Car Solutions QROI X Android System User manual

[email protected]
car-solutions.com
car-solutions.com

Installation must be done at designated QROI A/S
center. Do not dismantle, modify and install the
product in the unauthorized places. In case of product
failure while installing the product in the unauthorized
places warranty will be void
Warning
Always wear a seatbelt. In case of a sudden stop,
it may cause a passenger harm
Remove dust, oil, and waste on the display.
Manufacturer does not take a responsibility of
Incidental damages that occurs whether or not
passengers use its product.
Drivers must not use/control the product while
driving. Park the car in a safe place in the first
place before using it.
Do not use the product for a long time while engine
is turned off. The car battery might go flat.
A map guided on the screen might not be in
concordance with the actual road condition. In a
such condition, follow the actual traffic situation.
Warning
Warning / Precautions!
[email protected]
car-solutions.com
car-solutions.com

1. Features
•Android 8.1 (OREO)
•Powerful RAM and Internal Storage spec (RAM 4GB LPDDR3 & 32GB eMMC)
•Powerful CPU (ARM Cortex-A72 + [email protected]z (HEXA CORE)
ARM Mali-T860 (QUAD CORE) )
•Allows installing and updating various application via Android Play- Store
•Provides High quality video display (720P, simultaneous Video Output of LVDS
and HDMI)
•Multiple ways to store data and communication ports (3 * USB, 1*Micro SD slot)
•Supports AUX OUT by Bluetooth and FMTX
•Access to the Internet & Data with usingWiFiand 4G Data by Dongle
(Dongle Option)
•Program & FW update by USB Thumb memory stick
[email protected]
car-solutions.com
car-solutions.com

2. Product Dimensions
28mm
[email protected]
car-solutions.com
car-solutions.com

3. Specification
CATEGORY SPECIFICATION
OS Version 8.1 (OREO)
CPU ARM Cortex-A72 + [email protected] (HEXA CORE)
ARM Mali-T860 (QUAD CORE) - for GPU
Memory
RAM 4GB LPDDR3
INTERNAL STORAGE 32 GB eMMC
EXTERNAL STORAGE microSD slot (MAX 128GB)
Network
WI-FI 802.11 a/b/g/n/ac (2.4 GHz / 5 GHz) Internally on board with Antenn
a
BLUETOOTH 4.0 (Internally on board with Antenna)
MODEM LTE + UMTS + GSM
(CONNECT TYPE : External USB Dongle type): Option
GPS GPS + GLONASS
Video OUT LVDS 5CH x 1 / HDMI x 1
IN None
Audio OUT AUX + SPK + BT AUX + FM TX
IN MIC
USB PORT HOST x 3 (Internal 2.0 Port x 1 + 3.0 Port x 1 /
Extension Cable Port x 1)
OTG x 1
TOUCH INPUT Resistive + Capacitive + UART
Language Mulit-Language
Power DC 9V ~ 18V
Operating Temperature -10℃~ 70℃
Storage Temperature -20℃~ 80℃
[email protected]
car-solutions.com
car-solutions.com

4. Components
Mainboard * 1ea GPS * 1ea
(HAGPS0013)
POWER * 1ea
(HPOWER0245) MULTI * 1ea (HAERTC0321)
MIC * 1ea
(MICPHOC0003)
USB extension
cable * 1ea
(HARETC0078) Resistive touch * 1ea
(HTOUCH0022)
SPKEAR * 1ea
(SPEAKER007)
Capacitive Touch * 1ea
(HTOUCH0036)
Option
Touch Board * 1ea
(QCPASS0821)
Option
4G Dongle * 1ea
Option
4G Dongle cable * 1ea
Option
HDMI Cable * 1ea
(HARETC0067)
[email protected]
car-solutions.com
car-solutions.com

5. Product Exterior
Micro SD card
(option)
Dipswitch
settings
Power cable Multi cable
GPS cable
Capacitive
touch Cable
Option
Resistive
touch Cable
[email protected]
car-solutions.com
car-solutions.com

6. Dip switch
UART & Cap Touch Use
Resistive Touch Use
*Touch Type Selection
*Cap Touch Selection
Benz 8inch and 8.4inch Cap touch panel
(XWC2800)
Benz 12.1inch Cap touch panel
Universal 7inch Cap
touch panel (XWC2821)
Audi A3, Q2 7inch Cap
touch panel (XWC2410)
*Resolution type selection
1280 x 720 Resolution
1600 x 600 Resolution (For Wide monitor)
[email protected]
car-solutions.com
car-solutions.com

6. Dip switch
*Cap Touch Selection
Universal 6.5inch Cap Touch panel
(XWC1873)
Lexus NX 7inch Cap touch panel
(XWC3941)
Audi A4, A5, Q7 8inch Cap touch
panel
(XWC3536)
Audi A4, A5, Q7, Q2, A3 7inch Cap
touch panel
(XWC3534- Q2 & A3, XWC3535)
Benz 7inch Cap Touch Panel
(XWC2433)
Benz A, B Class 7inch Cap Touch Panel
(XWC1822)
[email protected]
car-solutions.com
car-solutions.com

7. Installation diagram
USB extension cable
12V GNDACC
A
U
D
I
O
O
U
T
(R)
A
U
D
I
O
O
U
T
(L)
S
P
E
K
E
A
L
M
U
T
E
GPS connection U
A
R
T
F
M
T
X
LVDS IN
Interface
[email protected]
car-solutions.com
car-solutions.com

8.1 Capacitive touch installation
Capacitive touch Panel
FPC connection
Capacitive touch
cable
*Capacitive touch cable is
included in Cap
touch Panel set. (option)
C-Touch B/D
Dip Switch No.4 should be Up.
PIN MAP
①⑦
PIN No. 1 : VCC3V3_SYS
PIN No. 2: CAP Touch Reset
PIN No. 3: Cap Touch SCL
PIN No. 4: Cap touch IRQ
PIN No. 5: Cap Touch SDA
PIN No. 6: GND
PIN No. 7: NC
[email protected]
car-solutions.com
car-solutions.com

8.2 Resistive touch installation
Interface
Dip Switch No.4 should be Down.
PIN MAP
①④
PIN No. 1 :X+
PIN No. 2: Y+
PIN No. 3: X-
PIN No. 4: Y-
[email protected]
car-solutions.com
car-solutions.com

8.3 Uart touch installation
Interface UART
Cable
RX (Red)
TX (White)
GND (Black)
RX
TX
A
U
D
I
O
O
U
T
(R)
A
U
D
I
O
O
U
T
(L)
S
P
E
K
E
A
L
M
U
T
EU
A
R
T
F
M
T
X
*When HDMI OUT uses, Uart
Touch wire should be connected
to Video interface.
*When LVDS OUT uses, no need
to connect Uart touch wire.
[email protected]
car-solutions.com
car-solutions.com

9. LVDS to RGB Converter installation
QDIS RGB Interface
RGB Cable tagged
HRGCA0024
LVDS TO RGB Converter
GND
ACC
*LVDS TO RGB Converter is
Option.
*This Converter is needed to
connect to only RGB-
In Interface
*LVDS TO RGB Converter Dip
No.2 Should be DOWN.
