inlet gasket 1
1091 673002600035 Water inlet 1
1093 674000900038 Sensing device 1
1113 673002500048 plane filter 1
1114 673001300137 Scran collection 1

Item Part Code Description Qty
DI465- Caple 45cm Fully Integrated Dishwasher
1115 674000300079 pressure switch(140/120) 1
1116 673001400083 power cord clasper 1
1117 674000300068 pressure switch assembly for
heating elements 1
2001 673002000084 Door edge guard piece 2
2002 672002200165 Inner door assembly 1
2003 673001700081 Inner door gasket 1
2004 672001700002 Dispenser bracket 2
2005 674000800032 Dispenser 1
2006 674000100447 Wiring harness 1
2008 672000500006 Ring Φ6 4
2009 672001300029 Left hinge 1
2010 672001200012 Joint pin 2
2011 672001300030 Right hinge 1
2012 672001300023 Door hinge 1
2013 672000100004 Door spring 2
2017 672001800337 Outer door 1
2018 673000402065 Control panel 1
2023 673001800513 Handle assembly 1
2024 674000300069 Door switch 1
2027 674000300065 Power switch 1
2028 674000400011 Red pilot lamp 1
2034 674001020117 Control board 1
2035 672000301002 Control panel film 1
2036 673002400095 Control board box 1

Item Part Code Description Qty
DI465- Caple 45cm Fully Integrated Dishwasher
2039 673002800090 Window 1
2040 673001800018 Screw sleeve 2
2041 673000700005 Sleeve cover 2
2053 673002800041 Control panel cover 1
2080 672000100012 button spring 3
2950 673000800906 Power button 1
2951 673000800905 Program key 3
3001 672001600273 Left panel 1
3003 672002100058 Left uprights 1
3005 672001500003 Upper rear crosspiece 1
3006 673001300061 Door lock and clamp 1
3007 672001400039 Door lock and clamp 1
3009 672001500247 Upper front crosspiece 1
3010 673001700056 Tank gasket 1
3011 672002100057 Upright right assembly 1
3012 672001600274 Right panel 1
3013 673001300072 Cup rack 4
3017 672000800148 Lower basket 1
3018 672000800147 Upper basket 1
3021 673001300044 Guide rail block 4
3022 672001700004 Guide rail 2
3023 673001400056 Guide rail bracket 4
3027 675000200144 Lower front crosspiece 1
3029 670400050036 Base tray 1
3031 672001900542 Tank assembly 1

Item Part Code Description Qty
DI465- Caple 45cm Fully Integrated Dishwasher
3032 673001700010 Tank band bracing block 2
3033 672001500234 Lower rear crosspiece 1
3034 672001500118 Middle rear crosspiece 1
3035 673002200079 Ration spoon 1
3048 672001100004 Adjust steel rope 2
3049 672002300002 Adjust nut 2
3050 673001300012 Top board hook 2
3051 672001100003 Adjust screw 2
3052 673001400146 Right adjuster holder assembly 1
3053 672001400036 Front foot 2
3055 672001100002 Adjustable pole 2
3056 673001400145 Left adjuster holder assembly 1
3057 672001400037 Back foot 2
1071+1072 672000200054 Motor support bracket 1
3014+3015+3016 673002200080 Cutlery basket assembly 1
C5004 673006200004 rinsing agent cup 1
OTK 175 672000700004 OTK 175 4
OTK 286 672000700003 OTK 286 1
OTK 310 672000700001 OTK 310 6
OTK 396 672000700007 OTK 396 3

WQP8-B9347A

2
Installation steps
5
3
¿Ì¶ 1.000
1
Aesthetic
panel
2
6

WQP8-B9347A
