Car-Interface c.LOGiC lite CI-C1-CCC User manual

Version 20.09.2017 CI-C1-CXC-TV1
c.LOGiC lite interfaces
CI-C1-CCC
CI-C1-CIC/CI-C1-CXC-TV1
CI-C1-E65/CI-C1-E65-TV
Compatible with
BMW Professional navigation systems
with iDrive and 6.5”/8.8” monitor
Interface-set AV and reverse camera input
with device control and video-in-motion

Version 20.09.2017 CI-C1-CXC-TV1
Page 1
Contents
1. Prior to Installation
1.1. Delivery contents
1.2. Check compatibility of vehicle and accessories
1.3. Check dip switch settings of the CAN-box
2. Installation
2.1. Installation 1series (E87), 3series (E90/E91/E92), 6series (E63/E64), X5(E70),
X6(E71) at example 5series (E60/E61)
2.1.1. Vehicles 5series w/o TV-tuner port
2.1.2. Vehicles 5series with TV-tuner port (factory TV-tuner uninstalled)
2.2. Installation 7series (E65/E66)
2.2.1. Vehicles 7series w/o TV-tuner port
2.2.2. Vehicles 7series with TV-tuner port (factory TV-tuner uninstalled)
3. Connections
3.1. Vehicles with factory rear-view camera
3.2. Vehicles with factory rear-view camera and factory-TV-tuner
3.3. Connecting an after-market rear-view camera
3.4. Special case –vehicles without fibre optical components (very rare)
4. Device control
4.1. Installation of IR-sensor additionally
5. Operation
5.1. Activation of the video-in-motion function
5.2. Selecting the interface as current AV-source
5.3. Assigning device control
5.4. Using device control
5.5. Button assignment table iDrive
6. Specifications
Appendix A –Device control table
Information
Changes of the vehicle software can cause malfunctions of the interface. We offer free
software-updates for interfaces for one year after purchase. To receive a free update, the
interface must be sent in at own cost. Labor cost for and other expenses involved with the
software-updates will not be refunded.

Version 20.09.2017 CI-C1-CXC-TV1
Page 2
1. Prior to installation
Read the manual prior to installation.
Technical knowledge is necessary for installation. The place of installation must be free of
moisture and away from heat sources.
1.1. Delivery contents
The necessary components for installation vary depending on the vehicle and accessories.
See below table to determine the parts necessary for installation. Product codes of the full
set are in bold letters (C1-xxx) while the set components (C1C-xxx) are listed below the set.
Options/
Navi Professional version
w/o factory TV-
tuner port
with factory
TV-tuner port
CCC Navigation (older iDrive, 1-2 buttons)
1series (E87), 3series (E90/91/92), 5series
(E60/61), 6series (E63/E64), X5 (E70), X6 (E71)
Vehicles from 2009 need additionally
harness TV-2X12P!
C1-CCC
C1C-M36
C1C-BM02
TV-436
TV-BM01
C1-CXC-TV1
C1C-M36
C1C-BM01
TV-436
TV-BM01
CIC Navigation (newer iDrive, 8 buttons)
3series (E90/91/92), 5series (E60/61), 6series
(E63/E64), X5 (E70), X6 (E71)
C1-CIC
C1C-M36
C1C-BM03
TV-436
TV-BM01
C1-CXC-TV1
C1C-M36
C1C-BM01
TV-436
TV-BM01
E65 Navigation
7series (E65/E66)
C1-E65
C1C-M36
C1C-BM02
TV-436
TV-BM65
C1-E65-TV
C1C-M36
C1C-BM01
TV-436
TV-BM65
If remote function of the interface should be used, additional IR-remote cables and
Y-adapters are needed, see chapter 4. Device control .
C1C-M36 HW_____ SW_____
C1C-BM01
TV-436 HW_____ SW_____
TV-BM65
C1C-BM02
C1C-BM03
TV-BM01
Take down the SW-version and HW-version of the interface boxes, cross the delivery
contents and store this manual for support purposes.

Version 20.09.2017 CI-C1-CXC-TV1
Page 3
1.2. Check compatibility of vehicle and accessories
1.3. Checking the DIP switches on the CAN-box
2. Installation
Switch off ignition and disconnect the vehicle from the battery!
The interface needs a permanent 12V source. If power source is not taken directly from
battery, the connection has to be checked for being start-up proven and stable.
Complete and correct function of the interface is possible only when, CAN and fibre optical
connections are made properly. Vehicles without TV icon will be programmed automatically
after installation of the interface.
Note: The loose white and green cable of harness TV-BM01/TV-BM65 are not required and
must be isolated.
Requirements
Vehicle 1series (E87) only CCC, 3series (E90/91/92), 5series (E60/61),
6series (E63/64), 7series (E65/66), X5 (E70), X6 (E71), Z4 (E89)
Navigation navigation system Professional CCC, E65 or CIC
with 6.5” or 8.8” monitor
Limitations
factory-TV-tuner has to be removed if installed
After-market rear-view cam Automatic switching to camera only from c.LOGiC mode.
factory-RSE (E65) need additional interface, VL-RGB02-C
Factory PDC If an after-market rear-view camera should be connected by the
c.LOGiC the visual PDC display must be deactivated occasionally
or permanently for camera picture.
Vehicles with CIC Dip 1 ON, Dip 2 OFF, Dip 3 OFF
Vehicles with CCC or E65 Dip 1 OFF, Dip 2 OFF, Dip 3 OFF

Version 20.09.2017 CI-C1-CXC-TV1
Page 4
2.1. Installation 1series (E87), 3series (E90/E91/E92), 6series (E63/E64), X5(E70), X6(E71)
at example 5series (E60/E61)
Needed parts
1. fibre optical interface C1C-M36
2. CAN interface TV-436
3. CAN interface harness TV-BM01

Version 20.09.2017 CI-C1-CXC-TV1
Page 5
2.1.1. Installation 5series w/o TV-tuner port
optical interface-harness C1C-BM02 for CCC-Navigation or C1C-BM03 for CIC-Navigation
is needed
Remove trim strip and step by step using a
plastic wedge. Do not proceed to quickly to
avoid breaking clamps of the trim strip.
Next remove screws 1 and 2 (see picture)
Remove climate control panel. Remove
CD/DVD drive trim. Trim is fixed by 2 screws
on the upper side and plugged to the
lower trim. Remove the lower trim
(plugged too).
Remove 4 screws and take out
navigation computer.

Version 20.09.2017 CI-C1-CXC-TV1
Page 6
Disconnect Quadlock connector from the back of the navigation computer.
The Quadlock connector includes different chambers. If present, remove the white, black
and the optical inserts, from the vehicle harness’ Quadlock connector. Plug the vehicle
harness’ Quadlock connector into the male Quadlock connector of the CAN interface harness
TV-BM01

Version 20.09.2017 CI-C1-CXC-TV1
Page 7
In the female Quadlock connector there is two compartments for inserts. Plug white insert
of the interface harness C1C-BMW0X into compartment for “Einsatz 1”.
If white insert in vehicle harness is present, remove video wires from white insert of fibre
optical interface harness and connect them to relating chambers in white vehicle harness’
insert.
On CCC navigation (C1C-BM02):
White insert („Einsatz 1“): video-signal (red) = PIN 4; signal-ground (black) = PIN 2
On CIC navigation (C1C-BM03):
White insert („Einsatz 1“): video-signal (red) = PIN 2; signal-ground (black) = PIN 12
On vehicles with factory rear-view camera, PIN 2 and PIN 12 are already occupied. In this
case connect according to 3.1. Vehicles with factory rear-view camera .
If no white insert in vehicle harness is present, connect white insert of fibre optical interface-
harness C1C-BM03 with Quadlock connector of the vehicle harness.
Remove optical insert from car side Quadlock connector.
Connect optical insert as shown in chapter 3. Connections with Quadlock
connector from CAN interface harness TV-BM01.
Connect the Quadlock connector from CAN interface harness TV-BM01 to the male Quadlock
plug of the navigation computer. Connect vehicle Quadlock connector with male Quadlock
plug of CAN interface harness TV-BM01.
Installation 5series with CIC w/o TV-port continue with chapter 4. Device control .

Version 20.09.2017 CI-C1-CXC-TV1
Page 8
2.1.2. Installation 5series with TV-tuner port (factory TV-tuner removed)
optical interface harness C1C-BM01 is needed
Installation of CAN interface analogue to
chapter 2.1.1. Installation 5series w/o TV-port .
Transfer white (if present), black and optical inserts from vehicle Quadlock connector to the
Quadlock connector of the CAN interface harness TV-BM01. Connect the CAN interface
harness Quadlock connector to the male Quadlock plug of the navigation computer and the
vehicle harness Quadlock connector to the male Quadlock plug of the CAN interface harness.
The blue factory-TV-tuner port is in found in
the trunk. Remove fibre optics from the blue
TV-port connector. Connect with black
connector of fibre optical interface harness
C1C-BM01. Obey the direction arrows
on the connector, see
chapter 3. Connections .
Connect black connector to fibre optical
interface. Connect blue plug to relating
counterpart of C1C-BM01 harness.
Factory rear-view cameras if present are connected to the factory TV-tuner.
Obey 3.2. Vehicles with factory rear-view camera and factory TV-tuner .
Installation 5series with TV-tuner port continue chapter 4. Device control .
2.2. Installation 7series (E65/E66)
Needed parts
1. fibre optical interface C1C-M36
2. CAN interface TV-436
3. CAN interface harness TV-BM65

Version 20.09.2017 CI-C1-CXC-TV1
Page 9
Board monitor removal
The CAN interface is connected to
the backside of the OEM screen.
Remove 3 TORX screws at the OEM screen.
Remove cover grill (only plugged). Place soft
towel beneath the board monitor
to avoid scratches
Flip down the board monitor. NOTE: The OEM
screen gets stuck with its connector at the upper
side of the cockpit. Insert a hard plastic sheet like
a credit card to prevent cockpit from
taking damage.
Remove the black connector at the backside of
the screen as shown below.

Version 20.09.2017 CI-C1-CXC-TV1
Page 10
Remove 12-pin insert from black vehicle
harness connector.
Insert 12-pin insert into black connector
of the CAN interface harness TV-BM65.
Insert the completed black connector into
CAN interface harness TV-BM65.
Connect 12-pin insert from CAN interface
harness TV-BM65 into black connector from
vehicle harness.
Insert completed connector into the plug on the backside of the board monitor.
NOTE: Pictures do NOT show the fibre optics connected in car!

Version 20.09.2017 CI-C1-CXC-TV1
Page 11
2.2.1. Installation 7series w/o TV-Port
fibre optical interface-harness C1C-BM02 is needed
The fibre optical interface installation is
made at the navigation computer, which
is located at the left side in the trunk
behind a cover and has to be removed.
The video lead (red - video signal, black - video ground) has to be removed from the white
insert of C1C-BM02. The white insert is not needed for E65/E66 installation.
Connect video lead to green 18-pin AMP connector
Video-signal (red) to chamber 3 of the green 18-pin AMP connector
Video-ground (black) to chamber 11 of the green 18-pin AMP connector
On vehicles with factory rear-view camera, PIN 3 and PIN 11 are already occupied. In this
case connect according to 3.1. Vehicles with factory rear-view camera .
Remove fibre optics from black 20-pin plug and connect them as shown in
chapter 3. Connections . Then reconnect the fibre optics in the black 20-pin connector.
Installation 7series w/o TV-port continue with chapter 4. Device control .
2.2.2. Installation 7series with TV-port (OEM-TV-Tuner removed)
fibre optical installation harness C1C-BM01 is needed
The installation of the fibre optical interface is analogue to
Chapter 2.1.2. Installation 5series with TV-tuner port (factory-TV-tuner removed) .

Version 20.09.2017 CI-C1-CXC-TV1
Page 12
3. Connections
Obey the direction
arrows of the optical
connectors!
NEW!
Remote signal and rear-view camera input + functions
4pin Molex connector pink –remote signal +12V, high when navigation is on
grey –connect to ground to activate 2-pin camera-input
green –camera power +12V (max 0.5A)
2pin AMP connector grey –camera video signal
black –camera video ground
3.1. Vehicles with factory rear-view camera
Transfer video-signal and video-signal ground pins from
vehicle connector to the 2pin AMP connector of the
fibre optical interface box harness.
Navi Connector Video-signal Video-signal ground
CCC white 12pin Quadlock Pin 4 Pin 2
CIC white 12pin Quadlock Pin 2 Pin 12
E65 green 18pin AMP Pin 3 Pin 11
Interface black 2pin AMP Pin 1 Pin 2

Version 20.09.2017 CI-C1-CXC-TV1
Page 13
Connect the 2pin AMP connector with
the 2pin AMP male plug of the harness
C1C-BMW0x.
Automatic switching to camera video will work from interface mode and from OEM mode.
3.2. Vehicles with factory rear-view camera and factory TV-tuner
The factory rear-view camera is connected to the white 18pin AMP connector of the factory
TV-tuner. Video-signal on pin 1 (yellow-black), video-signal ground on pin 10 (green).
Connect video-signal and video-signal ground analogue to
3.1. Vehicles with factory rear-view camera via the 2pin AMP.
3.3. Connecting an after-market rear-view camera
Connect video-signal and video-signal ground of the camera analogue to
3.1. Vehicles with factory rear-view camera via the 2pin AMP.
Automatical switching to the camera input when reverse gear is engaged is only possible in
interface mode.
With an existing factory PDC the visual PDC display must be deactivated occasionally or
permanently by iDrive while operating in the vehicle settings for camera picture. If needed
the PDC display can be switched on by PDC button.
3.4. Special case –vehicles without fibre optical components (very rare)
Vehicles without fibre optical components, which means without CDC, without phone or
other fibre optical components have optical wires at the navigation computer, but it can be
possible that the ring is not connected to diagnostic connector in the glove compartment. In
this case a connector bridge for optical wires is necessary.

Version 20.09.2017 CI-C1-CXC-TV1
Page 14
4. Device control
The c.Logic lite interface for BMW has the possibility to remotely control up to 2 pre-
programmed devices. The device list in the device control table shows the pre-programmed
remote channels and the related IR-remote cables.
An IR-remote cable STA-xxx must be ordered separately for every device which shall be
controlled.
If 2 devices shall be controlled, the 3-Pin AMP Y-cable STA-Y is needed (1 connector to 2
plugs). This is connected to the 3-Pin AMP plug of the interface harness,
and gives the opportunity to connect 2 IR remote cables.
The 3-Pin AMP connector of the IR-remote cable has to be connected to the interface
harness or the Y-adapter STA-Y, the device specific side to the IR port of the related device.
4.1. Installing the IR-sensor additionally
Additionally to the control via OEM navigation, it is possible to install the original IR-sensor
of a connected device. By using a Y-adapter (e.g. STA-Y35MM or STA-RJ12) for the IR-Port of
the connected device, the controls from navigation AND the devices IR-sensor can be
connected and used. If there are 2 devices connected, it´s possible to use the IR-remote
from one device for both connected devices. The installation of the additional IR-sensor is
recommended as the possible controls via navigation are limited, and not all functions may
be covered.
5. Operation
5.1. Activation of the video-in-motion function
On vehicles with CIC (8-button iDrive) the video-in-motion function is permanently active
without hurting the navigation performance.
On vehicles with CCC or E65 navigation (1 or 2 button iDrive) press the menu-button or the
iDrive wheel for about 3 seconds while in main menu. Alternatively it is possible to set dip-
switch 1 of the CAN box TV-436 to ON. But then the navigation performance is disturbed on
the first few kilometres of driving.
5.2. Selecting the interface as current AV source
Select TV through iDrive to choose the interface as current AV source.

Version 20.09.2017 CI-C1-CXC-TV1
Page 15
5.3. Assigning device control
After selecting the interface as current AV source,
push the iDrive knob to open the device control
menu.
Select control levels (setup) DEV1 and (setup)
DEV2 one after another and assign related IR-
codes as described in device control table.
Note: The IR-control channel is preset to RC-Code 41 compatible DVB-T tuners.
5.4. Using device control
Choose SELECT/USE DEV1(DEV2) to activate control level 1(2). After selection the menu will
close automatically. The iDrive knob, some Multi-function-steering wheel buttons and some
navigation buttons (HU) are now available for remote functions in the selected control level
(see assignment table for iDrive below).
By pressing the iDrive-MENU-button, the system returns to the factory iDrive functions. By
pressing the iDrive knob again, the control level menu opens up again, and the other control
level function can be selected and assigned.

Version 20.09.2017 CI-C1-CXC-TV1
Page 16
5.5. Button assignment table iDrive
iDrive Aktion
Gerät
DVD
DVC
DVB-T
iPod
MENU long
Setup
Setup
Setup
Setup
MENU short
Return to factory
iDrive functions
Return to factory iDrive
functions
Return to factory
iDrive functions
Return to factory iDrive functions
OPTIONS long *2
Audio
Audio
Info
KCE: Light Bulb, Vlink: Subtitle
OPTIONS short *2
Subtitle
Subtitle
Signal strength
KCE: lower vol, Vlink: Display
ENTER long
STOP
STOP
EXIT
-
ENTER short
Power
Power
Power
Power
NORTH long
OK
OK
OK
OK
NORTH short
Menu / PBC *1
Menu / PBC *1
EPG
Shuffle
WEST long
hoch
up
up
Previous chapter
WEST short
Play/Resume
Play/Resume
Exit
Play/Resume
SOUTH long
left
left
left
left
SOUTH short
Source
Source
AV
Source
EAST long
down
down
down
Next chapter
EAST short
Zoom
Next DVD or DVD selection
menu
Channel scan
KCE: increase vol, Vlink: ESC
Left turn
right
right
right
right
Right turn
Next chapter
Next chapter
Next channel
Up
MENU long
Previous chapter
Previous chapter
Previous channel
Down
DOWN short on
MFSW *3
Previous chapter
Previous chapter
Previous channel
Previous chapter
UP short on MFSW *3
Next chapter
Next chapter
Next channel
Next chapter
RIGHT short on HU *3
Previous chapter
Previous chapter
Previous channel
Previous chapter
LEFT short on HU *3
Next chapter
Next chapter
Next channel
Next chapter
*1 DVD title menu *2 not available on all vehicles *3 multi function steering wheel and head-unit
6. Specifications
Operation voltage 10.5 –14.8V DC
Stand-by power drain <1mA
Operation power drain 120mA
Power consumption 1.8W
Temperature range -30°C to +80°C
Weight 95g
Measurements (box only) B x H x T 106 x 30 x 71 mm
Legal disclaimer: Mentioned company and trademarks, as well as product names/codes are registered
trademarks ® of their corresponding legal owners.
