Integrated Dishwasher
instruction manual
Di651
Di651 Intergrated Dishwasher.indd 1 08/02/2017 12:59

Instruction manual Di651
Please keep this instruction manual for future reference
2
CONTENTS
WARNINGS 3
QUICK OPERATION GUIDE 9
CONTROL PANEL 10
DISHWASHER FEATURES 11
PRIOR TO USING FOR THE FIRST TIME 11
WATER SOFTENER 12
LOADING THE SALT INTO THE SOFTENER 13
FILL THE RINSE AID DISPENSER 14
FUNCTION OF DETERGENT 16
LOADING THE DISHWASHER BASKET 19
LOADING THE UPPER BASKET 21
LOADING THE LOWER BASKET 21
CUTLERY TRAY 24
WASH CYCLE TABLE 27
TURNING ON THE APPLIANCE 28
CHANGE THE PROGRAMME 28
AT THE END OF THE WASH CYCLE 29
CLEANING AND MAINTENANCE 30
FILTERING SYSTEM 30
CARING FOR THE DISHWASHER 32
INSTALLATION INSTRUCTION 34
INSTALLATION PREPARATION 34
TENSION ADJUSTMENT OF THE DOOR SPRING 38
CONNECTION OF DRAIN HOSES 38
DISHWASHER INSTALLATION STEPS 39
ELECTRICAL CONNECTION 41
COLD WATER CONNECTION 42
TROUBLESHOOTING TIPS 44
ERROR CODES 46
TECHNICAL INFORMATION 47
TECHNICAL FICHE 48
CAPLE CONTACT DETAILS 52
Di651 Intergrated Dishwasher.indd 2 08/02/2017 12:59

Instruction manual Di651
Please keep this instruction manual for future reference
3
WARNINGS
-This product is not designed for commercial use, it is a
household appliance only. It is not intended to be
used in:
1) Staff kitchen areas in shops, offices and other working
environments.
2) Bed and breakfast type environments.
3) By clients in hotels, motels and other residential type
environments.
-This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance
shall not be made by children without supervision.
-This appliance is not intended for use by persons
(including children )with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.
-This appliance is for indoor household use only.
Di651 Intergrated Dishwasher.indd 3 08/02/2017 12:59

Instruction manual Di651
Please keep this instruction manual for future reference
4
-To protect against the risk of electrical shock, do not
immerse the unit, cord or plug in water or other liquid.
-Please unplug before cleaning or performing
maintenance on the appliance.
-Use a slightly moistened soft cloth with mild soap, and
then use a dry cloth to wipe it again
-This appliance must be earthed. In the event of a
malfunction or breakdown, earthing will reduce the risk
of an electric shock by providing a path of less resistance
of electric current. This appliance is equipped with a
cord having an equipment-earthing conductor and a
grounding plug.
-The plug must be plugged into an appropriate outlet
that is installed and earthed in accordance with all local
codes and regulations.
-Improper connection of the equipment-earthing
conductor can result in the risk of an electric shock.
-Check with a qualified electrician or Caple service
representative if you are in doubt whether the appliance
is properly grounded.
-Do not modify the plug provided with the appliance;
If it does not fit the outlet.
-Have a proper outlet installed by a qualified electrician.
Di651 Intergrated Dishwasher.indd 4 08/02/2017 12:59

Instruction manual Di651
Please keep this instruction manual for future reference
5
-Do not abuse, sit on, or stand on the door or dish rack of
the dishwasher.
-Do not operate your dishwasher unless all enclosure
panels are properly in place.
-Open the door very carefully when the dishwasher is
operating, there is a risk of water squirting out.
-Do not place any heavy objects on or stand on the door
when it is open. The appliance could tip forward.
-When loading items to be washed:
1) Locate sharp items so that they are not likely to
damage the door seal
2) Warning: Knives and other utensils with sharp points
must be loaded in the basket with their points down
or placed in a horizontal position.
-Check that the detergent powder is empty after
completion of the wash cycle.
-Do not wash plastic items unless they are marked
dishwasher safe or the equivalent.
-For plastic items not marked, check the manufacturer’s
recommendations.
-Use only detergent and rinse additives designed for an
automatic dishwasher.
-Never use soap, laundry detergent, or hand washing
detergent in your dishwasher.
Di651 Intergrated Dishwasher.indd 5 08/02/2017 12:59

Instruction manual Di651
Please keep this instruction manual for future reference
6
-Children should be supervised to ensure that they do not
play with the appliance.
-The door should not be left open, since this could
increase the risk of tripping.
-The appliance may only be used with correctly adjusted
door springs.
-If the supply cord is damaged, it must be replaced by
Caple, its service agent or a similarly qualified person in
order to avoid a hazard.
-During installation, the power supply must not be
excessively or dangerously bent or flattened.
-The dishwasher must not be installed under a hob.
-Do not tamper with controls.
-The appliance is to be connected to the water mains
using new hose sets and that old hose-sets should not
be reused.
-The maximum number of place settings to be washed
is 15.
-The maximum permissible inlet water pressure is 1MPa.
-The minimum permissible inlet water pressure is
0.04MPa.
Di651 Intergrated Dishwasher.indd 6 08/02/2017 12:59

Instruction manual Di651
Please keep this instruction manual for future reference
7
WARNINGS
-Packaging material could be dangerous for children!
-For disposing of package and the appliance please go
to a recycling centre. Therefore cut off the power supply
cable and make the door closing device unusable.
-Cardboard packaging is manufactured from recycled
paper and should be disposed in the waste paper
collection for recycling.
-By ensuring this product is disposed of correctly, you will
help prevent potential negative consequences for the
environment and human health, which could otherwise
be caused by inappropriate waste handling of this
product.
-For more detailed information about recycling of this
product, please contact your local council office and your
household waste disposal service.
-DISPOSAL: Do not dispose this product as unsorted
municipal waste. Collection of such waste separately for
special treatment is necessary.
Di651 Intergrated Dishwasher.indd 7 08/02/2017 12:59

Instruction manual Di651
Please keep this instruction manual for future reference
8
ENVIRONMENTAL PROTECTION
Waste electrical products should not be disposed of with household waste. Please
recycle where facilities exist. Check with your Local Authority or retailer for recycling
advice. This appliance is marked according to the European directive 2002/96/EC on
Waste Electrical and Electronic Equipment (WEEE).
By ensuring this product is disposed of correctly, you will help prevent potential
negative consequences for the environment and human health, which could
otherwise be caused by inappropriate waste handling of this product. The symbol
on the product indicates that this product may not be treated as household waste.
Instead it shall be handed over to the applicable collection point for the recycling of
electrical and electronic equipment. Disposal must be carried out in accordance with
local environmental regulations for waste disposal.
For more detailed information about treatment, recovery and recycling of this
product, please contact your local council, your household waste disposal service or
the retailer where you purchased the product
CE DECLARATIONS OF CONFORMITY
This appliance has been manufactured to the strictest standards and complies
with all applicable legislation, Low Voltage Directive (LVD) and Electromagnetic
Compatibility (EMC).
Di651 Intergrated Dishwasher.indd 8 08/02/2017 12:59

Instruction manual Di651
Please keep this instruction manual for future reference
9
QUICK OPERATION GUIDE
For detailed operating method read the corresponding content on the instruction
manual.
Switch on the appliance Open the door,press the On/Off button to switch on the appliance
Fill the detergent
dispenser
Compartment A:
With each wash cycle.
Compartment B:
For programmes with prewash only.
(Follow the user instructions)
Check the rinse aid level Mechanical Indicator C:
Electric indicator on control panel
Check the regeneration
salt level Electric indicator on control panel
Load the baskets Scrape off any large amount of leftover food. Soften remnants of burnt food in
pans, then load the baskets. Refer to the dishwasher loading instructions
Select a programme Press the Programme Button that you require and it will light up. (See the section
entitled“Operation instruction”)
Running the dishwasher Close the door. The machine will start working at once.
Changing the
programme
1. A running cycle can only be modified if it has been
running for a short time. Otherwise the detergent
may have already been released and the water already
drained. If this is the case, the detergent dispenser must
be refilled.
2. Open the door.
3. Press the Rapid Programme Button for 3 seconds to
cancel the running programme.
4. Select a new programme.
5. Close the dishwasher door to restart the dishwasher.
WARNING
Open the door
carefully. Hot steam
may escape when
the door is opened!
Add forgotten dishes
in the dishwasher.
1.Open the door a little to stop the dishwasher.
2.After the spray arms stop working, you can open the
door completely.
3.Add the forgotten dishes.
4.Close the door, the dishwasher will start running again
If the appliance is
switched off during a
wash cycle
If the appliance is switched off during a wash cycle, when
switched on again, please re-select the washing cycle and
operate the dishwasher according to the original Power-on
state ).
Switch off the appliance
When the working cycle has finished, the buzzer of the dishwasher will sound
8 times, then stop. Turn off the appliance using the On/Off Button. Since the
appliance is standing by, it will power off automaticly after 30 minutes without
any operation.
Unload the Dishwasher
WARNING:wait a few minutes (about 15 minutes) before unloading the
dishwasher to avoid handling the dishes and utensils while they are still hot and
more susceptible to break. They will also dry better.Unload the appliance, starting
from the lower basket
A
C
B
Di651 Intergrated Dishwasher.indd 9 08/02/2017 12:59

Instruction manual Di651
Please keep this instruction manual for future reference
10
CONTROL PANEL
1 2 3 4 5 6 7
1. Power Button- touch on and off.
2. Program Buttons-touch to select the
Program, corresponding indicator
will light:
Auto
Intensive
Normal
ECO
Glass
90Min
Rapid
3. Screen - Shows the program time and
delay time:
Eg: program time
Delay time
4. Status Indicators:
Faucet is not open
Rinse detergent needs
to be refilled
Salt needs to be refilled
5. Delay Buttons:
Increase
Reduce
6. Alt Function Buttons and indicators:
Upper basket
Lower basket
7. Program functions, only one function
can be selected in a cycle:
Extra Drying, to improve the
drying efficiency
Power Wash, to improve the
cleaning efficiency
Express wash, to reduce the
program time
Di651 Intergrated Dishwasher.indd 10 08/02/2017 12:59

Instruction manual Di651
Please keep this instruction manual for future reference
11
DISHWASHER FEATURES
11
1
2
3
4
5
7
8
910
6
12
1. Top spray arm
2. Cutlery tray
3. Upper basket
4. Inner pipe
5. Lower basket
6. Salt container
7. Dispenser
8. Cup shelf
9. Spray arms
10. Filter assembly
11. Inlet pipe connector
12. Drain pipe
Front view Back view
PRIOR TO USING FOR THE FIRST TIME
Before using your dishwasher for the first time:
- Set the water softener
- Add 1.5Kg dishwasher salt and then fill the salt container with water
- Fill the rinse aid dispenser
- Fill in detergent
Di651 Intergrated Dishwasher.indd 11 08/02/2017 12:59

Instruction manual Di651
12
WATER SOFTENER
The water softener must be set manually, using the water hardness dial.
The water softener is designed to remove minerals and salts from the water, which
would have a detrimental or adverse effect on the operation of the appliance.
The higher the content of these minerals and salts, the harder your water is.
The softener should be adjusted according to the hardness of the water in your
area. Your local Water Authority can advise you on the hardness of the water in
your area.
ADJUSTING SALT CONSUMPTION
The dishwasher is designed to allow for adjustment in the amount of salt consumed
based on the hardness of the water used. This is intended to optimise and
customise the level of salt consumption.
Please follow the steps below for adjustment in salt consumption
1. Open the door and Switch on the appliance;
2. Press the Rapid Program button for more than 5 seconds to start the water
softener setting within 60 seconds after the appliance was switched on (The
Salt and Rinse aid warning lights will be on periodically when it is in this setting
mode);
3. Press the Rapid Program button to select the proper set according to your local
environment, the sets will change in the following sequence: H1->H2->;
4. Press the Power button to end the set up model.
WATER HARDNESS Selector
Position
Salt
consumption
(gram/cycle)
°dH °fH °Clarke mmol/l
0~5 0~9 0~6 0~0.94 H1 0
6-11 10-20 7-14 1.0-2.0 H2 9
12-17 21-30 15-21 2.1-3.0 H3 12
18-22 31-40 22-28 3.1-4.0 H4 20
23-34 41-60 29-42 4.1-6.0 H5 30
35-55 61-98 43-69 6.1-9.8 H6 60
NOTE: 1
°dH=1.25 °Clarke=1 1.78°fH=0.178mmol/l
°dH: German degree
°fH: French degree
°Clark: British degree
NOTE: 2
The manufactory setting: H3
(EN 50242)
Di651 Intergrated Dishwasher.indd 12 08/02/2017 12:59

Instruction manual Di651
13
Please keep this instruction manual for future reference
Contact your local water board for information on the hardness of your water
supply.
WATER SOFTENER
The hardness of the water varies from place to place. If hard water is used in the
dishwasher, deposits will form on the dishes and utensils.
The appliance is equipped with a special softener that uses a salt container
specifically designed to eliminate lime and minerals from the water.
LOADING THE SALT INTO THE SOFTENER
Always use salt intended for use with dishwashers.
The salt container is located beneath the lower basket and should be filled as
explained in the following:
ATTENTION!
- Only use salt specifically designed for the use in dishwashers! Every other type
of salt not specifically designed for the use in a dishwasher, especially table
salt, will damage the water softener. In case of damages caused by the use of
unsuitable salt the manufacturer does not give any warranty nor is liable for any
damages caused.
- Only fill with salt just before starting one of the complete washing programs.
This will prevent any grains of salt or salty water, which may have been spilled,
remaining on the bottom of the machine for any period of time, which may
cause corrosion.
1. The salt container must only be refilled when the salt warning light in the control panel comes on.
Depending on how well the salt dissolves, the salt warning light may still be on even though the salt
container is filled.
2. If there are spills of the salt, a soak or a rapid program should be run to remove the excessive salt.
Always use salt intended for use with dishwashers.
The salt container is located beneath the lower basket and should be filled as explained
in the following:
Attention!
Only use salt specifically designed for the use in dishwashers! Every other type of
salt not specifically designed for the use in a dishwasher, especially table salt, will
damage the water softener. In case of damages caused by the use of unsuitable
salt the manufacturer does not give any warranty nor is liable for any damages caused.
Only fill with salt just before starting one of the complete washing programs.
This will prevent any grains of salt or salty water, which may have been spilled,
remaining on the bottom of the machine for any period of time, which may cause
corrosion.
8
The rinse aid is released during the final rinse to prevent water from forming droplets on your dishes, which can
leave spots and streaks. It also improves drying by allowing water to roll off the dishes. Your dishwasher is
designed to use liquid rinse aids. The rinse aid dispenser is located inside the door next to the detergent dispenser.
To fill the dispenser, open the cap and pour the rinse aid into the dispenser until the level indicator turns completely
black. The volume of the rinse aid container is about 110ml.
Rinse Aid Dispenser
Function of Rinse Aid
Rinse aid is automatically added during the last rinse, ensuring thorough rinsing, and spot and streak free drying.
Attention!
Only use branded rinse aid for dishwasher. Never fill the rinse aid dispenser with any other substances
(e.g. Dishwasher cleaning agent, liquid detergent). This would damage the appliance.
A
B
C
D
E
After the lower basket has been removed, unscrew and remove the cap from the salt container.
Place the end of the funnel (supplied) into the hole and insert about 1.5kg of dishwasher salt.
Fill the salt container with water,It is normal for a small amount of water to come out of the salt
container.
After filling the container, screw the cap tightly back on, turning clockwise.
The salt warning light will turn off after the salt container has been filled with salt.
FImmediately after filling the salt into the salt container, a washing program should be started
program Otherwise the filter system, pump or other important parts of the machine may be damaged
by salty water.
(We suggest to use a short
).
1 2
Di651 Intergrated Dishwasher.indd 13 08/02/2017 12:59

Instruction manual Di651
Please keep this instruction manual for future reference
14
- After the lower basket has been removed, unscrew and remove the cap from the
salt container. (1)
- Place the end of the funnel (supplied) into the hole and insert about 1.5kg of
dishwasher salt.
- Fill the salt container with water,It is normal for a small amount of water to come
out of the salt container. (2)
- After filling the container, screw the cap tightly back on, turning clockwise.
- The salt warning light will turn off after the salt container has been filled with salt.
- Immediately after filling the salt into the salt container, a washing program should
be started. Otherwise the filter system, pump or other important parts of the
machine may be damaged by salty water.
NOTE:
1. The salt container must only be refilled when the salt warning light in the control
panel comes on. Depending on how well the salt dissolves, the salt warning light
may still be on even though the salt container is filled.
2. If there are spills of the salt, a soak or a rapid program should be run to remove
the excessive salt.
FILL THE RINSE AID DISPENSER
RINSE AID DISPENSER
The rinse aid is released during the final rinse to prevent water from forming
droplets on your dishes, which can leave spots and streaks. It also improves drying
by allowing water to roll off the dishes. Your dishwasher is designed to use liquid
rinse aids. The rinse aid dispenser is located inside the door next to the detergent
dispenser. To fill the dispenser, open the cap and pour the rinse aid into the
dispenser until the level indicator turns completely black. The volume of the rinse
aid container is about 110ml.
FUNCTION OF RINSE AID
Rinse aid is automatically added during the last rinse, ensuring thorough rinsing,
and spot and streak free drying.
ATTENTION!
Only use branded rinse aid for dishwasher. Never fill the rinse aid dispenser with
any other substances (e.g. Dishwasher cleaning agent, liquid detergent). This would
damage the appliance.
Di651 Intergrated Dishwasher.indd 14 08/02/2017 12:59

Instruction manual Di651
Please keep this instruction manual for future reference
15
WHEN TO REFILL THE RINSE AID DISPENSER
The rinse-aid warning light in the control panel will illuminate when the dispenser
needs re filling. You can also estimate the remaining amount from the colour of the
optical level indicator “C “located next to the cap. When the rinse-aid container
is full, the whole indicator will be dark. As the rinse-aid diminishes, the size of the
dark dot decreases. You should never let the rinse aid level fall 1 / 4 full.
As the rinse aid diminishes, the size of the black dot on the rinse aid level indicator
changes, as illustrated below:
Full
¾ full
½ full
¼ full - Should refill to eliminate spotting
Empty
C(Rinse-Aid indicator)
1 2 3
1. To open the dispenser, turn the cap to the “open” (left) arrow and lift it out
2. Pour the rinse aid into the dispenser, being careful not to overfill
3. Replace the cap by inserting it aligned with “open” arrow and turning it to the
closed (right) arrow.
NOTE:
Clean up any rinse aid spilled during filling with an absorbent cloth to avoid excessive
foaming during the next wash. Don’t forget to replace the cap before you close
dishwasher door.
Di651 Intergrated Dishwasher.indd 15 08/02/2017 12:59

Instruction manual Di651
Please keep this instruction manual for future reference
16
ADJUSTING RINSE AID DISPENSER
The rinse aid dispenser has six settings. Always
start with the dispenser set on “4”. If spots and
poor drying are a problem, increase the amount
of rinse aid dispensed by removing the dispenser
lid and rotating the dial to “5”. If the dishes still
are not drying properly or are show spots, adjust
the dial to the next higher lever until your dishes
are spot-free. The recommended setting is “4”.
(Factory value is “4”.)
NOTE:
Increase the dose if there are drops of water or lime spots on the dishes after
washing. Reduce it if there are sticky whitish stains on your dishes or a bluish film
on glassware or knife blades.
FUNCTION OF DETERGENT
Detergents with its chemical ingredients are necessary to remove dirt, crush dirt and
transport it out of the dishwasher. Most of the commercial quality detergents are
suitable for this purpose.
ATTENTION!
Proper Use of Detergent
Use only detergent specifically made for the use in dishwashers. Keep your
detergent fresh and dry. Don’t put powdered detergent into the dispenser until
you’re ready to wash dishes.
DETERGENTS
There are 3 sorts of detergents
1.With phosphate and with chlorine
2.With phosphate and without chlorine
3.Without phosphate and without chlorine
Adjust lever
(Rinse)
Di651 Intergrated Dishwasher.indd 16 08/02/2017 12:59

Instruction manual Di651
Please keep this instruction manual for future reference
17
Normally new pulverised detergent is without phosphate. Thus the water softener
function of phosphate is not given. In this case we recommend to fill salt in
the salt container even when the hardness of water is only 6 dH. If detergents
without phosphate are used in the case of hard water often white spots appear on
dishes and glasses. In this case please add more detergent to reach better results.
Detergents without chlorine do only bleach a little. Strong and coloured spots will
not be removed completely. In this case please choose a program with a higher
temperature.
CONCENTRATED DETERGENT
Based on their chemical composition, detergents can be split in two basic types:
- conventional, alkaline detergents with caustic components
- low alkaline concentrated detergents with natural enzymes
DETERGENT TABLETS
Detergent tablets of different brands dissolve at different speeds. For this reason
some detergent tablets cannot dissolve and develop their full cleaning power during
short programs. Therefore please use long programs when using detergent tablets,
to ensure the complete removal of detergent residuals.
DETERGENT DISPENSER
The dispenser must be refilled before the start of each wash cycle following the
instructions provided in the wash cycle table . Your dishwasher uses less detergent
and rinse aid than Conventional dishwashers. Generally, only one tablespoon of
detergent is needed for a normal wash load. More heavily soiled items need more
detergent. Always add the detergent just before starting the dishwasher, otherwise
it could get damp and will not dissolve properly.
AMOUNT OF DETERGENT TO USE
10
Based on their chemical composition, detergents can be split in two basic types:
Concentrated Detergent
Detergent Tablets
Detergent tablets of different brands dissolve at different speeds. For this reason some
detergent tablets cannot dissolve and develop their full cleaning power during short
programs. Therefore please use long programs when using detergent tablets, to
ensure the complete removal of detergent residuals.
Detergent Dispenser
The dispenser must be refilled before the start of each wash cycle following the instructions
provided in the wash cycle table . Your dishwasher uses less detergent and rinse aid than
Conventional dishwashers. Generally, only one tablespoon of detergent is needed for
a normal wash load. More heavily soiled items need more detergent. Always add the
detergent just before starting the dishwasher, otherwise it could get damp and will not
dissolve properly.
Amount of Detergent to Use
conventional, alkaline detergents with caustic components
low alkaline concentrated detergents with natural enzymes
Normally new pulverised detergent is without phosphate. Thus the water softener function of
phosphate is not given. In this case we recommend to fill salt in the salt container even when
the hardness of water is only 6 dH. If detergents without phosphate are used in the case of hard water
often white spots appear on dishes and glasses. In this case please add more detergent to reach
better results. Detergents without chlorine do only bleach a little. Strong and coloured spots will not
be removed completely. In this case please choose a program with a higher temperature.
°
Detergents
There are 3 sorts of detergents
1.With phosphate and with chlorine
2.With phosphate and without chlorine
3.Without phosphate and without chlorine
Always add the detergent just before starting each wash cycle.
Only use branded detergent aid for dishwasher.
If the lid is closed: press release button. The lid will spring open.
Dishwasher detergent is corrosive!
Take care to keep it out of reach of children.
Detergent tablet
Detergent powder
10
Based on their chemical composition, detergents can be split in two basic types:
Concentrated Detergent
Detergent Tablets
Detergent tablets of different brands dissolve at different speeds. For this reason some
detergent tablets cannot dissolve and develop their full cleaning power during short
programs. Therefore please use long programs when using detergent tablets, to
ensure the complete removal of detergent residuals.
Detergent Dispenser
The dispenser must be refilled before the start of each wash cycle following the instructions
provided in the wash cycle table . Your dishwasher uses less detergent and rinse aid than
Conventional dishwashers. Generally, only one tablespoon of detergent is needed for
a normal wash load. More heavily soiled items need more detergent. Always add the
detergent just before starting the dishwasher, otherwise it could get damp and will not
dissolve properly.
Amount of Detergent to Use
conventional, alkaline detergents with caustic components
low alkaline concentrated detergents with natural enzymes
Normally new pulverised detergent is without phosphate. Thus the water softener function of
phosphate is not given. In this case we recommend to fill salt in the salt container even when
the hardness of water is only 6 dH. If detergents without phosphate are used in the case of hard water
often white spots appear on dishes and glasses. In this case please add more detergent to reach
better results. Detergents without chlorine do only bleach a little. Strong and coloured spots will not
be removed completely. In this case please choose a program with a higher temperature.
°
Detergents
There are 3 sorts of detergents
1.With phosphate and with chlorine
2.With phosphate and without chlorine
3.Without phosphate and without chlorine
Always add the detergent just before starting each wash cycle.
Only use branded detergent aid for dishwasher.
If the lid is closed: press release button. The lid will spring open.
Dishwasher detergent is corrosive!
Take care to keep it out of reach of children.
Detergent tablet
Detergent powder
Di651 Intergrated Dishwasher.indd 17 08/02/2017 12:59

Instruction manual Di651
Please keep this instruction manual for future reference
18
NOTE:
- If the lid is closed: press release button. The lid will spring open
- Always add the detergent just before starting each wash cycle.
- Only use branded detergent aid for dishwasher.
WARNING:
Dishwasher detergent is corrosive!
Take care to keep it out of reach of children.
FILL THE DETERGENT DISPENSER
Fill the detergent dispenser with detergent. The marking indicates the dosing
levels, as illustrated on the right:
Please observe the manufacturers dosing and storage Recommendations as stated
on the detergent packaging.
Close the lid and press until it locks in place.
If the dishes are heavily soiled, place an additional detergent dose in the pre-wash
detergent chamber. This detergent will take effect during the pre-wash phase.
NOTE:
- You find information about the amount of detergent for the single programme on
the last page.
- Please aware, that according to the level soiling and the specific hardness of water
differences are possible.
- Please observe the manufacturer’s recommendations on the detergent packaging.
11
The place of main wash cycle detergent placed.
The place of pre-wash cycle detergent placed.
Please observe the manufacturers dosing and storage
Recommendations as stated on the detergent packaging.
Close the lid and press until it locks in place.
If the dishes are heavily soiled, place an additional
detergent dose in the pre-wash detergent chamber. This detergent will take effect during the pre-wash phase.
A
B
Fill the Detergent Dispenser
Fill the detergent dispenser with detergent. The marking
indicates the dosing levels , as illustrated on the right:
You find information about the amount of detergent for the single programme on the last page.
Please aware, that according to the level soiling and the specific hardness of water differences are possible.
Please observe the manufacturer's recommendations on the detergent packaging.
Close compartment;
Press down the lid (1) until it clicks
shut (2).
If you are using detergent in tablet form,
read the manufacturer recommendations
on the packaging in order to determine
where the tablets should be placed
inside the dishwasher (e.g. in cutlery
basket, detergent compartment, etc.).
Make sure that the lid on the detergent
compartment is closed, even if you are
using tablets.
If your dishes are only moderately dirty,
you may be able to use less detergent
than recommended.
Close the Detergent Dispenser
AThe place of main wash cycle detergent placed.
B The place of pre-wash cycle detergent placed
Di651 Intergrated Dishwasher.indd 18 08/02/2017 12:59

Instruction manual Di651
Please keep this instruction manual for future reference
19
CLOSE THE DETERGENT DISPENSER
If your dishes are only moderately dirty, you may be able to use less detergent than
recommended.
- Close compartment;
Press down the lid (1) until it clicks shut (2).
- If you are using detergent in tablet form, read the
manufacturer recommendations on the packaging
in order to determine where the tablets should be
placed inside the dishwasher (e.g. in cutlery basket,
detergent compartment, etc.). Make sure that the lid
on the detergent compartment is closed, even if you
are using tablets.
LOADING THE DISHWASHER BASKETS
RECOMMENDATION
- Consider buying utensils which are identified as dishwasher-proof.
- Use a mild detergent that is described as ‘kind to dishes’. If necessary, seek further
information from the detergent manufacturers.
- For particular items, select a program with as low a temperature as possible.
- To prevent damage, do not take glass and cutlery out of the dishwasher
immediately after the programme has ended.
THE FOLLOWING CUTLERY / DISHES:
ARE NOT SUITABLE
- Cutlery with wood, horn china or mother-of-pearl handles
- Plastic items that are not heat resistant
- Older cutlery with glued parts that are not temperature resistant
- Bonded cutlery items or dishes
- Pewter or copper items
- Crystal glass
- Steel items subject to rusting
- Wooden platters
- Items made from synthetic fibres
11
The place of main wash cycle detergent placed.
The place of pre-wash cycle detergent placed.
Please observe the manufacturers dosing and storage
Recommendations as stated on the detergent packaging.
Close the lid and press until it locks in place.
If the dishes are heavily soiled, place an additional
detergent dose in the pre-wash detergent chamber. This detergent will take effect during the pre-wash phase.
A
B
Fill the Detergent Dispenser
Fill the detergent dispenser with detergent. The marking
indicates the dosing levels , as illustrated on the right:
You find information about the amount of detergent for the single programme on the last page.
Please aware, that according to the level soiling and the specific hardness of water differences are possible.
Please observe the manufacturer's recommendations on the detergent packaging.
Close compartment;
Press down the lid (1) until it clicks
shut (2).
If you are using detergent in tablet form,
read the manufacturer recommendations
on the packaging in order to determine
where the tablets should be placed
inside the dishwasher (e.g. in cutlery
basket, detergent compartment, etc.).
Make sure that the lid on the detergent
compartment is closed, even if you are
using tablets.
If your dishes are only moderately dirty,
you may be able to use less detergent
than recommended.
Close the Detergent Dispenser
Di651 Intergrated Dishwasher.indd 19 08/02/2017 12:59

Instruction manual Di651
Please keep this instruction manual for future reference
20
ARE OF LIMITED SUITABILITY
- Some types of glasses can become dull after a large number of washes
- Silver and aluminum parts have a tendency to discolour during washing
- Glazed patterns may fade if machine washed frequently
BEFORE OR AFTER LOADING
THE DISHWASHER BASKET
(For best performance of the dishwasher, follow these loading guidelines. Features
and appearance of baskets and cutlery baskets may vary from your model.) Scrape
off any large amounts of leftover food. Soften remnants of burnt food in pans. It is
not necessary to rinse the dishes under running water.
Place objects in the dishwasher in following way:
1. Items such as cups, glasses, pots/pans, etc. are faced downwards.
2. Curved items, or ones with recesses, should be loaded aslant so that
water can run off.
3. All utensils are stacked securely and can not tip over.
4. All utensils are placed in the way that the spray arms can rotate
freely during washing.
NOTE: Very small items should not be washed in the dishwasher as they could
easily fall out of the basket.
- Load hollow items such as cups, glasses, pans etc. With the opening facing
downwards so that water cannot collect in the container or a deep base
- Dishes and items of cutlery must not lie inside one another, or cover each other.
- To avoid damage to glasses, they must not touch.
- Load large items which are most difficult to clean into the lower basket.
- The upper basket is designed to hold more delicate and lighter dishware such as
glasses, coffee and tea cups
- Long bladed knives stored in an upright position are a potential hazard!
- Long and/or sharp items of cutlery such as carving knives must be positioned
horizontally in the upper basket.
- Please do not overload your dishwasher. This is important for good results and for
reasonable consumption of energy.
Di651 Intergrated Dishwasher.indd 20 08/02/2017 12:59
