Caple CGI920/RED User manual
Island Hood
Instruction Manual
CGI920/RED
Contact Caple on 0117 938 7420 for spare parts or www.caple.co.uk
Instruction manual CGi920/RED
2Please keep this instruction manual for future reference
CONTENTS
Introduction 3
Safety Instructions 5
Installation 10
Operation 16
Care and Maintenance 17
Troubleshooting 18
Product Dimensions 19
Caple Contact Details 22
Instruction manual CGi920/RED 3
Please keep this instruction manual for future reference
INTRODUCTION
Thank you for choosing this Caple extractor hood.
To ensure that you get the best results from your new
extractor hood, we strongly suggest that you read this
instruction manual thoroughly before use. If treated with
care, your Caple product should give you years of trouble-
free use.
To register ownership, please ensure you complete and
return the guarantee card supplied with the appliance or
visit www.caple.co.uk and register here.
This instruction manual is designed to provide you with
all the required information related to the installation, use
and maintenance of the appliance.
This island extractor is designed to extract unpleasant
odours and cooking vapours from the kitchen. In order
to operate the unit correctly and safely, please read this
instruction manual carefully before installation and use.
Please read this manual carefully before using your
appliance. It contains important safety advice; it explains
how to use and look after your appliance so that it will
provide you with many years of reliable service.
Should a fault arise, please first consult the
“Troubleshooting” section. You can often rectify minor
problems yourself, thus saving unnecessary service costs.
Please keep this manual in a safe place and pass it on to
new owners for their information and safety.
Instruction manual CGi920/RED
4Please keep this instruction manual for future reference
IMPORTANT:
This appliance must only be used for the purpose it is
intended. Other types of use are not permitted and may
prove dangerous. Caple will not be held liable for any
damage caused by the incorrect use of the appliance.
Do not use any accessories or attachments not
recommended by Caple as this may result in fire, electric
shock or injury.
To protect against fire, electrical shock and injury to
persons, do not immerse cords or plugs in water or any other
liquid.
Never touch the appliance with wet or damp hands.
Never pull the power cable as you could damage it. If the
appliance is faulty, do not attempt to repair it. Isolate it from
the mains electric supply and contact Caple Service either by
phone 0117 938 7420 or email service@caple.co.uk
Keep all packaging (including plastic bags, polystyrene foam
etc) out of the reach and away from children.
Do not rest large or unstable objects on any part of
the appliance.
Instruction manual CGi920/RED 5
Please keep this instruction manual for future reference
IMPORTANT
Caple cannot be held responsible for injuries or losses caused
by incorrect use or installation of this product. Please note
that Caple reserve the right to invalidate the guarantee
supplied with this product following incorrect installation
or misuse of the appliance. Under no circumstances should
any external covers be removed for servicing or maintenance
except by suitably
qualified personnel.
SAFETY INSTRUCTIONS
-Never let children operate the machine.
-The cooker hood is for home use only, not suitable for
barbecuing, restaurants or other commercial purposes.
-The cooker hood and its filter should be cleaned regularly
in order to keep in good working condition.
-Clean the cooker hood according to the instruction
manual to reduce the risk of fire.
-When using a gas hob, do not leave naked flames under
the extractor.
-Before connecting this appliance check that the power
supply cord is not damaged.
Instruction manual CGi920/RED
6Please keep this instruction manual for future reference
-If the room where the hood is to be used contains a fuel
burning appliance such as a central heating boiler then
its flue must be of the sealed or balanced flue type. If
other types of flue or appliances are fitted ensure that
there is an adequate supply of air to the room.
-The air must not be discharged into a flue that is used
for exhausting fumes from appliances burning gas or
other fuels.
-Regulations concerning the discharge of air have to be
conformed to.
-Do not flambé under the cooker hood.
-Never leave frying pans unattended during use as over-
heated fats and oils may catch fire.
-To ensure the best performance, we recommend
switching on the extractor 15 minutes before cooking
and leave it running 15 minutes after. This will ensure
that the air in the kitchen is being circulated before
cooking commences and the air is being cleaned after
cooking has finished.
-The performance of your extractor will vary depending
on a number of factors. These include type of extraction,
room volume, length of ducting, ventilation available and
the cleanliness of the filters.
Instruction manual CGi920/RED 7
Please keep this instruction manual for future reference
-This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.
-Children should be supervised to ensure that they do not
play with the appliance.
-Cleaning and user maintenance must not be made by
children without supervision.
-Never immerse the appliance in water.
-To avoid all risk, if the power cable is damaged, it must
only be replaced by a Caple appointed engineer.
-Appliances can be used by persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning use of the
appliance in a safe way and understand the
hazards involved.
-Children must not play with this appliance.
-When not in use and before cleaning, always isolate the
appliance from the electrical supply.
Instruction manual CGi920/RED
8Please keep this instruction manual for future reference
WARNING
-Only plug this unit into a properly earthed outlet. If in
doubt seek advice from a suitably qualified engineer.
-Failure to follow these instructions can result in death,
fire, or electrical shock.
-This appliance must be connected to the mains by a
competent person. We recommend that the appliance is
connected by a qualified electrician who is a member of
the N.I.C.E.I.C who will comply with the I.E.E and local
regulations. Electrical information can be found on the
rating plate.
APPROPRIATE USE:
-This appliance is intended to be used in household and
similar applications such as:
› Staff kitchen areas in shops, offices and other
working environments.
› Farm Houses.
› By clients in hotels, motels and other residential
type environments.
› Bed and breakfast type environments.
Instruction manual CGi920/RED 9
Please keep this instruction manual for future reference
ENVIRONMENTAL PROTECTION
Waste electrical products should not be disposed of with household waste. Please recycle
where facilities exist. Check with your Local Authority or retailer for recycling advice. This
appliance is marked according to the European directive on Waste Electrical and Electronic
Equipment (WEEE).
By ensuring this product is disposed of correctly, you will help prevent potential negative
consequences for the environment and human health, which could otherwise be caused
by inappropriate waste handling of this product. The symbol on the product indicates that
this product may not be treated as household waste. Instead it shall be handed over to the
applicable collection point for the recycling of electrical and electronic equipment. Disposal
must be carried out in accordance with local environmental regulations for waste disposal.
For more detailed information about treatment, recovery and recycling of this product, please
contact your local council, your household waste disposal service or the retailer where you
purchased the product.
WARRANTY
Your new appliance is covered by warranty. The warranty card is enclosed - if it is missing, you
must provide the following information to your retailer in order to receive a replacement: date
of purchase, model and serial number. Registration can also be completed online by visiting
www.caple.co.uk.
Ensure you keep your warranty card safe, you may need to show it to Caple Service together
with proof of purchase. If you fail to show your warranty card you will incur all repair charges.
Spare parts are only available from Caple Service and spare parts authorised centres.
CE DECLARATIONS OF CONFORMITY
This appliance has been manufactured to the strictest standards and complies with all
applicable legislation, Low Voltage Directive (LVD) and Electromagnetic Compatibility (EMC).
UKCA DECLARATIONS OF CONFORMITY
This appliance has been manufactured to the strictest standards and complies with all
applicable legislation.
TECHNICAL FICHE
This appliance conforms to all current and applicable energy regulations. To view the Technical
Fiche that supports the energy labelling data, please visit the product page on our
website www.caple.co.uk
Instruction manual CGi920/RED
10 Please keep this instruction manual for future reference
INSTALLATION
PREPARE FOR THE INSTALLATION:
If you have an outlet to the outside, your cooker hood can be connected
as per the below picture by means of an extraction duct with an interior
diameter of 150mm.
Before installation, turn the unit off and unplug it from the outlet.
The cooker hood should be placed at a minimum distance of 65-76cm
above the hob. It is the manufacturer of the hob who determines the
clearance required and the clearance quoted by the hob manufacturer
must be followed. In the absence of any instructions supplied with a gas
hob the minimum distance between the hob and the hood must be
at least 760mm.
4
4
Earthed Outlet Box
Earthed Plug
Earthed Outlet
4
4
Instruction manual CGi920/RED 11
Please keep this instruction manual for future reference
INSTALLATION – DUCTED
WARNING:
Observe the warning concerning the operation of the appliance when air is discharged from
the room.
1. Position the hanging plate on the ceiling and then mark the position of the screw holes. The
hanging plate should be securely fixed to the ceiling.
11 x ST6 (40mm) screws for wooden ceiling
8 x expansion bolts for cement ceiling.
2. Fix the angle bars to the hanging plate, using the 8 x M5 screws.
3. Extend the angle bars to the required height and then fix them in position using the 16 x M5
screws and nuts with metal washers.
IMPORTANT:
The angle bars must have an overlap of at least 100mm.
4. If your cooker hood is going to be externally ventilated,
then you should connect the ducting hose to the ceiling
adaptor at this point. Fix the upper chimney section to the
hanging plate, using the 4 x self tapping screws.
Slide the lower chimney section onto the angle bars and
raise it until it sits just below the upper chimney section.
Instruction manual CGi920/RED 11
Please keep this instruction manual for future reference
INSTALLATION – DUCTED
WARNING:
Observe the warning concerning the operation of the appliance when air is discharged from
the room.
1. Position the hanging plate on the ceiling and then mark the position of the screw holes. The
hanging plate should be securely fixed to the ceiling.
11 x ST6 (40mm) screws for wooden ceiling
8 x expansion bolts for cement ceiling.
2. Fix the angle bars to the hanging plate, using the 8 x M5 screws.
3. Extend the angle bars to the required height and then fix them in position using the 16 x M5
screws and nuts with metal washers.
IMPORTANT:
The angle bars must have an overlap of at least 100mm.
4. If your cooker hood is going to be externally ventilated,
then you should connect the ducting hose to the ceiling
adaptor at this point. Fix the upper chimney section to the
hanging plate, using the 4 x self tapping screws.
Slide the lower chimney section onto the angle bars and
raise it until it sits just below the upper chimney section.
5
.
5
.
6
4) If your cooker hood is going to be externally ventilated, then you should
connect the ducting hose to the ceiling adaptor at this point.
Fix the upper chimney section to the hanging plate, using the 4 x self tapping
screws.
Instruction manual CGi920/RED 11
Please keep this instruction manual for future reference
INSTALLATION – DUCTED
WARNING:
Observe the warning concerning the operation of the appliance when air is discharged from
the room.
1. Position the hanging plate on the ceiling and then mark the position of the screw holes. The
hanging plate should be securely fixed to the ceiling.
11 x ST6 (40mm) screws for wooden ceiling
8 x expansion bolts for cement ceiling.
2. Fix the angle bars to the hanging plate, using the 8 x M5 screws.
3. Extend the angle bars to the required height and then fix them in position using the 16 x M5
screws and nuts with metal washers.
IMPORTANT:
The angle bars must have an overlap of at least 100mm.
4. If your cooker hood is going to be externally ventilated,
then you should connect the ducting hose to the ceiling
adaptor at this point. Fix the upper chimney section to the
hanging plate, using the 4 x self tapping screws.
Slide the lower chimney section onto the angle bars and
raise it until it sits just below the upper chimney section.
5
.
5
.
6
4) If your cooker hood is going to be externally ventilated, then you should
connect the ducting hose to the ceiling adaptor at this point.
Fix the upper chimney section to the hanging plate, using the 4 x self tapping
screws.
Instruction manual CGi920/RED 11
Please keep this instruction manual for future reference
INSTALLATION – DUCTED
WARNING:
Observe the warning concerning the operation of the appliance when air is discharged from
the room.
1. Position the hanging plate on the ceiling and then mark the position of the screw holes. The
hanging plate should be securely fixed to the ceiling.
11 x ST6 (40mm) screws for wooden ceiling
8 x expansion bolts for cement ceiling.
2. Fix the angle bars to the hanging plate, using the 8 x M5 screws.
3. Extend the angle bars to the required height and then fix them in position using the 16 x M5
screws and nuts with metal washers.
IMPORTANT:
The angle bars must have an overlap of at least 100mm.
4. If your cooker hood is going to be externally ventilated,
then you should connect the ducting hose to the ceiling
adaptor at this point. Fix the upper chimney section to the
hanging plate, using the 4 x self tapping screws.
Slide the lower chimney section onto the angle bars and
raise it until it sits just below the upper chimney section.
5
.
5
.
6
4) If your cooker hood is going to be externally ventilated, then you should
connect the ducting hose to the ceiling adaptor at this point.
Fix the upper chimney section to the hanging plate, using the 4 x self tapping
screws.
Instruction manual CGi920/RED
12 Please keep this instruction manual for future reference
5. If the glass canopy has not been pre-assembled at the factory, then it should be fixed to the
top of the main body of the cooker hood at this stage.
6. Lift the main body of the cooker hood onto the angle bars and then fix it into position using
the 16 x M5 screws.
IMPORTANT:
This stage of the installation process MUST be completed by two people.
The 16 x M5 screws MUST be securely tightened.
7. If you are using the hood in ducted / ventilation mode, you should fix the ducting hose to
the ceiling.
Instruction manual CGi920/RED
12 Please keep this instruction manual for future reference
5. If the glass canopy has not been pre-assembled at the factory, then it should be fixed to the
top of the main body of the cooker hood at this stage.
6. Lift the main body of the cooker hood onto the angle bars and then fix it into position using
the 16 x M5 screws.
IMPORTANT:
This stage of the installation process MUST be completed by two people.
The 16 x M5 screws MUST be securely tightened.
7. If you are using the hood in ducted / ventilation mode, you should fix the ducting hose to
the ceiling.
6
4) If your cooker hood is going to be externally ventilated, then you should
connect the ducting hose to the ceiling adaptor at this point.
Fix the upper chimney section to the hanging plate, using the 4 x self tapping
screws.
7
7) If you are using the hood in ducted / ventilation mode, you should fix
the ducting hose to the ceiling.
Instruction manual CGi920/RED
12 Please keep this instruction manual for future reference
5. If the glass canopy has not been pre-assembled at the factory, then it should be fixed to the
top of the main body of the cooker hood at this stage.
6. Lift the main body of the cooker hood onto the angle bars and then fix it into position using
the 16 x M5 screws.
IMPORTANT:
This stage of the installation process MUST be completed by two people.
The 16 x M5 screws MUST be securely tightened.
7. If you are using the hood in ducted / ventilation mode, you should fix the ducting hose to
the ceiling.
6
4) If your cooker hood is going to be externally ventilated, then you should
connect the ducting hose to the ceiling adaptor at this point.
Fix the upper chimney section to the hanging plate, using the 4 x self tapping
screws.
7
7) If you are using the hood in ducted / ventilation mode, you should fix
the ducting hose to the ceiling.
Instruction manual CGi920/RED 13
Please keep this instruction manual for future reference
› The electrical connection must correspond to the electrical requirement noted on the rating
plate, which is placed inside the cooker hood. The appliance should now be connected to the
electrical supply.
› Check that the appliance is operating correctly by selecting each speed and switching the
light bulbs on and off.
› Remove the hanging hook and then slide the lower chimney section downwards, until it
rests against the main body of the cooker hood.
› Use a stainless steel cleaner and polish on the stainless steel sections of the appliance.
› If you are using the appliance in recirculation mode, then you should now fit the charcoal
filter. See the “fitting the charcoal filter” section on page 14.
› Fix the one-way-valve to the air outlet of the cooker hood. Then, attach the exhaust pipe
onto the one-way-valve as shown below.
Exhaust Pipe
Cooker Hood
Exhaust Pipe
Cooker Hood
Instruction manual CGi920/RED
14 Please keep this instruction manual for future reference
INSTALLATION – RECIRCULATION MODE
If you do not have an outlet to the outside, the exhaust pipe is not required (as shown in the
section “Installation - ducted”), and charcoal filters must be installed.
8
, and
charcoal filters must be installed.
Instruction manual CGi920/RED 15
Please keep this instruction manual for future reference
9
(CAP61CF)
We recommend replacing these filters every 6 months. Replacement
filters (CAP61CF) can be purchased directly from www.caple.co.uk
9
(CAP61CF)
We recommend replacing these filters every 6 months. Replacement
filters (CAP61CF) can be purchased directly from www.caple.co.uk
INSTALLING THE CHARCOAL FILTER (CAP61CF)
An activated charcoal filter can be used to trap odours. In order to install the charcoal filter, the
grease filter should be detached first. Press the release button and pull it downward as
shown below.
Fit the activated charcoal filter onto the side of the motor and turn it in a clockwise direction to
lock into place. Repeat the same on the other side.
Scan the QR Code to access the ‘How To’ video.
NOTE:
Make sure the filter is securely locked. Otherwise, it may loosen and be dangerous.
When using a charcoal filter, the extraction power may be slightly reduced.
We recommend replacing these filters every 6 months. Replacement filters (CAP61CF) can be
purchased directly from www.caple.co.uk
Instruction manual CGi920/RED
16 Please keep this instruction manual for future reference
OPERATION - TOUCH CONTROL
OFF BUTTON
Switches off the extraction fan.
LOW SPEED BUTTON
Is suitable for simmering and cooking which does not produce much steam or odour.
MEDIUM SPEED BUTTON
Airflow speed is ideal for extracting with standard cooking.
HIGH SPEED BUTTON
When a high amount of steam or odours are produced, use the high speed setting for the
most effective extraction.
LIGHT BUTTON
Switches the light on and off.
IInnssttrruuccttiioonn mmaannuuaall CCGGII992200//RREEDD
Please keep this instruction manual for future reference
15
OPERATION
Off button
Switches the extraction fan off.
Low Speed button
Is suitable for simmering and cooking which does not produce much odour.
Medium Speed button
Airflow speed is ideal for extracting with standard cooking.
High Speed button
When a high amount of smoke or odour is produced, press the high speed
button for the most effective extraction.
Light button
Switches the light on and off.
10
10
10
10
10
10
IInnssttrruuccttiioonn mmaannuuaall CCGGII992200//RREEDD
Please keep this instruction manual for future reference
15
OPERATION
Off button
Switches the extraction fan off.
Low Speed button
Is suitable for simmering and cooking which does not produce much odour.
Medium Speed button
Airflow speed is ideal for extracting with standard cooking.
High Speed button
When a high amount of smoke or odour is produced, press the high speed
button for the most effective extraction.
Light button
Switches the light on and off.
10
10
10
10
10
10
IInnssttrruuccttiioonn mmaannuuaall CCGGII992200//RREEDD
Please keep this instruction manual for future reference
15
OPERATION
Off button
Switches the extraction fan off.
Low Speed button
Is suitable for simmering and cooking which does not produce much odour.
Medium Speed button
Airflow speed is ideal for extracting with standard cooking.
High Speed button
When a high amount of smoke or odour is produced, press the high speed
button for the most effective extraction.
Light button
Switches the light on and off.
10
10
10
10
10
10
IInnssttrruuccttiioonn mmaannuuaall CCGGII992200//RREEDD
Please keep this instruction manual for future reference
15
OPERATION
Off button
Switches the extraction fan off.
Low Speed button
Is suitable for simmering and cooking which does not produce much odour.
Medium Speed button
Airflow speed is ideal for extracting with standard cooking.
High Speed button
When a high amount of smoke or odour is produced, press the high speed
button for the most effective extraction.
Light button
Switches the light on and off.
10
10
10
10
10
10
IInnssttrruuccttiioonn mmaannuuaall CCGGII992200//RREEDD
Please keep this instruction manual for future reference
15
OPERATION
Off button
Switches the extraction fan off.
Low Speed button
Is suitable for simmering and cooking which does not produce much odour.
Medium Speed button
Airflow speed is ideal for extracting with standard cooking.
High Speed button
When a high amount of smoke or odour is produced, press the high speed
button for the most effective extraction.
Light button
Switches the light on and off.
10
10
10
10
10
10
Instruction manual CGi920/RED 17
Please keep this instruction manual for future reference
CARE AND MAINTENANCE
IMPORTANT:
Before cleaning or maintenance please switch off the electricity supply and remove the plug from
the wall.
REGULAR CLEANING
Use a soft damp cloth with lukewarm mildly soapy water or household cleaning detergent. Never
use metal pads, chemicals, abrasive material, abrasive cleaning creams or stiff brushes to clean
the appliance.
CLEANING THE GREASE FILTER
Clean the filter every month to help minimise the risk of fire. The filter collects grease, smoke and
dust, therefore the filter is directly affecting the efficiency of the cooker hood. If not cleaned, the
grease residue (which is potentially flammable) will saturate the filter. It can be easily cleaned with
warm water and washing up liquid, alternatively the filters can be cleaned in your dishwasher.
Please ensure no other items are washed with the filters, they must be washed separately to
prevent food becoming trapped in the gauze. Cleaning the grease filters in the dishwasher may
lead to discolouration, this is normal and is a not a fault with the product.
REPLACING YOUR CHARCOAL FILTER
This only applies if you are using the hood in recirculation mode (not vented to the outside). The
charcoal filter traps your cooking odours and they need to be replaced, this can vary depending on
how frequently the cooker hood is used. We recommend replacing them at least every 6 months.
This extractor uses CAP61CF charcoal filters. Filters can be purchased directly
from www.caple.co.uk.
REPLACING THE BULB
1. Switch the unit off and unplug the appliance.
2. Remove the lamp cover by unscrewing the 2 screws.
3. Replace with the same type and rated bulb/lamp fixing.
LED lamp (max.1.5W).
NOTE:
The lights must be replaced by a qualified person.
12
119 938 7420
Instruction manual CGi920/RED
18 Please keep this instruction manual for future reference
TROUBLESHOOTING
If the above table has not solved the problem please contact Caple Service by phone on
0117 938 7420 or by email service@caple.co.uk
FAULT CAUSE SOLUTION
The lights on, but the fan
does not work
The fan blade is jammed
Switch off the unit and contact Caple Service. To
be repaired by qualified service personnel only.
The motor is damaged
The lights and fan do
not work
A blown fuse Replace the fuse.
The power cord is loose Plug in to the power supply again.
Serious vibration of the unit
The fan blade is damaged Switch off the unit and contact Caple Service. To
be repaired by qualified service personnel only.
The fan motor is not fixed tightly Switch off the unit and contact Caple Service. To
be repaired by qualified service personnel only.
The unit is not hung correctly on the
bracket
Take down the unit and check whether the
bracket is in the correct location.
The extraction performance
is not good
The filter requires cleaning Clean the grease filter as directed in the ‘Care
and maintenance’ section. Replace the charcoal
filter (if in recirculation mode).
Instruction manual CGi920/RED 19
Please keep this instruction manual for future reference
PRODUCT DIMENSIONS
CGI920/RED
DIMENSIONS
600mm
297.5mm
900mm
327.5mm
92mm
600-910mm
NOTE;
Suitable to be installed in a standard room height of 2.3m.
Instruction manual CGi920/RED
20 Please keep this instruction manual for future reference
NOTES:
Table of contents
Other Caple Ventilation Hood manuals
Caple
Caple AS600BK User manual
Caple
Caple Tela TEL900 User manual
Caple
Caple D911BK User manual
Caple
Caple DD925CO User manual
Caple
Caple Zi900SS Technical manual
Caple
Caple SP610 User manual
Caple
Caple 1MBUCH2 User manual
Caple
Caple DD520BK User manual
Caple
Caple CGC710BK Manual
Caple
Caple ST523 User manual
Caple
Caple ST520SS User manual
Caple
Caple 2MINCH8 User manual
Caple
Caple Orbit OI363 User manual
Caple
Caple CE1000 User manual
Caple
Caple 1MBUCH3 User manual
Caple
Caple Vela VEL410BK User manual
Caple
Caple BUCH User manual
Caple
Caple COR540SL User manual
Caple
Caple CCH600 User manual
Caple
Caple DD910BK User manual
Popular Ventilation Hood manuals by other brands
AEG
AEG DD 8765 OPERATING AND INSTALLATION Manual
Siemens
Siemens LC479650UC use and care manual
CNP INDUSTRIES
CNP INDUSTRIES Wind Crest WCG300S Use, care and installation guide
ELICA
ELICA WAVE BK/F/51 Instruction on mounting and use
Electrolux
Electrolux LFP616X user manual
Pelgrim
Pelgrim OSW1080RVS/P01 Instructions for use
