Car Solutions QROI2-RGB User manual

Car-Solutions.com
[email protected]
www.car-solutions.com

•Specification
2
INDEX CONTENS
OS Android 5.1.1 (Lollipop)
CPU
Nexell S5P6818
(Cortex-A53 Octa-Core CPU
up to 1.6GHz)
Memory DDR3 2GB up to 800MHz
Internal Storage 8GB/16GB eMMC 5.1
Display OEM LCD / RGB / HDMI / CVBS
Resolution 800 x 480
SD CARD Micro SD Slot Support (up to 64GB)
GPS UBLOX-8
(GPS + GLONASS)
USB 2.0 High speed x 5
(USB Host x4, OTG x1)
Touch Resistive & Capacitive & UART Touch
Video Input CVBS x 1
Map voice exclusive Speaker 3Watts/8ohm, 1 way mono
Audio Output Stereo Output x 1 (for Car Audio)
Language Multi-Language
Power DC 9V ~ 18V
Operating Temperature -10℃~ 70℃
Storage Temperature -20℃~ 80℃
Car-Solutions.com
[email protected]
www.car-solutions.com

3
•Product Exterior
•Components
BUTTON * 1ea
(HARETC0001)
GPS Antenna * 1ea
(GPSANT0014)
USB cable * 1ea
(HARETC0111)
RGB Out * 1ea
(HRGBCA0025)
R touch cable * 1ea
HTOUCH0022
Microphone cable * 1ea
(MICPHO0002)
HDMI cable * 1ea
(HARETC0067)
B/T board * 1ea
(QCPASS0481)
Multi * 1ea
(HARETC0208)
B/T Cable * 1ea
(HARETC0209)
Speaker * 1ea
(SPEAKER009)
Power * 1ea
(HPOWER0137)
C touch board * 1ea
(Option)
C touch Cable * 1ea
(HTOUCH0036)
(Option)
WIFI dongle * 1ea
(Option)
(ETCETC0110)
Car-Solutions.com
[email protected] www.car-solutions.com

4
•DIP SWITCH
※ ON : DOWN / OFF : UP
•High resolution monitor
with resistive touch panel
•Low resolution monitor
with resistive touch panel
•High resolution monitor
with QDIS W222 capacitive touch panel
•High resolution monitor
with Uart capacitive touch panel
•High resolution monitor
with QDIS capacitive touch panel
Car-Solutions.com
[email protected]
www.car-solutions.com

5
•Installation
G
P
S
C
T
O
U
C
H
U
A
R
T
T
O
U
C
H
R
T
O
U
C
H
V
I
D
E
O
O
U
T
V
I
D
E
O
I
N
A
U
D
I
O
(R)
O
U
T
A
U
D
I
O
(L)
O
U
T
GPS
SPEAKER
MICROPHONE
T
O
G
G
L
E
I
F
S
P
E
A
K
E
R
Capacitive touch
HTOUCH0036
(Option)
Interface
RGB Cable HDM Cable
M
U
T
E
HARETC0209
12V
GND
ACC
Toggle
(Option)
Capacitive touch panel
HTOUCH0022
Resistive touch
Resistive touch panel
Car-Solutions.com
[email protected]
www.car-solutions.com

6
•Setting
※ Directory : Setting→QROI Settings
①Status bar hide :
Hide navigation bar located on the left
②Display Setting :
Adjust the screen
③Touch Calibration :
Start touch calibration
④Start Application :
Select startup application
When Qroi reboots
①
②
③
④
※ How to update the product
- Copy and paste “update file” to USB stick driver.
Once USB driver is inserted to USB port of Qroi,
the popup window will be created for the update.
Remove the USB driver after the completion.
