Capstan Turf Sprayer Edition SharpShooter With Rate... Installation instructions

SERVICE CONTACT INFORMATION
If a problem arises with the SSRS Turf System that cannot be corrected with the information in this manual, please
contact your dealer for service and technical assistance. If further assistance is needed, contact Capstan Ag Systems,
Inc.
NOTE: This document and the information provided are the property of Capstan Ag Systems, Inc. and may
only be used as authorized by Capstan Ag Systems, Inc.
FACTORY SERVICE / REPAIRS
Capstan Ag Systems, Inc.
4225 S.W. Kirklawn Ave.
Topeka, KS 66609
E-mail: [e-mail]
Toll-free number: [phone]
Topeka Office Fax: [phone]
Hours: 8:00 a.m. to 4:00 p.m. CST
Dealer:
Contact:
Phone:
Address:
City / State / Zip:
On-Line
Capstan Ag Systems, Inc
4225 S.W. Kirklawn Ave.
Topeka, KS 66609
Topeka Office Phone: [phone]
Topeka Office Fax: [phone]
[email protected]
Headquarters
www.CapstanAg.com

1


Contents
SharpShooter®with Rate Sync®- Turf Sprayer Edition
©2003, 2011, 2015 Capstan Ag Systems, Inc., All Rights Reserved | Version: P-3.0 | 6/9/2016
CONTENTS
1.0 INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.0 - SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.1 - Hazard Communications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.2 - Signal Words . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.3 - Definitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.4 - Conformance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.5 - HCS Pictograms and GHS Safety Labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.6 - Hazardous Energy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.7 - Chemical Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.8 - Unsafe Equipment Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.9 - Battery Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.10 - Extinguishing Fires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.0 - PARTS IDENTIFICATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.1 - SharpShooter with Rate Sync (SSRS Display) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.2 - Extension Harness, SSRS Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.3 - Power Hub . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.4 - Left Boom Harness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3.5 - Right Boom Harness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3.6 - Valve Driver Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3.7- Pressure Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3.8 - Extension Harness, Pressure Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3.9 - Power Harness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3.10 - Boom Shutoff Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
3.11 - Y-Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
3.12 - Battery Power Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
3.13 - Electrical Connector Dust Plugs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
3.14 - Nozzle Valve Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
3.15 - Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
3.16 - Wilger Nozzle Bodies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
3.17 - Hypro Dry Boom Adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
3.18 - Pressure Sensor Breakout Harness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
3.19 - SharpShooter with Rate Sync Turf Sprayer Edition Operator and Maintenance Manual
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
3.20 - Original Equipment Manufacturer Kits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
3.21 - Capstan Parts Support - Non Kit Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
4.0 - OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
4.1 - SSRS Operation Objectives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
4.2 - SSRS Display Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
4.2.1 - SSRS Display Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
5.0 - CONTROL FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
5.1 - Specific Menu Items . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

2
Contents
SharpShooter®with Rate Sync®- Turf Sprayer Edition
©2003, 2011, 2015 Capstan Ag Systems, Inc., All Rights Reserved | Version: P-3.0 | 6/9/2016
6.0 - EMERGENCY SPRAYING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
6.1 - Emergency Modes of Spraying . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
7.0 - TIP SELECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
7.1 - Tip Selection and Capacities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
8.0 - MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
8.1 - Strainers and Screens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
8.2 - Jump-Starting/Welding/Charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
8.3 - Servicing the Spray System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
8.4 - Inspecting the Spray System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
8.5 - Cleaning the Spray System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
8.6 - Product Tank and Boom Line Rinsing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
8.7 - Winterizing for Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
9.0 - TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
9.1 - Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
9.1.1 - SharpShooter with Rate Sync (SSRS Display) Data Logging Procedure . . . . . . . . . 47
9.1.2- SharpShooter with Rate Sync (SSRS Display) Programming . . . . . . . . . . . . . . . . . . 48
9.2 - SYSTEM TESTING AND TUNING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
9.2.1 - Recommended Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
9.2.2 - Baseline Evaluation Protocol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
9.3 - TROUBLESHOOTING TESTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
9.3.1 - SharpShooter with Rate Sync Dry Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
9.3.2 - SSRS Menu Items . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
9.3.3 - Boom Section Control Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
9.3.4 - Wet Test 1 Flow Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
9.3.5 - Wet Test Pressure Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
9.3.6 - Wet Test 3 Integrated Pressure and Flow Control . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
9.3.7 - Wet Test 4 Immediate ON/OFF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
9.3.8 - Wet Test 5 Rate Optimization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
9.4 - SWAPPING COMPONENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
9.5 - COMPONENT EVALUATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
9.5.1 - Fuses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
9.5.1.1 - OEM Turf SharpShooter System Fuse Location . . . . . . . . . . . . . . . . . . . . . . . . . . 62
9.5.1.2 - Turf Aftermarket Systems (Outside of SharpShooter) Fuse Location . . . . . . . . . . 62
9.5.2 - Nozzle Valves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
9.5.3 - Nozzle Valve Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
9.5.4 - Plunger Seal Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
9.5.5 - Coil Failure Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
9.5.6 - Battery Voltage Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
9.5.7 - System Load Capacity Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
9.5.8 - Valve Driver Voltage Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
9.5.9 - Pressure Sensor Signal Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

3


Contents
SharpShooter®with Rate Sync®- Turf Sprayer Edition
©2003, 2011, 2015 Capstan Ag Systems, Inc., All Rights Reserved | Version: P-3.0 | 6/9/2016
9.5.10 - Pressure Sensor Input Power Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
9.5.11 - Pulse Circuit Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
9.5.12 - Valve Driver Output Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
9.5.13 - Valve Driver Input Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
9.5.14 - Boom Section Run / Hold Signal Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
9.5.15 - Boom Section Shutoff Signal Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
9.6 - SYMPTOM ANALYSIS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
9.7 - TECHNICAL BULLETIN - JULY 11, 2001 (REVISED APRIL 12, 2006) . . . . . . . . . . . . . . 77
10.0 - WARRANTY POLICY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
11.0 - KIT SMITHCO 118600-230, 9-NOZZLE, 9-SECTION, (1-1-1-1-1-1-1-1-1), 15’ BOOM,
TURF SSRS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
11.1 - Power Hub, 9-Nozzle, 3-Section, Boom 4, 5, 6 - P/N118600-250 . . . . . . . . . . . . . . . 82
11.2- LH Boom Harness, 9-Nozzle, 3-Section, Boom 1, 2, 3 - P/N118600-251 . . . . . . . . . . 83
11.3 - RH Boom Harness, 9-Nozzle, 3-Section, Boom 7, 8, 9 - P/N118600-252 . . . . . . . . . 83
11.4 - Extension Harness, SSRS Display, PN118600-110 . . . . . . . . . . . . . . . . . . . . . . . . . . 84
11.5 - Power Harness, PN118600-107 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
11.6 - Extension Harness, Pressure Sensor, PN118600-108 . . . . . . . . . . . . . . . . . . . . . . . . 84
11.7 - Boom Shutoff Adapter, 9-Nozzle, 9-Section, PN118602-129 . . . . . . . . . . . . . . . . . . . 85
12.0 - KIT SMITHCO 118600-226, 11-NOZZLE, 10-SECTION, (1-1-1-1-1-2-1-1-1-1), 18’ BOOM,
TURF SSRS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
12.1 - Power Hub, 11-Nozzle, 3-Section, Boom 5, 6, 7 - P/N118600-253 . . . . . . . . . . . . . . 88
12.2 - LH Boom Harness, 11-Nozzle, 3-Section, Boom 1, 2, 3, 4 - P/N118600-254 . . . . . . 89
12.3 - RH Boom Harness, 11-Nozzle, 3-Section, Boom 8, 9, 10, 11 - P/N118600-255 . . . . 89
12.4 - Extension Harness, SSRS Display, PN118600-110 . . . . . . . . . . . . . . . . . . . . . . . . . . 90
12.5 - Power Harness, PN118600-107 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
12.6 - Extension Harness, Pressure Sensor, PN118600-108 . . . . . . . . . . . . . . . . . . . . . . . . 90
12.7 - Boom Shutoff Adapter, 11-Nozzle, 10-Section, PN118602-127 . . . . . . . . . . . . . . . . . 91
13.0 - KIT SMITHCO 118600-228, 12-NOZZLE, 10-SECTION, (1-1-1-1-1-2-1-1-1-1), 20’ BOOM,
TURF SSRS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
13.1 - Power Hub, 12-Nozzle, 3-Section, Boom 5, 6, 7, 8 - P/N118600-256 . . . . . . . . . . . . 94
13.2 - LH Boom Harness, 12-Nozzle, 3-Section, Boom 1, 2, 3, 4 - P/N118600-257 . . . . . . 95
13.3 - RH Boom Harness, 12-Nozzle, 3-Section, Boom 9, 10, 11, 12 - P/N118600-258 . . . 95
13.4 - Extension Harness, SSRS Display, PN118600-110 . . . . . . . . . . . . . . . . . . . . . . . . . . 96
13.5 - Power Harness, PN118600-107 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
13.6 - Extension Harness, Pressure Sensor, PN118600-108 . . . . . . . . . . . . . . . . . . . . . . . . 96
13.7 - Boom Shutoff Adapter, 12-Nozzle, 10-Section, PN118602-128 . . . . . . . . . . . . . . . . . 97
INDEX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99

4
Contents
SharpShooter®with Rate Sync®- Turf Sprayer Edition
©2003, 2011, 2015 Capstan Ag Systems, Inc., All Rights Reserved | Version: P-3.0 | 6/9/2016
THIS PAGE IS INTENTIONALLY LEFT BLANK

5
SharpShooter®with Rate Sync®- Turf Sprayer Edition
©2003, 2011, 2015 Capstan Ag Systems, Inc., All Rights Reserved | Version: P-3.0 | 6/9/2016
Table Of Figures
FIGURES
Figure 1: HCS Pictograms. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Figure 2: GHS Safety Label Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Figure 3: GHS Safety Warning Example. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Figure 4: SSRS Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Figure 5: SSRS Display Connection Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Figure 6: Extension Harness, SSRS Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Figure 7: Power Hub . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Figure 8: Left Boom Harness. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Figure 9: Right Boom Harness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Figure 10: Valve Driver Module. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . 16
Figure 11: Pressure Sensor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Figure 12: Extension Harness, Pressure Sensor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Figure 13: Power Harness. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Figure 14: Boom Shutoff Adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Figure 15: Boom Shutoff Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Figure 16: Y-Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . 20
Figure 17: Battery Power Cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Figure 18: Electrical Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Figure 19: Nozzle Valve Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Figure 20: Tips. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Figure 21: Wilger Nozzle Bodies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Figure 22: Hypro Dry Boom Adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Figure 23: Pressure Sensor Breakout Harness. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Figure 24: SSRS Turf Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Figure 25: SSRS Display Controls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . 28
Figure 26: Main Menu Items . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . 28
Figure 27: SSRS Display Screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Figure 28: Menu Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . 31
Figure 29: Line 1 -Backlight. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Figure 30: Line 2 - Alarm Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Figure 31: Line 3 - Spray Tip Size. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Figure 32: Line 4 - System Gain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Figure 33: Line 5 - P Gain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . 34
Figure 34: Line 6 - I Gain. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Figure 35: Line 7 - Rate Sync . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Figure 36: Line 8 - Rate Sync Ave. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Figure 37: Line 9 - Low Pressure Shutoff . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Figure 38: Line 10 - Run/Hold Delay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Figure 39: Pressure Increment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Figure 40: Line 12 - Boost Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . 37
Figure 41: Line 13 - Boost Tip Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Figure 42: Line 14 - Units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Figure 43: Line 15 - Pressure Sensor Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Figure 44: Sensor Offset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . 38
Figure 45: Sensor Volt Min . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Figure 46: Line 16 - Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Figure 47: Line 17 - Exit Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Figure 48: Strainers and Screens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Figure 49: SSRS Display Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Figure 50: Capstan Can Commander . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

6SharpShooter®with Rate Sync®- Turf Sprayer Edition
©2003, 2011, 2015 Capstan Ag Systems, Inc., All Rights Reserved | Version: P-3.0 | 6/9/2016
Table Of Figures
Figure 51: Verify Display Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Figure 52: SSRS Menu Items. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Figure 53: Nozzle Valve Debris . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Figure 54: Nozzle Valve Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . 64
Figure 55: Plunger Seal Inspection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Figure 56: Voltmeter Coil Check. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Figure 57: Battery Voltage Check. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Figure 58: System Load Capacity Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Figure 59: Valve driver Voltage Check. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . 67
Figure 60: Pressure Sensor Signal Test. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Figure 61: Pressure Sensor Input Power Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Figure 62: Pulse Circuit Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Figure 63: Valve Driver Output Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Figure 64: Valve Driver Input Check. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Figure 65: Boom Section Run / Hold Signal Test. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Figure 66: Boom Section Shutoff Signal Test. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

7
SharpShooter®with Rate Sync®- Turf Sprayer Edition
©2003, 2011, 2015 Capstan Ag Systems, Inc., All Rights Reserved | Version: P-3.0 | 6/9/2016
1.0 - Introduction
All trademarks, service marks, trade names, trade dress, product names, logos and brands
appearing in this manual are the property of their respective owners. Use of these marks, names,
logos, and brands does not imply endorsement or affiliation.
1.0 INTRODUCTION
SharpShooter®with Rate Sync®with Blended Pulse™ is an innovative Capstan Ag patented process that combines
a tip-management system with rate control technology to solve the greatest limitation of modern sprayer technology -
spraying from one tip size at a time.
As an aftermarket retro fit, SharpShooter®with Rate Sync®uses patented Blended Pulse-Width Modulation
technology providing a simple solution of having exactly the right effective tip size to maintain both a set rate and a
set pressure throughout the entire sprayer speed range.
SharpShooter®with Rate Sync®permits independent operator control over pressure, droplet size, rate and speed
without ever changing tips. It may seem magical but the impact on operational efficiency, application quality, drift
control and chemical savings is profound.
Since the spray function is controlled at the tip, spray shut off is instantaneous. The flow and pressure are retained in
the boom at the tips so when the boom is turned on there is instant flow at the proper rate and pressure.
SharpShooter®with Rate Sync®enhances the physics of spraying to provide a foundation for today’s advanced GPS
rate controllers with 10 section nozzle spray control and mapping features to truly provide a Total Turf Application
System.
SharpShooter®with Rate Sync®provides the right tip size at the right time automatically and instantaneously.
© 2010 CAPSTAN AG SYSTEMS, INC all rights reserved
Capstan Ag Systems, Inc. shall retain sole ownership of Copyrights and Patents for the SharpShooter®- Turf
spray system with Blended Pulse™ technology; along with all documentation, which shall not be copied, in
whole or in part, adapted, modified, or disseminated without written permission from Capstan Ag Systems,
Inc. This equipment is an agricultural-based system operated by a trained operator and maintained by
qualified personnel. Patented operational software, circuitry logic and processes supplied on each
SharpShooter®product remain the exclusive property of Capstan Ag Systems, Inc.
Capstan Ag Systems, Inc.
4225 SW Kirklawn Ave.
Topeka, KS 66609-1284
[phone] - Headquarters
[phone] - Fax
[phone] - Toll-Free
[e-mail] | www.capstanag.com

8SharpShooter®with Rate Sync®- Turf Sprayer Edition
©2003, 2011, 2015 Capstan Ag Systems, Inc., All Rights Reserved | Version: P-3.0 | 6/9/2016
1.0 - Introduction
THIS PAGE IS INTENTIONALLY LEFT BLANK

SharpShooter®with Rate Sync®- Turf Sprayer Edition
©2003, 2011, 2015 Capstan Ag Systems, Inc., All Rights Reserved | Version: P-3.0 | 6/9/2016
2.0 - Safety
9
2.0 - SAFETY
2.1 - Hazard Communications
This manual contains important information on how to
safely, efficiently and correctly install, operate and
maintain SharpShooter Turf System. Following these
instructions will help keep personnel safe, reduce
downtime and increase the reliability and life of the
equipment, its components and related systems.
• Review the Safety Information in the Original
Equipment Manufacturer (OEM) sprayer
equipment manual(s).
• Follow the instructions (in this manual) for each
step thoroughly to ensure safe work conditions in
and around OEM sprayer equipment.
• It is important for all individuals working with
chemicals to understand the potential risks,
necessary safety precautions, and proper
response in the event of accidental contact.
• Review the OEM sprayer equipment manual(s) for
chemical safety information.
• Review, understand and read procedures and use
Safety Data Sheets (SDS) and the required
Personal Protective Equipment (PPE) for
hazardous chemicals.
Please keep this manual and all enclosed
documentation in an accessible location known to all
operators, installation, and maintenance personnel.
If you do not understand the Capstan Ag Systems, Inc.
equipment after reading this manual, please obtain the
proper training before working with equipment to
ensure your own safety and well as your co-workers’
safety.
• Do not attempt to operate any equipment or
system until you completely understand why, when
and how it operates. If you are uncertain after
studying this manual, please contact Capstan Ag
Systems, Inc.
Capstan Ag Systems, Inc.
4225 SW Kirklawn Ave.
Headquarters: [phone]
Toll-free: [phone] Topeka, KS 66609
Fax: [phone]
E-mail: prodsuppo[email protected]
2.2 - Signal Words
Signal Words used in product safety messages (found
in this manual) are based upon these standards:
• American National Standards Institute (ANSI)
Z535.1-6
• American Society of Agricultural and Biological
Engineers (ASABE) MS-23/14
2.3 - Definitions
The DANGER symbol indicates a hazardous situation,
which if not avoided, will result in death or serious
injury. This signal word is limited to extreme situations.
The WARNING symbol indicates a hazardous
situation, which if not avoided, could result in serious
injury or equipment damage.
NOTE: DANGER or WARNING signal words are not
used for property damage accidents unless
personal injury risk is appropriate to a
specific hazardous situation level.
The NOTICE symbol addresses practices not related
to personal injury and safety practices.
The SAFETY INSTRUCTION symbol explains safety
practices and hazardous situations in detail, above
what the DANGER and WARNING symbols can
provide.
2.4 - Conformance
Safety Messages in this Capstan Ag manual conforms
to the ANSI Z535 Standard:
•Safety Color Code: (WARNING)
•Signal Word: WARNING!
•Hazard Statement: Chemical Residues may be
present in the OEM equipment.
•Instructions Statement: Release pressure on the
liquid application system before servicing. Rinse
the system with clean water prior to installing or
servicing fittings, hoses, valves, or nozzles.
•Consequences Statement: Use proper PPE at all
times to avoid personal injury.
Make certain that all personnel have
read this manual and thoroughly
understand safe and correct
operation and maintenance
procedures.

SharpShooter®with Rate Sync®- Turf Sprayer Edition
©2003, 2011, 2015 Capstan Ag Systems, Inc., All Rights Reserved | Version: P-3.0 | 6/9/2016
2.0 - Safety
10
2.5 - HCS Pictograms and GHS Safety
Labels
OSHA’s Hazard Communication Standard (HCS)
places pictograms on labels to alert users of chemical
hazard exposure [Figure 1]. You many find these
pictograms on OEM sprayer equipment. Review the
OEM sprayer manuals for further explanations on
these pictograms.
Figure 1: HCS Pictograms
The HCS aligned its provisions with the United Nations’
Globally Harmonized System (GHS) Classification and
Labeling of Chemicals in 2012. [Figure 2] displays a
GHS Safety Label example for a chemical hazard.
Figure 2: GHS Safety Label Example
Capstan Ag Systems, Inc. add-on spraying systems for
OEM and retrofit sprayer equipment (Booms and
Toolbars) may contain (where applicable) HCS
pictograms and GHS safety labels (on our equipment)
and safety “signal word” messages (in this manual)
[Figure 3].
These labels and safety messages warn all personnel
about hazardous chemicals or potentially unsafe
chemical conditions that may exist while working
around sprayer equipment.
Figure 3: GHS Safety Warning Example
2.6 - Hazardous Energy
People working around OEM sprayer equipment may
be exposed to hazardous energy in several forms and
combinations during installation, operation or
maintenance, of Capstan Ag equipment, such as:
• Kinetic (mechanical) - energy in the moving parts
of mechanical systems (springs or spring-loaded).
• Potential (residual) - energy stored in pressure
vessels, such as liquid application systems and
hydraulic cylinders and hoses.
• Electrical energy - generated electrical power,
static sources, or electrical storage devices (such
as batteries or capacitors).
• Thermal (high or low temperature) - energy
resulting from mechanical work, radiation,
chemical reaction, or electrical resistance.
2.7 - Chemical Safety
Following these common handling practices for
working safely around hazardous chemicals:
• Always have an ample water supply nearby.
• Never smoke or eat while working around chemical
spraying equipment.
• Have qualified technicians that are familiar with all
local, State or Province, and Country-specific laws
install and service the equipment.
• Operate the equipment according to the Product,
Operation or Maintenance Manual.
• Avoid chemical exposure by using the proper PPE.
Remove contaminated clothing immediately and
wash skin (and clothing) thoroughly with soap and
water. Wash contaminated clothing after every use.
• Bleed off pressurized sprayer equipment and flush
the chemical residue with clean water before
servicing.
• If symptoms of illness occur during or shortly after
working on or around spraying equipment,
immediately call a physician or go to a hospital.
2.8 - Unsafe Equipment Use
• The use of the Capstan Ag equipment by non-
qualified personnel.
•The use of unsuitable tools or replacing
components or spare parts with ones other than
those specified in this manual or by Capstan Ag
personnel.
•Re-engineering Capstan's operating software so it
changes the intended use of the Capstan Ag
equipment without FIRST consulting Capstan Ag
Systems, Inc.

SharpShooter®with Rate Sync®- Turf Sprayer Edition
©2003, 2011, 2015 Capstan Ag Systems, Inc., All Rights Reserved | Version: P-3.0 | 6/9/2016
2.0 - Safety
11
2.9 - Battery Safety
Use the procedure in the appropriate sprayer
equipment manual for connecting, disconnecting and
jump-starting the machine’s battery.
• Keep sparks and flames away from the battery.
Battery gas can explode and cause serious injury.
Do not smoke in battery charging area.
• Remove jewelry, which might make electrical
contact and create sparks.
• Avoid chemical burns by not rubbing eyes or skin
while working with the battery.
• Wash your hands immediately after completing the
job.
2.10 - Extinguishing Fires
Fire extinguishing systems must meet the applicable
OSHA requirements and all users of Portable/Fixed
Fire Suppression Equipment must know the types,
limitations, and proper uses of this equipment;
including hazards involved with incipient stage
firefighting.
Know where fire extinguishers and first aid kits are
located and how to use them.
• Inspect the fire extinguisher and service the fire
extinguisher regularly.
• Follow the recommendations on the instructions
plate.
• Very small fires can be put out (extinguished) with
a fire extinguisher. Use an appropriate method to
extinguish a fire (water for paper fires, and
chemical extinguishers for electrical or chemical
fires.
BATTERY SAFETY

SharpShooter®with Rate Sync®- Turf Sprayer Edition
©2003, 2011, 2015 Capstan Ag Systems, Inc., All Rights Reserved | Version: P-3.0 | 6/9/2016
2.0 - Safety
12
THIS PAGE IS INTENTIONALLY LEFT BLANK

SharpShooter®with Rate Sync®- Turf Sprayer Edition
©2003, 2011, 2015 Capstan Ag Systems, Inc., All Rights Reserved | Version: P-3.0 | 6/9/2016
3.0 - Parts Identification
13
3.0 - PARTS IDENTIFICATION
3.1 - SharpShooter with Rate Sync (SSRS
Display)
[Figure 4] - The SSRS Display is located at the
operator station.
The SSRS Display contains a user interface screen
and several keypad buttons:
• Power button
• Menu button
• Auto/Manual button
• Increase button
• Decrease button
[Figure 5] - Connections on the back of the SSRS
Display include the main connection port, a GPS
connection point and diagnostic connection (AUX).
3.2 - Extension Harness, SSRS Display
[Figure 6] - The Extension Harness routes from the
Power Hub to the SSRS Display.
Figure 4: SSRS Display
Figure 5: SSRS Display Connection Ports
Figure 6: Extension Harness, SSRS Display
PART NO. DESCRIPTION
118600-110 Extension Harness, 14’ for SmithCo /
Toro
118600-106 Extension Harness, 18’ for Jacobsen
118500-110
118600-110

SharpShooter®with Rate Sync®- Turf Sprayer Edition
©2003, 2011, 2015 Capstan Ag Systems, Inc., All Rights Reserved | Version: P-3.0 | 6/9/2016
3.0 - Parts Identification
14
3.3 - Power Hub
[Figure 7] - The Power Hub can usually be located at
the center of the boom mast.
The Power Hub is a junction block where the battery
power is routed to the Valve Drivers. The Power Hub
also routes Pressure Sensor signals and Valve Driver
signals to the SSRS Display.
The power hubs listed above replace the following
power hub part numbers:
Figure 7: Power Hub
PART NO. DESCRIPTION
118600-250 Power Hub, 9-Nozzle, 15’
118600-253 Power Hub, 11-Nozzle, 18’
118600-256 Power Hub, 12-Nozzle, 20’
118600-101 Power Hub,13-Nozzle, Universal
PART NO. DESCRIPTION
118600-104 Power Hub, 9-Nozzle, SmithCo
118600-105 Power Hub, 11-Nozzle, Universal
118600-103 Power Hub,12-Nozzle, SmithCo
Left and right boom harnesses, power
extension, display extension and
pressure sensor extensions will also
be required if replacing the older style
power hubs.
118600-253
118600-102

SharpShooter®with Rate Sync®- Turf Sprayer Edition
©2003, 2011, 2015 Capstan Ag Systems, Inc., All Rights Reserved | Version: P-3.0 | 6/9/2016
3.0 - Parts Identification
15
3.4 - Left Boom Harness
[Figure 8] - Left Boom Harness (Driver's left-hand
side) from the Power Hub.
3.5 - Right Boom Harness
[Figure 9] - Right Boom Harness (Driver's right-hand
side) from the Power Hub.
Figure 8: Left Boom Harness
Figure 9: Right Boom Harness
PART NO. DESCRIPTION
118600-251 Left Boom Harness, 3 Section,
9-Nozzle, 1-3, 15’
118600-254 Left Boom Harness, 3 Section,
11-Nozzle, 8-11, 18’
118600-257 Left Boom Harness, 3 Section,
12-Nozzle, 9-12, 20’
Not needed for the Universal 13
nozzle 118600-101 Power Hub.
PART NO. DESCRIPTION
118600-252 Right Boom Harness, 3 Section,
9-Nozzle, 7-9, 15’
118600-255 Right Boom Harness, 3 Section,
11-Nozzle, 8-11, 18’
118600-258 Right Boom Harness, 3 Section,
12-Nozzle, 9-12, 20’
Not needed for the Universal 13
nozzle 118600-101 Power Hub.
118600-254
118600-255

SharpShooter®with Rate Sync®- Turf Sprayer Edition
©2003, 2011, 2015 Capstan Ag Systems, Inc., All Rights Reserved | Version: P-3.0 | 6/9/2016
3.0 - Parts Identification
16
3.6 - Valve Driver Module
[Figure 10] - The ①Valve Driver Module(s) are usually
located next to the Power Hub. Two are required. One
is for the BOOST row of nozzles and one is for the non-
boosted nozzles.
Each Valve Driver has a single connector that connects
to the Power Hub. Each Valve Driver is equipped with a
②10A fuse.
3.7- Pressure Sensor
[Figure 11] - On most models the Pressure Sensor is
located near the center section of the rear boom. On
SmithCo models the Pressure Sensor is located at the
machine center behind the seat.
The Pressure Sensor provides pressure signals to the
SSRS Display.
Figure 10: Valve Driver Module
Figure 11: Pressure Sensor
118400-020 replaces 118400-101.
The Pressure Sensor must be
installed in a vertical upright position.
It should be located so product flow
aways flows past it to avoid plugging.
It must also be installed at a location
that will allow an accurate reading
when all, or only one boom section, is
turned on.
118400-020
2
1
118400-101
1
2
116301-001

SharpShooter®with Rate Sync®- Turf Sprayer Edition
©2003, 2011, 2015 Capstan Ag Systems, Inc., All Rights Reserved | Version: P-3.0 | 6/9/2016
3.0 - Parts Identification
17
3.8 - Extension Harness, Pressure Sensor
[Figure 12] - The Pressure Sensor Extension Harness
connects the Pressure Sensor to the Power Hub.
3.9 - Power Harness
[Figure 13] - The Power Harness connects the Power
Hub directly to the battery.
Figure 12: Extension Harness, Pressure Sensor
Figure 13: Power Harness
Pressure Sensor Extension Harness
is used on SmithCo Sprayers only.
PART NO. DESCRIPTION
118600-107 Power Harness, 14’ SmithCo / Toro
118600-109 Power Harness, 18’ Jacobsen
(with 5A fuse)
118600-108118600-108
118600-109
118600-107

SharpShooter®with Rate Sync®- Turf Sprayer Edition
©2003, 2011, 2015 Capstan Ag Systems, Inc., All Rights Reserved | Version: P-3.0 | 6/9/2016
3.0 - Parts Identification
18
3.10 - Boom Shutoff Adapter
Several Boom Shutoff Adapters are available
depending on the sprayer model and boom
configuration.
[Figure 14] - This style Boom Shutoff Adapter with the
Deutsch connector services the following power hubs:
The boom shutoff adapter intercepts the signals from
the rate controller section signals that open and close
the boom section shutoff valves. Typically the machine
boom section shutoff on SmithCo machines are
removed and the Boom Section Adapters connect
directly to the controller harness.
SharpShooter uses this signal to turn on and off the
nozzle valve assemblies located on the boom nozzle
bodies. These assemblies are located on the boom
section spray tubes. When the signal wire is powered
up, 12V, the nozzle valves open. When the signal wire
has no power, the nozzle valves close.
Applicable Shutoff Adapter service parts include the
following part numbers:
Figure 14: Boom Shutoff Adapters
PART NO. DESCRIPTION
118600-250 Power Hub, 9-Nozzle 15’
118600-253 Power Hub, 11-Nozzle 18’
118600-256 Power Hub, 12-Nozzle 20’
118602-124
118602-120
118602-127
9 and 10 Section Configurations
118602-129 SmithCo / Toro 9-Section Raven Envizio; 9-Noozle Boom
118602-118 Jacobsen
118602-127 SmithCo / Toro 10-Section Raven Envizio; 11-Nozzle Boom
118602-120 Jacobsen
118602-128 SmithCo / Toro 10-Section Raven Envzio; 12-Nozzle Boom
118602-122 Jacobsen
3 Section Configurations
118602-125 SmithCo / Toro 3-Section Raven 440; 9-Nozzle Boom (spade terminals)
118602-119 Jacobsen 3-Section Raven 440; 9-Nozzle Boom
118602-124 SmithCo / Toro / Deere 3-Section Raven 440; 11-Nozzle Boom (spade terminals)
118602-121 Jacobsen 3-Section Raven 440; 11-Nozzle Boom
118602-126 SmithCo / Toro 3-Section Raven 440; 12-Nozzle Boom (spade terminals)
118602-123 Jacobsen 3-Section Raven 440; 12-Nozzle Boom
