0031-M214-O1 Rev B HS25KGP
HS25KGP
Suspended Baby Scale
Owner’s Manual
CARDINAL SCALE MFG. CO.
8535-M214-O1 Rev B 203 E. Daugherty, Webb City, MO 64870 USA
03/15 Ph: 417-673-4631 Fax: [phone] Printed in USA
www.detecto.com
Technical Support: Ph: 866-254-8261 [email protected]

0031-M214-O1 Rev B HS25KGP

0031-M214-O1 Rev B HS25KGP
UNPACKING
1. Open box.
2. Remove top Styrofoam insert from box.
3. Next, remove S-hook from insert and set aside.
4. Grasp scale and remove from box.
5. Remove Pants (baby sling seat) from box.
6. Remove bottom Styrofoam insert from box.
7. Turn insert over to locate second S-hook.
8. Remove S-hook from insert and set aside.
9. Remove scale from plastic bag.
10. Remove cardboard dowel between scale case
and lower loop.
11. Scale is now ready to use.
OPERATION
1. Referring to Figure No. 1, install S-hooks on scale.
2. Unfold Pants (Baby Sling Seat).
3. Hang Pants on lower S-hook. See Figure No. 1.
4. Referring to Figure No. 2, turn Zero Adjust Knob
until dial pointer is reading “0”.
5. Place baby in Pants.
6. The dial pointer will indicate the baby’s weight.
7. Remove baby from Pants and re-zero scale if necessary.
NEVER leave a baby unattended in the Baby
Sling Seat. Failure to maintain control of the
baby at all times while they are in the Baby
Sling Seat can result in serious injury to baby.
CARE AND CLEANING
DO NOT spray; water directly on the scale.
DO clean scale using a damp, soft cloth and mild detergent.
NOTE! Some types of paper towels may scratch the dial lens.
DO NOT use acetone, alcohol, or other volatile solvents for cleaning.
PARTS LIST
ITEM QTY PART NUMBER DESCRIPTION
1 4 6600-1870 Lens Screw
2 1 6600-1871 Lens
3 2 6600-1872 S-Hook
4 1 HSPANT Pants (Baby Sling Seat)
Zero
Adjust
Knob
Figure No. 1
Figure No. 2
