Capri Tools CP21084-2PK User manual

CAPACITY:1500 LBS PER JACK
1. Place the jack on the floor and press down on the pedal to release
the pedal lock. Pull out the lock pin from the frame.
2. Before operating , release valve by turning hand-wheel count-
er-clowise. Expand the jack by hand. Place it around the tire and
position it so that both rollers contact the tire tread. To obtain the
best control over the jack, place your left hand on top of the left
side axle and your right hand at the center of the pedal. Close the
release valve by turning the hand- wheel clockwise to a snug-tight
position. The jack may now be used.
3. Install the jack so that the unit is parallel to the sidewall of the tire to
be lifted. Leave approximately 3/4’’ of clearance between the tire
and the jack. This is very important. If the unit is misaligned, it is
possible that the tire will be forced to hit the axle of the jack and
not the rollers, this may damage the jack and void the warranty.
4. To lift the tire , flip the directional lever up and place your foot on
the pedal , depressing with smooth, even strokes. Cycle the pedal
until the tire is lifted from the surface one inch or less. After lifting,
the lower the tire is to the ground the more stable the jack will be.
After lifting, be sure to always lock the pin in place before operat-
ing. Repeat this process on the other tires and maneuver the
vechicle as desired.
5. To release the jack, pull the pin out from the frame and open the
valve by turning the handwheel counterclockwise slowly. The jack
may be removed once the rollers are disengaged from the tire.
© Capri Tools [phone] | [email protected]www.capritools.com
Introduction
This Capri Tools® product includes a limited one year
warranty against defects from workmanship and
materials. This does not cover abuse, misuse or
regular wear and tear. For additional information,
contact us at: [phone] or email us at:
[email protected].
Warranty
1. DO NOT operate the jack on inclined surfaces . It must be used on
level surfaces only. Unanticipated motion will occur as soon as Jack
lifts tire from surface.
2. DO NOT load the jack with more than 1500lbs per unit.
3. DO NOT start the vehicle’s engine or drive while the jack is in use.
Jacks are designed for manually maneuvering vehicles only.
4. DO NOT use the jack to lift tires wider than 9 inches.
5. DO NOT attempt to push the jack over obstacles. It is designed to
be used on level and reasonably smooth surfaces only.
6. After lifting, be sure to always lock the pin in place before operating.
Pull the pin out after finishing work and then release the valve.
Contact our customer service for product support
and assistance.
We are here to help.
Questions, problems?
Contact Us
[e-mail]
[phone]
www.capritools.com
WARNING!
Read all instructions and warnings before attempting to
operate this jack.

© Capri Tools [phone] | [email protected]www.capritools.com
HYDRAULIC VEHICLE POSITIONING JACK
PART LIST
Ref#
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
QTY
1
1
1
1
4
2
8
4
4
1
1
4
4
4
1
1
1
1
1
3
1
1
1
1
1
1
1
1
1
1
Descripon
Ram Assembly
Bolt M16x115
Flat Washer ø16
Nut M16
Roller Raceway
Roller
Raceway Lock Screw
Lock Nut M12
4” Swivel Caster
Le Frame
Lock Pin with Chain
Screw M6x20
Lock Washer ø6
Flat Washer ø6
Right Frame
Hook
Washer for Hook
Nut for Hook
Foot Pedal
Pedal Pin ø8x28
Connecting Rod
Connecting Bolt
Spring Cover
Flat Washer
Spring
Pump
Pump Core
O-Ring
Back-up Ring
Screw M10x1.25
Ref#
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
QTY
1
3
1
1
1
2
1
1
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
Descripon
Small Spring
Steel Ball ø6
Cylinder Copper Washer
Ram Base
Copper Washer
Screw M5
Steel Ball ø5
Rectangle Seal Ring
Release Valve
Tank Washer
Ram
Cylinder
Oil-plug
Tank
Y-Ring
Piston
Piston O-Ring
Bowl Seal Ring
Tank Nut
Steel Ball ø6
Steel Ball Seat
Safety Valve Spring
Safety Valve Screw
O-Ring
Screw
