Car-Interface.com CI-VL7-C3D User manual

www.car-interface.com
User Manual
Camera Interface for 2016-2020,Alfa Romeo, Giulia and Stelvio,6.5" and 8.8"
Model name
CI-VL7-C3D
Released Date
2020-04-10
Manual Version
1.2
Language
English
1
www.car-interface.com

www.car-interface.com
1. Car Compatibility Chart
Car Models
Production Year
2 Alfa Giulia
2016-2020
3 Alfa Stelvio
2016-2020
2
www.car-interface.com

www.car-interface.com
Contents
1.Features.............................................................................................................................................................................................................................................4
2.Specifications...............................................................................................................................................................................................................................5
3.Wiring Diagram...........................................................................................................................................................................................................................6
4.DIP Switch Settings.................................................................................................................................................................................................................8
5.Operation Instructions.......................................................................................................................................................................................................10
6.Safety Considerations.......................................................................................................................................................................................................15
3
www.car-interface.com

www.car-interface.com
1. Features:
A. Support Intelligent Parking Assist System including PDC (Parking Distance Control) and FPG
(Flexible Parking Guidelines)
B. Support further software update by TF Card
C. Support adjust FPG position for 6.5" and 8.8" screen
D. Supply power for rear view camera
E. Supply power for DVR device
F. Support automatically switched to front view camera, auto trigger after R to D gear
4
www.car-interface.com

www.car-interface.com
2. Specifications
A. Interface I/O Spec:
Input: CVBS *3 (Front/Rear View Camera, 360, Video), VGA *1 (Specific 360 Panoramic System)
Output: LVDS Output
B. Power Spec:
C. Package Content:
Interface Unit * 1
Main Power Cable * 1
LVDS Cable * 1
5
www.car-interface.com

www.car-interface.com
3.Wiring Diagram
6
www.car-interface.com

www.car-interface.com
7
www.car-interface.com

www.car-interface.com
4.DIP Switch Settings
8
www.car-interface.com

www.car-interface.com
Some common DIP shortcuts:
Aftermarket rear camera (CANbus control): 4 OFF, 5 OFF, 6 OFF, 7 OFF, 8 OFF
Aftermarket rear camera (rear lights control): 4 OFF, 5 OFF, 6 OFF, 7 OFF, 8 ON
Factory R-cam: 4 OFF, 5 ON, 6 OFF, 7 OFF, 8 ON
9
www.car-interface.com

www.car-interface.com
5.Operation Instructions
5.1 Installation Process
* Please note that need to power off and take protection measures to avoid damaging in the installation process.
12
1. Please confirm Interior dash-board(pic 1) and pry down supporting plate beside driving position by professional tools(pic 2).
10
www.car-interface.com

www.car-interface.com
34
2. Then use a screwdriver to unscrew the left and right screws under the steering wheel( above the brake, as pic 3), then
take out the panel(pic 4).
11
www.car-interface.com

www.car-interface.com
56
3. Screw off the screws on the head unit and take out( pic 5). Connect the provided LVDS cable to the OEM LVDS socket
in the original radio. The OEMLVDS connector pulled out from the OEM radio connect with provided LVDS-OUT cable.
And then transfer the power cable as pic 6.
12
www.car-interface.com

www.car-interface.com
7
4. Recover the dash board after confirming all cables are well connected. Rear view as pic 7 .
13
www.car-interface.com

www.car-interface.com
5.2 Interface wire diagram as below picture
14
www.car-interface.com

www.car-interface.com
6.Safety Considerations
1. In order to protect driving safety and avoid breaking the traffic law, please do not watch the program or use this product
when you’re driving.
2. Please do not put the product in the damp environment or water, in order to avoid electric shock, damaged and fire
accident caused by short circuit.
3. The reversing surveillance function just be used in reversing assistance. Once happened reversing accident does not
concern us. And hint of fault message need to be confirmed by professional maintenance Center.
4. In order to safety and ensure the use of product, the installation please leave it to the professional. Do not unload by
yourself in order to avoid causing damaged or accident.
5. Start the engine before loading, check the interface whether have function displayed, key control whether correct, the
vehicle interface whether have scratch. Please give the feedback to customers if there has any questions.
6. Please note that put the disassemble automotive components in a good way on the installation process, avoid
scratching the instrument panel, the leftovers of connect cables need to handle and do not leave it in the car. The
connecting plug must be insulated in order to short circuit.
15
www.car-interface.com

www.car-interface.com
7. The cables should be connected in a good way, the vehicle installation space is small, so reduce space usage as far as
possible, and it will easy installation for monitor. There should be a good plan about connect cables, avoid affecting
the active component of connecting, such as control components of turning steering wheel, throttle and brake pedal.
There need to be fasten after connecting cables in case of drop.
8. Please do not plug or pull the connected cables in the state of power-on, in order to avoid damaging monitor or
accessory.
16
www.car-interface.com

www.car-interface.com
www.car-interface.com
17
