Dishwasher
Instruction Manual
DI631
Di631 Intergrated Dishwasher Instruction Manual .indd 1Di631 Intergrated Dishwasher Instruction Manual .indd 1 12/08/2020 10:0912/08/2020 10:09

Instruction manual DI631
2
Please keep this instruction manual for future reference
CONTENTS
Warnings 3
Environmental Protection 8
Quick Operation Guide 9
Control Panel 10
Dishwasher Features 11
Loading the Dishwasher Baskets 19
Programming the Dishwasher 25
Cleaning and Maintenance 28
Installation Instruction 32
Troubleshooting 41
Technical Information 44
Caple Contact Details 48
Di631 Intergrated Dishwasher Instruction Manual .indd 2Di631 Intergrated Dishwasher Instruction Manual .indd 2 12/08/2020 10:0912/08/2020 10:09

Instruction manual DI631
3
Please keep this instruction manual for future reference
SAFETY INSTRUCTIONS
-This product is not designed for commercial use, it is a
household appliance only. It is not intended to be
used in:
• Staff kitchen areas in shops, offices and other
working environments.
• Bed and breakfast type environments.
• By clients in hotels, motels and other residential
type environments.
-This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance
shall not be made by children without supervision.
-This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.
-This appliance is for indoor household use only.
-To protect against the risk of electrical shock, do not
immerse the unit, cord or plug in water or other liquid.
-Please unplug before cleaning or performing
maintenance on the appliance.
Di631 Intergrated Dishwasher Instruction Manual .indd 3Di631 Intergrated Dishwasher Instruction Manual .indd 3 12/08/2020 10:0912/08/2020 10:09

Instruction manual DI631
4
Please keep this instruction manual for future reference
-Use a slightly moistened soft cloth with mild soap, and
then use a dry cloth to wipe it again.
-This appliance must be earthed. In the event of a
malfunction or breakdown, earthing will reduce the risk
of an electric shock by providing a path of less resistance
of electric current. This appliance is equipped with a
cord having an equipment-earthing conductor and a
grounding plug.
-The plug must be plugged into an appropriate outlet
that is installed and earthed in accordance with all local
codes and regulations.
-Improper connection of the equipment-earthing
conductor can result in the risk of an electric shock.
-Check with a qualified electrician or Caple service
representative if you are in doubt whether the appliance
is properly grounded.
-Do not modify the plug provided with the appliance;
If it does not fit the outlet.
-Have a proper outlet installed by a qualified electrician.
-Do not abuse, sit on, or stand on the door or dish rack of
the dishwasher.
-Do not operate your dishwasher unless all enclosure
panels are properly in place.
-Open the door very carefully when the dishwasher is
operating, there is a risk of water squirting out.
Di631 Intergrated Dishwasher Instruction Manual .indd 4Di631 Intergrated Dishwasher Instruction Manual .indd 4 12/08/2020 10:0912/08/2020 10:09

Instruction manual DI631
5
Please keep this instruction manual for future reference
-Do not place any heavy objects on or stand on the door
when it is open. The appliance could tip forward.
-When loading items to be washed:
• Locate sharp items so that they are not likely to
damage the door seal.
• Warning: Knives and other utensils with sharp points
must be loaded in the basket with their points down or
placed in a horizontal position.
-Check that the detergent powder is empty after
completion of the wash cycle.
-Do not wash plastic items unless they are marked
dishwasher safe or the equivalent.
-For plastic items not marked, check the manufacturer’s
recommendations.
-Use only detergent and rinse additives designed for an
automatic dishwasher.
-Never use soap, laundry detergent, or hand washing
detergent in your dishwasher.
-Children should be supervised to ensure that they do not
play with the appliance.
-The door should not be left open, since this could
increase the risk of tripping.
-The appliance may only be used with correctly adjusted
door springs.
Di631 Intergrated Dishwasher Instruction Manual .indd 5Di631 Intergrated Dishwasher Instruction Manual .indd 5 12/08/2020 10:0912/08/2020 10:09

Instruction manual DI631
6
Please keep this instruction manual for future reference
-If the supply cord is damaged, it must be replaced by
Caple, its service agent or a similarly qualified person in
order to avoid a hazard.
-During installation, the power supply must not be
excessively or dangerously bent or flattened.
-The dishwasher must not be installed under a hob.
-Do not tamper with controls.
-The appliance is to be connected to the water mains
using new hose sets and that old hose-sets should not
be reused.
-The maximum permissible inlet water pressure is 1MPa.
-The minimum permissible inlet water pressure
is 0.04MPa.
Di631 Intergrated Dishwasher Instruction Manual .indd 6Di631 Intergrated Dishwasher Instruction Manual .indd 6 12/08/2020 10:0912/08/2020 10:09

Instruction manual DI631
7
Please keep this instruction manual for future reference
WARNINGS:
-Packaging material could be dangerous for children!
-For disposing of package and the appliance please go
to a recycling centre. Therefore cut off the power supply
cable and make the door closing device unusable.
-Cardboard packaging is manufactured from recycled
paper and should be disposed in the waste paper
collection for recycling.
-By ensuring this product is disposed of correctly, you will
help prevent potential negative consequences for the
environment and human health, which could otherwise
be caused by inappropriate waste handling of
this product.
-For more detailed information about recycling of this
product, please contact your local council office and your
household waste disposal service.
-DISPOSAL: Do not dispose this product as unsorted
municipal waste. Collection of such waste separately for
special treatment is necessary.
Di631 Intergrated Dishwasher Instruction Manual .indd 7Di631 Intergrated Dishwasher Instruction Manual .indd 7 12/08/2020 10:0912/08/2020 10:09

Instruction manual DI631
8
Please keep this instruction manual for future reference
ENVIRONMENTAL PROTECTION
Waste electrical products should not be disposed of with household waste. Please recycle where
facilities exist. Check with your Local Authority or retailer for recycling advice. This appliance is
marked according to the European Directive on Waste Electrical and Electronic Equipment (WEEE).
By ensuring this product is disposed of correctly, you will help prevent potential negative
consequences for the environment and human health, which could otherwise be caused by
inappropriate waste handling of this product. The symbol on the product indicates that this
product may not be treated as household waste. Instead it shall be handed over to the applicable
collection point for the recycling of electrical and electronic equipment. Disposal must be carried
out in accordance with local environmental regulations for waste disposal.
For more detailed information about treatment, recovery and recycling of this product, please
contact your local council, your household waste disposal service or the retailer where you
purchased the product.
CE DECLARATIONS OF CONFORMITY
This appliance has been manufactured to the strictest standards and complies with all applicable
legislation, Low Voltage Directive (LVD) and Electromagnetic Compatibility (EMC).
WARRANTY:
Your new appliance is covered by warranty. The warranty card is enclosed - if it is missing, you
must provide the following information to your retailer in order to receive a replacement: date
of purchase, model and serial number (placed on the inside of the appliance storage drawer).
Registration can also be completed online by visiting www.caple.co.uk.
Ensure you keep your warranty card safe, you may need to show it to Caple Service together with
proof of purchase.
If you fail to show your warranty card you will incur all repair charges.
Spare parts are only available from Caple Service and spare parts authorised centres.
Di631 Intergrated Dishwasher Instruction Manual .indd 8Di631 Intergrated Dishwasher Instruction Manual .indd 8 12/08/2020 10:0912/08/2020 10:09

Instruction manual DI631
9
Please keep this instruction manual for future reference
QUICK OPERATION GUIDE
For detailed operating method read the corresponding content on the instruction manual.
Switch on the appliance Open the door,press the On/Off button to switch on the appliance
Fill the detergent
dispenser
Compartment A:
With each wash cycle.
Compartment B:
For programmes with prewash only.
(Follow the user instructions)
Check the Rinse
Aid level
Mechanical Indicator C:
Electric indicator on control panel
Check the regeneration
salt level Electric indicator on control panel
Load the baskets Scrape off any large amount of leftover food. Soften remnants of burnt food in pans, then
load the baskets. Refer to the dishwasher loading instructions
Select a programme Press the Programme button until the required programme lights up. (See the section entitled
“operation instruction”)
Running the dishwasher Close the door. The machine will start working at once.
Changing the
programme
1. A running cycle can only be modified if it has been running
for a short time. Otherwise the detergent may have already
been released and the water already drained. If this is the
case, the detergent dispenser must be refilled.
2. Open the door.
3. Press the Programme Button for 3 seconds to cancel the
running programme.
4. Select a new programme.
5. Close the dishwasher door to restart the dishwasher.
WARNING:
Open the door carefully. Hot
steam may escape when the door
is opened!
Add forgotten dishes
in the dishwasher.
1.Open the door a little to stop the dishwasher.
2.After the spray arms stop working, you can open the door
completely.
3.Add the forgotten dishes.
4.Close the door, the dishwasher will start running again
If the appliance is
switched off during a
wash cycle
If the appliance is switched off during a wash cycle, when
switched on again, please re-select the washing cycle and
operate the dishwasher according to the original Power-on
state).
Switch off the appliance
When the working cycle has finished, the buzzer of the dishwasher will sound 8 times, then
stop. Turn off the appliance using the On/Off Button. Since the appliance is standing by, it will
power off automatically after 30 minutes without any operation.
Unload the Dishwasher WARNING:Wait a few minutes (about 15 minutes) before unloading the dishwasher
to avoid handling the dishes and utensils while they are still hot and more susceptible to
break. They will also dry better. Unload the appliance, starting from the lower basket.
With each wash cycle.
Compartment
For programmes with pre-wash only.
(Follow the user instructions!)
Electric indicator on control panel (if provided).
Check the rinse aid level
(On models with water softener system only.)
Electric indicator on control panel (if provided).
If there is no salt warning light in the control panel
(for some models), you can estimate when to fill the salt into
the softener by the number of cycles the dishwasher has run.
Check the regeneration
salt level
Load the baskets
Select a programm e
Turn on the water tap ,close the door . The machine will start working after about 10 seconds.Runnin g the dishwasher
Switch off the appliance
Turn off the water tap,
unload the baskets
Fill the detergent dispenser
Warning: wait a few minutes ( about 15 minutes) before unloading the d ishwasher to avoid handling
the dishes and utensils while they are still hot and more susceptible to break.
They will also dry better.Unload the appliance, starting from t he lower b asket.
Changing the programme
Add forgotten dishe s in the
dishwasher.
Scrape off any large amount of leftover food. Soften remnants of burnt food in pans,
then load the baskets. Refer to the dishwasher loading instructions.
Press the Programme Button until the selected programme lights up.
( See the section entitled Operation instruction )“”
When the working cycle has finished, the buzzer of the
dishwasher will soun d 8 times, then stop .
Turn off the appliance using the On/Off Button.
If the app liance is switched
off during a wash cycle.
Open the door carefully.
Hot steam may escape
when the door is opened!
If the app liance is switched off during a w ash cycle, when sw itched
on again, please re-select the washing cycle and o perate the dishwasher
according to the original Powe r-on state ).
Switch on the appliance Open the door,press the On/Off button to switch on the appliance .
1.Open the door a li ttle to stop the dishwasher.
2.After the spray arms stop working, you can open the door completely.
3.Add the forgotten dishes.
4.Close the door, the dishwasher will star t running again after 10 seconds.
For detailed operating method read the corresponding content on the instruction manual.
1. A running cycle can only be modified if it has been running for a shor t time. Otherwise the detergent
may have already been releas ed and the water already drained. If this is the case, the detergent
dispenser must be refilled.
2. Open th e door.
3. Press the for mo re than 3 seconds to cancel the running programme.
4. Select a new programme.
5. Restart the dishwasher.
Programme Button
5
A B
With each wash cycle.
Compartment
For programmes with pre-wash only.
(Follow the user instructions!)
Electric indicator on control panel (if provided).
Check the rinse aid level
(On models with water softener system only.)
Electric indicator on control panel (if provided).
If there is no salt warning light in the control panel
(for some models), you can estimate when to fill the salt into
the softener by the number of cycles the dishwasher has run.
Check the regeneration
salt level
Load the baskets
Select a programm e
Turn on the water tap ,close the door . The machine will start working after about 10 seconds.Running the dishwasher
Switch off the applianc e
Turn off the water tap,
unload the baskets
Fill the detergent dispenser
Warning: wait a few minutes ( about 15 minutes) before unloading the d ishwasher to avoid handling
the dishes and utensils while they are still hot and more susceptible to break.
They will also dry better.Unloa d the appli ance, starting from t he lower b asket.
Changing the programme
Add forgo tten dishe s in the
dishwasher.
Scrape off any large amount of leftover food. Soften remnants of burnt food in pans,
then load the baskets. Refer to the dishwasher loading instructions.
Press the Programme Button until the selected programme lights up.
( See the section entitled Operation instruction )“”
When the working cycle has finished, the buzzer of the
dishwasher will soun d 8 times, then stop .
Turn off the appliance using the On/Off B utton.
If the app liance is sw itched
off during a wash cycle.
Open the door carefully.
Hot steam may escape
when the door is opened!
If the app liance is sw itched off during a w ash cycle , wh en sw itched
on again, please re-select the washing c ycle and o perate the dishwasher
according to the original Power-on state ).
Switch on the appliance Open the door,press the On/Off button to switch on the appliance .
1.Open the door a little to stop the dishwasher.
2.After the spray arms stop working, you can open the door completely.
3.Add the forgotten dishes.
4.Close the door, the dishwasher will start running again after 10 seconds.
For detailed operating method read the corresponding content on the instruction manual.
1. A running cycle can only be modified if it has been running for a short time. Otherwise the detergent
may have already been releas ed and the water already drain ed. If this is the case, the detergent
dispenser must be refilled.
2. Open the door.
3. Press the for mo re than 3 seconds to cancel the running programme.
4. Select a new prog ramme.
5. Restart the dishwasher.
Programme Button
5
A B
Di631 Intergrated Dishwasher Instruction Manual .indd 9Di631 Intergrated Dishwasher Instruction Manual .indd 9 12/08/2020 10:0912/08/2020 10:09

Instruction manual DI631
10
Please keep this instruction manual for future reference
CONTROL PANEL
6
before using it for the first time.
To get the best performance from your dishwasher, read all operating instructions
Back ViewFront view
11
Adjuster
11
1
2
3
4
5
6
7
8
910
Dispenser
Cup Shelf
Spray arms
Filter assembly
Inlet pipe connector
Drain pip e
Lower Basket
Inner pipe
Upper Basket
1Salt Container
5
6
7
8
9
10
3
2
4
2.Delay Button : To press the button to delay.
3.Program Button : To press the button to select a
wash Program.
4.On/off Button:
To turn on/off the power supply.
1. in dic ato rs :D isp lay to show th e error c ode,
d elay time e tc .
Program indicators:
Delay time:3/6/9 hours option
Rinse Aid indicator:
Indicates when the dispenser needs to be refilled.
Add salt indicator:
Indicates when the dispenser needs to be refilled.
1. Display in indicators: to show the error
code, delay time etc.
»Rinse Aid indicator:
Indicates when dispenser needs to
be refilled.
»Add salt indicator:
Indicates when dispenser needs to
be refilled.
»Delay time: 3/6/9 hours option.
»Programme indicators:
2. Delay button:
Press the button to delay.
3. Programme button:
Press the button to select a
wash programme.
4. On/off Button:
To turn off The power supply.
1 2 3 4
6
before using it for the first time.
To get the best performance from your dishwasher, read all operating instructions
Back ViewFront view
11
Adjuster
11
1
2
3
4
5
6
7
8
910
Dispenser
Cup Shelf
Spray arms
Filter assembly
Inlet pipe connector
Drain pipe
Lower Basket
Inner pipe
Upper Basket
1Salt Container
5
6
7
8
9
10
3
2
4
2.Delay Button : To press the button to delay.
3.Program Button : To press the button to select a
wash Program.
4.On/off Button:
To turn on/off the power supply.
1. in dic ato rs :D isp lay to sh ow the e rror c od e,
delay time e tc.
Program indicators:
Delay time:3/6/9 hours option
Rinse Aid indicator:
Indicates when the dispenser needs to be refilled.
Add salt indicator:
Indicates when the dispenser needs to be refilled.
Di631 Intergrated Dishwasher Instruction Manual .indd 10Di631 Intergrated Dishwasher Instruction Manual .indd 10 12/08/2020 10:0912/08/2020 10:09

Instruction manual DI631
11
Please keep this instruction manual for future reference
DISHWASHER FEATURES
6
before using it for the first time.
To get the best performance from your dishwasher, read all operating instructions
Back ViewFront view
11
Adjuster
11
1
2
3
4
5
6
7
8
910
Dispenser
Cup Shelf
Spray arms
Filter assembly
Inlet pipe connector
Drain pipe
Lower Basket
Inner pipe
Upper Basket
1Salt Container
5
6
7
8
9
10
3
2
4
2.Delay Button : To press the button to delay.
3.Program Button : To press the button to select a
wash Program.
4.On/off Button:
To turn on/off the power supply.
1. in dic ato rs :D isp lay to sh ow the e rror c od e,
d elay tim e e tc.
Program indicators:
Delay time:3/6/9 hours option
Rinse Aid indicator:
Indicates when the dispenser needs to be refilled.
Add salt indicator:
Indicates when the dispenser needs to be refilled.
3
1
2 4
1. Top Spray Arm
2. Inner Pipe
3. Lower Basket
4. Salt Container
5. Dispenser
6. Cup Shelf
7. Spray Arms
8. Filter Assembly
9. Inlet Pipe Connector
10. Drain Pipe
11. Adjuster
Front View Back View
PRIOR TO USING FOR THE FIRST TIME
Before using your dishwasher for the first time:
»Set the water softener.
»Add 1.5Kg dishwasher salt and then fill the salt container with water.
»Fill the Rinse Aid dispenser.
»Fill in detergent.
Di631 Intergrated Dishwasher Instruction Manual .indd 11Di631 Intergrated Dishwasher Instruction Manual .indd 11 12/08/2020 10:0912/08/2020 10:09

Instruction manual DI631
12
Please keep this instruction manual for future reference
WATER SOFTENER
The water softener must be set manually, using the water hardness dial.
The water softener is designed to remove minerals and salts from the water, which would have a
detrimental or adverse effect on the operation of the appliance.
The higher the content of these minerals and salts, the harder your water is.
The softener should be adjusted according to the hardness of the water in your area. Your local
Water Authority can advise you on the hardness of the water in your area.
ADJUSTING SALT CONSUMPTION
The dishwasher is designed to allow for adjustment in the amount of salt consumed based on the
hardness of the water used. This is intended to optimise and customise the level of
salt consumption.
Please follow the steps below for adjustment in salt consumption:
1. Open the door and Switch on the appliance.
2. Press the Programme button for more than 5 seconds to start the water softener setting within
60 seconds after the appliance was switched on (The Salt and Rinse Aid warning lights will be
on periodically when it is in this setting mode).
3. Press the Programme button to select the proper set according to your local environment, the
sets will change in the following sequence: H1->H2->.H3->H4->H5->H6;
4. Press the Power button to end the set up model.
WATER HARDNESS Selector Position Salt consumption
(gram/cycle)
°DH °FH °CLARKE MMOL/L
0~5 0~9 0~6 0~0.94 H1 0
6-11 10-20 7-14 1.0-2.0 H2 9
12-17 21-30 15-21 2.1-3.0 H3 12
18-22 31-40 22-28 3.1-4.0 H4 20
23-34 41-60 29-42 4.1-6.0 H5 30
35-55 61-98 43-69 6.1-9.8 H6 60
NOTE: 1
°dH=1.25 °Clarke=1 1.78°fH=0.178mmol/l
°dH: German degree
°fH: French degree
°Clark: British degree
NOTE: 2
The manufactory setting: H3
(EN 50242)
Di631 Intergrated Dishwasher Instruction Manual .indd 12Di631 Intergrated Dishwasher Instruction Manual .indd 12 12/08/2020 10:0912/08/2020 10:09

Instruction manual DI631
13
Please keep this instruction manual for future reference
Contact your local water board for information on the hardness of your water supply.
WATER SOFTENER
The hardness of the water varies from place to place. If hard water is used in the dishwasher,
deposits will form on the dishes and utensils.
The appliance is equipped with a special softener that uses a salt container specifically designed
to eliminate lime and minerals from the water.
LOADING THE SALT INTO THE SOFTENER
Always use salt intended for use with dishwashers.
The salt container is located beneath the lower basket and should be filled as explained in
the following:
ATTENTION:
»Only use salt specifically designed for the use in dishwashers. Every other type
of salt not specifically designed for the use in a dishwasher, especially table salt, will damage
the water softener. In case of damages caused by the use of unsuitable salt the manufacturer
does not give any warranty nor is liable for any damages caused.
»Only fill with salt just before starting one of the complete washing programmes. This will
prevent any grains of salt or salty water, which may have been spilled, remaining on the
bottom of the machine for any period of time, which may cause corrosion.
1. The salt container must only be refilled when the salt warning light in the control panel comes on.
Depending on how well the salt dissolves, the salt warning light may still be on even though the salt
container is filled.
2. If there are spills of the salt, a soak or a rapid program should be run to remove the excessive salt.
Always use salt intended for use with dishwashers.
The salt container is located beneath the lower basket and should be filled as explained
in the following:
Attention!
Only use salt specifically designed for the use in dishwashers! Every other type of
salt not specifically designed for the use in a dishwasher, especially table salt, will
damage the water softener. In case of damages caused by the use of unsuitable
salt the manufacturer does not give any warranty nor is liable for any damages caused.
Only fill with salt just before starting one of the complete washing programs.
This will prevent any grains of salt or salty water, which may have been spilled,
remaining on the bottom of the machine for any period of time, which may cause
corrosion.
8
The rinse aid is released during the final rinse to prevent water from forming droplets on your dishes, which can
leave spots and streaks. It also improves drying by allowing water to roll off the dishes. Your dishwasher is
designed to use liquid rinse aids. The rinse aid dispenser is located inside the door next to the detergent dispenser.
To fill the dispenser, open the cap and pour the rinse aid into the dispenser until the level indicator turns completely
black. The volume of the rinse aid container is about 110ml.
Rinse Aid Dispenser
Function of Rinse Aid
Rinse aid is automatically added during the last rinse, ensuring thorough rinsing, and spot and streak free drying.
Attention!
Only use branded rinse aid for dishwasher. Never fill the rinse aid dispenser with any other substances
(e.g. Dishwasher cleaning agent, liquid detergent). This would damage the appliance.
A
B
C
D
E
After the lower basket has been removed, unscrew and remove the cap from the salt container.
Place the end of the funnel (supplied) into the hole and insert about 1.5kg of dishwasher salt.
Fill the salt container with water,It is normal for a small amount of water to come out of the salt
container.
After filling the container, screw the cap tightly back on, turning clockwise.
The salt warning light will turn off after the salt container has been filled with salt.
FImmediately after filling the salt into the salt container, a washing program should be started
program Otherwise the filter system, pump or other important parts of the machine may be damaged
by salty water.
(We suggest to use a short
).
1 2
Di631 Intergrated Dishwasher Instruction Manual .indd 13Di631 Intergrated Dishwasher Instruction Manual .indd 13 12/08/2020 10:0912/08/2020 10:09

Instruction manual DI631
14
Please keep this instruction manual for future reference
»After the lower basket has been removed, unscrew and remove the cap from the
salt container. (1)
»Place the end of the funnel (supplied) into the hole and insert about 1.5kg of dishwasher salt.
»Fill the salt container with water. It is normal for a small amount of water to come out of the
salt container. (2)
»After filling the container, screw the cap tightly back on, turning clockwise.
»The salt warning light will turn off after the salt container has been filled with salt.
»Immediately after filling the salt into the salt container, a washing programme should be
started. Otherwise the filter system, pump or other important parts of the machine may be
damaged by salty water.
NOTE:
1. The salt container must only be refilled when the salt warning light in the control panel comes
on. Depending on how well the salt dissolves, the salt warning light may still be on even though
the salt container is filled.
2. If there are spills of the salt, a soak or a rapid programme should be run to remove the
excessive salt.
FILL THE RINSE AID DISPENSER
RINSE AID DISPENSER
The Rinse Aid is released during the final rinse to prevent water from forming droplets on your
dishes, which can leave spots and streaks. It also improves drying by allowing water to roll off the
dishes. Your dishwasher is designed to use liquid Rinse Aids. The Rinse Aid dispenser is located
inside the door next to the detergent dispenser. To fill the dispenser, open the cap and pour the
Rinse Aid into the dispenser until the level indicator turns completely black. The volume of the
Rinse Aid container is about 110ml.
FUNCTION OF RINSE AID
Rinse Aid is automatically added during the last rinse, ensuring thorough rinsing, and spot and
streak free drying.
ATTENTION:
Only use branded Rinse Aid for dishwasher. Never fill the Rinse Aid dispenser with any other
substances (e.g. Dishwasher cleaning agent, liquid detergent). This would damage the appliance.
Di631 Intergrated Dishwasher Instruction Manual .indd 14Di631 Intergrated Dishwasher Instruction Manual .indd 14 12/08/2020 10:0912/08/2020 10:09

Instruction manual DI631
15
Please keep this instruction manual for future reference
WHEN TO REFILL THE RINSE AID DISPENSER
The Rinse Aid warning light in the control panel will illuminate when the dispenser needs re-filling.
You can also estimate the remaining amount from the colour of the optical level indicator “C“
located next to the cap. When the Rinse Aid container is full, the whole indicator will be dark. As
the Rinse Aid diminishes, the size of the dark dot decreases. You should never let the Rinse Aid
level fall 1 / 4 full.
As the Rinse Aid diminishes, the size of the black dot on the Rinse Aid level indicator changes, as
illustrated below:
Full
¾ full
½ full
¼ full - Should refill to eliminate spotting
Empty
9
To open the dispenser, turn the cap to t he "open" (left) arrow and lift it out.
Pour the rinse aid into the dispenser, being careful not to overfill.
Replace the cap by inserting it aligned with "open" arrow and turning it to the closed (right) arrow.
Adjusting Rinse Aid Dispenser
The rinse aid dispenser has s ix or four settings. Always start with the dispenser
set on "4". If spots and poor drying are a problem, incre ase the amount of rinse
aid disp e nsed by r emovi ng th e d ispenser lid and ro tatin g the di al t o "5 ". If t he
dishes still are not drying properly or are show s pots, adjust the dial to the next
higher lever until your dishes are spot-free. The recommended setting is "4".
(Fac tor y va lue is " 4".)
In crea se the d o se if the re are d rops o f wate r or l ime sp ots on t he dishes af te r wash in g.
Reduce i t i f there a re stic ky whiti sh stains on your d ish es or a bluish film on glassware or
kni fe b l ade s.
1
2
3
As the rinse aid diminishes, the size of the black dot
on the rinse aid level indicator changes, as illustrated below.
Full
3 / 4 full
1 / 2 full
1 / 4 full - Should refill to eliminate spotting
Empty
When to Refill the Rinse Aid Dispenser
If there is no rinse-aid warning light in the control panel, you can estimate the amount from the colour
of the optical level indicator C located next to the cap. When the rinse-aid container is full, the whole
indicator will be dark .As the rinse-aid diminishes, the size of the dark dot decreases. You should never let
the rinse aid level fall 1 / 4 full.
during the next wash. Don't forget to replace the cap before you close dishwasher door.
Clean up any rinse aid spilled while during filling with an absorbent cloth to avoid excessive foaming
Detergents with its chemical ingredients are necessary to remove dirt, crush dirt and transport it out of the dishwasher.
Most of the commercial qu ality detergents are suitable for this purpose.
""
Proper Use of Detergent
Use only detergent specifically made for the use in dishwashers. Keep your detergent fresh and dry.
Don't put powdered detergent into the dispenser until you're ready to wash dishes.
Attention!
C(Rinse-Aid indicator)
1 2 3
1. To open the dispenser, turn the cap to the “open” (left) arrow and lift it out.
2. Pour the Rinse Aid into the dispenser, being careful not to overfill.
3. Replace the cap by inserting it aligned with “open” arrow and turning it to the closed
(right) arrow.
NOTE:
Clean up any Rinse Aid spilled during filling with an absorbent cloth to avoid excessive foaming
during the next wash. Don’t forget to replace the cap before you close dishwasher door.
9
To open the dispenser, turn the cap t o the "open" (left) arrow and lift it out.
Pour the rinse aid into the dispenser, being careful not to overfill.
Replace the cap by inserting it aligned wit h "open" arrow and turning it to the closed (right) a rrow.
Adjusting Rinse Aid Dispenser
The rinse aid dispenser has s ix or four settings. Always start with the dispenser
set on "4". If spots and poor drying are a problem, incre ase the amount of rinse
aid di sp ensed by r emoving th e d ispenser li d an d ro tat in g the di a l t o "5 ". If t he
dishes still are not drying properly or are show spots, adjust the dial to the next
higher lever until your dishes are spot-free. The recommended setting is "4".
(Fac tor y va lue is "4 ".)
In crea se the do se if the re are d rops o f wat er o r l ime sp ots on t he dishes af te r washi n g.
Reduce it if there are sticky whiti sh stains on your dish es or a bluish film on glassware or
kni fe bl ade s .
1
2
3
As the rinse aid diminishes, the size of the black dot
on the rinse aid level indicator changes, as illustrated below.
Full
3 / 4 full
1 / 2 full
1 / 4 full - Should refill to eliminate spotting
Empty
When to Refill the Rinse Aid Dispenser
If there is no rinse-aid warning light in the control panel, you can estimate the amount from the colour
of the optical level indicator C located next to the cap. When the rinse-aid container is full, the whole
indicator will be dark .As the rinse-aid diminishes, the size of the dark dot decreases. You should never let
the rinse aid level fall 1 / 4 full.
during the next wash. Don't forget to replace the cap before you close dishwasher door.
Clean up any rinse aid spilled while during filling with an absorbent cloth to avoid excessive foaming
Detergents with its chemical ingredients are necessary to remove dirt, crush dirt and transport it out of the dishwasher.
Most of the commercial quality detergents are suitable for this purpose.
""
Proper Use of Detergent
Use only detergent specifically made for the use in dishwashers. Keep your detergent fresh and dry.
Don't put powdered detergent into the dispenser until you're ready to wash dishes.
Attention!
Di631 Intergrated Dishwasher Instruction Manual .indd 15Di631 Intergrated Dishwasher Instruction Manual .indd 15 12/08/2020 10:0912/08/2020 10:09

Instruction manual DI631
16
Please keep this instruction manual for future reference
ADJUSTING RINSE AID DISPENSER
The Rinse Aid dispenser has six settings. Always start with
the dispenser set on “4”. If spots and poor drying are a
problem, increase the amount of Rinse Aid dispensed by
removing the dispenser lid and rotating the dial to “5”. If
the dishes still are not drying properly or are showing spots,
adjust the dial to the next higher lever until your dishes are
spot-free. The recommended setting is “4”.
(Factory value is “4”.)
NOTE:
Increase the dose if there are drops of water or lime spots on the dishes after washing. Reduce it if
there are sticky whitish stains on your dishes or a bluish film on glassware or knife blades.
FUNCTION OF DETERGENT
Detergents with chemical ingredients are necessary to remove dirt, crush dirt and transport it out
of the dishwasher. Most of the commercial quality detergents are suitable for this purpose.
ATTENTION:
Proper Use of Detergent:
Use only detergent specifically made for the use in dishwashers. Keep your detergent fresh and
dry. Don’t put powdered detergent into the dispenser until you’re ready to wash dishes.
DETERGENTS
There are 3 sorts of detergents
1.With phosphate and with chlorine
2.With phosphate and without chlorine
3.Without phosphate and without chlorine
Normally new pulverised detergent is without phosphate. Thus the water softener function of
phosphate is not given. In this case we recommend to fill salt in the salt container even when the
hardness of water is only 6 dH. If detergents without phosphate are used in the case of hard water
often white spots appear on dishes and glasses. In this case please add more detergent to reach
better results. Detergents without chlorine do only bleach a little. Strong and coloured spots will
not be removed completely. In this case please choose a programme with a higher temperature.
Adjust lever
(Rinse)
Di631 Intergrated Dishwasher Instruction Manual .indd 16Di631 Intergrated Dishwasher Instruction Manual .indd 16 12/08/2020 10:0912/08/2020 10:09

Instruction manual DI631
17
Please keep this instruction manual for future reference
CONCENTRATED DETERGENT
Based on their chemical composition, detergents can be split in two basic types:
»Conventional, alkaline detergents with caustic components.
»Low alkaline concentrated detergents with natural enzymes.
DETERGENT TABLETS
Detergent tablets of different brands dissolve at different speeds. For this reason some detergent
tablets cannot dissolve and develop their full cleaning power during short programmes. Therefore
please use long programmes when using detergent tablets, to ensure the complete removal of
detergent residuals.
DETERGENT DISPENSER
The dispenser must be refilled before the start of each wash cycle following the instructions
provided in the wash cycle table. Your dishwasher uses less detergent and Rinse Aid than
conventional dishwashers. Generally, only one tablespoon of detergent is needed for a normal
wash load. More heavily soiled items need more detergent. Always add the detergent just before
starting the dishwasher, otherwise it could get damp and will not dissolve properly.
AMOUNT OF DETERGENT TO USE
10
Amount of Detergent to Use
Based on their chemical composition, detergents can be split in two basic types:
Detergent tablets of different brands dissolve at different speeds. For this reason some
detergent tablets cannot dissolve and develop their full cleaning power during short
programs. Therefore please use long programs when using detergent tablets, to
ensure the complete removal of detergent residuals.
The dispenser must be refilled before the start of each wash cycle following the instructions
provided in the wash cycle table . Your dishwasher uses less detergent and rinse aid than
Conventional dishwasher. Generally, only one tablespoon of detergent is needed for
a normal wash load. More heavily soiled items need more detergent. Always add the
detergent just before starting the dishwasher, otherwise it could get damp and will not
dissolve properly.
Concentrated Detergent
Detergent Tablets
Detergent Dispenser
conventional, alkaline detergents with caustic components
low alkaline concentrated detergents with natural enzymes
Normally new pulverised detergent is without phosphate. Thus the water softener function of
phosphate is not given. In this case we recommend to fill salt in the salt container even when
the hardness of water is only 6 dH. If detergents without phosphate are used in the case of hard water
often white spots appear on dishes and glasses. In this case please add more detergent to reach
better results. Detergents without chlorine do only bleach a little. Strong and coloured spots will not
be removed completely. In this case please choose a program with a higher temperature.
°
Detergents
There are 3 sorts of detergents
1.With phosphate and with chlorine
2.Wi th p hosph a te an d w ith out ch lo rine
3.Without phosphate and without chlorine
Always add the detergent just before starting each wash cycle.
Only use branded detergent aid for dishwasher.
If the lid is closed: press release button. The lid will spring open.
Dishwasher detergent is corrosive!
Take care to keep it out of reach of children.
NOTE:
»If the lid is closed: press release button. The lid will spring open.
»Always add the detergent just before starting each wash cycle.
»Only use branded detergent aid for dishwasher.
10
Amount of Detergent to Use
Based on their chemical composition, detergents can be split in two basic types:
Detergent tablets of different brands dissolve at different speeds. For this reason some
detergent tablets cannot dissolve and develop their full cleaning power during short
programs. Therefore please use long programs when using detergent tablets, to
ensure the complete removal of detergent residuals.
The dispenser must be refilled before the start of each wash cycle following the instructions
provided in the wash cycle table . Your dishwasher uses less detergent and rinse aid than
Conventional dishwasher. Generally, only one tablespoon of detergent is needed for
a normal wash load. More heavily soiled items need more detergent. Always add the
detergent just before starting the dishwasher, otherwise it could get damp and will not
dissolve properly.
Concentrated Detergent
Detergent Tablets
Detergent Dispenser
conventional, alkaline detergents with caustic components
low alkaline concentrated detergents with natural enzymes
Normally new pulverised detergent is without phosphate. Thus the water softener function of
phosphate is not given. In this case we recommend to fill salt in the salt container even when
the hardness of water is only 6 dH. If detergents without phosphate are used in the case of hard water
often white spots appear on dishes and glasses. In this case please add more detergent to reach
better results. Detergents without chlorine do only bleach a little. Strong and coloured spots will not
be removed completely. In this case please choose a program with a higher temperature.
°
Detergents
There are 3 sorts of detergents
1.With phosphate and with chlorine
2.Wi th p hosph a te an d w ith out ch lo rine
3.Without phosphate and without chlorine
Always add the detergent just before starting each wash cycle.
Only use branded detergent aid for dishwasher.
If the lid is closed: press release button. The lid will spring open.
Dishwasher detergent is corrosive!
Take care to keep it out of reach of children.
Di631 Intergrated Dishwasher Instruction Manual .indd 17Di631 Intergrated Dishwasher Instruction Manual .indd 17 12/08/2020 10:0912/08/2020 10:09

Instruction manual DI631
18
Please keep this instruction manual for future reference
WARNING:
Dishwasher detergent is corrosive.
Take care to keep it out of reach of children.
FILL THE DETERGENT DISPENSER
Fill the detergent dispenser with detergent. The marking indicates the dosing
levels, as illustrated on the right:
Please observe the manufacturers dosing and storage recommendations as stated on the
detergent packaging.
Close the lid and press until it locks in place.
If the dishes are heavily soiled, place an additional detergent dose in the pre-wash detergent
chamber. This detergent will take effect during the pre-wash phase.
NOTE:
»You find information about the amount of detergent for the single programme in the ‘Wash
cycle table’.
»Please be aware, that according to the level of soiling and the specific hardness of water,
differences are possible.
»Please observe the manufacturer’s recommendations on the detergent packaging.
Fill the detergent dispenser with detergent.
The marking indicates the dosing levels , as
illustrated on the right:
The place of main wash cycle detergent placed.
The place of pre-wash cycle detergent placed.
Please observe the manufacturers dosing and storage
Recommendations as stated on the detergent packaging.
Close the lid and press until it locks in place.
If the dishes are heavily soiled, place an additional
detergent dose in the pre-wash detergent chamber. This detergent will take effect during the pre-wash phase.
A
B
Fill in Detergent
You find information about the amount of detergent for the single programme on the last page.
Please aware, that according to the level soiling and the specific hardness of water differences are possible.
Please observe the manufacturer's recommendations on the detergent packaging.
11
AB
AThe place of main wash cycle detergent placed.
B The place of pre-wash cycle detergent placed.
Di631 Intergrated Dishwasher Instruction Manual .indd 18Di631 Intergrated Dishwasher Instruction Manual .indd 18 12/08/2020 10:0912/08/2020 10:09

Instruction manual DI631
19
Please keep this instruction manual for future reference
LOADING THE DISHWASHER BASKETS
RECOMMENDATION
»Consider buying utensils which are identified as dishwasher-proof.
»Use a mild detergent that is described as ‘kind to dishes’. If necessary, seek further information
from the detergent manufacturers.
»For particular items, select a programme with as low a temperature as possible.
»To prevent damage, do not take glass and cutlery out of the dishwasher immediately after the
programme has ended.
THE FOLLOWING CUTLERY / DISHES:
ARE NOT SUITABLE
»Cutlery with wood, horn china or mother-of-pearl handles.
»Plastic items that are not heat resistant.
»Older cutlery with glued parts that are not temperature resistant.
»Bonded cutlery items or dishes.
»Pewter or copper items.
»Crystal glass.
»Steel items subject to rusting.
»Wooden platters.
»Items made from synthetic fibres.
ARE OF LIMITED SUITABILITY
»Some types of glasses can become dull after a large number of washes.
»Silver and aluminium parts have a tendency to discolour during washing.
»Glazed patterns may fade if machine washed frequently.
Di631 Intergrated Dishwasher Instruction Manual .indd 19Di631 Intergrated Dishwasher Instruction Manual .indd 19 12/08/2020 10:0912/08/2020 10:09

Instruction manual DI631
20
Please keep this instruction manual for future reference
BEFORE OR AFTER LOADING
THE DISHWASHER BASKET
(For best performance of the dishwasher, follow these loading guidelines. Features and appearance
of baskets and cutlery baskets may vary from your model.)
Scrape off any large amounts of leftover food. Soften remnants of burnt food in pans. It is not
necessary to rinse the dishes under running water.
Place objects in the dishwasher in the following way:
1. Items such as cups, glasses, pots/pans, etc. are faced downwards.
2. Curved items, or ones with recesses, should be loaded aslant so that water can run off.
3. All utensils are stacked securely and can not tip over.
4. All utensils are placed in the way that the spray arms can rotate freely during washing.
NOTE:
Very small items should not be washed in the dishwasher as they could
easily fall out of the basket.
»Load hollow items such as cups, glasses, pans etc. With the opening facing downwards so that
water cannot collect in the container or a deep base.
»Dishes and items of cutlery must not lie inside one another, or cover each other.
»To avoid damage to glasses, they must not touch.
»Load large items which are most difficult to clean into the lower basket.
»The upper basket is designed to hold more delicate and lighter dishware such as glasses,
coffee and tea cups.
»Long bladed knives stored in an upright position are a potential hazard.
»Long and/or sharp items of cutlery such as carving knives must be positioned horizontally in
the upper basket.
»Please do not overload your dishwasher. This is important for good results and for
reasonable consumption of energy.
Di631 Intergrated Dishwasher Instruction Manual .indd 20Di631 Intergrated Dishwasher Instruction Manual .indd 20 12/08/2020 10:0912/08/2020 10:09
