Carf-Models Ultra Flash User manual

CARF-Models Ultra Flash
New for 2010 the Ultra Flash is an updated version of the best selling Flash, designed for higher
performance with a new wing and tailplane. The new wing is swept back with greater span, larger
flaps and tapering section from root to tip. The swept design makes the Ultra Flash easier to balance
with the lighter i-Po cells now used by the majority of jet modellers. The wing design has been
successfully tested on designs like the Spark and Ultra ightning. The Ultra Flash has also been
designed from the start for use with a trailing link undercarriage set, the main wheel wells are a few
mm back from the leg centre and the main leg openings are wider to accept the CARF supplied
trailing link legs.
Construction follows the same process as the original Flash, the fuselage is identical, as is the
process for installing the elevator servos. The wings use the same combined gear cover and
aileron/flap servo mounting plate, screwed to the wing with 9 screws.
Follow the construction process shown in the manual, using this addendum.
Wings
The wings follow the same assembly process. If you are using the original straight Oleo leg from the
original Flash, leg cover plates are supplied. These can also be fitted to some trailing link main legs if
you want a cleaner lower wing surface.
The kit also includes a pair of moulded U section mouldings to seal the leg openings. These will
require trimming around the under carriage units and to length.
The wing flaps use a ball link connection at the flap end and a clevis at the servo. The flap is factory
fitted with a pair of horns ready to accept the supplied ball link. A long Allen driver is required to fit
the M3 x 16 ball link screw. Access is from inside the moulded hinge cover knuckle. Move the aileron
up and flap down to gain access.
Spend some time setting the Flap pushrod length before fully screwing the cover plate down.
The threaded rod should be approximately 50mm long and a good starting point for the push rod
centres would be 75mm. This is centre of ball link to clevis pin.
The aileron pushrods need to be approximately 60mm long with 86mm centres. Both figures based
on JR 8411 servos.
The flap settings for the Ultra Flash are:
The Ultra Flash requires down elevator with flap. Take off 1.5mm and anding 4.5-5mm measured at
the elevator trailing edge tip. Exact figures will be affected by balance position.
Movements ailerons 15mm up and 18mm down-Expo 35-40%. Elevators 15mm up and 16mm down
45-50% expo, Rudder 45mm each way 30-35% expo. Ail/Elev tip joint. Rudder lower TE point.
Balance point, gear up 220-22 mm back from the wing/fuselage joint.

‘Flash’
Thank you very much for purchasing our CARF-Models ‘Ultra Flash’ sport-jet, made with the revo-
lutionary Total Area Vacuum Sandwich (TAVS) technology.
Please note that a few of the photos in this Instruction manual show some views from the 2 pro-
totypes, so please don’t get confused by the slightly different colour schemes!
Before you get started building and setting-up your aircraft, please make sure you have read this
instruction manual, and understood it. If you have any questions, please don’t hesitate to con-
tact your Rep, or CARF directly. Below are the contact details:
Email:
LQIR#FDUIPRGHOVFRP
Website:
KWWSZZZFDUIPRGHOVFRP
Liability Exclusion and Damages
You have acquired a kit, which can be assembled into a fully working R/C model when fitted out
with suitable accessories, as described in the instruction manual with the kit.
However, as manufacturers, we at CARF-Models are not in a position to influence the way you
build and operate your model, and we have no control over the methods you use to install,
operate and maintain the radio control system components. For this reason we are obliged to
deny all liability for loss, damage or costs which are incurred due to the incompetent or incorrect
application and operation of our products, or which are connected with such operation in any
way. Unless otherwise prescribed by binding law, the obligation of the CARF-Models compa-
ny to pay compensation is excluded, regardless of the legal argument employed.
This applies to personal injury, death, damage to buildings, loss of turnover and business,
interruption of business or other direct and indirect consequent damages. In all circumstances
our total liability is limited to the amount which you actually paid for this model.
BY OPERATING THIS MODEL YOU ASSUME FULL RESPONSIBILITY FOR YOUR ACTIONS.
It is important to understand that CARF-Models Co., Ltd, is unable to monitor whether you
follow the instructions contained in this instruction manual regarding the construction, operation
and maintenance of the aircraft, nor whether you install and use the radio control system
correctly. For this reason we at CARF-Models are unable to guarantee, or provide, a
contractual agreement with any individual or company that the model you have made will
function correctly and safely. You, as operator of the model, must rely upon your own expertise
and judgement in acquiring and operating this model.
2

Attention !
This ‘jet’ aircraft is a high-end product and can create an enormous risk for both pilot and spec-
tators, if not handled with care & used according to the instructions. Make sure that you operate
your ‘Flash’ according to the laws and regulations governing model flying in the country of use.
The engine, landing gear, servos, linkages and control surfaces have to be attached properly.
Please use only the recommended servos and accessories. Make sure that the ‘Centre of
Gravity’ is located in the recommended place. Use the nose heavy end of the CG range for your
first flights. A tail heavy plane can be an enormous danger for you and all spectators. Fix any
weights, and heavy items like batteries, very securely into the plane.
Make sure that the plane is secured properly
when you start the engine. Have a helper hold
your plane from the nose before you start the
engine. Make sure that all spectators are far
behind, or far in front, of the aircraft when run-
ning up the engine.
Make sure that you range check your R/C sys-
tem thoroughly before the 1st flight. It is
absolutely necessary to range check your
complete R/C installation first WITHOUT the
engine running. Leave the transmitter antenna
retracted, and check the distance you can walk
before ‘fail-safe’ occurs. Then start the engine,
run at about half throttle and repeat this range
check. Make sure that there is no range reduc-
tion before ‘fail-safe’ occurs. If the range with
engine running is less then with the engine off,
please DON’T FLY at that time.
Check that the wing and stab retaining bolts are tight, and that all linkages are secured. Please
don’t ignore our warnings, or those provided by other manufacturers. They refer to things and
processes which, if ignored, could result in permanent damage or fatal injury.
Important/General Notes
Elastic Hinges:
The ailerons, elevators, flaps and rudder are all hinged already for you - laminated in the mould
and attached with a special nylon hinge-cloth, sandwiched between the outer skin and the foam.
This nylon hinge is 100% safe and durable. You will never have to worry about breaking it, or
wearing it out. There is no gap at all on the top side of the surface, and there is a very narrow
slot in the bottom surface, where the control surface slides under the skin during ‘down’ throw.
This means that the hinge axis line is on the top surface of the wing and stab, not in the centre.
This is NOT a disadvantage, but you need to program in about 10% NEGATIVE differential in
your transmitter. This means that the ‘down’ throw needs to be about 10% more than the ‘up’
throw. Why? Because the axis of the hinge is not at the centreline of the aileron/elevator, so it
moves slightly in and out when operated, and the control surface gets a little "smaller" in surface
3
Secure the
plane
before starting
engine.
DANGER ZONES
NO !!!
NO NO

4
area when moving downwards.
The slot needs some explanation, too. The cut line is
exactly in the correct position so that the control surface
slides under the wing skin smoothly. If the cut was a few
mm forward or backwards, it would not work properly. So,
make sure that the lip is not damaged, and that the control
surface slides under this lip perfectly. It will not lock at any
time, as long as the lip is not damaged. If damage occurs,
you can cut a maximum of 2-3 mm off the lip on the wing in front of the control surface, but you
should never cut off more than this.
Servo Choice:
We strongly advise that you use the recommended high-torque digital metal-geared
JR/Graupner servos on all the main flight controls, and the milled plywood mounts are specifi-
cally designed for these.
The elevator servos cannot be thicker than 19mm, otherwise they will not fit in the stabiliser,
and we have used JR8311 in all our prototypes without any problems.
The ailerons are very large surfaces, and the shock-load on the servo geartrain in a ‘hard’
landing is quite severe - so please use a metal geared servo like the JR8411 for these.
A good alternative for the ailerons, flaps and rudder is the Futaba S9351, but this servo is too
thick to fit in the stabiliser. See the recommended servo list on page 6.
Servo Screws:
Fix the all the servos into the milled plywood servo mounts using the 2.9 Ø x13mm or 16mm
sheet metal screws provided in the kit, not the standard screws normally supplied with servos
by the servo manufacturer. This is because all the holes in our milled servo mounts are 2mm
diameter, due to our CNC manufacturing process, and this is too big for the normal screws.
Building Sequence:
The actual building sequence is your choice, but it is definitely most efficient to start at the
back of the fuselage and work forwards, in the same order as shown below.
Take Care:
Composite sandwich parts are extremely strong, but fragile at the same time. Always keep in
mind that these contest airplanes are designed for minimum weight and maximum strength in
flight. Please take care of it, especially during transport, to make sure that none of the critical
parts and linkages are damaged. Always handle your airplane with great care, especially on the
ground and during transport, so you will have many hours of pleasure with it.
To protect the finished paint on the outside of the model from scratches and dents during build-
ing, cover your work table with a piece of soft carpet, cloth or bubble-plastic. The best way to
stop small spots of glue getting stuck to the outside painted surfaces is to give the whole model
2 good coats of clear car wax first, but of course you must be sure to remove this 100% proper-
ly before adding any additional paint, markings or trim.
Centreline of hinge axis
Phenolic control horn

Adhesives and Solvents
Not all types of glues are suited to working with composite parts. Here is a selection of what we
normally use, and what we can truly recommend. Please don’t use inferior quality glues - you will
end up with an inferior quality plane, that is not so strong or safe.
Jet models require good gluing techniques, due to the higher flying speeds, and hence higher
loads on many of the joints. We highly recommend that you use a slow filled thixotropic epoxy
for gluing highly stressed joints (eg: Hysol 9462). The self-mixing nozzles make it easy to apply
exactly the required amount, in exactly the right place, and it will not run or flow onto places
where you don’t want it! It takes about 1 - 2 hours to start to harden so it also gives plenty of time
for accurate assembly. Finally it gives a superb bond on all fibreglass and wood surfaces. Of
course there are many similar glues available, and you can use your favourite type.
1. CA glue ‘Thin’ and ‘Thick’ types. We recommend ZAP, as this is very high quality.
2. ZAP-O or Plasti-ZAP, odourless, or ZAP canopy glue 560 (for clear canopy)
3. 30 minute epoxy (stressed joints must be glued with at least 30 min & NOT 5 min epoxy).
4. Loctite Hysol 9462 or equivalent (optional, but highly recommended)
5. Epoxy laminating resin (12 - 24 hr cure) with hardener.
6. Milled glass fibre, for adding to slow epoxy for stronger joints.
7. Micro-balloons, for adding to slow epoxy for lightweight filling.
8. Thread-locking compound (Loctite 243, ZAP Z-42, or equivalent)
We take great care during production at the factory to ensure that all joints are properly glued,
but of course it is wise to check these yourself and re-glue any that might just have been missed.
When sanding areas on the inside of the composite sandwich parts to prepare the surface for
gluing something onto it, do NOT sand through the layer of lightweight glasscloth on the inside
foam sandwich. It is only necessary to rough up the surface, with 80/120 grit, and wipe off any
dust with acetone or de-natured alcohol (or similar) before gluing to make a perfect joint. Of
course, you should always prepare both parts to be joined before gluing for the highest quality
joints. Don’t use Acetone for cleaning external, painted, surfaces as you will damage the paint.
Tip: For cleaning small (uncured) glue spots or marks off the painted
surfaces you can use old-fashioned liquid cigarette-lighter fuel, like
‘Ronsonol’ or equivalent. This does not damage the paint, as Acetone
and many other solvents will, and this is what we use at the factory.
At CARF-Models we try our best to offer you a high quality kit, with
outstanding value-for-money, and as complete as possible. However, if
you feel that some additional or different hardware should be included,
please feel free to let us know.
Email us: [email protected].
We know that even good things can be made better !
Did you read the hints and warnings above and the instructions carefully?
Did you understand everything in this manual completely?
Then, and only then, let’s start assembling your
&$5)0RGHOV 8/75$)/$6+
If not, please read it again before you continue.
5

Accessories
This is a list of the main additional items you will need to get your CARF Ultra Flash into
the air. Some of them are mandatory, and some can be chosen by you. What we list here are
highly recommended items, and have been thoroughly tested.
1. Power servos (min. 7). All main flight surfaces require a minimum 8kg digital servo, such
as the excellent JR 8311/8411, and these are what the Ultra Flash was designed for. The
Futaba S9351 is an alternative for the ailerons, flaps and rudder. See list below.
2. Turbine engine set. Recommended thrust range 8 - 12kg (18 - 27lbs). The Ultra Flash is
designed for a maximum turbine thrust of 120 Newtons. Please do not exceed this.
3. Retractable Landing gear set (C-ARF product #670500). The Flash is designed specifical
ly around the high-quality Behotec C-36/2 set, and this includes parts designed specially
for the Ultra Flash. Set includes trailing link noseleg, and Intairco main wheels and brakes.
4. Retract & brake valves: The Behotec combined retract/brake mechanical valve included
in the landing gear set works perfectly and is efficient with air volume used. However you
can use any valve type that you chose, and CARF can supply the proven ‘Jet-tronics’ elec
tronic brake and retract valves as an option.
5. Batteries and extension leads (see list below for JR extension leads required).
6. Powerbox Sensor switch. A highly recommended item which combines 2 voltage regula
tors with 2 separate electronic switches for connecting 2 separate batteries to your
receiver. Available from C-ARF as an option. Product # 960600.
7. Heavy duty plastic servo arms (8 pieces).
JR part #JRPA215 or Graupner # Nr. 3544.
Recommended Servos:
Ailerons 2 x JR/Graupner 8411
Flaps/speedbrakes 2 x JR/Graupner 8311 or 8411
Elevators 2 x JR/Graupner 8321/8311/8411 (max. thickness 19mm)
Rudder: 1 x JR/Graupner 8311 or 8411
Nosegear steering: 1 x any standard-sized, metal output gear, servo with min. 5 kg torque.
Retract/Brake valve: 1 x mini-servo, min. torque 2.5kg.(eg JR/GR3041, 3241, 361 etc)
If you choose alternative servos of similar quality and torque for the main flight surfaces, for
example Futaba S9351, you might have to adjust the cnc milled plywood servo mounts a little.
Extension leads:
If using the JR/Graupner servos listed above, installed as recommended, you will require the fol-
lowing length extension leads to reach the normal receiver position under the cockpit.
Elevator and rudder servos; 3 x 1050mm, 1 x 180mm and 1 x 320mm
Flaps and Ailerons: 4 x 550mm (in wing) and 4 x 180mm from Receiver.
Standard RX battery cable lengths will reach the Powerbox ‘Sensor’ switch in the recommend-
ed position, as will standard Turbine fuel pump and Turbine battery cables.
6

About the ‘FLASH’
The CARF Ultra Flash's aerodynamical design is based on the CARF Ultra Lightning.
The Ultra Flash is 20% reduced in size, and has a few additional modifications made. After more
than a year of experience with the Lightning we were able to further simplify the design and
even improve the aerobatic performance.
We decided to build the whole Flash based on the K.I.S.S. principle. A single piece wing and sta-
biliser means that the plane consists of only 3 structural parts, plus a canopy frame and an
exhaust nozzle. With a wingspan of 1.64m transportation is not an issue and assembly at the
field is made very easy and quick. Servo installation is made very easy, too. We omitted the need
for gear doors, another important point to keep the design simple. The well proven
Behotec/Intairco landing gear/wheels & brakes does its job in the Ultra Flash with authority.
Prefabrication is taken to the limits of what is possible. Only R/C, fuel system and engine equip-
ment needs to be installed, there is absolutely no building work necessary. We give you the
choice of using a lightweight engine (eg: P-70, P-80), and only carrying about 2.3 litres of fuel in
the plane, with a perfect ducting system around the engine, or a heavier, more powerful turbine,
with an additional wing fuel tank available as an optional item. We strongly recommend to keep
the Flash as simple and light as possible, so that it can best present its breathtaking aerobatic
manouverability.
The Flash's maximum speed easily reaches the AMA's legal limit (200 mph) but this is not what
the plane is designed for. Control surface arrangement, airfoils, wing loading and tail moments
are all designed for perfect pattern-style aerobatics. Constant speed vertically up and down is
more important than top speed in a low pass. Still, the low wing loading and the powerful
flaps/spoilers give the Flash incredible slow speed characteristics, feeling very ‘light’ with no ten-
dency to ‘tipstall’ at all. Very high angles of attack of 20 - 30 degrees are possible in slow flight.
Still, the plane ‘snaps’ really well and, due to the single piece wing, it takes a lot of hard flying
without "hard feelings" !
The Flash is the "right-sized" Sport Jet for most of us. Easy to transport, easy to store, quick to
put together at the field, yet large enough for unbeatable flying performance. Incredibly strong
structure, combined with the strong but simple landing gear even lets it take some abuse. Short
landings on small and rough fields are handled with ease due to the slow landing speed.
The CARF Ultra Flash if the best flying Jet possible for the money paid, there is no question
about that. It is the most prefabricated and strongest design for the money paid - no question
about that either. How much more can you expect ? How much more would you need ?
How much more would you possibly want to spend, especially when the "Go Fly Price" of others
equals the "Go-Fly-Twice-Price" of CARF-Models ?
CARF-Models rules...!
7

Building Instructions
Exhaust Nozzle
The fibreglass exhaust nozzle is completely painted, fin-
ished and trimmed for you at the factory. It is secured to
the fuselage at the top using an M3 x 6mm button-head
bolt that slides into a slot you must file in the exhaust noz-
zle, and 2 sheetmetal screws at the bottom that are
screwed into plywood plates glued in side the exhaust noz-
zle. You can remove the exhaust nozzle through the stab
opening in the bottom of the fuselage, without having to
remove the thrust tube.
Glue a small piece of the 3mm x 12mm plywood strip
inside the top of the fuselage, as shown. Drill a 2.5mm Ø
hole thru the fuselage into the plywood, and screw in an
M3 button-head bolt, leaving about 1.5mm between the
head and the fibreglass. With a small flat file, cut a 3mm
wide slot in the top edge of the exhaust nozzle that will
slide tightly over the thread of the bolt. Screw bolt in until it
just touches the inside if the exhaust nozzle. After final
adjustment, secure the bolt with a drop of thin CA.
Firmly tape the exhaust nozzle exactly in final position, and
drill 2 holes (2mm Ø) from the inside of the fuselage ,
using a long drill, for the Ø2.9 x 13mm sheetmetal screws.
Glue another 2 small ply plates on the inside of the
exhaust nozzle for the screws to go into, using thick CA.
Redrill holes thru’ the plywood plates, and then secure with
the 2 screws.
There are several times when an extra-long drill bit is use-
ful during the assembly, and these can easily be made by
gluing a drill bit into a length of brass tube with thick CA.
Stabiliser
The stabiliser is 99% factory-completed. It is held to the fuselage with a 10mm diameter car-
bon pin at the front, and two M4 x 30 bolts at the back, which screw into two steel insert-nuts
which have been bonded into the fuselage at the factory. Alignment and incidence is pre-set.
The dual phenolic elevator horns are also jig-installed for you.
Servo Choice: Because of the thickness of the stabiliser profile you cannot use any servo that
is more than 19mm thick. The servo fixing system was designed specifically for the
JR/Graupner 8321, 8311, 8411 servos and we highly recommend that you fit these.
The 2 stab servos are secured to the CNC milled composite servo hatches using aluminium
angles and bolts supplied. Check the fit of both servo hatches in the moulded recesses in the
8
(above) Top of exhaust nozzle is
held by button-head bolt in slot.
(below) Use a long drill to make
the holes for the sheetmetal
screws, into small 3mm ply plates
glued into the exhaust nozzle.
Lower photo also shows insert
nuts for stab bolts bonded into
fuselage at factory.

stab, and sand the edges a little if necessary
for a perfect fit. Glue the milled 1.5mm ply-
wood triangles under each corner of the servo
bay (where the fixing screws will be) to rein-
force the area, using thick CA. Sand and trim
the inside edges of the servo bays to reduce
the width of the lips between each corner to
about 1.5 - 2mm wide. (photo right)
Fit the rubber grommets and brass eyelets
into the servos, and loosely bolt them to the
angles with the M3 x 10 allen bolts and wash-
ers (with the servo output shafts towards the
back). Using the M3 x 6 button-head bolts secure the ali.
brackets to the hatches, with a small drop of Loctite on
each. The milled holes in the hatch are 2.5mm diameter,
and the bolts will cut their own thread in the composite ply-
wood. Check that the upper face of the servos is complete-
ly flush against the inside of the servo hatches, and then
tighten the securing allen bolts.
Centre both servos with your R/C, and fit a heavy-duty
plastic servo arms, using a drop of Loctite on the servo
arm bolts for safety. Drill two 9mm Ø holes for the supplied
plastic grommets, in the position shown in the photo,
thread the servo cables through and fit the grommets in
place. We recommend that you protect the servo cables
with a short length of spiral-wrap, or similar, just in case
you have a turbine ‘wet-start’, as they are quite close to
the thrust tube. With the servo hatches in place, drill
Ø2mm through the fixing holes in each corner, and secure
the hatches with the Ø 2.9 x 10mm sheetmetal screws.
Make up the linkages from the 45mm long M3 all-threaded
rod provided, with an M3 steel clevise and M3 nut to con-
nect to the outer hole of the HD servo arm and an M3 ball-
link bolted between the dual phenolic elevator horns with
an M3 x 16mm bolt and M3 lock nut.
Check the servo centering again with your R/C system, as
it’s more tricky to adjust the linkages after the linkage cov-
ers are glued in place. When satisfied, trim and sand the
painted stab linkage covers, and glue onto the stab hatch
with a couple of drops of thick CA. See photo P1.
Fit the completed stabiliser, making sure that there are M4
washers under the heads of the M4 x 30mm steel bolts.
The stab has a chamfer on the upper back edge, so that
you can fit and remove it easily without having to remove,
or loosen, the exhaust nozzle.
We recommend that you protect the elevator servo exten-
sion leads inside the fuselage with aluminium tape (includ-
9
(below) Protect servo cables with
the supplied aluminium tape.
(above) Glue 1.5mm ply reinforce-
ments under corners. Trim the lips
around the edge of the servo bays
to 2mm wide. Note position of
grommets for servo cables.
(below) Stabs servos are mounted
to hatches on aluminium angles.
Chamfer corners if needed for fit.

ed), as shown in the photo here - as it is directly above the exhaust ducting and could be dam-
aged if you have any accidental wet-starts or similar.
Rudder
The rudder is cut loose, hinged and the dual phenolic con-
trol horns are installed at the factory, and you just need to
fit the rudder servo and linkage.
Servo Choice: Any standard sized minimum 8kg torque
digital servo will be OK for the rudder, but we highly rec-
ommend the JR8311 or 8411.
Centre the rudder servo using your R/C, and fit a plastic
HD (Heavy Duty) servo arm. Fit the rudder servo
(JR8311/8411/Futaba S9351) into the plywood servo
mount, with the output shaft towards the back end of the
servo, and screw into place with the 2.9Ø x 13mm sheet-
metal screws provided. As the servo is mounted inverted,
you should fit the brass eyelets upside-down into the rub-
ber grommets on the servo. Cut a small slot (5mm wide) in
the side of the fin in line with your servo output arm, and
lengthen this slot to suit the linkage later.
Glue the 50mm x 100m balsa plate across the fuselage
under the servo, and cover the plate with aluminium tape.
This will give the servo and extension cable some protec-
tion in the case of an accidental hot, or wet, start.
Make up the linkage using the M3 x 120mm all-thread,
steel clevise and nut at servo end, and the M3 ball-link,
and M3 x 16mm bolt and locknut to secure the ball-link
between the dual phenolic horns (see photo P2).
Supplied in the kit is plastic linkage fairing, pre-painted to
match the fin colour, which can be glued in place to cover
the linkage with a couple of drops of CA. (photo right).
Route the rudder and elevator servo extension cables
down one side of the fuselage, and the turbine cables and
fuel/propane tubes down the other side. Secure them so
that they cannot touch the thrust tube. Protect them with
spiral-wrap sleeves, or similar, where they pass through
plywood bulkheads, and especially when they pass
through fibreglass or carbon-fibre parts which could cut
through the cables or tubes in a few seconds.
10
(above) Rudder servo mount is
installed for you at the factory.
(below) Servo installed with balsa
protection glued in position.
(above) Secure rudder & stab
servo extensions to fuselage.
Cover rudder servo plate with alu-
minium tape for heat protection.
(below) Rudder linkage fairing.

Exhaust Duct/Thrust tube
The thrust tube consists of a lightweight aluminium outer
tube and a 0.25mm thick stainless steel inner tube,
spotwelded together. It is designed to work with a wide
range of turbines and it is, therefore, a compromise - but has
already been used very successfully with several different
turbines with thrust ranges from 8kgs (18Lbs) up to the max-
imum allowed of 12 kgs (28 Lbs).
Drill a 3mm diameter hole centrally in each of the 2 small
stainless steel angle brackets that are pop-rivetted to the
sides of the aluminium tube. With the fibreglass exhaust
nozzle fixed in place, slide the outer tube into the fuselage
from the wing opening until the angle brackets touch the
front face of the bulkhead F7. The back end of the outer
thrust tube should be flush with the back of the exhaust noz-
zle, or maximum 1mm in front of it (see photo P3). Bend the
angle brackets if needed to set this length. Rotate the thrust
tube so that the brackets are at about the 3 o’clock and 9
o’clock positions. Using a long Ø 2mm drill bit, make two
pilot holes into the bulkhead F7 and secure the tube with the
Ø2.9 x 10mm sheetmetal screws.
Bend the 6 metal tabs spot-welded onto the back of the
inner tube into a shallow ‘V’ shape as shown, to centre the
inner tube in the outer tube (photo right). The inner tube
must be secured inside the carbonfibre bellmouth (entry
cone). You can either use the 4 small (2.2 x 10mm) sheet-
metal screws provided, or 4 small pop-rivets. Both methods
work fine. Push the tube into the carbon bellmouth about
10mm (it is a tight fit and you may need to sand the carbon
a little), and insert into the fuselage so that the front face of
the carbon is exactly flush with the front of bulkhead F6.
Check that the back of the inner thrust tube is 6 - 8mm inside
the outer thrust tube (see photo P3). Adjust the position of
the tube in the carbon bellmouth to set this length. When the
length is correct, drill the 4 pilot holes through the carbon
and thrust tube for either screws or rivets (photo P4). Hold a
strip of plywood inside the thrust tube to prevent the drill bit
bending the tube (photo right), and use a sharp drill bit.
Fix the 2 small angle brackets (included) to the outside
edges of the carbon bellmouth as shown, using either the
small sheetmetal screws, or pop-rivets. Make sure that the
brackets align with the slots milled in the rear engine bulk-
head (F6) as shown. Adjust the size of slots to match brack-
ets if necessary. Drill 2mm Ø pilot holes and secure the bell-
mouth centrally in F6 with two Ø2.9 x 10mm screws.
We advise that you cut 2 small ‘NACA-style’ auxiliary air
intakes in the bottom of the fuselage either side of the ven-
11
(above) Drill Ø 3mm hole in
brackets on outer tube.
(below) Bend the 6 tabs at back
of inner tube into ‘V’ shape.
(above) Fix carbon bellmouth to
inner tube with rivets or screws.
(below) Fix 2 small angle brackets
to the bellmouth as shown here.
(bottom) Bellmouth brackets
secured to F6 with small screws.

tral fin, as shown, to allow extra cooling air to enter the outer
thrust tube - and this is especially important if you fly in high
ambient temperatures. They should be approx. 60mm long
and 30mm wide. On both prototypes, with these intakes, the
fuselage did not get warm - even after 2 or 3 minutes of
engine idling in ambient temperatures of around 30° C. See
template at end of Manual for shape.
Engine and Bypass/Inlet Joiner Installation
Turbine installation is extremely simple with easy access
thru’ the large wing opening. It is a fully-bypassed system,
using a new carbon composite bypass duct, and a sepa-
rate fibreglass joiner to connect the bypass to the inlet
ducts that are already installed for you at the factory.
We recommend a turbine of 8 - 12kg thrust, and the proto-
types have been flown extensively with both Jetcat P70
and P120. Both give more than adequate performance,
and take-off from grass is only about 75metres with the
P70 - and any similar turbine in this thrust range will be
suitable. The bypass duct is 135mm diameter, which suits
installation of turbines up to a maximum of 116mm max.
diameter. With the recommended receiver and turbine bat-
teries positioned in the pockets either side of the nosegear,
you will find that Centre of Gravity is easily set without
adding any additional weight in the nose.
IMPORTANT: Please note that the Flash is designed for a
maximum turbine thrust of 14kg (140 Newtons) and this
must not be exceeded. All the photos in this section show
a JetCat P120 installed.
Large engine mounting:
If fitting a ‘standard-sized’ 116mm diameter turbine (eg:
Jetcat P80 or P120) secure the engine mount to the motor
with the glowplug (or kerosene start) orientated as shown
(see photo P6).
Most brands of turbine have slightly offset mounting brack-
ets (eg: JetCat), and in this case you should pack them off
the ply mounting rails with plywood spacers to get the tur-
bine in the precise vertical centre of the bypass, which is
very important for the best performance and cooling of the
motor and thrust tube. For Jetcat P80 or P120 this spacer
should be 5mm thick. Cut the spacers from the 3mm x
12
(above) Glue spacers onto the
factory-installed engine mounting
rails to centre your turbine in the
bypass as necessary.
(above) Inlet ducts are factory-
installed and painted for you.
(below) General view of P120
installed in carbon bypass duct.

12mm wide plywood strip included in the kit, sand to required thickness, and glue to the
mounting rails with CA (photo above).
Normally the turbine will need to be mounted right at the front of the engine mounting rails,
against F5, so that the back edge of the outer casing (the ‘chromed’ part on Jetcats’) is about
15 - 18mm in front of the front edge of the carbon bellmouth and F6 bulkhead.
Make sure that the turbine is aligned exactly central with the thrust tube and then drill the
Ø4mm mounting holes, using the mounting bracket as the template. Remove the mounting
bracket and open the holes up to Ø 5.5mm for the T-nuts. Using one M4 bolt and a large
washer, pull each T-nut into the mounting rails just a little, with a drop of 30 minute epoxy on
each. Then re-install the engine and mounting bracket and tighten all four M4 x 16 bolts tightly,
which will make sure that the T-nuts are perfectly aligned when the glue has cured.
Final vertical alignment of the turbine can be adjusted by using 1 or 2 of the extra M4 washers
supplied, glued to the plywood with a drop of thick CA.
Small engine mounting:
If you chose a turbine at the smaller end of the recom-
mended range you will find that the plywood mounting rails
are too far apart for the turbine mounting bracket, and we
include adapter plates to solve this.
In the milled wood pack you will find 4 plywood rectangles
80mm long x 30mm wide (2 @ 3mm thick, and 2 @
1.5mm thick). Glue one of each thickness together with 30
minute epoxy to make 2 adapter plates at 4.5mm thick.
Use the supplied M4 x 16 bolts and T-nuts (as described
above) to fix these new plates to the original plywood
engine mounting rails to reduce the width between the
mounting rails, and also raise them 4.5mm to centralise
‘Jetcat type’ mounting brackets in the bypass duct. In the
hardware are 4 extra M4 bolts and M4 locknuts you can
use to secure the aluminium engine mounting bracket to
the small engine mounting plates.
Bypass duct:
The carbon bypass duct needs final trimming to suit your
engine mounting bracket and installation, and the photos
here show it trimmed for a P120. The fine lines moulded
into the parts to guide your trimming and sanding are for
this engine size. If fitting a smaller engine you will need to
adjust these to suit.
Note: The ‘upper’ bypass half is the one that will be at the
top when the fuselage is the correct way up, but all the
next section is done with the plane upside down - working
thru’ the hatch in the bottom of the fuselage. In this case
the ‘cover’ is the lower part of the bypass. Please don’t get
confused !
Take the 4 small pieces of milled 3mm ply and glue togeth-
13
(above & below) Upper bypass
ducting is secured to these 2
blocks with M3 bolts & T-nuts.
(below) Small engine mounting
adapters are made by gluing the
milled ply 3mm and 1.5mm rectan-
gles together with 30 min epoxy.

er as shown above. Then glue these 2 parts into the milled
slots in the front engine bulkhead as shown, using epoxy.
These will have M3 T-nuts glued to them to secure the
upper bypass later.
Trim and fit the ‘upper’ bypass. The stepped flange at the
back goes over the outside of the carbon bellmouth, and if
it is a tight fit you can sand the Ø140mm hole in bulkhead
F6 a little. File the small notches in the back corners of the
bypass to clear the bellmouth mounting angles, and also in
each side to clear the turbine mounting. You might need to
sand the front outside edges of the carbon bellmouth a lit-
tle for the bypass duct to fit nicely over it.
When satisfied with the fit and alignment, drill Ø3mm diam-
eter through the bypass into the centre of each of the 2
small plywood blocks that you glued into the front of F5
earlier. There are small dimples in the carbon bypass
moulding to guide you on the hole position. Remove the
upper bypass, and redrill the 2 holes in the plywood blocks
to Ø4.5mm. Fit an M3 T-nut to the back of each block, with
a small drop of 30 minute epoxy. Refit the bypass and
secure it with two M3 x 12mm allen bolts and washers, screwed tightly into the T-nuts before
the epoxy cures to ensure perfect alignment (photo P5).
The bypass cover has stepped flanges that fit over the outside of the upper bypass, and it also
fits over the outside of the carbon bellmouth in F6. Trim it as shown, checking the fit on the
upper part several times to get good alignment. Chamfer the back end of the cutouts that go
over the engine mounting bracket, so that it is easy to get on and off - in case you have to
change a glow-plug at the airfield. If you fit a 116mØ JetCat with kerosene starting, then you
will have to make a small hole for clearance around the starter plug. Make sure that it is orient-
ed as shown in the photos, right at one end of the mounting bracket slot - so that it clears the
wing ! If necessary you can even mill a small clearance hole ( Ø 25mm) in the upper wing sur-
face without any loss of strength.
The cover is secured to the upper bypass with a single wrap of double-sided velcro band at
the front, as shown. These photos show 3 ‘handmade’ ply-
wood hoops glued to the upper bypass to retain the Velcro,
but production kits have CNC milled parts that give more
gluing area (inset photo). Mark where the fuel, gas and
electrical services will enter the bypass duct first, to deter-
mine the correct position of the Velcro band. Sand the
surface of the bypass as needed and glue them in place
with 30 minute epoxy.
Included in the hardware pack are some small and large
plastic grommets to protect the tubes and wires that must
enter the bypass duct for the turbine, and we strongly rec-
ommend that you use these. Carbon composite is
extremely abrasive, and electrically conductive, and can
cut through your fuel line or RPM sensor cables in just a
couple of seconds - maybe even from the vibration during
transporting your plane. Drill suitable holes, oval shaped if
14
(above) Upper bypass trimmed for
P80/P120 installation.
(below) Bypass cover trimmed
ready for final installation.
(below) View of upper bypass,
showing plastic grommets for tube
and cable protection and hoops
to retain Velcro strap. Inset is CNC
milled hoop included in kits

needed for an electrical connector, and fix the grommets
to the bypass with a small drop of thin CA.
Inlet Joiner:
The pre-painted inlet ducts are factory-installed, and only
the back end may need trimming a little to exact length to
fit the fibreglass inlet joiner. The inlet joiner is joined in the
factory for you, and has 2 reinforcing ribs laminated into it
during manufacture to ensure that it cannot be sucked flat
by the turbine. Check the fit over the back of the inlet
ducts. Included in the hardware pack is a length of 1” wide
fibreglass band, and you can apply one wrap of this
around the back of the inlets if necessary to get a nice tight
fit of the joiner over the inlets. Sand the outer surface of
the inlets, clean, and apply the band with slow (24hr) lami-
nating resin and sand smooth when cured.
The back of the inlet joiner fits inside the moulded flange
at the front of the the bypass duct. Trim the inlet joiner
length to fit exactly. After final trimming to length, apply 1
wrap of the fibreglass joining tape around the back edge
with laminating epoxy for a nice tight fit inside the bypass
duct. The flange on the side of the inlet joiner needs to be
notched at the back so that it just clears the front of the
bypass, but stops the inlet joiner moving backwards dur-
ing operation. (photo right)
Now you can make all the tube and electrical connections to your turbine, and secure them to
the fuselage on the opposite side to the extension cables from your rudder and stabiliser ser-
vos, as shown in photos P6 and P7.
Important: Whatever make of turbine you install, please read, and follow, the manufacturers
instructions and recommendations before installing your motor.
15
(above) Inlet joiner is pre-joined
at the factory, and only needs
final trimming and fitting.
(below) Trim back end & joining
flange of joiner so that it fits inside
the bypass, and cannot move
backwards. Sand cutouts as need-
ed to clear fuel and gas feeds.

Fuel System.
The standard Flash kit includes a single composite fuel
tank (2.2 litres) that installed in the fuselage above the
inlet ducts, and a hopper tank that is installed in the cock-
pit area. If you are installing a turbine of 9kg thrust or
more, you will also need to install the optional wing fuel
tank (1.4 litres) to give reasonable length flight times.
Important Note: Please wash out all fuel tanks carefully
before final assembly and installation to remove any parti-
cles from the manufacturing and joining processes.
Fuselage Tank:
The fuselage tank is pre-joined and tested at the factory
and has a central baffle installed to prevent fuel surge and
Centre of Gravity changes during aerobatic manoeuvres.
It is installed above the inlet ducts on 2 composite glass-
balsa plates that you need to fit.
Trim the flanges all around the back of the cockpit open-
ing by about 3 - 4mm so that you can push the fuel tank
into place. Don’t trim them too much - the tank should still
be a little tight to push into the fuselage at the top. Also
trim the horizontal flanges at the back of the cockpit area
for about 35mm length (behind the canopy hook slots),
which makes it easier to get the tank in and out of the
fuselage. (see photos right)
Position the front face of the fuel tank about 10mm (3/8”)
behind the back of the cockpit opening. Cut 2 strips of the
3mm thick composite balsa-fibreglass sheet provided,
both 25mm wide, to secure the back end of the tank.
Sand the surfaces of the fuselage, and glue the horizontal
strip across the fuselage first with slow epoxy. Then shape
the ‘stop’ that fits vertically behind it to match the fuselage
shape and glue it in place. Finally reinforce the glue joints
with a couple of pieces (approx. 60mm x 40mm) of the
200 gram fibreglass cloth provided and slow (24hr) lami-
nating resin.
Cut another strip of the composite balsa 152mm wide and
50mm deep, to make the front tank support. Taper the
sides a little so that it is about 148mm wide at the back to
match the shape of the fuselage. With the tank in place
against the back stop, fit this strip under the front of the
tank as shown here, with 2 scrap pieces of 3mm balsa or
plywood as temporary packers between the strip and the
bottom of the tank. These packers are important! (see
photo P8)
The front edge of the tank support should be about 5 -
16
(above) The fuselage tank com-
pleted, ready for installation.
(below) Trim the flanges of the
cockpit area as shown to fit the
the fuel tank.
(above) Rear fuel tank support
reinforced with fibreglass cloth.
(below) Tack front front tank sup-
port in place with 3mm thick
packers under the tank.

6mm in front of the tank. Check that it is horizontal and
then tack glue to the fuselage sides with a couple of drops
of thin CA. Remove the temporary packers and the tank.
Prepare the inside surface of the fuselage and tank sup-
port by sanding and cleaning, and glue the support in per-
manently with 30 min. epoxy. When cured, reinforce the
joints with small patches of the fibreglass cloth and lami-
nating epoxy in the same way as the rear tank support.
The ‘stop‘ to prevent the tank moving forward is made
from a milled plywood strip (151 x 15mm) screwed into the
front of 2 blocks glued against the fuselage sides. Each
block is made from 2 pieces of 3mm plywood laminated
together with CA. (see photo right and P8). Prepare the
surfaces of the fuselage, and glue the blocks to the sides
with 30 minute epoxy. You may need to sand or file them a
little to clear the edges of the fuel tank.
Assemble the included aluminium tank cap hardware with
2 of the Ø 4mm brass tubes as shown. Solder the short
lengths of Ø 5mm brass tube on all the ends of the 4mm
tube to act as ‘barbs’ and prevent the fuel tube sliding off.
Make up the connections exactly as shown, using Tygon or
equivalent flexible tubing that is suitable for kerosene fuel.
The tube to the clunk must be joined in the middle with a
length of the brass tube where it passes through the fibre-
glass baffle - otherwise it will be cut in a few seconds! The
length from the back of the stopper to the centre of the
brass tube should be 125mm, and after assembly check
that the baffle cannot touch the Tygon tube in any position.
For extra safety you can add a small tie-wrap or length of
stainless steel tying wire around each connection.
If fitting only the fuselage tank, it is most con-
venient if you fit the overflow/vent tube in the
bottom of the fuselage immediately behind
the wing, to one side of the Ventral fin.
This is so that you can put the fuselage on its
nose for assembly on the airfield, even when
there is fuel in the tanks and it will not drain
out. See ‘Wing Tank’ section for assembly of
the vent tube.
Hopper Tank:
Included in the kit is a 180ml hopper tank, and all the hardware required to complete and install
it in the CNC milled plywood mount at the back of the cockpit area for easy visibility and main-
tenance. Assemble the mount from the plywood parts as shown in photo below with thin CA, and
then glue permanently with 30 minute epoxy. The hopper tank is secured in position using a short
17
(above) Front fuel tank support
glue joints reinforced with F’glass
cloth and laminating epoxy.
(below) Front stop is a milled ply-
wood strip, screwed to small
milled blocks glued against the
fuselage sides.
(above) Detail view of the fuel tank cap assem-
bly, with the short lengths of 4mm I.D tube sol-
dered on to act as ‘barbs’ and prevent the tub-
ing sliding off.
(below) From the back of the cap hardware to
the centre of the brass tube should be 125mm
(5”) to place it at the baffle position.
150 mm 125 mm

length of the included double-sided Velcro.
Our preferred method is to have a felt clunk (Webra #1121)
fixed to the end of the brass feed tube inside the hopper
tank, in the 3-dimensional centre of the fuel tank, which is
connected to the fuel pump. Photo P9 shows the detail of
how to assemble this, using a short length of the included
clear 4mm I.D fuel tube. The very short length of Tygon tube
immediately in front of the felt clunk is to prevent the felt slid-
ing forwards off the metal clunk, and this is retained with a
small cable-tie. Connect the ‘vent’ tube of the hopper tank to
the ‘feed’ tube and clunk o the main fuselage tank.
The photo here shows the recommended position of the
hopper tank and mount, which is glued to the fuselage floor
with 30 minute epoxy and micro-balloon mixture. This posi-
tion gives nice short connections between the hopper an
main tank, which is directly above it. You can install the fuel
pump, on its milled plywood mount, on the underside of the
front fuel tank support (above the hopper), as shown in the
photos in the ‘Gear Installation’ section.
If you wish you can fit a 3rd brass tube into the hopper tank
cap for filling the fuel system. Alternatively you can install a
quick-connect Festo or Rectus (or similar) fitting between
the feed tube and the fuel pump and disconnect here to fill.
This has the added advantage that you cannot accidentally
fill the turbine with fuel if the manual shut-off valve has been
left open, or the fuel solenoid valve allows a small amount of
fuel to pass thought it. It’s your choice.
Wing Tank (Optional):
The wing tank has a capacity of about 1.3 litres, and is fitted
in the pre-cut and hinged tank bay in the centre of the wing.
It is joined and leak-tested at the factory, and is supplied
with aluminium cap hardware, kerosene stopper and brass
tubes needed.
Assemble the included aluminium tank cap hardware with
2 of the Ø 4mm brass tubes in the same way as for the
main tank. You will need to bend the ‘vent/overflow’ brass
tube inside the tank almost 90 degrees to make sure that it
reaches to top of the tank, and it can be extended with a
short length of Tygon as shown here.
To prevent kinking or flattening the tube when you bend it
you can fit a spring over the outside of the tube (eg: the
ones available at “K&S metal centres” in most good hobby
stores). Extend the brass tube as necessary with a short
length of Tygon, as shown, to reach the top surface of the
18
(above) Wing fuel tank cap assem-
bly details, with felt clunk.
(Below) A spring is used to bend
the brass tube without kinking.
(above) Assemble hopper tank
mount from the milled plywood.
(below) Hopper tank is held in
the mount with velcro band.
(bottom) Hopper tank shown in
the recommended position.
